高精度光纖時間頻率一體化傳遞

楊文哲; 楊宏雷; 王學運; 張升康; 趙環; 楊軍; 馮克明

doi:10.11999/JEIT180807

高精度光纖時間頻率一體化傳遞

doi: 10.11999/JEIT180807

楊文哲^{1, 2, 3},
楊宏雷^{1, 2, 3},
王學運^{1, 2, 3},
張升康^{1, 2, 3, ,},
趙環^{1, 2, 3},
楊軍^{1, 2, 3},
馮克明³

1.
北京無線電計量測試研究所 ??北京 ??100854
2.
計量與校準技術國家重點實驗室 ??北京 ??100854
3.
中國航天科工集團第二研究院 ??北京 ??100854

詳細信息

作者簡介:
楊文哲：男，1991年生，博士生，研究方向?yàn)闀r(shí)間同步與校準技術等

楊宏雷：男，1990年生，工程師，研究方向?yàn)楣忸l梳及其精密測量應用等

王學運：男，1982年生，高級工程師，研究方向?yàn)闀r(shí)間同步與校準技術等

張升康：男，1980年生，研究員，研究方向?yàn)闀r(shí)間同步與校準技術等

趙環：女，1980年生，高級工程師，研究方向?yàn)楣鈱W(xué)等

楊軍：男，1970年生，研究員，研究方向?yàn)槭貢r(shí)與時間同步技術等

馮克明：男，1966年生，研究員，研究方向?yàn)樾盘?hào)與系統等

通訊作者:
張升康　Shengkang.zhang@hotmail.com

中圖分類號: TN929.11
計量
- 文章訪問數: 3653
- HTML全文瀏覽量: 1543
- PDF下載量: 161
- 被引次數: 0
出版歷程
- 收稿日期: 2018-08-17
- 修回日期: 2019-01-28
- 網絡出版日期: 2019-02-16
- 刊出日期: 2019-07-01

High Precision Time and Frequency Integration Transfer via Optical Fiber

Wenzhe YANG^{1, 2, 3},
Honglei YANG^{1, 2, 3},
Xueyun WANG^{1, 2, 3},
Shengkang ZHANG^{1, 2, 3
, ,},
Huan ZHAO^{1, 2, 3},
Jun YANG^{1, 2, 3},
Keming FENG³

1.
Beijing Institute of Radio Metrology and Measurement, Beijing 100854, China
2.
Science and Technology on Metrology and Calibration Laboratory, Beijing 100854, China
3.
The Second Academy of China Aerospace, Beijing 100854, China

摘要

摘要: 為滿足各工程應用領域?qū)τ诟呔葧r(shí)間頻率同步的需求，降低系統復雜度，保障大規模光纖時頻傳遞網絡的順利建設，該文提出基于偽碼調制技術的光纖時間頻率一體化傳遞方法，設計并搭建了光纖時間頻率一體化傳遞系統，完成了光纖單向和雙向時頻一體化傳遞。在單向時頻傳遞試驗中，分析了溫度變化對于系統傳輸時延的影響；在雙向時頻傳遞試驗中，實現了時間頻率的高精度傳遞，系統附加時間傳遞抖動為0.28 ps/s, 0.82 ps/1000 s，附加頻率傳遞不穩定度為4.94×10^–13/s, 6.39×10^–17/40000 s。試驗結果表明，該方法實現了時間、頻率一體化高精度同步，且系統附加時間傳遞抖動優于目前各光纖時間同步方案。
- 光纖 /
- 時間傳遞 /
- 頻率傳遞 /
- 偽碼調制
Abstract: To satisfy the demand of the high precision time and frequency synchronization for engineering application, to reduce system complexity and ensure the construction of large-scale optical fiber network for time and frequency transmission, a method of high precision time and frequency integration transfer via optical fiber based on pseudo-code modulation is developed. The optical fiber time and frequency transfer system is designed and built. The unidirectional and bidirectional time and frequency transfer test via optical fiber are completed. In the unidirectional time-frequency transfer test, the influence of temperature change on the transmission delay of the system is analyzed. In the bidirectional time-frequency transfer test, the system additional time transfer jitter is 0.28 ps/s, 0.82 ps/1000 s, the additional frequency transfer instability is 4.94×10^–13/s, and 6.39×10^–17/40000 s. The results show that the proposed method achieves high precision time and frequency integration synchronization, and the system additional time transfer jitter is better than the current optical fiber time synchronization schemes.
- Optical fiber /
- Time transfer /
- Frequency transfer /
- Pseudo-code modulation

HTML全文

圖 1 光纖單向時間頻率一體化傳遞原理圖

下載: 全尺寸圖片幻燈片

圖 2 光纖單向時間頻率一體化傳遞系統裝置圖

下載: 全尺寸圖片幻燈片

圖 3 時延測量結果與溫度變化曲線

下載: 全尺寸圖片幻燈片

圖 4 單向傳遞系統頻率傳遞穩定度曲線

下載: 全尺寸圖片幻燈片

圖 5 光纖雙向時間頻率一體化同步原理圖

下載: 全尺寸圖片幻燈片

圖 6 光纖雙向時間頻率一體化同步試驗系統裝置圖

下載: 全尺寸圖片幻燈片

圖 7 光纖雙向時間同步結果

下載: 全尺寸圖片幻燈片

圖 8 光纖雙向時間傳遞穩定度結果

下載: 全尺寸圖片幻燈片

圖 9 光纖雙向頻率傳遞穩定度結果

下載: 全尺寸圖片幻燈片

表 1 光纖雙向傳遞實驗結果與國際頂尖實驗結果比對

方案	年份	傳輸距離	時間同步穩定度結果		頻率傳遞穩定度結果
方案	年份	傳輸距離	秒穩定度(ps/s)	長期穩定度	秒穩定度(/s)	長期穩定度
文獻[23]	2014	300	40	11 ps/86400 s	—	—
文獻[20]	2015	120	30	0.7 ps/1000 s	—	—
文獻[24]	2015	短光纖(米級)	0.3	20 fs/10000 s	—	—
文獻[16]	2010	204	—	—	6×10^–14	5×10^–17/10⁵ s
文獻[18]	2012	80	—	—	7×10^–15	5×10^–19/86400 s
本文	2018	100	0.28	1.19 ps/10000 s	4.94×10^–13	6.39×10^–17/40000 s

下載: 導出CSV

參考文獻(24)

HE Wei, LIAN Baowang, and YANG Qiong. Time synchronization system design and research in GPS/INS Integrated Navigation System on complex dynamic situation[C]. Proceedings of 2013 IEEE International Conference of IEEE Region 10 (TENCON 2013), Xi’an, China, 2013: 1–5.

曾濤, 殷丕磊, 楊小鵬, 等. 分布式全相參雷達系統時間與相位同步方案研究[J]. 雷達學報, 2013, 2(1): 105–110. doi: 10.3724/SP.J.1300.2013.20104

ZENG Tao, YIN Pilei, YANG Xiaopeng, et al. Time and phase synchronization for distributed aperture coherent radar[J]. Journal of Radars, 2013, 2(1): 105–110. doi: 10.3724/SP.J.1300.2013.20104

方立軍, 馬駿, 柳勇, 等. 一種大型分布式陣列雷達頻率與相位同步[J]. 雷達科學與技術, 2017, 15(1): 85–88. doi: 10.3969/j.issn.1672-2337.2017.01.015

FANG Lijun, MA Jun, LIU Yong, et al. Frequency and phase coherence in large distributed digital array radar[J]. Radar Science and Technology, 2017, 15(1): 85–88. doi: 10.3969/j.issn.1672-2337.2017.01.015

SCHILLER S, TINO G M, GILL P, et al. Einstein gravity explorer-a medium-class fundamental physics mission[J]. Experimental Astronomy, 2009, 23(2): 573–610. doi: 10.1007/s10686-008-9126-5

BONDARESCU R, BONDARESCU M, HETéNYI G, et al. Geophysical applicability of atomic clocks: Direct continental geoid mapping[J]. Geophysical Journal International, 2012, 191(1): 78–82. doi: 10.1111/j.1365-246X.2012.05636.x

CALHOUN M, HUANG S, and TJOELKER R L. Stable photonic links for frequency and time transfer in the deep-space network and antenna arrays[J]. Proceedings of the IEEE, 2007, 95(10): 1931–1946. doi: 10.1109/JPROC.2007.905048

LEWANDOWSKI W, AZOUBIB J, and KLEPCZYNSKI W J. GPS: Primary tool for time transfer[J]. Proceedings of the IEEE, 1999, 87(1): 163–172. doi: 10.1109/5.736348

GUANG Wei, DONG Shaowu, WU Wenjun, et al. Progress of BeiDou time transfer at NTSC[J]. Metrologia, 2018, 55(2): 175–187. doi: 10.1088/1681-7575/aaa673

王學運, 趙博, 張升康, 等. 衛星雙向時間頻率傳遞調制解調器研制進展[J]. 宇航計測技術, 2014, 34(5): 23–26. doi: 10.3969/j.issn.1000-7202.2014.05.006

WANG Xueyun, ZHAO Bo, ZHANG Shengkang, et al. The progress of BIRMM two-way satellite time and frequency transfer modem[J]. Journal of Astronautic Metrology and Measurement, 2014, 34(5): 23–26. doi: 10.3969/j.issn.1000-7202.2014.05.006

王學運, 王海峰, 張升康, 等. 全新衛星雙向時間比對調制解調器設計[J]. 電子學報, 2017, 45(10): 2555–2560. doi: 10.3969/j.issn.0372-2112.2017.10.034

WANG Xueyun, WANG Haifeng, ZHANG Shengkang, et al. Design of a new two-way satellite time and frequency transfer modem[J]. Acta Electronica Sinica, 2017, 45(10): 2555–2560. doi: 10.3969/j.issn.0372-2112.2017.10.034

DROSTE S, UDEM T, H?NSCH T W, et al. Optical frequency transfer over a single-span 1840-km fiber link[C]. Proceedings of the 2013 Joint European Frequency and Time Forum & International Frequency Control Symposium (EFTF/IFC), Prague, Czech Republic, 2013: 1004–1006. doi: 10.1109/EFTF-IFC.2013.6702150.

劉濤, 劉杰, 鄧雪, 等. 光纖時間頻率信號傳遞研究[J]. 時間頻率學報, 2016, 39(3): 207–215. doi: 10.13875/j.issn.1674-0637.2016-03-0207-09

LIU Tao, LIU Jie, DENG Xue, et al. Research on fiber-based time and frequency transfer[J]. Journal of Time and Frequency, 2016, 39(3): 207–215. doi: 10.13875/j.issn.1674-0637.2016-03-0207-09

MARRA G, SLAVIK R, MARGOLIS H S, et al. High-resolution microwave frequency transfer over an 86-km-long optical fiber network using a mode-locked laser[J]. Optics Letters, 2011, 36(4): 511–513. doi: 10.1364/OL.36.000511

LESSING M, MARGOLIS H S, BROWN C T A, et al. Frequency comb-based time transfer over a 159 km long installed fiber network[J]. Applied Physics Letters, 2017, 110(22): 221101. doi: 10.1063/1.4984144

KIM J, CHEN J, ZHANG Zhigang, et al. Long-term femtosecond timing link stabilization using a single-crystal balanced cross correlator[J]. Optics Letters, 2007, 32(9): 1044–1046. doi: 10.1364/OL.32.001044

FUJIEDA M, KUMAGAI M, and NAGANO S. Coherent microwave transfer over a 204-km telecom fiber link by a cascaded system[J]. IEEE Transactions on Ultrasonics, Ferroelectrics, and Frequency Control, 2010, 57(1): 168–174. doi: 10.1109/TUFFC.2010.1394

LOPEZ O, KANJ A, POTTIE P E, et al. Simultaneous remote transfer of accurate timing and optical frequency over a public fiber network[J]. Applied Physics B, 2013, 110(1): 3–6. doi: 10.1007/s00340-012-5241-0

WANG Bo, GAO Cao, CHEN Weiliang, et al. Precise and continuous time and frequency synchronisation at the 5×10^-19 accuracy level[J]. Scientific Reports, 2012, 2: 556. doi: 10.1038/srep00556

劉琴, 韓圣龍, 王家亮, 等. 采用級聯方式實現430 km高精度頻率傳遞[J]. 中國激光, 2016, 43(9): 0906001. doi: 10.3788/CJL201643.0906001

LIU Qin, HAN Shenglong, WANG Jialiang, et al. High precise frequency transfer over a 430 km fiber backbone network using cascaded system[J]. Chinese Journal of Lasers, 2016, 43(9): 0906001. doi: 10.3788/CJL201643.0906001

CHEN Xing, LU Jinlong, CUI Yifan, et al. Simultaneously precise frequency transfer and time synchronization using feed-forward compensation technique via 120 km fiber link[J]. Scientific Reports, 2015, 5: 18343. doi: 10.1038/srep18343

BAI Yu, WANG Bo, GAO Cao, et al. Fiber-based multiple-access ultrastable radio and optical frequency dissemination[C]. Proceedings of the 2013 Joint European Frequency and Time Forum & International Frequency Control Symposium (EFTF/IFC), Prague, Czech Republic, 2013: 1014–1017. doi: 10.1109/EFTF-IFC.2013.6702187.

SLAVIK R, MARRA G, FOKOUA E N, et al. Ultralow thermal sensitivity of phase and propagation delay in hollow core optical fibres[J]. Scientific Reports, 2015, 5: 15447. doi: 10.1038/srep15447

HU Liang, WU Guiling, ZHANG Hao, et al. A 300-kilometer optical fiber time transfer using bidirectional TDM dissemination[C]. Proceedings of the 46th Annual Precise Time and Time Interval Systems and Applications Meeting, Boston, USA, 2014: 41–44.

KODET J, PáNEK P, and PROCHáZKA I. Two-way time transfer via optical fiber providing subpicosecond precision and high temperature stability[J]. Metrologia, 2016, 53(1): 18–26. doi: 10.1088/0026-1394/53/1/18
