Controlled Physical Unclonable Function Research Based on Sensitivity Confusion Mechanism
-
The Information Engineering University, Zhengzhou 450001, China
-
摘要: 為了克服物理不可克隆函數(PUF)面對建模攻擊的脆弱性，該文提出一種基于敏感度混淆機制的控制型PUF架構。根據PUF的布爾函數定義及Walsh譜理論，推導出各個激勵位具有不同敏感度，分析并歸納了與混淆值位寬奇偶性有關的位置選取規則。利用該規則指導了多位寬混淆算法(MWCA)的設計，構建了具有高安全性的控制型PUF架構。將基礎PUF結構作為控制型PUF的防護對象進行實驗評估，發現基于敏感度混淆機制的控制型PUF所產生的響應具有較好的隨機性。采用邏輯回歸算法對不同PUF結構進行建模攻擊，實驗結果表明，相比基本ROPUF、仲裁器PUF以及基于隨機混淆機制的OB-PUF，基于敏感度混淆機制的控制型PUF能夠顯著提高PUF的抗建模攻擊能力。
-
關鍵詞:
- 信息安全 /
- 機器學習 /
- 布爾函數 /
- 敏感度
Abstract: In order to overcome the vulnerability of Physical Unclonable Function (PUF) to modeling attacks, a controlled PUF architecture based on sensitivity confusion mechanism is proposed. According to the Boolean function definition of PUF and Walsh spectrum theory, it is derived that each excitation bit has different sensitivity, and the position selection rules related to the parity of the confound value bit width are analyzed and summarized. This rule guides the design of the Multi-bit Wide Confusion Algorithm (MWCA) and constructs a controlled PUF architecture with high security. The basic PUF structure is evaluated as a protective object of the controlled PUF. It is found that the response generated by the controlled PUF based on the sensitivity confusion mechanism has better randomness. Logistic regression algorithm is used to model different PUF attack. The experimental results show that compared with the basic ROPUF, the arbiter PUF and the OB-PUF based on the random confusion mechanism, the controlled PUF based on the sensitivity confusion mechanism can significantly improve the PUF resistance capabilities for modeling attack.-
Key words:
- Information security /
- Machine learning /
- Boolean function /
- Sensitivity information
-
圖 3
${N_{{\rm{OB}}}} = {\rm{2}}$ 時概率期望${E_{\Pr }}\left( {\rm{{Aa,Ta,Sa}}} \right)$ 的分布圖
圖 4
${N_{{\rm{OB}}}} = {\rm{3}}$ 時概率期望${E_{\Pr }}\left( {\rm{{Aa,Ta,Sa}}} \right)$ 的分布圖表 1
${N_{{\rm{OB}}}} = {\rm{1}},2,{\rm{3}},{\rm{4}}$ 時混淆值位置選擇所有組合情況NOB (Aa,Ta,Sa) 1 (1,0,0);(0,1,0);(0,0,1) 2 (1,1,0);(1,0,1);(0,1,1);(2,0,0);(0,2,0);(0,0,2) 3 (1,1,1);(2,1,0);(2,0,1);(1,2,0);(0,2,1);(1,0,2);(0,1,2);
(3,0,0);(0,3,0);(0,0,3)4 (2,1,1);(1,2,1);(1,1,2);(2,2,0);(2,0,2);(0,2,2);(3,1,0);(3,0,1);
(1,3,0);(0,3,1);(1,0,3);(0,1,3);(4,0,0);(0,4,0);(0,0,4)
下載: 導出CSV
表 2 MWCA的具體算法
輸入：混淆激勵集合${C_{\rm OB}} = \left\{ {c_{\rm OB}^k|k \in \left\{ {1,2, ·\!·\!· ,\sum\nolimits_{i = 1}^t {{2^{N - i}}} } \right\}} \right\}; $ 混淆值集合$Y = \left\{ {{y_k}|k \in \left\{ {1,2, ·\!·\!· ,\sum\nolimits_{i = 1}^t {{2^{N - i}}} } \right\}} \right\} $ 過程： $(1)\;{\rm for}\;\forall k \in \left\{ {1,2, ·\!·\!· ,\sum\nolimits_{i = 1}^t {{2^{N - i}}} } \right\}{\rm do} $ $(2)\;{\text{輸入混淆激勵集合}}c_{\rm OB}^k = \left\{ {{c_1},{c_2}, ·\!·\!· ,{c_t}} \right\}\text{、}\ {\text{混淆值}}{y_k}{\text{和標識值}}{a_k} ; $ $(3)\;{\rm if}\;{a_k} = 1\;{\rm then} $ $(4)\;{\text{調用位置選擇策略}}{P_k} ;{\text{產生完整激勵}}{C_k}{\rm{ = }}{P_k}(c_{{\rm{OB}}}^k,{y_k}) ;{\rm return} $ $(5)\;{\rm else} $ $(6)\;{\text{計算}}{{ r = ({N} - t) }}\% 2 ; $ $(7)\;\rm end\;if$ $(8)\;{\rm if}\;r = 0\;{\rm then}$ $(9)\;{\text{調用偶數規則}}{\rm{Rule}}\_{\rm E},{\text{生成位置選擇策略}}{P_k},{a_k} = 1;$ $(10)\;\rm else $ $(11)\;{\text{調用奇數規則}}{\rm{Rule}}\_{\rm O},{\text{生成位置選擇策略}}{P_k},{a_k} = 1;$ $(12)\;\rm end\;if $ $(13)\;{\text{存儲標識值}}{a_k}{\text{和策略}}{P_k} ,{\text{用于之后激勵混淆步驟的判斷依據}} ;$ (14) 按照策略將混淆值插入混淆激勵$c_{{\rm{OB}}}^k,$產生完整激勵 ${C_k}{\rm{ = }}{P_k}(c_{{\rm{OB}}}^k,{y_k}) ;\rm return$ $ (15) \;\rm end\;for$ 輸出：完整激勵集合${C_f} = {\rm{\{ }}{C_k}|k \in {\rm{\{ }}1,2, ·\!·\!· ,\sum\nolimits_{i = 1}^t {{2^{N - i}}} {\rm{\} \} }}。$
下載: 導出CSV
表 4 NIST隨機數測試結果
測試項目 基本ROPUF[10] 本文 P_value 結果 P_value 結果 頻率檢驗 0.000003 失敗 0.829896 通過 塊內頻數檢驗 0.050764 通過 0.580358 通過 向前累加和檢驗 0.000000 失敗 0.502594 通過 向后累加和檢驗 0.000000 失敗 0.347179 通過 游程檢驗 0.302788 通過 0.329404 通過 塊內最長游程檢驗 0.000062 失敗 0.024892 通過 近似熵檢驗 0.000001 失敗 0.693147 通過 向前序列檢驗 0.070160 通過 0.024892 通過 向后序列檢驗 0.192277 通過 0.756264 通過
下載: 導出CSV
表 5 不同PUF結構的攻擊結果對比
PUF類型 訓練集數量 攻擊時間 預測成功率(%) OB-PUF(1) 4400 26 87.6 OB-PUF(2) 5200 30 84.4 OB-PUF(3) 6000 62 73.1 OB-PUF(4) 8000 128 69.8 基本ROPUF 5200 8 99.5 控制型ROPUF 7200 262 53.4 仲裁器PUF 4800 15 93.9 控制型APUF 6500 187 67.2
下載: 導出CSV
-
RüHRMAIR U, S?LTER J, SEHNKE F, et al. PUF modeling attacks on simulated and silicon data[J]. IEEE Transactions on Information Forensics and Security, 2013, 8(11): 1876–1891. doi: 10.1109/TIFS.2013.2279798 GASSEND B, VAN DIJK M, CLARKE D, et al. Controlled physical random functions[J]. ACM Transactions on Information and System Security, 2008, 10(4): 23–25. KATZENBEISSER S, KO?ABAS ü, VAN DER LEEST V, et al. Recyclable PUFs: Logically Reconfigurable PUFs[M]. Berlin, Germamy: Springer, 2011: 374–389. LAO Yingjie and PARHI K K. Reconfigurable architectures for silicon physical unclonable functions[C]. Proceedings of 2011 IEEE International Conference on Electro/Information Technology, Mankato, USA, 2011: 1–7. MAJZOOBI M, KOUSHANFAR F, and POTKONJAK M. Techniques for design and implementation of secure reconfigurable PUFs[J]. ACM Transactions on Reconfigurable Technology and Systems, 2009, 2(1): 5. GAO Yansong, AL-SARAWI S F, ABBOTT D, et al. Modeling attack resilient reconfigurable latent obfuscation technique for PUF based lightweight authentication[J]. arXiv:1706.06232, 2017. 許道云, 韋立, 王曉峰. 布爾函數的學習與性質測試[J]. 武漢大學學報: 理學版, 2012, 58(2): 125–134.XU Daoyun, WEI Li, and WANG Xiaofeng. Learning and testing of properties for Boolean functions[J]. Journal of Wuhan University:Natural Science Edition, 2012, 58(2): 125–134. GANJI F, TAJIK S, F??LER F, et al. Strong machine learning attack against PUFs with no mathematical model[C]. Proceedings of the 18th International Conference on Cryptographic Hardware and Embedded Systems, Santa, USA, 2016: 391–411. ZALIVAKA S S, PUCHKOV A V, KLYBIK V P, et al. Multi-valued arbiters for quality enhancement of PUF responses on FPGA implementation[C]. Proceedings of 201621st Asia and South Pacific Design Automation Conference, Macau, China, 2016: 533–538. GASSEND B, CLARKE D, VAN DIJK M, et al. Silicon physical random functions[C]. Proceedings of the 9th ACM Conference on Computer and Communications Security, USA, 2002: 148–160. LAO Yingjie and PARHI K K. Statistical analysis of MUX-based physical unclonable functions[J]. IEEE Transactions on Computer-Aided Design of Integrated Circuits and Systems, 2014, 33(5): 649–662. doi: 10.1109/TCAD.2013.2296525 龐子涵, 周強, 高文超, 等. FPGA物理不可克隆函數及其實現技術[J]. 計算機輔助設計與圖形學學報, 2017, 29(9): 1590–1603. doi: 10.3969/j.issn.1003-9775.2017.09.002PANG Zihan, ZHOU Qiang, GAO Wenchao, et al. Hardware implementation of physical unclonable function on FPGAs[J]. Journal of Computer-Aided Design &Computer Graphics, 2017, 29(9): 1590–1603. doi: 10.3969/j.issn.1003-9775.2017.09.002 DENG R, WENG Jian, REN Kui, et al. Security and Privacy in Communication Networks[M]. Cham: Springer, 2016: 675–693. KODYTEK F and LóRENCZ R. Proposal and properties of ring oscillator-based PUF on FPGA[J]. Journal of Circuits, Systems and Computers, 2016, 25(3): 1640016. doi: 10.1142/S0218126616400168 KODYTEK F, LóRENCZ R, and BU?EK J. Improved ring oscillator PUF on FPGA and its properties[J]. Microprocessors and Microsystems, 2016, 47: 55–63. doi: 10.1016/j.micpro.2016.02.005 -
