一種快速響應無片外電容低壓差線性穩壓器

佟星元,  李茂,  董嗣萬

佟星元, 李茂, 董嗣萬. 一種快速響應無片外電容低壓差線性穩壓器[J]. 電子與信息學報, 2019, 41(11): 2592-2598. doi: 10.11999/JEIT181060
引用本文: 佟星元, 李茂, 董嗣萬. 一種快速響應無片外電容低壓差線性穩壓器[J]. 電子與信息學報, 2019, 41(11): 2592-2598. doi: 10.11999/JEIT181060
Xingyuan TONG, Mao LI, Siwan DONG. A Capacitor-less Low Dropout Regulator with Fast Response[J]. Journal of Electronics & Information Technology, 2019, 41(11): 2592-2598. doi: 10.11999/JEIT181060
Citation: Xingyuan TONG, Mao LI, Siwan DONG. A Capacitor-less Low Dropout Regulator with Fast Response[J]. Journal of Electronics & Information Technology, 2019, 41(11): 2592-2598. doi: 10.11999/JEIT181060

一種快速響應無片外電容低壓差線性穩壓器

doi: 10.11999/JEIT181060

  • 西安郵電大學電子工程學院 西安 710121

基金項目: 國家自然科學基金(61674122，61804124)，陜西省創新人才推進計劃(2017KJXX-46)，陜西省高層次人才特殊支持計劃(2018-36)
詳細信息
    作者簡介:

    佟星元：男，1984年生，博士后，教授，研究方向為生物醫療電子、超低功耗模擬. 混合信號集成電路設計

    李茂：男，1994年生，碩士生，研究方向為電源管理及無線能量傳輸電路設計

    董嗣萬：男，1988年生，博士，講師，研究方向為模擬集成電路設計

    通訊作者:

    佟星元 mayxt@126.com

  • 中圖分類號: TN431.2

A Capacitor-less Low Dropout Regulator with Fast Response

  • School of Electronics Engineering, Xi’an University of Posts and Telecommunications, Xi’an 710121, China

Funds: The National Natural Science Foundation of China (61674122, 61804124), Shaanxi Innovation Talents Promotion Plan(2017KJXX-46), Shaanxi Provincial High-level Talents Special Support Plan (2018-36)
  • 摘要: 為了改善負載跳變對低壓差線性穩壓器(LDO)的影響，該文提出一種用于無片外電容LDO(CL-LDO)的新型快速響應技術。通過增加一條額外的快速通路，實現CL-LDO的快速瞬態響應，并且能夠減小LDO輸出過沖和下沖的幅度。該文電路基于0.18 μm CMOS工藝設計實現，面積為0.00529 mm2。流片測試結果表明，當輸入電壓范圍為1.5～2.5 V時，輸出電壓為1.194 V；當負載電流以 1 μs的上升時間和下降時間在 100 μA～10 mA之間變化時，CL-LDO的過沖恢復時間為489.537 ns，下沖恢復為960.918 ns；相比未采用該技術的傳統CL-LDO，響應速度能夠提高7.41倍，輸出過沖和下沖的電壓幅值能夠分別下降35.3%和78.1%。
    Abstract: A novel technique for increasing the load response speed of Capacitor-Less Low-DropOut linear regulator (CL-LDO) is proposed to improve the transient response of CL-LDO when its load current changes. With an additional fast signal feedback path, the CL-LDO can achieve fast transient response so that the overshoot and undershoot of its output voltage can be dramatically reduced. A CL-LDO with fast response is realized in 0.18 μm CMOS and occupies an active area of 0.00529 mm2. The CL-LDO has an output voltage of 1.194 V when the input supply voltage ranges from 1.5 V to 2.5 V. When the load current changes from 100 μA to 10 mA with the rise and fall time of 1 μs, the output of LDO can be recovered from its overshoot and undershoot to a stable voltage within 489.537 ns and 960.918 ns, respectively. Compared with a traditional CL-LDO without this proposed technique, the transient response speed of this CL-LDO is increased by 7.41 times. The overshoot and undershoot of the output voltage is decreased by 35.3% and 78.1%, respectively.
    • HTML全文

  • 圖  1  傳統LDO和CL-LDO結構

    圖  2  本文提出CL-LDO的整體結構

    圖  3  本文提出CL-LDO的工作原理

    圖  4  本文提出的快速瞬態調節電路

    圖  5  本文CL-LDO的小信號模型等效電路

    圖  6  環路特性仿真結果

    圖  7  本文提出CL-LDO的芯片照片和版圖

    圖  8  本文CL-LDO的瞬態測試結果

    圖  9  本文CL-LDO的直流特性測試結果

    表  1  控制信號Ctrl1和Ctrl2的工作原理

    ILVfbCtrl1Ctrl2M1M2
    升高下沖/<0.70 V低電平低電平導通關斷
    降低過沖/>0.90 V高電平高電平關斷導通
    穩定穩定/=0.80 V高電平低電平關斷關斷
    下載: 導出CSV

    表  2  本文設計的CL-LDO與其它文獻的CL-LDO性能比較

    參數文獻[13]*文獻[14]文獻[15]文獻[16]本文
    W/OW
    工藝 (nm)18065180130180
    Vin (V)1.21.21.2～1.81～1.41.5～2.5
    Vout (V)110.8～1.60.81.2
    IL (mA)1000.1～251-1000.12～250.1～10
    過沖/下沖 (mV)220225200284597/946386/207
    環路增益 (dB)––>59.87585～8785～87
    負載調整率 (mV/mA)0.0230.0420.0810.1730.970.96
    線性調整率 (mV/V)0.693.8–2.2511.310.0
    恢復時間 (μs)3.6＊1.3?0.22?0.19#3.624＊0.489＊
    電源抑制比 (dB)49.652–5750.2
    面積 (mm2)0.0220.0870.0310.0080.00529
    *考慮寄生參數的電路后仿真數據；＊電流階躍變化的上升時間和下降時間為1 μs；?電流階躍變化的上升時間和下降時間約為300 ps；#電流階躍變化的上升時間和下降時間約為100 ns。
    下載: 導出CSV
  • MILLIKEN R J, SILVA-MARTINEZ J, and SANCHEZ-SINENCIO E. Full on-chip CMOS low-dropout voltage regulator[J]. IEEE Transactions on Circuits and Systems I: Regular Papers, 2007, 54(9): 1879–1890. doi: 10.1109/TCSI.2007.902615
    YEO J, JAVED K, LEE J, et al. A capacitorless low-dropout regulator with enhanced slew rate and 4.5-μA quiescent current[J]. Analog Integrated Circuits and Signal Processing, 2017, 90(1): 227–235. doi: 10.1007/s10470-016-0869-z
    TONG Xingyuan and SUN Tiantian. A programmable multi-output technique in LDO regulator for multi-reference SAR ADC application[J]. International Journal of Electronics, 2017, 104(3): 528–538. doi: 10.1080/00207217.2016.1218069
    HUANG W J, LU S H, and LIU Shenluan. A capacitor-free CMOS low dropout regulator with slew rate enhancement[C]. Proceedings of 2006 International Symposium on VLSI Design, Automation and Test, Hsinchu, China, 2006: 1–4.
    LIU Nanqi, JOHNSON B, NADIG V, et al. A transient-enhanced fully-integrated LDO regulator for SoC application[C]. Proceedings of 2018 IEEE International Symposium on Circuits and Systems, Florence, Italy, 2018: 1–5.
    LEUNG K N and NG Y S. A CMOS low-dropout regulator with a momentarily current-boosting voltage buffer[J]. IEEE Transactions on Circuits and Systems I: Regular Papers, 2010, 57(9): 2312–2319. doi: 10.1109/TCSI.2010.2043171
    AL-SHYOUKH M, LEE H, and PEREZ R. A transient-enhanced low-quiescent current low-dropout regulator with buffer impedance attenuation[J]. IEEE Journal of Solid-State Circuits, 2007, 42(8): 1732–1742. doi: 10.1109/JSSC.2007.900281
    TONG Xingyuan and WEI Kangkang. A fully integrated fast-response LDO voltage regulator with adaptive transient current distribution[C]. Proceedings of 2017 IEEE Computer Society Annual Symposium on VLSI, Bochum, Germany, 2017: 651–654.
    MARANO D, GRASSO A D, PALUMBO G, et al. Optimized active single-miller capacitor compensation with inner half-feedforward stage for very high-load three-stage OTAs[J]. IEEE Transactions on Circuits and Systems I: Regular Papers, 2016, 63(9): 1349–1359. doi: 10.1109/TCSI.2016.2573920
    ZENG Yanhan, LI Yuao, ZHANG Xin, et al. A push-pulled FVF based output-capacitorless LDO with adaptive power transistors[J]. Microelectronics Journal, 2017, 64: 69–77. doi: 10.1016/j.mejo.2017.04.008
    LEUNG K N and MOK P K T. Analysis of multistage amplifier-frequency compensation[J]. IEEE Transactions on Circuits and Systems I: Fundamental Theory and Applications, 2001, 48(9): 1041–1056. doi: 10.1109/81.948432
    AAMIR S A, HARIKUMAR P, and WIKNER J J. Frequency compensation of high-speed, low-voltage CMOS multistage amplifiers[C]. Proceedings of 2013 IEEE International Symposium on Circuits and Systems, Beijing, China, 2013: 381–384.
    SHIRMOHAMMADLI V, SABERKARI A, MARTINEZ-GARCIA H, et al. Low power output-capacitorless class-AB CMOS LDO regulator[C]. Proceedings of 2017 IEEE International Symposium on Circuits and Systems, Baltimore, USA, 2017: 1–4.
    LIM Y, LEE J, PARK S, et al. An external capacitorless low-dropout regulator with high PSR at all frequencies from 10 kHz to 1 GHz using an adaptive supply-ripple cancellation technique[J]. IEEE Journal of Solid-State Circuits, 2018, 53(9): 2675–2685. doi: 10.1109/JSSC.2018.2841984
    TANG Jun, LEE J, and ROH J. Low-power fast-transient capacitor-less LDO regulator with high slew-rate Class-AB amplifier[J]. IEEE Transactions on Circuits and Systems II: Express Briefs, 2019, 66(3): 462–466. doi: 10.1109/TCSII.2018.2865254
    BU Shi, GUO Jianping, and LEUNG K N. A 200-ps-response-time output-capacitorless low-dropout regulator with unity-gain bandwidth >100 MHz in 130-nm CMOS[J]. IEEE Transactions on Power Electronics, 2018, 33(4): 3232–3246. doi: 10.1109/TPEL.2017.2711017
