改進多元宇宙算法求解大規模實值優化問題

劉小龍

doi:10.11999/JEIT180751

改進多元宇宙算法求解大規模實值優化問題

doi: 10.11999/JEIT180751

劉小龍^,

華南理工大學工商管理學院廣州 510641

基金項目: 國家自然科學基金(71471065, 71571072, 71771091)，廣州社科聯基金(2018GZGJ02)

詳細信息

作者簡介:
劉小龍：男，1977年生，講師，研究方向?yàn)榉律鷥?yōu)化與計算智能

通訊作者:
劉小龍　xlliu@scut.edu.cn

中圖分類號: TP301.6
計量
- 文章訪問數: 3201
- HTML全文瀏覽量: 1296
- PDF下載量: 118
- 被引次數: 0
出版歷程
- 收稿日期: 2018-07-22
- 修回日期: 2019-01-17
- 網絡出版日期: 2019-02-14
- 刊出日期: 2019-07-01

Application of Improved Multiverse Algorithm to Large Scale Optimization Problems

Xiaolong LIU^,

School of Business Administration, South China University of Technology, Guangzhou 510641, China

Funds: The National Natural Science Foundation of China (71471065, 71571072, 71771091), Guangzhou Social Science Federation Fund (2018GZGJ02)

摘要

摘要: 針對多元宇宙優化(MVO)算法中蟲洞存在機制、白洞選擇機制等不足，該文提出一種改進多元宇宙優化算法(IMVO)。設計固定概率的蟲洞存在機制和前期快速收斂后期平緩收斂的蟲洞旅行距離率，加快算法全局探索能力和快速迭代能力；提出黑洞的隨機白洞選擇機制，設計黑洞圍繞白洞恒星進行公轉并模型化，解決代間宇宙信息溝通的問題，中低維度數值比較實驗驗證了改進算法的優良性能。選取大規模實值問題較難優化的3個基準測試函數進行對比實驗，改進算法在大規模優化問題上的求解精度和成功率方面具有較好的適用性和魯棒性。
- 大規模優化問題 /
- 多元宇宙優化 /
- 元啟發式優化 /
- 非線性收斂因子
Abstract: To overcome the mechanism shortcomings of wormhole and white hole selection in the Multi-Verse Optimizer (MVO), an Improved Multi-Universes Optimization (IMVO) algorithm is proposed. To speed up global exploration ability and quick iteration ability, this thesis designs the existence mechanism of wormhole with fixed probability and the Travel Distance Rate (TDR) that its convergence from early stage's smoothly to later stage's fast. The random white hole selection mechanism is proposed; Black holes can revolve around selected white hole stars and is modelled to solve the problem of information communication of the Inter-generational Universes. The performance of IMVO is verified by comparison experiments in low-middle dimensions. Three benchmarks test functions are selected for comparison in large scale which are difficult to be optimized, the experimental results show that IMVO has good applicability and robustness with higher solving accuracy and success rate in large scale optimization problem.
- Large scale optimization problem /
- Multi-Verses Optimization (MVO) /
- Meta heuristic optimization /
- Non-linear convergence factor

HTML全文

圖 1 多元宇宙算法內部主循環結構

下載: 全尺寸圖片幻燈片

圖 2 黑洞圍繞白洞螺旋式公轉

下載: 全尺寸圖片幻燈片

表 1 文獻[10]的時間復雜度

操作	計算復雜度	循環次數
初始化	O(N)	1×D
計算宇宙膨脹率	O(N)	L×D
排序/標準化宇宙	O(N)	L×D
黑白洞換維度	O(K)	L×D
穿越選擇	O((1–K)WEP)	L×D
參數更新	O(1)	L

下載: 導出CSV

表 2 本文的時間復雜度

操作	計算復雜度	循環次數
初始化	O(N)	1×D
計算宇宙膨脹率	O(N)	L×D
黑白洞選擇	O(N)	L×D
策略1：穿越	O(N/2)	L×D
策略2：公轉	O(N/2)	L×D
參數更新	O(1)	L

下載: 導出CSV

表 3 單峰基準測試函數的50維對比實驗

	算法	均值	標準差	成功率(%)
f₁	文獻[10]	2.08583	0.648651	0
f₁	本文	4.64e-21	9.90e-21	100
f₂	文獻[10]	15.92479	44.7459	0
f₂	本文	4.04e-11	3.86e-11	100
f₅	文獻[10]	1272.13	1479.477	0
f₅	本文	6.70e-20	1.77e-19	100
f₇	文獻[10]	0.051991	0.029606	100
f₇	本文	3.08e-04	3.91e-04	100

下載: 導出CSV

表 4 多峰基準測試函數的50維對比實驗

	算法	均值	標準差	成功率(%)
f₉	文獻[10]	118.046	39.34364	0
f₉	本文	0	0	100
f₁₀	文獻[10]	4.074904	5.501546	0
f₁₀	本文	8.71e-12	5.66e-12	100
f₁₁	文獻[10]	0.938733	0.059535	100
f₁₁	本文	0	0	100
f₁₂	文獻[10]	2.459953	0.791886	0
f₁₂	本文	1.83e-23	3.51e-23	100

下載: 導出CSV

表 5 基準測試函數30維度的算法對比實驗

		f₁	f₂	f₅	f₇	f₉	f₁₀	f₁₁	f₁₂
文獻[6]	均值	6.54e-125	2.15e-73	27.27950	2.42e04	0	3.02e-15	0	0.087646
文獻[6]	標準差	6.80e-125	3.64e-73	0.215438	4.41e-04	0	1.95e-15	0	0.011997
本文	均值	5.24e-21	1.86e-11	2.46e-20	3.41e-04	0	5.51e-12	0	1.14e-23
本文	標準差	1.96e-20	1.37e-11	4.03e-20	3.23e-04	0	6.56e-12	0	1.90e-23

下載: 導出CSV

表 6 基準測試函數10維度的算法對比實驗

函數	算法	DA^[18]	CSA^[17]	MVO^[10]	IMVO^[11]	本文
f₁₀	均值	2.28	1.07	8.06e-02	4.27e-05	9.66e-12
	標準差	1.13	0.921	2.04e-01	2.22e-05	8.08e-12
	最差值	4.20	3.02	1.16	1.04e-04	7.76e-11
	最好值	4.44e-15	1.75e-03	1.17e-02	7.08e-06	3.67e-13
f₁₂	均值	9.78e-01	3.83e-01	1.07e-02	1.25e-10	4.32e-23
	標準差	8.58e-01	6.07e-01	5.70e-02	1.18e-10	1.06e-22
	最差值	3.49	3.20	3.12e-01	4.45e-10	4.71e-22
	最好值	4.84e-03	5.67e-05	9.21e-05	7.76e-12	9.15e-27

下載: 導出CSV

表 7 本文IMVO算法和文獻[6,10]中WOA, IWOA對較大規模單峰和多峰函數尋優對比

F	對比算法	D=200			D=500
F	對比算法	均值	標準差	成功率(%)	均值	標準差	成功率(%)
f₂	文獻[10]	7.50e-51	9.40e-51	100	1.10e-49	2.10e-49	100
	文獻[6]	1.60e-67	1.90e-67	100	5.30e-66	9.60e-66	100
	本文	1.59e-10	1.43e-10	100	2.56e-10	2.41e-10	100
f₅	文獻[10]	1.98e+02	2.22e-01	0	4.96e02	4.66e-01	0
	文獻[6]	1.98e+02	5.43e-02	0	4.96e02	3.78e-01	0
	本文	6.13e-20	1.29e-19	100	3.48e-19	4.15e-19	100
f₁₀	文獻[10]	5.15e-15	1.94e-15	100	5.86e-15	2.97e-15	100
	文獻[6]	8.88e-16	0	100	4.44e-15	0	100
	本文	7.16e-12	6.87e-12	100	6.49e-12	1.13e-11	100
f₁₂	文獻[10]	8.09e-02	4.05e-02	0	9.19e-02	5.92e-02	0
	文獻[6]	2.02e-02	2.75e-02	0	8.30e-02	3.17e-02	0
	本文	5.09e-24	8.06e-24	100	4.25e-24	9.01e-24	100

下載: 導出CSV

表 8 求解不同規模f₂和f₁₀函數的優化均值對比

維度D	f₂均值			f₁₀均值
維度D	文獻[10]	文獻[6]	本文	文獻[10]	文獻[6]	本文
30	1.00e-21	2.20e-73	1.86e-11	7.40	3.02e-15	5.51e-12
200	7.50e-51	1.60e-67	1.59e-10	5.15e-15	8.88e-16	7.16e-12
500	1.10e-49	5.30e-66	2.56e-10	5.86e-15	4.44e-15	6.49e-12

下載: 導出CSV

表 9 改進算法的大規模實值優化結果(閾值為1)

F	對比算法	D=1000			D=2000
F	對比算法	均值	標準差	成功率(%)	均值	標準差	成功率(%)
f₅	文獻[10]	8.70e+08	7.81e+07	0	7.11e+09	3.23e+08	0
f₅	本文	2.05e-19	3.42e-19	100	5.62e-19	1.37e-18	100
f₇	文獻[10]	1.08e+04	8.35e+02	0	1.81e+05	9.44e+03	0
f₇	本文	2.52e-04	3.99e-04	100	2.70e-04	3.87e-04	100
f₉	文獻[10]	1.37e+04	3.36e+02	0	3.04e+04	3.28e+02	0
f₉	本文	0	0	100	0	0	100

下載: 導出CSV

參考文獻(18)

MAHDAVI S, RAHNAMAYAN S, and SHIRI M E. Multilevel framework for large-scale global optimization[J]. Soft Computing, 2017, 21(14): 4111–4140. doi: 10.1007/s00500-016-2060-y

BOLUFé-R?HLER A, FIOL-GONZáLEZ S, and CHEN S. A minimum population search hybrid for large scale global optimization[C]. Proceedings of 2015 IEEE Congress on Evolutionary Computation, Sendai, Japan, 2015: 1958–1965. doi: 10.1109/CEC.2015.7257125.

梁靜, 劉睿, 于坤杰, 等. 求解大規模問題協同進化動態粒子群優化算法[J]. 軟件學報, 2018, 29(9): 2595–2605. doi: 10.13328/j.cnki.jos.005398

LIANG Jing, LIU Rui, YU Kunjie, et al. Dynamic multi-swarm particle swarm optimization with cooperative coevolution for large scale global optimization[J]. Journal of Software, 2018, 29(9): 2595–2605. doi: 10.13328/j.cnki.jos.005398

羅家祥, 倪曉曄, 胡躍明. 融合多種搜索策略的差分進化大規模優化算法[J]. 華南理工大學學報: 自然科學版, 2017, 45(3): 97–103. doi: 10.3969/j.issn.1000-565X.2017.03.014

LUO Jiaxiang, NI Xiaoye, and HU Yueming. A hybrid differential evolution algorithm with multiple search strategies for large-scale optimization[J]. Journal of South China University of Technology:Natural Science Edition, 2017, 45(3): 97–103. doi: 10.3969/j.issn.1000-565X.2017.03.014

MIRJALILI S and LEWIS A. The whale optimization algorithm[J]. Advances in Engineering Software, 2016, 95: 51–67. doi: 10.1016/j.advengsoft.2016.01.008

龍文, 蔡紹洪, 焦建軍, 等. 求解大規模優化問題的改進鯨魚優化算法[J]. 系統工程理論與實踐, 2017, 37(11): 2983–2994. doi: 10.12011/1000-6788(2017)11-2983-12

LONG Wen, CAI Shaohong, JIAO Jianjun, et al. Improved whale optimization algorithm for large scale optimization problems[J]. Systems Engineering-Theory &Practice, 2017, 37(11): 2983–2994. doi: 10.12011/1000-6788(2017)11-2983-12

MIRJALILI S, MIRJALILI S M, and LEWIS A. Grey wolf optimizer[J]. Advances in Engineering Software, 2014, 69: 46–61. doi: 10.1016/j.advengsoft.2013.12.007

姜天華. 混合灰狼優化算法求解柔性作業車間調度問題[J]. 控制與決策, 2018, 33(3): 503–508. doi: 10.13195/j.kzyjc.2017.0124

JIANG Tianhua. Flexible job shop scheduling problem with hybrid grey wolf optimization algorithm[J]. Control and Decision, 2018, 33(3): 503–508. doi: 10.13195/j.kzyjc.2017.0124

梁靜, 劉睿, 瞿博陽, 等. 進化算法在大規模優化問題中的應用綜述[J]. 鄭州大學學報: 工學版, 2018, 39(3): 15–21. doi: 10.13705/j.issn.1671-6833.2017.06.016

LIANG Jing, LIU Rui, QU Boyang, et al. A survey of evolutionary algorithms for large scale optimization problem[J]. Journal of Zhengzhou University:Engineering Science, 2018, 39(3): 15–21. doi: 10.13705/j.issn.1671-6833.2017.06.016

MIRJALILI S, MIRJALILI S M, and HATAMLOU A. Multi-verse optimizer: A nature-inspired algorithm for global optimization[J]. Neural Computing and Applications, 2016, 27(2): 495–513. doi: 10.1007/s00521-015-1870-7

趙世杰, 高雷阜, 徒君, 等. 耦合橫縱向個體更新策略的改進MVO算法[J]. 控制與決策, 2018, 33(8): 1422–1428. doi: 10.13195/j.kzyjc.2017.0441

ZHAO Shijie, GAO Leifu, TU Jun, et al. Improved multi verse optimizer coupling horizontal-and-vertical individual updated strategies[J]. Control and Decision, 2018, 33(8): 1422–1428. doi: 10.13195/j.kzyjc.2017.0441

CHOPRA N and SHARMA J. Multi-objective optimum load dispatch using Multi-verse optimization[C]. Proceedings of the 2016 IEEE 1st International Conference on Power Electronics, Intelligent Control and Energy Systems, Delhi, India, 2016: 1–5.

HU Cong, LI Zhi, ZHOU Tian, et al. A multi-verse optimizer with levy flights for numerical optimization and its application in test scheduling for network-on-chip[J]. PLOS One, 2016, 11(12): e0167341. doi: 10.1371/journal.pone.0167341

FARIS H, ALJARAH I, and MIRJALILI S. Training feedforward neural networks using multi-verse optimizer for binary classification problems[J]. Applied Intelligence, 2016, 45(2): 322–332. doi: 10.1007/s10489-016-0767-1

JANGIR P, PARMAR S A, TRIVEDI I N, et al. A novel hybrid particle swarm optimizer with multi verse optimizer for global numerical optimization and optimal reactive power dispatch problem[J]. Engineering Science and Technology, An International Journal, 2017, 20(2): 570–586. doi: 10.1016/j.jestch.2016.10.007

ALI E E, EL-HAMEED M A, EL-FERGANY A A, et al. Parameter extraction of photovoltaic generating units using multi-verse optimizer[J]. Sustainable Energy Technologies and Assessments, 2016, 17: 68–76. doi: 10.1016/j.seta.2016.08.004

MIRJALILI S. Dragonfly algorithm: A new meta-heuristic optimization technique for solving single-objective, discrete, and multi-objective problems[J]. Neural Computing and Applications, 2016, 27(4): 1053–1073. doi: 10.1007/s00521-015-1920-1

ASKARZADEH A. A novel metaheuristic method for solving constrained engineering optimization problems: Crow search algorithm[J]. Computers & Structures, 2016, 169: 1–12. doi: 10.1016/j.compstruc.2016.03.001
