基于Hilbert信號空間的未知干擾自適應識別方法

黃國策; 王桂勝; 任清華; 董淑福; 高維廷; 魏帥

doi:10.11999/JEIT180891

基于Hilbert信號空間的未知干擾自適應識別方法

doi: 10.11999/JEIT180891

1.
空軍工程大學信息與導航學院西安 710077
2.
95910部隊 ??酒泉 ??735000

基金項目: 國家自然科學基金(61701521)，中國博士后科學基金(2016M603044)，陜西省自然科學基金(2018JQ6074)

詳細信息

作者簡介:
黃國策：男，1962年生，博士，教授，研究方向?yàn)檐娛潞娇胀ㄐ拧⒍滩ńM網

王桂勝：男，1992年生，博士生，研究方向?yàn)檐娛潞娇胀ㄐ拧⑼ㄐ趴垢蓴_、認知無線網絡

任清華：男，1967年生，教授，研究方向?yàn)檐娛潞娇胀ㄐ拧⒆儞Q域通信

董淑福：男，1971年生，教授，研究方向?yàn)檐娛潞娇胀ㄐ拧⒍滩ńM網

高維廷：男，1984年生，博士，研究方向?yàn)殡姶蓬l譜管理

魏帥：女，1993年生，碩士，研究方向?yàn)槎嗄繕?biāo)跟蹤識別

通訊作者:
王桂勝　wgsfuyun@163.com

中圖分類號: TN92
計量
- 文章訪問數: 2088
- HTML全文瀏覽量: 1028
- PDF下載量: 78
- 被引次數: 0
出版歷程
- 收稿日期: 2018-09-18
- 修回日期: 2019-03-26
- 網絡出版日期: 2019-04-23
- 刊出日期: 2019-08-01

Adaptive Recognition Method for Unknown Interference Based on Hilbert Signal Space

1.
College of Information and Navigation, Air Force Engineering University, Xi’an 710077, China
2.
The 95910 Troop, Jiuquan 735000, China

Funds: The National Natural Science Foundation of China (61701521), The Postdoctoral Science Foundation of China (2016M603044), The Shaanxi Province Natural Science Foundation (2018JQ6074)

摘要

摘要: 針對大樣本下未知干擾類型的分類識別問題，該文提出一種基于信號特征空間的未知干擾自適應識別方法。首先，基于Hilbert信號空間理論對干擾信號進行處理，建立干擾信號特征空間，進而利用投影定理對未知干擾進行最佳逼近，提出基于信號特征空間的概率神經網絡(PNN)分類算法，并設計了未知干擾分類識別器的處理流程。仿真結果表明，與兩種傳統方法相比，該方法在已知干擾的分類精度方面分別提高了12.2%和2.8%；滿足條件的未知干擾最佳逼近效果隨功率強度呈線性變化，設計的分類識別器在滿足最佳逼近的各類干擾中總體識別率達到91.27%，處理干擾識別的速度明顯改善；在信噪比達到4 dB時，對未知干擾識別準確率達到92%以上。
- 無人機通信 /
- 未知干擾 /
- 自適應識別 /
- Hilbert信號空間 /
- 概率神經網絡
Abstract: In order to solve the problem of classification and recognition of unknown interference types under large samples, an adaptive recognition method for unknown interference based on signal feature space is proposed. Firstly, the interference signal is processed and the interference signal feature space is established with the Hilbert signal space theory. Then the projection theorem is used to approximate the unknown interference. The classification algorithm based on signal feature space with Probabilistic Neural Network (PNN) is proposed, and the processing flow of unknown interference classifier is designed. The simulation results show that compared with two kinds of traditional methods, the proposed method improves the classification accuracy of the known interference by 12.2% and 2.8% respectively. The optimal approximation effect of the unknown interference varies linearly with the power intensity in the condition, and the overall recognition rate of the designed classifier reaches 91.27% in the various types of interference satisfying the optimal approximation, and the speed of processing interference recognition is improved significantly. When the signal-to-noise ratio reaches 4 dB, the accuracy of unknown interference recognition is more than 92%.
- Unmanned aerial vehicle communications /
- Unknown interference /
- Adaptive recognition /
- Hilbert signal space /
- Probabilistic Neural Network (PNN)

HTML全文

圖 1 基于信號特征空間的概率神經網絡結構圖

下載: 全尺寸圖片幻燈片

圖 2 干擾分類處理流程圖

下載: 全尺寸圖片幻燈片

圖 3 不同干擾功率下最佳逼近均方根誤差圖

下載: 全尺寸圖片幻燈片

圖 4 不同信噪比下本文多分類算法識別率

下載: 全尺寸圖片幻燈片

表 1 干擾信號參數

干擾類型	干擾參數	數值
單音干擾	干擾頻點(MHz)	150
多音干擾	干擾頻點(MHz)	50, 100, ···, 250
部分頻帶干擾	覆蓋帶寬(MHz)	250～400
脈沖干擾	占空比(%)	10
線性調頻干擾 (單分量)	初始頻率(MHz)	150
線性調頻干擾 (單分量)	調頻率	500
梳狀譜干擾	分量數目	3
梳狀譜干擾	帶寬(MHz)	800

下載: 導出CSV

表 2 干擾分類算法識別率比較

信號空間數據集	識別率(%)
信號空間數據集	單音干擾	多音干擾	部分頻帶	線性調頻	脈沖干擾	梳狀譜	總體識別率
傳統SVM分類器	85.0	98.7	100	82.5	90	81.2	86.3
文獻[12]	100	98.7	100	98.7	100	98.7	95.7
本文算法	100	100	100	91.0	100	100	98.5

下載: 導出CSV

表 3 多分類算法性能比較(%)

干擾空間數據集	分類識別率		訓練識別率		測試識別率
干擾空間數據集	本文算法	傳統算法	本文算法	傳統算法	本文算法	傳統算法
單音干擾	92.41	47.55	92.59	50.85	91.27	46.24
多音干擾	98.73	45.37
部分頻帶	81.01	45.99
線性調頻	100	45.37
脈沖干擾	74.36	45.86
梳狀譜	98.72	46.94
未知干擾	93.59	46.62

下載: 導出CSV
