一種低延遲的3維高效視頻編碼中深度建模模式編碼器

王莉; 曹一凡; 杜高明; 劉冠宇; 王曉蕾; 張多利

doi:10.11999/JEIT180798

一種低延遲的3維高效視頻編碼中深度建模模式編碼器

doi: 10.11999/JEIT180798

合肥工業大學電子科學與應用物理學院?合肥?230009

基金項目: 國家自然科學基金(61474036)，教育部IC設計網上合作研究中心項目(JSGG20170413153845042)

詳細信息

作者簡介:
王莉：女，1977年生，副教授，博士，研究方向?yàn)榧{米材料和半導體器件

曹一凡：男，1994年生，碩士生，研究方向?yàn)橐曨l編解碼的數字集成電路設計

杜高明：男，1977年生，副研究員，博士，研究方向?yàn)槎嗪思呻娐敷w系結構、2維/3維片上網絡集成體系結構

劉冠宇：男，1995年生，碩士生，研究方向?yàn)閿?shù)字集成電路設計

王曉蕾：女，1978年生，副研究員，碩士，研究方向?yàn)榧呻娐吩O(shè)計

張多利：男，1976年生，研究員，博士，研究方向?yàn)槎嗪颂幚砥黧w系架構和設計方法

通訊作者:
杜高明　dugaoming@hfut.edu.cn

中圖分類號: TN47; TN919.81
計量
- 文章訪問數: 1616
- HTML全文瀏覽量: 756
- PDF下載量: 59
- 被引次數: 0
出版歷程
- 收稿日期: 2018-08-16
- 修回日期: 2019-02-27
- 網絡出版日期: 2019-03-18
- 刊出日期: 2019-07-01

A Low-latency Depth Modelling Mode-1 Encoder in 3D-high Efficiency Video Coding Standard

School of Electronic Science & Applied Physics, Hefei University of Technology, Hefei 230009, China

Funds: The National Natural Science Foundation of China(61474036), The Project of IC Design Web-cooperation Research Center of MOE(JSGG20170413153845042)

摘要

摘要: 為了更好地對3D視頻中深度圖進行編碼，該文將3維高效視頻編碼(3D-HEVC)標準新引入了深度建模模式(DMMs)，新模式在提高了編碼質量的同時改進了原有算法的復雜度。在設計DMM-1編碼器電路時，傳統架構電路的編碼周期均較長，只能滿足較低分辨率和幀率的視頻實時編碼要求。為了進一步提高3D-HEVC中DMM-1編碼器的性能，該文對DMM-1算法架構進行了研究，針對其中楔形塊評估無數據相關性的特點，提出了一種5級流水線架構的DMM-1編碼器硬件電路，以期能夠降低一個深度塊編碼所需的編碼周期，并使用Verilog HDL進行實現。實驗表明：該架構與Sanchez等人(2017年)的工作相比，以電路門數增加約1568門為代價，可減少至少52.3%的編碼周期。
- 3維高效視頻編碼 /
- 深度圖 /
- 幀內預測 /
- 深度建模模式算法 /
- Verilog
Abstract: In order to encode better the depth maps in 3D video, the 3D-High Efficiency Video Coding (3D-HEVC) standard is introduced in Depth Modeling Modes(DMMs), which increase the quality of original algorithm while improving the encoding complexity. The traditional architecture of DMM-1 encoder circuit has a longer coding period and can only meet real-time coding requirements of lower resolution and frame rate. In order to improve the performance of DMM-1 encoder, the structure of DMM-1 algorithm is researched and a five-stage pipeline architecture of DMM-1 encoder is proposed. The pipeline architecture can reduce the coding cycles. The architecture is implemented by Verilog HDL. Experiments show that this architecture can reduce the coding cycle by at least 52.3%, at the cost of 1568 gates compared to previous work by Sanchez G. et al. (2017).
- 3D-High Efficiency Video Coding (3D-HEVC) /
- Depth map /
- Intra prediction /
- Depth Modelling Mode (DMM) algorithm /
- Verilog

HTML全文

圖 1 3D-HEVC編解碼流程圖

下載: 全尺寸圖片幻燈片

圖 2 紋理圖和深度圖示意圖

下載: 全尺寸圖片幻燈片

圖 3 深度圖幀內預測流程圖

下載: 全尺寸圖片幻燈片

圖 4 DMM-1和DMM-4示意圖

下載: 全尺寸圖片幻燈片

圖 5 DMM-1算法流程圖

下載: 全尺寸圖片幻燈片

圖 6 DMM-1算法計算實例圖

下載: 全尺寸圖片幻燈片

圖 7 流水線架構電路時序圖

下載: 全尺寸圖片幻燈片

圖 8 楔形塊數據庫存儲模塊結構圖

下載: 全尺寸圖片幻燈片

圖 9 搜索模塊結構圖

下載: 全尺寸圖片幻燈片

圖 10 4組測試激勵及預測結果示意圖

下載: 全尺寸圖片幻燈片

圖 11 楔形塊編碼周期對比示意圖

下載: 全尺寸圖片幻燈片

圖 12 楔形塊編碼時間對比示意圖

下載: 全尺寸圖片幻燈片

表 1 深度圖幀內預測模式序號和名稱

模式序號	模式名稱
0	Planar
1	DC
2～34	Directional
35	DMM-1
36	DMM-4

下載: 導出CSV

表 2 流水線架構性能和對比

工作	塊尺寸	工藝	門數	頻率(MHz)	周期/塊	時間/塊
本文	4×4	Nangate 45	4859	350.0	63	179.5
文獻[15]	4×4	ST 65	4070	515.5	134	259.9
文獻[16]	4×4	ST 65	3291	514.3	132	256.7

下載: 導出CSV

參考文獻(16)

LEE J Y, WEY H C, and PARK D S. A fast and efficient Multi-View depth image coding method based on temporal and Inter-View correlations of texture images[J]. IEEE Transactions on Circuits and Systems for Video Technology, 2011, 21(12): 1859–1868. doi: 10.1109/TCSVT.2011.2154730

SHEN Liquan, ZHANG Zhaoyang, and LIU Zhi. Inter mode selection for depth map coding in 3D video[J]. IEEE Transactions on Consumer Electronics, 2012, 58(3): 926–931. doi: 10.1109/TCE.2012.6311338

CERNIGLIARO G, JAUREGUIZAR F, CABRERA J, et al. Low complexity mode decision and motion estimation for H.264/AVC based depth maps encoding in free viewpoint video[J]. IEEE Transactions on Circuits and Systems for Video Technology, 2013, 23(5): 769–783. doi: 10.1109/TCSVT.2012.2223632

MüLLER K, MERKLE P, TECH G, et al. 3D video coding with depth modeling modes and view synthesis optimization[C]. Proceedings of 2012 Asia Pacific Signal and Information Processing Association Annual Summit and Conference, Hollywood, USA, 2012: 1–4.

ZHANG Qiuwen, LI Nana, HUANG Lixun, et al. Effective early termination algorithm for depth map intra coding in 3D-HEVC[J]. Electronics Letters, 2014, 50(14): 994–996. doi: 10.1049/el.2014.0065.

GU Zhouye, ZHENG Jianhua, LING N, et al. Fast depth modeling mode selection for 3D HEVC depth intra coding[C]. Proceedings of 2013 IEEE International Conference on Multimedia and Expo Workshops, San Jose, USA, 2013: 1–4.

GU Zhouye, ZHENG Jianhua, LING N, et al. " 3D-CE5.h related: Fast intra prediction mode selection for intra depth map coding[C]. Proceedings of the 5th Meeting of Joint Collaborative Team on 3D Video Coding Extension Development (JCT-3V) of ITU-T SG 16 WP 3 and ISO/IEC JTC 1/SC 29/WG 11, Vienna, Austria, 2013: 3–5.

GUO Ruixue, HE Gang, LI Yunsong, et al. Fast algorithm for prediction unit and mode decisions of intra depth coding in 3D-HEVC[C]. Proceedings of 2016 IEEE International Conference on Image Processing, Phoenix, Arizona, USA, 2016: 1121–1125.

LI Kun. The research of intra mode coding for the depth maps[D]. [Master dissertation], Shenzhen University, 2016: 24–49.

粘春湄, 陳婧, 曾煥強. 紋理類型預判和SDC優化的3D-HEVC深度圖幀內算法[J]. 計算機科學與探索, 2018, 12(6): 994–1003. doi: 10.3778/j.issn.1673-9418.1711040

NIAN Chunmei, CHEN Jing, and ZENG Huanqiang. Depth map intra algorithm for 3D-HEVC by prejudging texture type and SDC optimization[J]. Journal of Frontiers of Computer Science and Technology, 2018, 12(6): 994–1003. doi: 10.3778/j.issn.1673-9418.1711040

SANCHEZ G, SALDANHA M, BALOTA G, et al. Complexity reduction for 3D-HEVC depth maps intra-frame prediction using simplified edge detector algorithm[C]. Proceedings of 2014 IEEE International Conference on Image Processing, Paris, France, 2014: 3209–3213.

SANCHEZ G, SALDANHA M, BALOTA G, et al. A complexity reduction algorithm for depth maps intra prediction on the 3D-HEVC[C]. Proceedings of 2014 IEEE Visual Communications and Image Processing Conference, Valletta, Malta, 2014: 134–140.

SANCHEZ G, SALDANHA M, ZATT B, et al. S-GMOF: A gradient-based complexity reduction algorithm for depth-maps intra prediction on 3D-HEVC[C]. Proceedings of the 6th Latin American Symposium on Circuits & Systems, Montevideo, Uruguay, 2015: 1–4.

SALDANHA M, ZATT B, PORTO M, et al. Solutions for DMM-1 complexity reduction in 3D-HEVC based on gradient calculation[C]. Proceedings of the 7th Latin American Symposium on Circuits & Systems, Florianopolis, Brazil, 2016: 211–214.

SANCHEZ G, MARCON C, and AGOSTINI L. Real-time scalable hardware architecture for 3D-HEVC bipartition modes[J]. Journal of Real-time Image Processing, 2017, 13(1): 71–83. doi: 10.1007/s11554-016-0609-8

SANCHEZ G, AGOSTINI L, MóR F, et al. Low-area scalable hardware architecture for DMM-1 encoder of 3D-HEVC video coding standard[C]. Proceedings of the 30th Symposium on Integrated Circuits and Systems Design, Fortaleza, Brazil, 2017: 36–40.
