一種基于天牛須算法的新型超寬帶功分器研究

李杰; 閻躍鵬; 梁曉新; 萬晶; 王魁松

doi:10.11999/JEIT181003

一種基于天牛須算法的新型超寬帶功分器研究

doi: 10.11999/JEIT181003

李杰^{1, 2},
閻躍鵬^{1, 2},
梁曉新^{1, 2, ,},
萬晶¹,
王魁松¹

1.
中國科學院微電子研究所北京 100029
2.
中國科學院大學 北京 100049

詳細信息

作者簡介:
李杰：女，1977年生，工程師，博士生，研究方向?yàn)樯漕l微波電路設計

閻躍鵬：男，1963年生，博士生導師，研究員，研究方向?yàn)榧呻娐吩O(shè)計，射頻微波電路設計

梁曉新：女，1979年生，碩士生導師，研究員，研究方向微波毫米波芯片及模塊

通訊作者:
梁曉新　liangxiaoxin@ime.ac.cn

中圖分類號: TN626
計量
- 文章訪問數: 3697
- HTML全文瀏覽量: 1414
- PDF下載量: 60
- 被引次數: 0
出版歷程
- 收稿日期: 2018-11-01
- 修回日期: 2019-04-22
- 網絡出版日期: 2019-05-29
- 刊出日期: 2020-02-19

Research on the Novel Ultra-wideband Power Divider Based on Beetle Antennae Search Algorithm

Jie LI^{1, 2},
Yuepeng YAN^{1, 2},
Xiaoxin LIANG^{1, 2
, ,},
Jing WAN¹,
Kuisong WANG¹

1.
Institute of Microelectronics of Chinese Academy of Sciences, Beijing 100029, China
2.
University of Chinese Academy of Sciences, Beijing 100049, China

摘要

摘要:
根據對馬刺線的原理分析，該文提出一種新型馬刺線結構，并在此基礎上設計出一種新穎的超寬帶功分器(頻率范圍為2.5～13.2 GHz)。該超寬帶功分器尺寸較小，制作結構簡單，帶內傳輸特性好，輸入與輸出端口的回波損耗均小于–12 dB，帶內插入損耗小于3.5 dB。在設計過程中，根據理想傳輸線模型，利用奇偶模分析方法，推導出設計的目標函數，并利用天牛須算法對其進行優化設計，有效提高了功分器的設計準確性和靈活性。為了驗證設計的準確性，采用材料RO4003C作為基板設計超寬帶功分器。實驗結果表明，采用新型馬刺線結構的超寬帶功分器結合天牛須算法有效縮短了計算時間，提高了設計精度，可以廣泛運用于超寬帶功分器設計。
- 超寬帶功分器 /
- 馬刺線 /
- 天牛須
Abstract:
Based on the study of the spur-line, a novel spurs-line structure is proposed. The design of a novel Ultra-WideBand (UWB) power divider is described based on the novel spur line structure for the 2.5～13.2 GHz frequency range. The designed device is compact and has a simple structure and good frequency response in the band. Its return loss insertion is less than –12 dB and its insertion loss is less than 3.5 dB. The equations used for the design are based on the concept of odd-even modes and transmission line analysis. The Beetle Antennae Search (BAS) algorithm is used to improve the efficiency and accuracy of the power divider design. In order to verify the accuracy of the design, a UWB power divider is designed by using material RO4003C as substrate. The results validate the feasibility of the spur line-based design and demonstrat that the BAS algorithm has a shortened running time and improved precision compared to other optimization methods. It can be widely used in UWB power divider design.
- UWB power divider /
- Spur-line /
- Beetle Antenna Search(BAS)

HTML全文

圖 1 新型馬刺線結構

下載: 全尺寸圖片幻燈片

圖 2 超寬帶功分器結構圖

下載: 全尺寸圖片幻燈片

圖 3 功分器的奇偶模等效電路

下載: 全尺寸圖片幻燈片

圖 4 扇形線示意圖

下載: 全尺寸圖片幻燈片

圖 5 功分器實物圖

下載: 全尺寸圖片幻燈片

圖 6 S參數仿真和測試結果對比

下載: 全尺寸圖片幻燈片

表 1 優化參數前后結果對比

最優值(dB)	${S_{11}}$	${S_{22}}/{S_{11}}$	${S_{23}}/{S_{32}}$	${S_{21}}/{S_{31}}$
沒有采用優化算法	$ - 20$	$ - 29$	$ - 29$	$ - 3.2$
采用天牛須算法	$ - 40$	$ - 50$	$ - 40$	$ - 3.1$

下載: 導出CSV

表 2 功分器性能對比

參考文獻	拓?fù)浣Y(jié)構	復雜度	尺寸(cm$ \times $cm)	插入損耗(dB)	15 dB 隔離度(比值，(BW, GHz))	隔離電阻數量
文獻[1]	CPD	低	3.0$ \times $1.0	3.5	3.00:1 (3.5–10.5)	1
文獻[2]	多模諧振	低	3.0$ \times $2.0	5.0	2.90:1 (4.0–11.7)	1
文獻[5]	級聯	低	3.3$ \times $2.3	4.0	6.00:1 (2.0–12.0)	5
文獻[6]	SIR	低	3.0$ \times $2.0	5.0	–	1
文獻[7]	非共面	高	4.0$ \times $4.0	4.0	–	1
文獻[9]	Radial Stub	低	2.0$ \times $1.5	3.8	1.50:1 (7.1–10.6)	1
文獻[10]	耦合振蕩	低	4.0$ \times $1.2	3.7	隔離度均大于–15 dB	1
本文	馬刺線級聯	低	1.4$ \times $1.5	<3.5	2.67:1 (4.5–12.0)	1

下載: 導出CSV

參考文獻(15)

UCHENDU I E and KELLY J R. Ultrawide isolation bandwidth compensated power divider for UWB applications[J]. Microwave and Optical Technology Letters, 2017, 59(12): 3177–3180. doi: 10.1002/mop.30899

WENG Meili, SONG Yaoliang, and ZHAO Junding. Design of compact microstrip UWB power divider using square ring multiple-mode resonator[C]. 2015 Asia-pacific Microwave Conference, Nanjing, China, 2015: 1–3. doi: 10.1109/APMC.2015.7411703.

WU Y and LIU Y. Compact 3–11 GHz UWB planar unequal power divider using two-section asymmetric coupled transmission lines and non-uniform microstrip[J]. Electronics Letters, 2013, 49(16): 1002–1003. doi: 10.1049/el.2013.0296

XU Xin and TANG Xiaohong. Design of an ultra-wideband power divider with harmonics suppression[J]. International Journal of RF and Microwave Computer-Aided Engineering, 2015, 25(4): 299–304. doi: 10.1002/mmce.20862

郭崢, 池少騰, 楊自強. 2~12 GHz超寬帶功分器的設計[J]. 應用科技, 2015, 42(4): 34–36. doi: 10.3969/j.issn.1009-671X.201502002

GUO Zheng, CHI Shaoteng, and YANG Ziqiang. Design of 2~12 GHz ultra-wideband power dividers[J]. Applied Science and Technology, 2015, 42(4): 34–36. doi: 10.3969/j.issn.1009-671X.201502002

MONDAL P and PARUI S K. Multi-mode resonator-based ultra-wideband power divider[J]. Microwave and Optical Technology Letters, 2016, 58(10): 2419–2422. doi: 10.1002/mop.30063

PENG Hao, YANG Ziqiang, LIU Yu, et al. An improved UWB non-coplanar power divider[J]. Progress in Electromagnetics Research, 2013, 138: 31–39. doi: 10.2528/PIER13011003

SEDDIKI M L, GHANEM F, and NEDIL M. A compact power divider multilyer for UWB applications[C]. The 17th International Symposium on Antenna Technology and Applied Electromagnetics, Montreal, Canada, 2016: 1–2. doi: 10.1109/ANTEM.2016.7550208.

RAHIM N H A, SAARI M F A H, IBRAHIM S Z, et al. Wideband power divider using radial stub for six-port interferometer[C]. 2016 IEEE Asia-Pacific Conference on Applied Electromagnetics, Langkawi, Malaysia, 2016: 127–131. doi: 10.1109/APACE.2016.7915868.

MONDAL P and PARUI S K. Wideband coupled resonator based ultra-wideband 3db power divider[C]. 2017 IEEE Applied Electromagnetics Conference, Aurangabad, India, 2017: 1–2. doi: 10.1109/AEMC.2017.8325699.

武歡歡, 陳明, 張延冬, 等. 寬帶Wilkinson功分器的粒子群優化設計[J]. 強激光與粒子束, 2018, 30(3): 30033003. doi: 10.11884/HPLPB201830.170314

WU Huanhuan, CHEN Ming, ZHANG Yandong, et al. Design of broadband Wilkinson power divider based on particle swarm optimization[J]. High Power Laser and Particle Beams, 2018, 30(3): 30033003. doi: 10.11884/HPLPB201830.170314

回海生, 劉建霞, 梁軍. 基于改進PSO算法優化RF MEMS功分器設計[J]. 微納電子技術, 2017, 54(4): 254–260. doi: 10.13250/j.cnki.wndz.2017.04.006

HUI Haisheng, LIU Jianxia, and LIANG Jun. Design of the RF MEMS power divider based on an improved PSO algorithm[J]. Micronanoelectronic Technology, 2017, 54(4): 254–260. doi: 10.13250/j.cnki.wndz.2017.04.006

JIANG Xiangyuan and LI Shuai. BAS: Beetle antennae search algorithm for optimization problems[J]. International Journal of Robotics and Control, 2018, 1(1): 1–5. doi: 10.5430/ijrc.v1n1p1

VINDING J P. Radial line stubs as elements in strip line circuits[R]. NEREM Record, 1967: 108–109.

ZHU Zongyao, ZHANG Zhiyu, MAN Weishi, et al. A new beetle antennae search algorithm for multi-objective energy management in microgrid[C]. The 13th IEEE Conference on Industrial Electronics and Applications, Wuhan, China, 2018: 1599–1603. doi: 10.1109/ICIEA.2018.8397965.
