Chernof f加權分類器框架在運動想象腦-機接口中的應用

譚平,  劉利枚,  郭璠,  周開軍

譚平, 劉利枚, 郭璠, 周開軍. Chernof f加權分類器框架在運動想象腦-機接口中的應用[J]. 電子與信息學報, 2020, 42(2): 488-494. doi: 10.11999/JEIT181132
引用本文: 譚平, 劉利枚, 郭璠, 周開軍. Chernof f加權分類器框架在運動想象腦-機接口中的應用[J]. 電子與信息學報, 2020, 42(2): 488-494. doi: 10.11999/JEIT181132
Ping TAN, Limei LIU, Fan GUO, Kaijun ZHOU. Applying Chernoff Weighted Classification Frame Method to MotorImagery Brain Computer Interface[J]. Journal of Electronics & Information Technology, 2020, 42(2): 488-494. doi: 10.11999/JEIT181132
Citation: Ping TAN, Limei LIU, Fan GUO, Kaijun ZHOU. Applying Chernoff Weighted Classification Frame Method to MotorImagery Brain Computer Interface[J]. Journal of Electronics & Information Technology, 2020, 42(2): 488-494. doi: 10.11999/JEIT181132

Chernof f加權分類器框架在運動想象腦-機接口中的應用

doi: 10.11999/JEIT181132
  • 1.

    湖南工商大學新零售虛擬現實技術湖南省重點實驗室 長沙 410205

  • 2.

    中南大學自動化學院 長沙 410083

基金項目: 國家自然科學基金(61502537)，國家社科基金(19BGL111)，湖南省教育廳科學研究優秀青年項目(18B338)，湖南省重點實驗室開放研究基金項目(2017TP1026)，教育部人文社科基金(14YJCZH099)
詳細信息
    作者簡介:

    譚平：男，1981年生，講師，主要研究方向為腦電信號處理、計算智能、模式識別

    劉利枚：女，1975年生，教授，主要研究方向為人工智能、機器人

    郭璠：女，1982年生，副教授，主要研究方向為圖像增強、機器視覺、模式識別

    周開軍：男，1978年生，副教授，主要研究方向為機器視覺、模式識別

    通訊作者:

    郭璠　guofancsu@163.com

  • 中圖分類號: R741.044;?TP391

Applying Chernoff Weighted Classification Frame Method to MotorImagery Brain Computer Interface

  • 1.

    Key Laboratory of Hunan Province for New Retail Virtual Reality Technology, Hunan University ofTechnology and Business, Changsha 410205, China

  • 2.

    School of Automation, Central South University, Changsha 410083, China

Funds: The National Natural Science Foundation of China (61502537), The National Social Science Foundation of China (19BGL111), The Scientific Research Project of the Education Department of Hunan Province (18B338), The Open Fund of Key Laboratory of Hunan Province (2017TP1026), The Foundation of Ministry of Education Humanities and Social Sciences (14YJCZH099)
  • 摘要:

    針對現有腦機接口(BCI)分類器與大腦認知過程結合不夠緊密的問題，該文提出一種基于Chernoff加權的分類器集成框架方法，并用于同步運動想象腦機接口中。通過對訓練數據進行統計分析，獲得各時刻腦電信號(EEG)的統計特性，并建立基于大腦認知過程的高斯概率模型。然后利用Chernoff邊界特性得到該概率模型的最小誤差，并以此確定該時刻分類器的權重，通過對各時刻分類器的加權，實現同步腦機接口的信號分類。以腦機接口競賽數據作為測試，并與線性判決分析、支持向量機和極限學習方法分別結合構成新的集成方法。由實驗結果可知，加權集成框架方法的分類性能比原獨立分類方法有顯著提高。

    Abstract:

    For the problem that the classifier is less considered to be combined with the brain's cognitive process in the Brain-Computer Interface (BCI) system, a Chernoff-weighted based classifier integrated frame method is proposed and used in synchronous motor imagery BCI. In the method, the statistic characteristics of ElectroEncephaloGraphy (EEG) are obtained by analyzing in each time point of synchronous BCI, and then the probability model is established to compute the Chernoff error bound, which is adopted as the weight of common classifier to take the discriminant process. The test experiments are based on the datasets from BCI competitions, and the proposed frame method is employed to compose with LDA, SVM, ELM respectively. The experimental results demonstrate that the proposed frame method shows competitive performance compared with other methods.

    • HTML全文

  • 圖  1  Chernoff加權框架方法的結構框圖

    圖  2  每次試驗的時序示意圖

    圖  3  各個時刻的特征統計概率分布圖

    圖  4  數據集1的互信息圖

    圖  5  數據集2的互信息圖

    圖  6  數據集3的互信息圖

    圖  7  數據集4的互信息圖

    圖  8  各算法分類精度結果圖

    圖  9  dout的統計均值和方差變化圖

    表  1  算法1 Chernoff框架方法的訓練過程

    　輸入：EEG訓練數據
    　輸出：獨立分類器模型參數和概率權重w
    　步驟 1　對EEG數據進行預處理，提取特征向量；
    　步驟 2　利用獨立分類器訓練得到模型參數；
    　步驟 3　利用式(1)得到特征向量的均值和方差；
    　步驟 4：利用式(8)得到權重w。
    下載: 導出CSV

    表  2  算法2 Chernoff框架方法的測試過程

    　輸入：t 時刻的測試 EEG 數據,獨立分類器參數和權重w
    　輸出：分類結果和判定值dout(t)
    　步驟 1　對EEG數據進行預處理，提取特征向量；
    　步驟 2　通過獨立分類器的訓練模型得到yc(t)；
    　步驟 3　利用式(11)和式(12)將yc轉化到p(t)∈[0, 1]；
    　步驟 4　利用式(9)計算pout(t)；
    　步驟 5　利用式(10)將pout(t) 變換到dout(t)∈[–1, 1]；
    　步驟 6　通過dout(t)的符號獲得分類結果。
    下載: 導出CSV

    表  3  實驗中的數據集

    序號數據集來源訓練集個數(試驗次數)測試集個數(試驗次數)類別
    1BCI II (III)1 (140)1 (140)2
    2BCI III (IIIb)1 (320)1 (320)2
    3BCI IV (IIb)3 (400)2 (320)2
    4BCI IV (IIb)3 (400)2 (320)2
    下載: 導出CSV

    表  4  數據集1的最大互信息

    分類方法最大互信息
    ELM0.524/0.051
    LDA0.414
    SVM0.471
    LSTM0.511
    ELM-CF0.680/0.020
    LDA-CF0.631
    SVM-CF0.662
    第II屆BCI競賽的第1名0.61
    下載: 導出CSV
  • TIWARI N, EDLA D R, DODIA S, et al. Brain computer interface: A comprehensive survey[J]. Biologically Inspired Cognitive Architectures, 2018, 26: 118–129. doi: 10.1016/j.bica.2018.10.005
    楊幫華, 李博. 基于腦機接口的康復訓練系統[J]. 系統仿真學報, 2019, 31(2): 174–180. doi: 10.16182/j.issn1004731x.joss.18-0791

    YANG Banghua and LI Bo. Rehabilitation training system based on brain computer interface[J]. Journal of System Simulation, 2019, 31(2): 174–180. doi: 10.16182/j.issn1004731x.joss.18-0791
    ALAZRAI R, ALWANNI H, BASLAN Y, et al. EEG-based brain-computer interface for decoding motor imagery tasks within the same hand using Choi-Williams time-frequency distribution[J]. Sensors, 2017, 17(9): 1937. doi: 10.3390/s17091937
    LEEB R, LEE F, KEINRATH C, et al. Brain-computer communication: Motivation, aim, and impact of exploring a virtual apartment[J]. IEEE Transactions on Neural Systems and Rehabilitation Engineering, 2007, 15(4): 473–482. doi: 10.1109/TNSRE.2007.906956
    GUY V, SORIANI M H, BRUNO M, et al. Brain computer interface with the P300 speller: Usability for disabled people with amyotrophic lateral sclerosis[J]. Annals of Physical and Rehabilitation Medicine, 2018, 61(1): 5–11. doi: 10.1016/j.rehab.2017.09.004
    HASAN M R, IBRAHIMY M I, MOTAKABBER S M A, et al. Classification of multichannel EEG signal by linear discriminant analysis[C]. The 23rd International Conference on Systems Engineering, 2015: 279–282. doi: 10.1007/978-3-319-08422-0_42.
    SELIM S, TANTAWI M M, SHEDEED H A, et al. A CSP\AM-BA-SVM approach for motor imagery BCI system[J]. IEEE Access, 2018, 6: 49192–49208. doi: 10.1109/access.2018.2868178
    BHADURI S, KHASNOBISH A, BOSE R, et al. Classification of lower limb motor imagery using K nearest neighbor and na?ve-bayesian classifier[C]. The 3rd IEEE International Conference on Recent Advances in Information Technology (RAIT), Dhanbad, India, 2016: 1–6. doi: 10.1109/RAIT.2016.7507952.
    ZHANG Yu, WANG Yu, JIN Jing, et al. Sparse Bayesian learning for obtaining sparsity of EEG frequency bands based feature vectors in motor imagery classification[J]. International Journal of Neural Systems, 2017, 27(2): 1650032. doi: 10.1142/S0129065716500325
    HAZRATI M K and ERFANIAN A. An online EEG-based brain-computer interface for controlling hand grasp using an adaptive probabilistic neural network[J]. Medical Engineering & Physics, 2010, 32(7): 730–739. doi: 10.1016/j.medengphy.2010.04.016
    程時偉, 周桃春, 唐智川, 等. 卷積神經網絡實現的運動想象腦電分類及人-機器人交互應用[J]. 軟件學報, 2019, 30(10): 1–14. doi: 10.13328/j.cnki.jos.005782

    CHENG Shiwei, ZHOU Taochun, TANG Zhichuan, et al. Motor imagery EEG classifcation based on convolutional neural network and its application in human-robot interaction[J]. Journal of Software, 2019, 30(10): 1–14. doi: 10.13328/j.cnki.jos.005782
    LEMM S, SCHAFER C, and CURIO G. BCI competition 2003-data set Ⅲ: Probabilistic modeling of sensorimotorμ-rhythms for classification of imaginary hand movements[J]. IEEE Transactions on Biomedical Engineering, 2004, 51(6): 1077–1080. doi: 10.1109/TBME.2004.827076
    TAN Ping, TAN Guanzheng, CAI Zixing, et al. Using ELM-based weighted probabilistic model in the classification of synchronous EEG BCI[J]. Medical & Biological Engineering & Computing, 2017, 55(1): 33–43. doi: 10.1007/s11517-016-1493-x
    MATSUI H. Variable and boundary selection for functional data via multiclass logistic regression modeling[J]. Computational Statistics & Data Analysis, 2014, 78: 176–185. doi: 10.1016/j.csda.2014.04.015
    SCHLOGL A, KEINRATH C, SCHERER R, et al. Information transfer of an EEG-based brain computer interface[C]. The 1st International IEEE EMBS Conference on Neural Engineering, Capri Island, Italy, 2003: 641–644. doi: 10.1109/CNE.2003.1196910.
    FORSTMANN B U, RATCLIFF R, and WAGENMAKERS E J. Sequential sampling models in cognitive neuroscience: Advantages, applications, and extensions[J]. Annual Review of Psychology, 2016, 67: 641–666. doi: 10.1146/annurev-psych-122414-033645
