一種快速穩健的致密焦面陣列饋源設計方法

何山紅; 紀萌茜; 解良玉; 范瑾; 范沖

doi:10.11999/JEIT190026

一種快速穩健的致密焦面陣列饋源設計方法

doi: 10.11999/JEIT190026

1.
安徽工業大學電氣與信息工程學院 ??馬鞍山 ??243002
2.
中國科學院國家天文臺FAST項目組 ??北京 ??100012
3.
南京理工大學通信工程系 ??南京 ??210094

基金項目: 國家自然科學基金(U1631115, 11403054)，國家自然科學基金－中國科學院天文聯合基金(U1631115)，國家自然科學基金與瑞典科研教育國際合作基金(11611130023)

詳細信息

作者簡介:
何山紅：男，1973年生，教授，主要研究方向?yàn)榇笮头瓷涿嫣炀€(xiàn)及饋源、陣列天線及寬帶天線設計及研究

紀萌茜：女，1996年生，碩士生，研究方向?yàn)樘炀€(xiàn)中的優化設計

解良玉：女，1996年生，碩士生，研究方向?yàn)閷拵炀€(xiàn)、多頻天線和多波束天線設計

范瑾：女，1985年生，工程師，博士，研究方向?yàn)榇笮蜕潆娞煳耐h(yuǎn)鏡天線及高性能饋源設計及研究

范沖：男，1990年生，博士生，研究方向?yàn)橹芷谛越Y(jié)構天線、透鏡天線及反射面的設計及研究

通訊作者:
何山紅　antennaeng@163.com

中圖分類號: TN823
計量
- 文章訪問數: 4729
- HTML全文瀏覽量: 1483
- PDF下載量: 85
- 被引次數: 0
出版歷程
- 收稿日期: 2019-01-11
- 修回日期: 2019-04-18
- 網絡出版日期: 2019-05-23
- 刊出日期: 2019-11-01

A Fast and Robust Design Method for Dense Focal Plane Array Feed

1.
School of Electrical Engineering & Information, Anhui University of Technology, Ma’anshan 243002, China
2.
Department of FAST in the National Astronomy Observatory, Chinese Academy of Sciences, Beijing 100012, China
3.
Department of Communication Engineering, Nanjing University of Science and Technology, Nanjing 210094, China

Funds: The National Natural Science Foundation of China (U1631115, 11403054), The Joint Research Fund in Astronomy under Cooperative Agreement between the National Natural Science Foundation of China and Chinese Academy of Science(U1631115), The Swedish Foundation for International Cooperation with NSFC in Research and Higher Education (11611130023)

摘要

摘要: 致密焦面陣列饋源(DFPAF)融合了多喇叭多波束饋源和相控陣列饋源(PAF)的特點，與多喇叭多波束饋源和常規相控陣列饋源相比較，它可以同時提供更多的固定賦形波束進一步拓寬視場。在射電天文、雷達、電子偵察和衛星通信等領域引起了極大的關注。由于其陣列結構與常規陣列饋源不同，導致設計方法也具有特殊性，因此近年來展開了對其設計方法的研究。該文充分利用反射面天線的固有特性，并結合陣列天線理論，提出一種可以快速、穩健地設計致密焦面陣列饋源的方法，給出了設計原理和設計結果，并和最具代表性的多喇叭多波束饋源進行了性能對比分析，為設計致密焦面陣列饋電的大型反射面提供理論和數據參考。
- 致密焦面陣列 /
- 多波束饋源 /
- 反射面 /
- 相控陣列
Abstract: The Dense Focal Plane Array Feed (DFPAF), which integrates the characters of multi-beam feed with multiple independent horns and Phased Array Feed (PAF), can simultaneously provide more fixed shaped beams and wider field of view than multi-beam feed with multiple independent horns and PAF. It attracts more attention in radio telescope, radar, electronic reconnaissance, satellite communication and so on. Its unique structure promotes the studies on special design method recently. Combing the theory of array antenna and inherent characteristic of parabolic reflector antenna, a fast design method with robust processing procedure is proposed in this paper. The design principle, calculated results, and comparison between DFPAF and the most representative multi-beam feed with multiple independent horns are presented. All these provide a theoretical basis and reference data for the design of giant reflector with DFPAF.
- Dense focal plane array /
- Multi-beam feed /
- Reflector /
- Phased array

HTML全文

圖 1 拋物面天線坐標系

下載: 全尺寸圖片幻燈片

圖 2 饋源結構

下載: 全尺寸圖片幻燈片

圖 3 中心頻率的焦面電場分布

下載: 全尺寸圖片幻燈片

圖 4 中心頻率的初級輻射方向圖($\varphi $ = 90°平面)

下載: 全尺寸圖片幻燈片

圖 5 拋物面天線在中心頻率的遠場輻射方向圖($\varphi $=90°)

下載: 全尺寸圖片幻燈片

圖 6 50號波束中心頻率的立體遠場輻射方向圖

下載: 全尺寸圖片幻燈片

表 1 多波束反射面天線性能總結表

波束	饋源類型	天線增益(dB)	天線效率(%)	第1旁瓣電平(dB)	半功率波束寬度(°)	波束指向(°)	與中心波束的增益差(dB)
1號1.05 GHz	焦面場	75.08	74.00	–17.10	0.0596	0.000	0.00
	多喇叭多波束饋源	74.46	64.15	–24.10	0.0612	0.000	0.00
	致密焦面陣列饋源	74.98	72.32	–17.60	0.0606	0.000	0.00
5號1.05 GHz	焦面場	75.01	72.82	–16.40	0.0600	–0.045	–0.07
	多喇叭多波束饋源	74.38	62.97	–19.90	0.0616	–0.045	–0.08
	致密焦面陣列饋源	74.94	71.66	–16.10	0.0616	–0.045	–0.04
14號1.05 GHz	焦面場	74.92	71.32	–16.50	0.0599	–0.090	–0.16
	多喇叭多波束饋源	74.20	60.47	–17.60	0.0619	–0.090	–0.26
	致密焦面陣列饋源	74.74	68.43	–20.20	0.0622	–0.090	–0.24
29號1.05 GHz	焦面場	74.81	69.54	–16.40	0.0598	–0.140	–0.27
	多喇叭多波束饋源	74.00	57.70	–15.40	0.0622	–0.140	–0.46
	致密焦面陣列饋源	74.61	66.41	–17.10	0.0619	–0.140	–0.37
50號1.05 GHz	焦面場	74.58	65.95	–15.60	0.0617	–0.180	–0.50
	多喇叭多波束饋源	73.78	54.91	–13.50	0.0626	–0.185	–0.68
	致密焦面陣列饋源	74.42	63.57	–15.30	0.0626	–0.180	–0.56
1號1.25 GHz	焦面場	76.67	75.46	–16.90	0.0500	0.000	0.00
	多喇叭多波束饋源	76.18	67.29	–26.80	0.0527	0.000	0.00
	致密焦面陣列饋源	76.62	74.42	–19.10	0.0514	0.000	0.00
5號1.25 GHz	焦面場	76.57	73.66	–17.10	0.0500	–0.045	–0.10
	多喇叭多波束饋源	76.05	65.34	–21.50	0.0530	–0.045	–0.12
	致密焦面陣列饋源	76.55	73.36	–18.40	0.0519	–0.045	–0.06
14號1.25 GHz	焦面場	76.46	71.80	–16.20	0.0502	–0.090	–0.21
	多喇叭多波束饋源	75.84	62.31	–17.20	0.0542	–0.090	–0.33
	致密焦面陣列饋源	76.25	68.37	–18.60	0.0529	–0.090	–0.36
29號1.25 GHz	焦面場	76.33	69.67	–16.10	0.0505	–0.140	–0.34
	多喇叭多波束饋源	75.60	58.97	–15.00	0.0538	–0.140	–0.57
	致密焦面陣列饋源	76.20	67.66	–19.20	0.0526	–0.135	–0.41
50號1.25 GHz	焦面場	76.13	66.50	–15.70	0.0512	–0.180	–0.54
	多喇叭多波束饋源	75.29	54.86	–13.00	0.0548	–0.185	–0.88
	致密焦面陣列饋源	75.97	64.17	–15.80	0.0535	–0.185	–0.64
1號1.45 GHz	焦面場	78.06	77.07	–16.70	0.0426	0.000	0.00
	多喇叭多波束饋源	77.52	68.06	–30.60	0.0468	0.000	0.00
	致密焦面陣列饋源	78.01	76.19	–19.90	0.0440	0.000	0.00
5號1.45 GHz	焦面場	77.97	75.49	–16.60	0.0426	–0.045	–0.09
	多喇叭多波束饋源	77.39	66.05	–21.60	0.0470	–0.045	–0.13
	致密焦面陣列饋源	77.90	74.28	–18.80	0.0437	–0.045	–0.11
14號1.45 GHz	焦面場	77.85	73.43	–16.20	0.0427	–0.095	–0.21
	多喇叭多波束饋源	77.16	62.64	–17.20	0.0480	–0.095	–0.35
	致密焦面陣列饋源	77.64	69.96	–20.10	0.0456	–0.095	–0.37
29號1.45 GHz	焦面場	77.67	70.45	–16.50	0.0488	–0.140	–0.39
	多喇叭多波束饋源	76.86	58.46	–15.00	0.0486	–0.140	–0.65
	致密焦面陣列饋源	77.49	67.59	–17.50	0.0445	–0.140	–0.52
50號1.45 GHz	焦面場	77.43	66.66	–16.00	0.0439	–0.185	–0.63
	多喇叭多波束饋源	76.44	53.07	–12.80	0.0499	–0.185	–1.07
	致密焦面陣列饋源	77.22	63.52	–13.70	0.0465	–0.180	–0.79

下載: 導出CSV

參考文獻(22)

CHEN Yang, MENG Hongfu, GAN Yu, et al. Millimeter wave multi-beam reflector antenna[C]. 2018 International Workshop on Antenna Technology, Nanjing, China, 2018: 1–3. doi: 10.1109/IWAT.2018.8379140.

MANOOCHEHRI O, EMADEDDIN A, DARVAZEHBAN A, et al. A new method for designing high efficiency multi feed multi beam reflector antennas[C]. 2017 International Conference on Electromagnetics in Advanced Applications, Verona, Italy, 2017: 551–554. doi: 10.1109/ICEAA.2017.8065304.

ANGEVAIN J C, FONSECA N, SCHOBERT D, et al. Multibeam reflector antennas for space applications: Current trends and future perspectives in Europe[C]. The 12th European Conference on Antennas and Propagation, London, UK, 2018: 1–5. doi: 10.1049/cp.2018.0804.

HE Shanhong, LI Wenkai, LU Xiaojia, et al. Predicting influence of the rest spherical surface on the instantaneous parabolic surface of multi-beam for radio astronomy[C]. 2018 IEEE MTT-S international wireless symposium, Chengdu, China, 2018: 1–3. doi: 10.1109/IEEE-IWS.2018.8400911.

SMITH S L, DUNNING A, SMART K W, et al. Performance validation of the 19-element multibeam feed for the five-hundred-metre aperture spherical radio telescope[C]. 2017 IEEE International Symposium on Antennas and Propagation & USNC/URSI National Radio Science Meeting, San Diego, USA, 2017: 2137–2138.

DUNNING A, BOWEN M, CASTILLO S, et al. Design and laboratory testing of the five hundred meter aperture spherical telescope (FAST) 19 beam L-band receiver[C]. The 2017 32nd General Assembly and Scientific Symposium of the International Union of Radio Science, Montreal, Canada, 2017. doi: 10.23919/URSIGASS.2017.8105012.

LIU Lei and GRAINGE K. Realization of phased arrays for reflector observing systems[C]. The 2017 32nd General Assembly and Scientific Symposium of the International Union of Radio Science, Montreal, Canada, 2017. doi: 10.23919/URSIGASS.2017.8105014.

HUT B, VAN DEN BRINK R H, and VAN CAPPELLEN W A. Status update on the system validation of APERTIF, the phased array feed system for the westerbork synthesis radio telescope[C]. The 2017 11th European Conference on Antennas and Propagation, Paris, France, 2017: 1960–1961. doi: 10.23919/EuCAP.2017.7928787.

WU Yang, WARNICK K F, and JIN Chengjin. Design study of an L-band phased array feed for wide-field surveys and vibration compensation on FAST[J]. IEEE Transactions on Antennas and Propagation, 2013, 61(6): 3026–3033. doi: 10.1109/TAP.2013.2254438

IVASHINA M V, KEHN M N M, KILDAL P S, et al. Control of reflection and mutual coupling losses in maximizing efficiency of dense focal plane arrays[C]. The 20061st European Conference on Antennas and Propagation, Nice, France, 2006: 1–6. doi: 10.1109/EUCAP.2006.4585045.

IVASHINA M and VAN ARDENNE J D B A. A way to improve the field of view of the radiotelescope with a dense focal plane array[C]. The 12th International Conference Microwave and Telecommunication Technology, Sevastopol, Ukraine, 2002: 278–281. doi: 10.1109/CRMICO.2002.1137238.

IVASHINA M and BREGMAN J. Experimental synthesis of a feed pattern with a dense focal plane array[C]. The 200232nd European Microwave Conference, Milan, Italy, 2002: 1–4. doi: 10.1109/EUMA.2002.339456.

SHI Wei, ZHANG Quansheng, and DU Hui. Quantum particle swarm optimization for integer programming of phased array feeds[C]. 2010 International Conference on Microwave and Millimeter Wave Technology, Chengdu, China, 2010: 1386–1389. doi: 10.1109/ICMMT.2010.5524774.

CHANG D C, HU C N, HUNG C I, et al. Pattern synthesis of the offset reflector antenna system with less complicated phased array feed[J]. IEEE Transactions on Antennas and Propagation, 1994, 42(2): 240–245. doi: 10.1109/8.277218

TANAKA S, YAMADA T, MURATA T, et al. A study on pattern synthesis method for array-fed reflector antenna for advanced direct broadcasting satellites[C]. 2001 IEEE Antennas and Propagation Society International Symposium, Boston, USA, 2001: 566–569. doi: 10.1109/APS.2001.958916.

SAKA B and YAZGAN E. Pattern optimization of a reflector antenna with planar-array feeds and cluster feeds[J]. IEEE Transactions on Antennas and Propagation, 1997, 45(1): 93–97. doi: 10.1109/8.554245

WHITE W D. Circular aperture distribution functions[J]. IEEE Transactions on Antennas and Propagation, 1977, 25(5): 714–716. doi: 10.1109/TAP.1977.1141672

SKULKIN S P, TURCHIN V I, KASCHEEV N I, et al. Transient field calculation of aperture antennas for various field distributions over the aperture[J]. IEEE Antennas and Wireless Propagation Letters, 2017, 16: 2295–2298. doi: 10.1109/LAWP.2017.2715323

DUAN D W and RAHMAT-SAMII Y. A generalized three-parameter (3-P) aperture distribution for antenna applications[J]. IEEE Transactions on Antennas and Propagation, 1992, 40(6): 697–713. doi: 10.1109/8.144605

IUPIKOV O A, IVASHINA M V, SKOU N, et al. Multibeam focal plane arrays with digital beamforming for high precision space-borne ocean remote sensing[J]. IEEE Transactions on Antennas and Propagation, 2018, 66(2): 737–748. doi: 10.1109/TAP.2017.2763174

ELMER M, JEFFS B D, WARNICK K F, et al. Beamformer design methods for radio astronomical phased array feeds[J]. IEEE Transactions on Antennas and Propagation, 2012, 60(2): 903–914. doi: 10.1109/TAP.2011.2173143

CHIPPENDALE A P, MCCONNELL D, BANNISTER K, et al. Recent developments in measuring signal and noise in phased array feeds at CSIRO[C]. The 201610th European Conference on Antennas and Propagation, Davos, Switzerland, 2016: 1–5. doi: 10.1109/EuCAP.2016.7481741.
