基于屬性攻擊圖的網絡動態威脅分析技術研究

楊英杰; 冷強; 常德顯; 潘瑞萱; 胡浩

doi:10.11999/JEIT181025

基于屬性攻擊圖的網絡動態威脅分析技術研究

doi: 10.11999/JEIT181025

信息工程大學 鄭州 450001

基金項目: 國家“863”高技術研究發展計劃(2015AA016006)，國家重點研發計劃課題(2016YFF0204003)，國家自然科學基金(61471344)

詳細信息

作者簡介:
楊英杰：男，1971年生，教授，研究方向?yàn)樾畔踩?/p>
冷強：男，1993年生，碩士生，研究方向?yàn)樾畔踩L(fēng)險評估

常德顯：男，1977年生，副教授，研究方向?yàn)樾畔踩?/p>
潘瑞萱：女，1995年生，碩士生，研究方向?yàn)镾DN網絡協議安全

胡浩：男，1989年生，講師，研究方向?yàn)榫W(wǎng)絡安全態勢感知和圖像秘密共享

通訊作者:
冷強　lqsly1993@163.com

中圖分類號: TP393
計量
- 文章訪問數: 2290
- HTML全文瀏覽量: 1302
- PDF下載量: 88
- 被引次數: 0
出版歷程
- 收稿日期: 2018-11-07
- 修回日期: 2019-03-25
- 網絡出版日期: 2019-04-22
- 刊出日期: 2019-08-01

Research on Network Dynamic Threat Analysis Technology Based on Attribute Attack Graph

Information Engineering University, Zhengzhou 450001, China

Funds: The National High Technology Research and Development Program of China (2015AA016006), The National Key Research and Development Program of China (2016YFF0204003), The National Natural Science Foundation of China (61471344)

摘要

摘要: 該文首先利用屬性攻擊圖理論構建了網絡動態威脅分析屬性攻擊圖(DT-AAG)模型，該模型在全面刻畫系統漏洞和網絡服務導致的威脅轉移關系的基礎上，結合通用漏洞評分標準(CVSS)和貝葉斯概率轉移計算方法設計了威脅轉移概率度量算法；其次基于構建的DT-AAG模型，利用威脅與漏洞、服務間的關聯關系，設計了動態威脅屬性攻擊圖生成算法(DT-AAG-A)，并針對生成的屬性攻擊圖存在的威脅傳遞環路問題，設計了環路消解機制；最后通過實驗驗證了該模型和算法的有效性。
- 屬性攻擊圖 /
- 威脅轉移 /
- 通用漏洞評分標準 /
- 傳遞環路
Abstract: Firstly, a network Dynamic Threat Attribute Attack Graph (DT-AAG) analysis model is constructed by using Attribute Attack Graph theory. On the basis of the comprehensive description of system vulnerability and network service-induced threat transfer relationship, a threat transfer probability measurement algorithm is designed in combination with Common Vulerability Scoring System (CVSS) vulnerability evaluation criteria and Bayesian probability transfer method. Secondly, based on the model, a Dynamic Threat Attribute Attack Graph generation Algorithm (DT-AAG-A) is designed by using the relationship between the threat and the vulnerability as well as the service. What’s more, to solve the problem that threat transfer loop existing in the generated attribute attack graph, the loop digestion mechanism is designed. Finally, the effectiveness of the proposed model and algorithm is verified by experiments.
- Attribute Attack Graph (AAG) /
- Threat to transfer /
- Common Vulerability Scoring System (CVSS) scoring standard /
- Transfer loop

HTML全文

圖 1 DT-AAG攻擊示意圖

下載: 全尺寸圖片幻燈片

圖 2 多步攻擊威脅轉移概率圖

下載: 全尺寸圖片幻燈片

圖 3 模式構建圖

下載: 全尺寸圖片幻燈片

圖 4 DT-AAG-A過程圖

下載: 全尺寸圖片幻燈片

圖 5 實驗環境圖

下載: 全尺寸圖片幻燈片

圖 6 DT-AAG生成圖

下載: 全尺寸圖片幻燈片

圖 7 文獻[8]實驗圖

下載: 全尺寸圖片幻燈片

表 1 DT-AAG-A生成算法

　輸入：DT-AAG-PL

　輸出：DT-AAG

　(1) DT-AAG-PL$ \ne \varnothing $; /* DT-AAG-PL數據庫不為空 */

　(2) DT-AAG${\rm{ = }}\varnothing $; /* 設置DT-AAG初始值為空 */

　(3) $t,i \in $DT-AAG-PL

　(4) For each $t = [{\rm{I}}{{\rm{D}}_t},{\rm{IPpreCo}}{{\rm{n}}_t},{\rm{IPpostCo}}{{\rm{n}}_t}]$

　(5) DO { /* 任取DT-AAG-PL中一個元素 */

　(6) SearchIDIPpre (DT-AAG-PL) }

　(7) For rest $j \in$DT-AAG-PL DO {

　　 /* 搜索匹配DT-AAG-PL中剩余元素*/

　(8) SearchIDIPpre (DT-AAG-PL, ${\rm{DT {\tiny{-}} AAG}}$)；

　　 /* 范圍為DT-AAG-PL 和${\rm{DT {\tiny{-}} AAG}}$ */ }

　(9) 　 If DT-AAG-PL$= \varnothing${

　　 /* 當DT-AAG-PL中所有元素都被移動 */

　(10) Return DT-AAG； }

　(11) SearchIDIPpre (DT-AAG-PL) {

　(12) 　If ${\rm{I}}{{\rm{D}}_t} = {\rm{I}}{{\rm{D}}_i}\& \& {\rm{IPpostCo}}{{\rm{n}}_t} = {\rm{IPpostCo}}{{\rm{n}}_i}$；

　　 /* 根據ID和IP搜索匹配 */

　(13) 　　{$a = t \to i$; Put a to ${\rm{DT - AAG}}$；}

　　 /* 將匹配到的元素移到${\rm{DT {\tiny{-}} AAG}}$ */

　(14) 　else

　(15) 　　{$a = t$; Put a to ${\rm{DT {\tiny{-}} AAG}}$；}

　　 /* 將未匹配的元素移到${\rm{DT {\tiny{-}}AAG}}$中 */ }

下載: 導出CSV

表 2 主機與服務器存在的漏洞和協議信息表

Host/Server	Protocol/Vulnerability	Port
user1	–	80/445
user2	HIDP	80
user3	GUN Wget	80
user4	NDproxy	445
WebServer	IIS	80
FileServer	Protocol with user3/Apache	80
DataServer	Protocol with user4	445
MainServer	Protocol with user2&user3&user4	80&445

下載: 導出CSV

表 3 漏洞信息表

Vulnerability	ExpSco+ImpSco	CVE Num.
HIDP	7.0	CVE-2018-8169
GUN Wget	8.8	CVE-2016-4971
NDproxy	7.2	CVE-2013-5065
IIS	7.8	CVE-2015-7597
Apache	7.5	CVE-2018-8015

下載: 導出CSV

表 4 攻擊路徑和威脅轉移概率表

攻擊路徑	a$ \to $d$ \to $i	a$ \to $d$ \to $j	a$ \to $d$ \to $k	a$ \to $d$ \to $l	a$ \to $e	a$ \to $f	a$ \to $g	b$ \to $j	b$ \to $k	b$ \to $l	c$ \to $m	c$ \to $n
轉移概率	0.38	0.30	0.49	0.49	0.44	0.34	0.56	0.53	0.88	0.88	0.58	0.58

下載: 導出CSV

表 5 關聯分析表

	攻擊路徑	攻擊成功概率	全攻擊路徑	消解環路	權限	系統業務關系
文獻[8]	√	√	×	√	√	×
文獻[9]	√	√	√	×	×	×
本文	√	√	√	√	√	√

下載: 導出CSV

參考文獻(19)

PHILLIPS C and SWILER L P. A graph-based system for network-vulnerability analysis[C]. The 1998 Workshop on New Security Paradigms, Charlottesville, Virginia, USA, 1998; 71–79.

SWILER L P, PHILLIPS C, ELLIS D, et al. Computer-attack graph generation tool[C]. DARPA Information Survivability Conference and Exposition II, DISCEX’01, Anaheim, CA, USA, 2001, 2: 307–321.

INGOLS K, CHU M, LIPPMANN R, et al. Modeling modern network attacks and countermeasures using attack graphs[C]. 2009 Annual Computer Security Applications Conference, Honolulu, Hawaii, USA, 2009: 117–126.

黃永洪, 吳一凡, 楊豪璞, 等. 基于攻擊圖的APT脆弱節點評估方法[J]. 重慶郵電大學學報(自然科學版), 2017, 29(4): 535–541. doi: 10.3979/j.issn.1673-825X.2017.04.017

HUANG Yonghong, WU Yifan, YANG Haopu, et al. Graph-based vulnerability assessment for APT attack[J]. Journal of Chongqing University of Posts and Telecommunications (Natural Science Edition), 2017, 29(4): 535–541. doi: 10.3979/j.issn.1673-825X.2017.04.017

LEE J, MOON D, KIM I, et al. A semantic approach to improving machine readability of a large-scale attack graph[J]. The Journal of Supercomputing, 2018: 1–18. doi: 10.1007/s11227-018-2394-6

胡浩, 劉玉嶺, 張紅旗, 等. 基于吸收Markov鏈的網絡入侵路徑預測方法[J]. 計算機研究與發展, 2018, 55(4): 831–845. doi: 10.7544/issn1000-1239.2018.20170087

HU Hao, LIU Yuling, ZHANG Hongqi, et al. Route prediction method for network intrusion using absorbing markov Chain[J]. Journal of Computer Research and Development, 2018, 55(4): 831–845. doi: 10.7544/issn1000-1239.2018.20170087

HU Hao, LIU Yuling, ZHANG Hongqi, et al. Security metric methods for network multistep attacks using AMC and big data correlation analysis[J]. Security and Communication Networks, 2018, 2018: 57871012. doi: 10.1155/2018/5787102

吳迪, 連一峰, 陳愷, 等. 一種基于攻擊圖的安全威脅識別和分析方法[J]. 計算機學報, 2012, 35(9): 1938–1950. doi: 10.3724/SP.J.1016.2012.01938

WU Di, LIAN Yifeng, CHEN Kai, et al. A security threats identification and analysis method based on attack graph[J]. Chinese Journal of Computers, 2012, 35(9): 1938–1950. doi: 10.3724/SP.J.1016.2012.01938

HOMER J, ZHANG Su, OU Xinming, et al. Aggregating vulnerability metrics in enterprise networks using attack graphs[J]. Journal of Computer Security, 2013, 21(4): 561–597. doi: 10.3233/JCS-130475

王會梅, 鮮明, 王國玉. 基于擴展網絡攻擊圖的網絡攻擊策略生成算法[J]. 電子與信息學報, 2011, 33(12): 3015–3021. doi: 10.3724/SP.J.1146.2011.00414

WANG Huimei, XIAN Ming, and WANG Guoyu. A network attack decision-making algorithm based on the extended attack graph[J]. Journal of Electronics &Information Technology, 2011, 33(12): 3015–3021. doi: 10.3724/SP.J.1146.2011.00414

WANG Huan, CHEN Zhanfang, ZHAO Jianping, et al. A vulnerability assessment method in industrial internet of things based on attack graph and maximum flow[J]. IEEE Access, 2018, 6: 8599–8609. doi: 10.1109/ACCESS.2018.2805690

張海霞, 蘇璞睿, 馮登國. 基于攻擊能力增長的網絡安全分析模型[J]. 計算機研究與發展, 2007, 44(12): 2012–2019.

ZHANG Haixia, SU Purui, and FENG Dengguo. A network security analysis model based on the increase in attack ability[J]. Journal of Computer Research and Development, 2007, 44(12): 2012–2019.

SINGH U K, JOSHI C, and GAUD N. Information security assessment by quantifying risk level of network vulnerabilities[J]. International Journal of Computer Applications, 2016, 156(2): 37–44. doi: 10.5120/ijca2016912375

胡浩, 葉潤國, 張紅旗, 等. 面向漏洞生命周期的安全風險度量方法[J]. 軟件學報, 2018, 29(5): 1213–1229. doi: 10.13328/j.cnki.jos.005507

HU Hao, YE Runguo, ZHANG Hongqi, et al. Vulnerability life cycle oriented security risk metric method[J]. Journal of Software, 2018, 29(5): 1213–1229. doi: 10.13328/j.cnki.jos.005507

陳鋒, 張怡, 蘇金樹, 等. 攻擊圖的兩種形式化分析[J]. 軟件學報, 2010, 21(4): 838–848. doi: 10.3724/SP.J.1001.2010.03584

CHEN Feng, ZHANG Yi, SU Jinshu, et al. Two formal analyses of attack graphs[J]. Journal of Software, 2010, 21(4): 838–848. doi: 10.3724/SP.J.1001.2010.03584

葉子維, 郭淵博, 王宸東, 等. 攻擊圖技術應用研究綜述[J]. 通信學報, 2017, 38(11): 121–132. doi: 10.11959/j.issn.1000-436x.2017213

YE Ziwei, GUO Yuanbo, WANG Chendong, et al. Survey on application of attack graph technology[J]. Journal on Communications, 2017, 38(11): 121–132. doi: 10.11959/j.issn.1000-436x.2017213

CVSS v3.0 specification document[EB/OL]. https://www.first.org/cvss/specification-document, 2018.

CVE. Common vulnerabilities and exposures[EB/OL]. http://cve.mitre.org/, 2018.

NIST. National vulnerability database[EB/OL]. https://nvd.nist.gov/, 2018.
