基于改進深度卷積神經網絡的紙幣識別研究

蓋杉; 鮑中運

doi:10.11999/JEIT181097

基于改進深度卷積神經網絡的紙幣識別研究

doi: 10.11999/JEIT181097

蓋杉^,,
鮑中運

南昌航空大學信息工程學院南昌 330063

基金項目: 國家自然科學基金(61563037)，江西省杰出青年計劃(20171BCB23057)

詳細信息

作者簡介:
蓋杉：男，1980年生，副教授，碩士生導師，研究方向?yàn)橛?jì)算機視覺、圖像處理、深度學習

鮑中運：男，1990年生，碩士生，研究方向?yàn)橛?jì)算機視覺、圖像處理、深度學習

通訊作者:
蓋杉　gaishan@nchu.edu.cn

中圖分類號: TP391.41; TP181
計量
- 文章訪問數: 4230
- HTML全文瀏覽量: 1281
- PDF下載量: 116
- 被引次數: 0
出版歷程
- 收稿日期: 2018-11-28
- 修回日期: 2019-03-27
- 網絡出版日期: 2019-04-21
- 刊出日期: 2019-08-01

Banknote Recognition Research Based on Improved Deep Convolutional Neural Network

Shan GAI^,,
Zhongyun BAO

School ofInformation Engineering, Nanchang HangkongUniversity, Nanchang 330063, China

Funds: The National Natural Science Foundation of China(61563037), The Outstanding Youth Scheme of Jiangxi Province (20171BCB23057)

摘要

摘要: 針對如何提高紙幣識別率的問題，該文提出一種改進深度卷積神經網絡(DCNN)的紙幣識別算法。該算法首先通過融合遷移學習、帶泄露整流(Leaky ReLU)函數、批量歸一化(BN)和多層次殘差單元構造深度卷積層，對輸入的不同尺寸紙幣進行穩定而快速的特征提取與學習；然后采用改進的多層次空間金字塔池化算法對提取的紙幣特征實現固定大小的輸出表示；最后通過網絡全連接層和softmax層實現紙幣圖像分類。實驗結果表明，該算法在分類性能、泛化能力與穩定性上明顯優于常用的紙幣分類算法；同時該算法也能夠滿足紙幣清分系統的實時性要求。
- 紙幣識別 /
- 深度卷積神經網絡 /
- 殘差學習 /
- 空間金字塔池化
Abstract: In order to improve the recognition rate of banknotes, the improved banknote recognition algorithm based on Deep Convolutional Neural Network(DCNN) is proposed. Firstly, the algorithm constructs a deep convolution layer by integrating transfer learning, Leaky-Rectified Liner Unit (Leaky ReLU) function, Batch Normalization(BN) and multi-level residual unit that perform stable and fast feature extraction and learning on input different size banknotes. Secondly, a fixed-size output representation of the extracted banknote features is obtained by using the improved multi-level spatial pyramid pooling algorithm. Finally, the banknote classification is implemented by the full connection layer and the softmax layer of the network. The experimental results show that the proposed algorithm can effectively improve the recognition rate of banknotes, and has better generalization ability and robustness than the traditional banknote classification method. Meanwhile, the algorithm can meet the real-time requirements of the banknote sorting system.
- Banknote recognition /
- Deep Convolutional Neural Network (DCNN) /
- Residual learning /
- Spatial pyramid pooling

HTML全文

圖 1 算法結構示意圖

下載: 全尺寸圖片幻燈片

圖 2 紙幣圖像預處理(RMB-100)

下載: 全尺寸圖片幻燈片

圖 3 紙幣圖像預處理(USD-100)

下載: 全尺寸圖片幻燈片

圖 4 紙幣圖像預處理(EUR-500)

下載: 全尺寸圖片幻燈片

圖 5 多層次殘差單元結構圖

下載: 全尺寸圖片幻燈片

圖 6 多層次空間金字塔池化算法結構框架

下載: 全尺寸圖片幻燈片

圖 7 紙幣圖像的4個面向

下載: 全尺寸圖片幻燈片

表 1 紙幣數據庫

紙幣種類	紙幣面值	紙幣分類	紙幣樣本數	訓練樣本數	測試樣本數
人民幣(RMB)	5, 10, 20, 50, 100	20	46000	36000	10000
美元(USD)	1, 2, 10, 20, 50, 100	24	38000	25000	13000
歐元(EUR)	5, 10, 20, 50, 100, 200, 500	28	35000	26000	9000

下載: 導出CSV

表 2 數據庫DB1平均識別率(%)

人民幣	網格特征^[3]	自由掩模^[2]	VGGNet19^[10]	PReLU-net^18]	BN-inception^[16]	ResNet-34B^[13]	本文算法
100	74.25	76.44	91.52	91.45	92.38	94.16	96.68
50	74.02	74.75	90.83	91.76	92.11	95.98	97.80
20	75.23	76.88	92.34	91.56	93.64	94.88	95.03
10	80.12	83.34	94.06	94.76	95.67	96.86	96.97
5	83.24	80.57	93.16	93.27	95.53	95.66	97.82

下載: 導出CSV

表 3 數據庫DB2平均識別率(%)

美元	網格特征^[3]	自由掩模^[2]	VGGNet19^[10]	PReLU-net^[18]	BN-inception^[16]	ResNet-34B^[13]	本文算法
100	70.13	72.24	89.26	91.33	93.25	94.46	95.67
50	73.14	72.28	91.35	91.49	92.98	94.29	94.96
20	74.56	77.82	90.23	92.14	93.05	95.11	95.89
10	76.21	75.34	91.25	93.34	93.67	94.28	95.15
2	78.11	80.12	92.13	92.86	93.58	95.67	96.75
1	81.23	80.02	91.24	90.36	94.27	96.16	97.98

下載: 導出CSV

表 4 數據庫DB3平均識別率(%)

歐元	網格特征^[3]	自由掩模^[2]	VGGNet19^[10]	PReLU-net^[18]	BN-inception^[16]	ResNet-34B^[13]	本文算法
500	81.12	84.23	93.25	92.91	94.56	94.93	96.98
200	81.65	82.32	93.24	94.13	94.68	95.12	98.20
100	85.46	86.94	94.12	94.67	95.23	96.11	97.75
50	79.25	83.24	93.20	93.12	94.35	95, 29	96.79
20	83.24	84.52	94.25	95.28	95.64	96.33	98.76
10	85.33	87.12	94.24	94.76	94.19	97.20	97.88
5	84.20	83.52	94.16	93.26	95.12	95.78	97.89

下載: 導出CSV

表 5 污損紙幣實際測試識別率(%)

污損樣本	網格特征^[3]	自由掩模^[2]	VGGNet19^[10]	PReLU-net^[18]	BN-inception^[16]	ResNet-34B^[13]	本文算法
DB1(16100)	78.65	82.49	92.45	93.18	94.37	95.06	97.58
DB2(15960)	75.42	79.16	88.24	91.07	92.53	94.84	96.75
DB3(10500)	80.28	83.17	91.52	93.65	95.18	96.78	97.29

下載: 導出CSV

表 6 不同識別算法運行時間

自由掩模^[2]	網格特征^[3]	VGGNet19^[10]	PReLU-Net^[18]	BN-inception^[16]	ResNet-34B^[13]	本文算法
0.98	0.85	1.97	1.72	1.58	1.24	1.06

下載: 導出CSV
