基于Lowe分類法的5G網絡EAP-AKA<inline-formula><tex-math id="Z-20190723051620-1">\begin{document}$ ' $\end{document}</tex-math><alternatives><graphic xmlns:xlink="http://www.w3.org/1999/xlink" xlink:href="190063_Z-20190723051620-1.jpg"></graphic><graphic xmlns:xlink="http://www.w3.org/1999/xlink" xlink:href="190063_Z-20190723051620-1.png"></graphic></alternatives></inline-formula>協議安全性分析

劉彩霞; 胡鑫鑫; 劉樹新; 游偉; 趙宇

doi:10.11999/JEIT190063

基于Lowe分類法的5G網絡EAP-AKA$ ' $協議安全性分析

doi: 10.11999/JEIT190063

國家數字交換系統工程技術研究中心 ??鄭州 ??450002

基金項目: 國家自然科學創新研究群體基金(61521003)，國家自然科學基金(61801515)

詳細信息

作者簡介:
劉彩霞：女，1974年生，教授，博士生導師，研究方向?yàn)橐苿?dòng)通信網絡、新型網絡體系結構

胡鑫鑫：男，1994年生，碩士生，研究方向?yàn)?G 網絡安全、新一代移動通信技術

劉樹新：男，1987年生，博士，講師，研究方向?yàn)閺?fù)雜網絡、網絡信息挖掘

游偉：男，1984年生，博士，講師，研究方向?yàn)槊艽a學、移動通信網絡

趙宇：男，1984年生，博士，講師，研究方向?yàn)橐苿?dòng)通信網絡安全、新型網絡體系結構

通訊作者:
胡鑫鑫　justinhu@hust.edu.cn

中圖分類號: TP309
計量
- 文章訪問數: 3605
- HTML全文瀏覽量: 2018
- PDF下載量: 141
- 被引次數: 0
出版歷程
- 收稿日期: 2019-01-23
- 修回日期: 2019-05-19
- 網絡出版日期: 2019-05-27
- 刊出日期: 2019-08-01

Security Analysis of 5G Network EAP-AKA′ Protocol Based on Lowe’s Taxonomy

National Digital Switching System Engineering & Technological R&D Center, Zhengzhou 450002, China

Funds: The National Natural Science Fund for Innovative Research Groups (61521003), The National Natural Science Foundation of China (61801515)

摘要

摘要: 移動網鑒權認證協議攻擊不斷涌現，針對5G網絡新協議EAP-AKA$ '$，該文提出一種基于Lowe分類法的EAP-AKA$ '$安全性分析模型。首先對5G網絡協議EAP-AKA$ '$、信道及攻擊者進行形式化建模。然后對Lowe鑒權性質進行形式化描述，利用TAMARIN證明器分析協議中安全錨點密鑰K_SEAF的Lowe鑒權性質、完美前向保密性、機密性等安全目標，發現了3GPP隱式鑒權方式下的4條攻擊路徑。最后針對發現的安全問題提出2種改進方案并驗證其有效性，并將5G網絡兩種鑒權協議EAP-AKA$ '$和5G AKA的安全性進行了對比，發現前者在Lowe鑒權性質方面更安全。
- 網絡安全 /
- 安全錨點密鑰 /
- EAP-AKA$ '$ /
- Lowe分類法 /
- Dolev-Yao敵手模型 /
- TAMARIN
Abstract: Mobile network authentication protocol attacks continue to emerge. For the new 5G network protocol EAP-AKA', an EAP-AKA' security analysis method based on Lowe’s taxonomy is proposed. Firstly, 5G network, EAP-AKA', communication channel and adversary are formally modeled. Then Lowe authentication property is formally modeled. Using the TAMARIN prover, objectives of the security anchor key K_SEAF are analyzed, such as Lowe’s taxonomy, perfect forward secrecy, confidentiality, etc. Four attack paths under 3GPP implicit authentication mode are discovered. Two improved schemes are proposed for the discovered security problems and their security is verified. Finally, the security of the two authentication protocols EAP-AKA’ and 5G AKA of the 5G network is compared, and it is found that the former is safer in terms of Lowe authentication property.
- Network security /
- Security anchor key /
- EAP-AKA$ '$ /
- Lowe’s taxonomy /
- Dolev-Yao adversary model /
- TAMARIN

HTML全文

圖 1 5G網絡漫游場景下的信任模型

下載: 全尺寸圖片幻燈片

圖 2 5G網絡EAP-AKA’協議鑒權流程

下載: 全尺寸圖片幻燈片

圖 3 基于Lowe分類法的EAP-AKA$ ' $協議安全分析模型

下載: 全尺寸圖片幻燈片

圖 4 安全目標形式化描述

下載: 全尺寸圖片幻燈片

圖 5 TAMARIN證明器工作原理

下載: 全尺寸圖片幻燈片

圖 6 兩種改進方案

下載: 全尺寸圖片幻燈片

表 1 符號說明

符號	定義
Create(A, id, R)	對編號為id的角色A創建一個事件
Claim_type(A, t)	角色A在時刻t聲明一個事件
Honest(A)	角色A不被攻擊者感染
Reveal(A)	角色A被攻擊者感染
K(t)	攻擊者獲取了傳遞的信息
F@i	在時刻i發生事件F
#i<#j	時刻i早于時刻j
#i=#j	時刻i與時刻j相同
x=y	消息變量x, y相等

下載: 導出CSV

表 2 用spthy語言描述協議狀態轉移

　rule SN_1send:

　let m = ‘Identity Request’

　in [ St_SN_0($SN, ～id, $HN, SK) ]

　--[ Send($SN, m)]->

　[ Out(m), St_SN_1($SN, ～id, $HN, SK)]

下載: 導出CSV

表 3 隱式鑒權和顯式鑒權對比(對K_SEAF的機密性、完美前向保密性)

協議參與方	UE		SN		HN
	隱式	顯式	隱式	顯式	隱式	顯式
K_SEAF機密性	√	√	√	√	√	√
K_SEAF完美前向保密性	×	×	×	×	×	×

下載: 導出CSV

表 4 EAP-AKA$ '$和5G AKA對比(隱式鑒權)

協議參與方	UE對SN		UE對HN		SN對UE		HN對UE
	EAP-AKA′	5G AKA	EAP-AKA′	5G AKA	EAP-AKA′	5G AKA	EAP-AKA′	5G AKA
存活性	√	×	√	√	√	√	√	√
弱一致性	√	×	√	√	√	×	√	√
非單射一致性	×	×	√	×	√	×	√	×
單射一致性	×	×	√	×	√	×	√	×

下載: 導出CSV

表 5 EAP-AKA$ '$和5G AKA對比(顯式鑒權)

協議參與方	UE對SN		UE對HN		SN對UE		HN對UE
	EAP-AKA′	5G AKA	EAP-AKA′	5G AKA	EAP-AKA′	5G AKA	EAP-AKA′	5G AKA
存活性	√	√	√	√	√	√	√	√
弱一致性	√	√	√	√	√	√	√	√
非單射一致性	√	√	√	√	√	√	√	×
單射一致性	√	√	√	√	√	√	√	×

下載: 導出CSV

表 6 改進MAC計算方式

　MAC=f₁(K, <SQN_HN, R, SNN >)

　故AUTN=<CONC, f₁(K, MAC)>

　　　　　=< SQN_HN⊕AK, f₁(K, <SQN_HN, R, SNN >)>

　　　　　=< SQN_HN⊕f₅(K, R), f₁(K, <SQN_HN, R, SNN >)>

　　　　　=KDF_AUTN(SQN_HN, K, R, SNN)

下載: 導出CSV

參考文獻(17)

ARAPINIS M, MANCINI L, RITTER E, et al. New privacy issues in mobile telephony: Fix and verification[C]. Proceedings of 2012 ACM Conference on Computer and Communications Security, Raleigh, North Carolina, USA, 2012: 205–216.

HUSSAIN S R, CHOWDHURY O, MEHNAZ S, et al. LTEInspector: A systematic approach for adversarial testing of 4G LTE[C]. Network and Distributed Systems Security (NDSS), San Diego, California, USA, 2018.

BORGAONKAR R, HIRSHI L, PARK S, et al. New adventures in spying 3G & 4G users: Locate, track, monitor[EB/OL]. https://www.blackhat.com/docs/us-17/wednesday/us-17-Borgaonkar-New-Adventures-In-Spying-3G-And-4G-Users-Locate-Track-And-Monitor.pdf, 2017.

ZHANG Muxiang and FANG Yuguang. Security analysis and enhancements of 3GPP authentication and key agreement protocol[J]. IEEE Transactions on Wireless Communications, 2005, 4(2): 734–742. doi: 10.1109/twc.2004.842941

RUPPRECHT D, KOHLS K, HOLZ T, et al. Breaking LTE on layer two[C]. The 40th IEEE Symposium on Security and Privacy, San Francisco, USA, 2019.

SHAIK A, BORGAONKAR R, SEIFERT J P, et al. Practical attacks against privacy and availability in 4G/LTE[C]. The 23nd Annual Network and Distributed System Security (NDSS), San Diego? California, USA, 2016.

HUSSAIN S R, ECHEVERRIA M, CHOWDHURY O, et al. Privacy attacks to the 4G and 5G cellular paging protocols using side channel information[C]. The 23nd Annual Network and Distributed System Security (NDSS), San Diego? California, USA, 2019.

RAVISHANKAR B, LUCCA H, SHINJO P, et al. New privacy threat on 3G, 4G, and upcoming 5G AKA protocols[C]. Privacy Enhancing Technologies, Stockholm, Sweden, 2019.

BASIN D, DREIER J, HIRSCHI L, et al. A formal analysis of 5G authentication[C]. 2018 ACM SIGSAC Conference on Computer and Communications Security, Toronto, Canada, 2018: 1383–1396.

KOUTSOS A. The 5G-AKA authentication protocol privacy[EB/OL]. https://arxiv.org/pdf/1811.06922.pdf, 2019.

FERRAG M A, MAGLARAS L, ARGYRIOU A, et al. Security for 4G and 5G cellular networks: A survey of existing authentication and privacy-preserving schemes[J]. Journal of Network and Computer Applications, 2018, 101: 55–82. doi: 10.1016/j.jnca.2017.10.017

RUPPRECHT D, DABROWSKI A, HOLZ T, et al. On security research towards future mobile network generations[J]. IEEE Communications Surveys & Tutorials, 2018, 20(3): 2518–2542. doi: 10.1109/COMST.2018.2820728

JI Xinsheng, HUANG Kaizhi, JIN Liang, et al. Overview of 5G security technology[J]. Science China Information Sciences, 2018, 61(8): 081301. doi: 10.1007/s11432-017-9426-4

劉彩霞, 李凌書, 湯紅波, 等. 基于子圖同構的vEPC虛擬網絡分層協同映射算法[J]. 電子與信息學報, 2017, 39(5): 1170–1177. doi: 10.11999/JEIT160642

LIU Caixia, LI Lingshu, TANG Hongbo, et al. Hierarchical coordination strategy for vEPC virtual network embedding based on subgraph isomorphism[J]. Journal of Electronics &Information Technology, 2017, 39(5): 1170–1177. doi: 10.11999/JEIT160642

DOLEV D and YAO A. On the security of public key protocols[J]. IEEE Transactions on Information Theory, 1983, 29(2): 198–208. doi: 10.1109/TIT.1983.1056650

LOWE G. A hierarchy of authentication specifications[C]. The 10th Computer Security Foundations Workshop, Rockport, USA, 1997: 31–43.

3GPP. 3GPP TS 33.501 Security architecture and procedures for 5G system (Release 15)[S].Nice: 3GPP, 2018.
