基于隨機位置選擇和矩陣編碼的語音信息隱藏方法
doi: 10.11999/JEIT181163
-
中國民航大學電子信息與自動化學院 天津 300300
Speech Information Hiding Method Based on Random Position Selection and Matrix Coding
-
College of Information Engineering and Automation, Civil Aviation University of China, Tianjin 300300, China
-
摘要:
針對低速率語音編碼問題,該文提出基于G.723.1編碼標準的信息隱藏算法。在基音預測編碼過程中,通過控制閉環基音周期(自適應碼本)的搜索范圍,該文結合隨機位置選擇方法(RPS)和矩陣編碼方法(MCM),實現秘密信息的嵌入,在語音編碼過程中實現了信息的隱藏。RPS方法的采用降低了載體碼字之間的關聯性,MCM方法的采用降低了載體的改變率。實驗結果證明,該文算法下PESQ惡化率平均值最大為1.63%,隱蔽性良好。
-
關鍵詞:
- 低速率語音編碼 /
- G.723.1編碼標準 /
- 基音預測 /
- 閉環基音周期
Abstract:For the low-rate speech encoding problem, an information hidden algorithm based on the G.723.1 coding standard is proposed. In the pitch prediction coding process, by controlling the search range of the closed-loop pitch period (adaptive codebook), combined with the Random Position Selection (RPS) method and the Matrix Coding Method (MCM), the secret information is embedded, which is implemented in the speech coding process. The adoption of the RPS method reduces the correlation between the carrier code-words, and the adoption of the MCM method reduces the rate of change of the carrier. The experimental results show that the average PESQ (Perceptual Evaluation of Speech Quality) deterioration rate under the algorithm is 1.63%, and the concealment is good.
-
表 1 發送方、接收方臺式PC配置情況
處理器 內存 聲卡 系統 Intel(R) Core(TM) i5-4590 CPU @ 3.30 GHz 4 GB Realtek High Definition Audio Windows 7專業版 Service Pack 1 下載: 導出CSV
表 2 本文隱藏算法的PESQ統計值
載密語音樣本 未載密語音樣本 PESQ改變率(%) 3 s語音樣本 CSM CSW ESM ESW CSM CSW ESM ESW CSM CSW ESM ESW 平均值 3.4237 3.3440 3.4165 3.4750 3.4429 3.3995 3.4259 3.5193 –0.55 –1.63 –0.27 –1.20 最大值 3.8999 3.7815 4.0995 4.1015 3.8262 3.7406 3.8863 3.9458 1.93 1.09 5.49 3.94 最小值 2.9756 2.9615 2.9756 2.9022 3.0930 3.1701 3.1160 3.1265 –3.80 –6.58 –4.51 –7.17 10 s語音樣本 CSM CSW ESM ESW CSM CSW ESM ESW CSM CSW ESM ESW 平均值 3.4095 3.3528 3.3990 3.3822 3.4218 3.3900 3.4102 3.4362 –0.37 –1.09 –0.33 –1.50 最大值 3.7954 3.7102 3.7614 3.8714 3.7406 3.6783 3.7406 3.8632 1.47 0.87 2.12 0.21 最小值 2.9965 2.9113 3.1003 2.9965 3.0590 3.0180 3.1123 3.0590 –2.00 –3.53 –1.20 –2.00 下載: 導出CSV
表 5 在滿嵌入率下兩種隱藏算法檢測率(%)
隱藏方法 語音種類 樣本時長 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0 2.0 3.0 4.0 5.0 6.0 文獻[10]隱藏算法 英文 85.40 88.00 88.50 89.25 90.10 91.45 91.40 92.40 92.95 93.70 96.20 96.95 97.15 97.65 97.35 中文 86.80 88.65 90.20 90.50 91.20 92.25 93.10 94.25 94.70 94.05 96.80 97.20 98.15 97.75 97.95 文獻[11]隱藏算法 英文 87.65 90.11 90.81 91.65 92.89 94.00 94.15 95.01 95.20 96.64 97.20 98.70 100.00 100.00 100.00 中文 90.70 92.95 94.00 94.55 95.79 96.83 97.16 98.22 98.30 98.89 99.16 99.99 100.00 100.00 100.00 本文隱藏算法 英文 43.20 46.43 46.95 47.33 48.39 49.51 49.44 50.36 51.64 51.93 54.67 55.68 55.92 56.04 55.94 中文 45.51 46.91 47.56 47.48 48.72 49.70 49.53 52.14 52.37 52.87 55.06 55.86 56.09 56.35 55.63 下載: 導出CSV
表 6 在不同嵌入率下3種隱藏算法檢測率(%)
隱藏方法 語音種類 嵌入率(%) 10 20 30 40 50 60 70 80 90 100 文獻[10]隱藏算法 英文 50.61 57.64 75.53 80.29 82.81 85.63 86.35 90.58 94.32 97.35 中文 51.93 58.49 75.28 80.56 82.49 85.27 87.92 92.56 95.63 97.95 文獻[11]隱藏算法 英文 53.94 60.89 78.66 83.49 85.91 88.69 89.35 93.74 97.25 100.00 中文 54.53 61.67 79.55 84.88 86.77 89.55 91.83 95.66 98.55 100.00 本文隱藏算法 英文 16.32 17.52 30.87 39.48 41.16 44.15 45.62 48.12 52.61 55.94 中文 15.22 17.35 30.56 39.52 41.74 44.16 44.59 49.31 52.38 55.63 下載: 導出CSV
-
PETITCOLAS F A P, ANDERSON R J, and KUHN M G. Information hiding - a survey[J]. The IEEE, 1999, 87(7): 1062–1078. doi: 10.1109/5.771065 丁琦, 平西建. 基于脈沖位置參數統計特征的壓縮域語音隱寫分析[J]. 計算機科學, 2011, 38(1): 217–220. doi: 10.3969/j.issn.1002-137X.2011.01.051DING Qi and PING Xijian. Steganalysis of compressed speech based on statistics of pulse position parameters[J]. Computer Science, 2011, 38(1): 217–220. doi: 10.3969/j.issn.1002-137X.2011.01.051 DITTMANN J, HESSE D, and HILLERT R. Steganography and steganalysis in voice-over IP scenarios: Operational aspects and first experiences with a new steganalysis tool set[J]. SPIE, 2005, 5681: 607–618. TIAN Hui, SUN Jun, CHANG C C, et al. Detecting bitrate modulation-based covert voice-over-IP communication[J]. IEEE Communications Letters, 2018, 22(6): 1196–1199. doi: 10.1109/LCOMM.2018.2822804 TIAN Hui, SUN Jun, CHANG C C, et al. Hiding information into voice-over-IP streams using adaptive bitrate modulation[J]. IEEE Communications Letters, 2017, 21(4): 749–752. doi: 10.1109/LCOMM.2017.2659718 XIAO Bo, HUANG Yongfeng, and TANG Shanyu. An approach to information hiding in low bit-rate speech stream[C]. 2008 IEEE Global Telecommunications Conference, New Orleans, USA, 2008: 1–5. TIAN Hui, LIU Jin, and LI Songbin. Improving security of quantization-index-modulation steganography in low bit-rate speech streams[J]. Multimedia Systems, 2014, 20(2): 143–154. doi: 10.1007/s00530-013-0302-8 CHIANG Y K, TSAI P, and HUANG Fenglong. Codebook partition based steganography without member restriction[J]. Fundamenta Informaticae, 2008, 82(1/2): 15–27. LI Songbin, JIA Yizhen, and KUO C C J. Steganalysis of QIM steganography in low-bit-rate speech signals[J]. IEEE/ACM Transactions on Audio, Speech, and Language Processing, 2017, 25(5): 1011–1022. doi: 10.1109/TASLP.2017.2676356 HUANG Yongfeng, LIU Chenghao, TANG Shanyu, et al. Steganography integration into a low-bit rate speech codec[J]. IEEE Transactions on Information Forensics and Security, 2012, 7(6): 1865–1875. doi: 10.1109/TIFS.2012.2218599 LIU C, BAI S, and HUANG Y. An information hiding algorithm in G. 729a based on pith prediction[C]. The 10th National Academic Conference on Information Hiding and Multimedia Information Security, Beijing, China, 2012: 15–18. LIN Zinan, HUANG Yongfeng, and WANG Jilong. RNN-SM: Fast steganalysis of VoIP streams using recurrent neural network[J]. IEEE Transactions on Information Forensics and Security, 2018, 13(7): 1854–1868. doi: 10.1109/TIFS.2018.2806741 YANG Wanxia, TANG Shanyu, LI Miaoqi, et al. Steganalysis of low embedding rates LSB speech based on histogram moments in frequency domain[J]. Chinese Journal of Electronics, 2107, 26(6): 1254–1260. doi: 10.1049/cje.2017.09.026 WU Zhijun, Gao Wei, and YANG Wei. LPC parameters substitution for speech information hiding[J]. The Journal of China Universities of Posts and Telecommunications, 2009, 16(6): 103–112. doi: 10.1016/S1005-8885(08)60295-2 HUANG Yongfeng, TANG Shanyu, and YUAN Jian. Steganography in inactive frames of VoIP streams encoded by source codec[J]. IEEE Transactions on Information Forensics and Security, 2011, 6(2): 296–307. doi: 10.1109/TIFS.2011.2108649 李松斌, 賈已真, 付江云, 等. 基于碼書關聯網絡的基音調制信息隱藏檢測[J]. 計算機學報, 2014, 37(10): 2107–2117. doi: 10.3724/SP.J.1016.2014.02107LI Songbin, JIA Yizhen, FU Jiangyun, et al. Detection of pitch modulation information hiding based on codebook correlation network[J]. Chinese Journal of Computers, 2014, 37(10): 2107–2117. doi: 10.3724/SP.J.1016.2014.02107 TIAN Hui, JIANG Hong, ZHOU Ke, et al. Transparency-orientated encoding strategies for voice-over-IP steganography[J]. The Computer Journal, 2012, 55(6): 702–716. doi: 10.1093/comjnl/bxr111 WESTFELD A. F5-A steganographic algorithm: High capacity despite better steganalysis[C]. The 4th International Workshop on Information Hiding, Pittsburgh, USA, 2001: 289–302. ITU-T. ITU-T P.862 Perceptual evaluation of speech quality (PESQ): An objective method for end-to-end speech quality assessment of narrow-band telephone networks and speech codecs[S]. Geneva, Switzerland: International Telecommunications Union, 2001. -
