基于高超聲速平臺前斜視多通道SAR-GMTI雜波抑制方法
doi: 10.11999/JEIT181002
-
1.
西安電子科技大學雷達信號處理國家重點實驗室 西安 710071
-
2.
通信網信息傳輸與分發技術重點實驗室 石家莊 050081
Multi-channel SAR-GMTI Clutter Suppression Method Based onHypersonic Platform Forward Squint
-
1.
National Key Technology of Radar Signal Processing, Xidian University, Xi’an 710071, China
-
2.
Science and Technology on Information Transmission and Dissemination in Communication Networks Laboratory, Shijiazhuang 050081, China
-
摘要:
針對高超聲速(HSV)平臺雷達系統,該文提出一種基于高超聲速平臺前斜視多通道合成孔徑雷達地面動目標檢測(SAR-GMTI)雜波抑制方法。該方法先進行時域距離走動校正和距離壓縮,并補償距離向通道相位誤差實現距離向包絡對齊;然后再對方位多普勒擴展的信號進行3階線調頻傅里葉變換(CFT)壓縮,并補償方位向通道相位誤差實現方位向包絡對齊;接著在距離時域-方位CFT域利用數字波束形成(DBF)技術對雜波及其模糊分量置零進行空時自適應處理(STAP),從而可以有效抑制靜止雜波及其模糊分量并提取出無模糊的運動目標回波信號。
-
關鍵詞:
- 合成孔徑雷達地面動目標檢測 /
- 高超聲速飛行器 /
- 前斜視 /
- 多普勒模糊 /
- 空時自適應處理
Abstract:According to the HyperSonic Vehicle (HSV) borne radar platform system, a multi-channel SAR-GMTI clutter suppression method is presented based on hypersonic platform forward squint mode. First, range walk correction and range compression are completed in the time domain, and the distance envelope is aligned simultaneously with phase error compensation. Then, the Doppler extended signal is compressed by three-order azimuth Chirp Fourier Transform (CFT), and the azimuth envelope of the echo is aligned with phase error compensation simultaneously. Next, the Digital Beam Forming (DBF) technology is applied to the range time-azimuth CFT domain by nulling the clutter and its ambiguous components to achieve Space-Time Adaptive Processing (STAP). The stationary clutter and its ambiguous components can be suppressed effectively and the echo signs of the moving target without blurring can be extracted.
-
表 1 仿真參數
參數名稱 載頻${f_{\rm{c}}}$ 斜視角 平臺高度H 中心斜距R 距離分辨率 信號多普勒帶寬 重頻PRF 平臺速度V 相鄰?fù)ǖ篱g距d 方位分辨率 參數值 10 GHz 50° 30 km 60 km 1 m 1530 Hz 554 Hz 2380 m/s 1.5 m 1 m 下載: 導出CSV
-
