基于分布式壓縮感知的寬帶欠定信號DOA估計

蔣瑩; 王冰切; 韓俊; 何翼

doi:10.11999/JEIT180723

基于分布式壓縮感知的寬帶欠定信號DOA估計

doi: 10.11999/JEIT180723

蔣瑩¹,
王冰切¹,
韓俊¹,
何翼^2, ,

1.
空軍預警學院 ??武漢 ??430000
2.
海軍研究院 ??北京 ??100161

基金項目: 國家自然科學基金(61771484)，湖北省自然科學基金(2016CFB288)

詳細信息

作者簡介:
蔣瑩：女，1991年生，博士生，研究方向?yàn)殡娮訉?duì)抗信息處理

王冰切：男，1972年生，副教授，碩士生導師，研究方向?yàn)槔走_(dá)系統與雷達對抗

韓俊：男，1983年生，講師，研究方向?yàn)槔走_(dá)對抗

何翼：男，1989年生，助理研究員，研究方向?yàn)橐曨l圖像處理及模式識別與人工智能

通訊作者:
何翼　jty614@163.com

中圖分類號: TN971
計量
- 文章訪問數: 3535
- HTML全文瀏覽量: 1211
- PDF下載量: 120
- 被引次數: 0
出版歷程
- 收稿日期: 2018-07-18
- 修回日期: 2019-01-11
- 網絡出版日期: 2019-01-22
- 刊出日期: 2019-07-01

Underdetermined Wideband DOA Estimation Based on Distributed Compressive Sensing

Ying JIANG¹,
Bingqie WANG¹,
Jun HAN¹,
Yi HE^{2
, ,}

1.
Air Force Early Warning Academy, Wuhan 430000, China
2.
Naval Research Academy, Beijing 100161, China

Funds: The National Natural Science Foundation of China(61771484), The Natural Science Foundation of Hubei Province (2016CFB288)

摘要

摘要: 為解決基于稀疏陣列的寬帶欠定信號到達角(DOA)估計問題，該文提出基于分布式壓縮感知(DCS)的寬帶DOA估計算法。首先，對稀疏陣列寬帶信號處理模型進行理論推導與分析，將寬帶信號DOA估計建模成DCS問題；其次，利用經典DCS算法實現稀疏陣列上的寬帶欠定信號DOA估計；最后，引入網格失配誤差，建立包含網格失配參數的DCS模型，并進行迭代求解，實現對DOA和網格失配參數的聯合估計。仿真結果表明，該算法能夠?qū)崿F(xiàn)寬帶欠定信號DOA估計，較現有成果而言，在保證測向精度的同時，具備分辨率高、運算速度快的優點。
- 到達角估計 /
- 分布式壓縮感知 /
- 稀疏陣列 /
- 聯合稀疏 /
- 網格失配
Abstract: In order to realize underdetermined wideband Direction Of Arrival(DOA) estimation based on sparse array, an algorithm on account of Distributed Compressive Sensing(DCS) is proposed. Firstly, wideband signal processing model based on sparse array is deduced and the underdetermined wideband DOA estimation is formulated as a DCS problem. Then, the DCS-Simultaneous Orthogonal Matching Pursuit(DCS-SOMP) algorithm is utilized to solve this problem. Finally, the off-grid problem is considered and a joint DCS model containing off-grid parameters is established. Estimations of DOAs and off-grid parameters are achieved through iterative solution. Simulation results show that the proposed algorithm is effective and have advantages in resolution and computational complexity.
- Direction Of Arrival(DOA) estimation /
- Distributed Compressive Sensing(DCS) /
- Sparse array /
- Joint sparsity /
- Off-grid problem

HTML全文

圖 1 CACIS型互質陣列結構

下載: 全尺寸圖片幻燈片

圖 2 SS-MUSIC, DCS-SOMP和DCS-JSOMP算法的空間譜

下載: 全尺寸圖片幻燈片

圖 3 信噪比變化對測向精度的影響

下載: 全尺寸圖片幻燈片

圖 4 頻域快拍次數變化對測向精度的影響

下載: 全尺寸圖片幻燈片

圖 5 到達角臨近信號估計能力

下載: 全尺寸圖片幻燈片

表 1 DCS-SOMP算法

輸入：虛擬陣列接收數據${{\text{z}}_h}$，過完備字典集${\text{Φ}_h}\left( \psi \right)$，信號個數$K$。
輸出：重構信號${{\text{s}}_h}$，支撐基列標集合$\varOmega$。
初始化：迭代計數$i = 1,{\varOmega_0}=\varnothing ,{\hat {\text{s}}_h} = {\text{0}}$，殘差初值${{\text{r}}_{h, 0}} = {{\text{z}}_h}$。
步驟 1 ?支撐基選擇： $ {g_i} = \mathop {\arg \max }\limits_{g \in \left\{ {1, 2, \cdots , G} \right\}} \sum\limits_{h = 1}^H {\frac{{\left\| {\left\langle {{{\text{r}}_{h, i - 1}}, {{\text{φ}} _{h, g}}} \right\rangle } \right\|}}{{{{\left\\| {{{\text{φ}} _{h, g}}} \right\\|}_2}}}} ,{\varOmega_i}={\varOmega_{i - 1}} \cup \left\{ {{g_i}} \right\}$；
步驟 2 ?殘差更新：${\hat{\text{ s}}_h}={{\text{Φ}} _{{\varOmega_i}}}^\dagger {{\text{z}}_h},{{\text{r}}_{h, i}} = {{\text{z}}_h} - {{\text{Φ}} _{{\varOmega_i}}}{\hat {\text{s}}_h}$；
步驟 3 ?條件判斷：若$i < K$，則$i = i + 1$跳至步驟1，否則跳至步驟4；
步驟 4 ?結果結算：$\varOmega={\varOmega_i},{{\text{s}}_h}={{\text{Φ}} _\varOmega}^\dagger {{\text{z}}_h}$。

下載: 導出CSV

表 2 DCS-JSOMP算法

　輸入：虛擬陣列接收數據${{\text{z}}_h}$，過完備字典集${\text{Φ}_h}\left( \text{Ψ} \right)$，網格失配字典${\text{Γ}_h}\left( \text{Ψ} \right)$，信號個數$K$。

　輸出：重構信號${{\text{s}}_h}$，支撐基列標集合$\varOmega$，網格失配誤差${\text{Δ}} $。

　初始化：迭代計數$i = 1,{\varOmega_0}=\varnothing,{\hat{\text{ s}}_h} = {\text{0}},\hat{\text{β}}_h={\text{0}}$，殘差${{\text{r}}_{h, 0}} = {{\text{z}}_h}$。
　步驟 1 ?支撐基選擇：${c_g} = \sum\limits_{h = 1}^H {\frac{{\left| {\left\langle {{{\text{r}}_{h, i - 1}}, {{\text{φ }}_{h, g}}} \right\rangle } \right|}}{{{{\left\| {{{\text{φ}} _{h, g}}} \right\|}_2}}}} ,{d_g} = \sum\limits_{h = 1}^H {\frac{{\left| {\left\langle {{{\text{r}}_{h, i - 1}}, {\text{γ}_{h, g}}} \right\rangle } \right|}}{{{{\left\| {{\text{γ}_{h, g}}} \right\|}_2}}}} ,{g_i} = \mathop {\arg \max }\limits_{g \in \left\{ {1, 2, \cdots , G} \right\}} \sqrt {{c_g}^2 + {d_g}^2} ,{\varOmega_i}={\varOmega_{i - 1}} \cup \left\{ {{g_i}} \right\}$；

　步驟 2 ?殘差更新：${\hat{\text{ s}}_h} = {{\text{Φ}} _{{\varOmega_i}}}^\dagger \left( {{{\text{z}}_h} - {{\text{Γ}} _{{\varOmega_i}}}{\hat{\text{β}}_h}} \right),{\hat{\text{β}}_h} = {{\text{Γ}} _{{\varOmega_i}}}^\dagger \left( {{{\text{z}}_h} - {{\text{Φ}} _{{\varOmega_i}}}{{\hat {\text{s}}}_h}} \right),{{\text{r}}_{h, i}} = {{\text{z}}_h} - {{\text{Φ}} _{{\varOmega_i}}}{\hat{\text{ s}}_h} - {{\text{Γ}} _{{\varOmega_i}}}{\hat{\text{β}}_h}$；

　步驟 3 ?條件判斷：若$i < K$，則$i = i + 1$跳至步驟1，否則跳至步驟4；
　步驟 4 ?結果結算：$\varOmega={\varOmega_i},{{\text{s}}_h} = {{\text{Φ}} _\varOmega}^\dagger \left( {{{\text{z}}_h} - {{\text{Γ}} _\varOmega}{\hat{\text{β}}_h}} \right),{\text{β}_h} = {{\text{Γ}} _\varOmega}^\dagger \left( {{{\text{z}}_h} - {{\text{Φ}} _\varOmega}{{\text{s}}_h}} \right),{\text{Δ}} =\frac{1}{H}\sum\limits_{h = 1}^H {\frac{{{{\text{β}} _h}}}{{{{\text{s}}_h}}}} $。

下載: 導出CSV

表 3 5種算法單次蒙特卡洛實驗用時(s)

算法	信噪比變化	頻域快拍次數變化
DCS-SOMP	0.1747	0.1943
DCS-JSOMP	0.3439	0.3784
SS-MUSIC	0.5021	0.5207
WNNSBL	3.3751	3.0231
OGSLIM	0.6068	0.6678

下載: 導出CSV

參考文獻(19)

SELVA J. Efficient wideband DOA estimation through function evaluation techniques[J]. IEEE Transactions on Signal Processing, 2018, 66(12): 3112–3123. doi: 10.1109/TSP.2018.2824256

DAS A and SEJNOWSKI T J. Narrowband and wideband off-grid direction-of-arrival estimation via sparse Bayesian learning[J]. IEEE Journal of Oceanic Engineering, 2018, 43(1): 108–118. doi: 10.1109/JOE.2017.2660278

ZHANG Ailian and XU Wen. A new sparse subspace method for wideband DOA estimation[C]. OCEANS, Aberdeen, UK, 2017: 1–7.

LIU Jianyan, LU Yilong, ZHANG Yanmei, et al. DOA estimation with enhanced DOFs by exploiting cyclostationarity[J]. IEEE Transactions on Signal Processing, 2017, 65(6): 1486–1496. doi: 10.1109/TSP.2016.2645542

SHEN Qing, CUI Wei, LIU Wei, et al. Underdetermined wideband DOA estimation of off-grid sources employing the difference co-array concept[J]. Signal Processing, 2017, 130: 299–304. doi: 10.1016/j.sigpro.2016.07.022

PAL P and VAIDYANATHAN P P. Nested arrays: A novel approach to array processing with enhanced degrees of freedom[J]. IEEE Transactions on Signal Processing, 2010, 58(8): 4167–4181. doi: 10.1109/TSP.2010.2049264

VAIDYANATHAN P P and PAL P. Sparse sensing with co-prime samplers and arrays[J]. IEEE Transactions on Signal Processing, 2011, 59(2): 573–586. doi: 10.1109/TSP.2010.2089682

VAIDYANATHAN P P and PAL P. Sparse sensing with coprime arrays[C]. Proceedings of the 2010 Conference Record of the 44th Asilomar Conference on Signals, Systems and Computers, Pacific Grove, USA, 2010: 1405–1409. doi: 10.1109/acssc.2010.5757766.

HAN Keyong and NEHORAI A. Wideband direction of arrival estimation using nested arrays[C]. Proceedings of the 20135th IEEE International Workshop on Computational Advances in Multi-Sensor Adaptive Processing, St. Martin, France, 2013: 188–191. doi: 10.1109/camsap.2013.6714039.

HAN Keyong and NEHORAI A. Wideband Gaussian source processing using a linear nested array[J]. IEEE Signal Processing Letters, 2013, 20(11): 1110–1113. doi: 10.1109/LSP.2013.2281514

SHEN Qing, LIU Wei, CUI Wei, et al. Group sparsity based wideband DOA estimation for co-prime arrays[C]. Proceedings of 2014 IEEE China Summit & International Conference on Signal and Information Processing, Xi'an, China, 2014: 252–256. doi: 10.1109/chinasip.2014.6889242.

SHEN Qing, LIU Wei, CUI Wei, et al. Low-complexity direction-of-arrival estimation based on wideband co-prime arrays[J]. IEEE/ACM Transactions on Audio, Speech, and Language Processing, 2015, 23(9): 1445–1456. doi: 10.1109/TASLP.2015.2436214

HE Zhenqing, SHI Zhiping, HUANG Lei, et al. Underdetermined DOA estimation for wideband signals using robust sparse covariance fitting[J]. IEEE Signal Processing Letters, 2015, 22(4): 435–439. doi: 10.1109/LSP.2014.2358084

HU Nan, SUN Bing, ZHANG Yi, et al. Underdetermined DOA estimation method for wideband signals using joint nonnegative sparse Bayesian learning[J]. IEEE Signal Processing Letters, 2017, 24(5): 535–539. doi: 10.1109/LSP.2017.2673850

HU Nan, SUN Bing, WANG Jiajun, et al. Source localization for sparse array using nonnegative sparse Bayesian learning[J]. Signal Processing, 2016, 127: 37–43. doi: 10.1016/j.sigpro.2016.02.025

馮明月, 何明浩, 徐璟, 等. 低信噪比條件下寬帶欠定信號高精度DOA估計[J]. 電子與信息學報, 2017, 39(6): 1340–1347. doi: 10.11999/JEIT160921

FENG Mingyue, HE Minghao, XU Jing, et al. High accuracy DOA estimation under low SNR condition for wideband underdetermined signals[J]. Journal of Electronics &Information Technology, 2017, 39(6): 1340–1347. doi: 10.11999/JEIT160921

DUARTE M F, SARVOTHAM S, BARON D, et al. Distributed compressed sensing of jointly sparse signals[C]. Proceedings of the Conference Record of the 39th Asilomar Conference on Signals, Systems and Computers, Pacific Grove, USA, 2005: 1537–1541.

TROPP J A, GILBERT A C, and STRAUSS M J. Simultaneous sparse approximation via greedy pursuit[C]. Proceedings of 2005 IEEE International Conference on Acoustics, Speech, and Signal Processing, Philadelphia, USA, 2005: 721–724. doi: 10.1109/icassp.2005.1416405.

TAN Zhao and NEHORAI A. Sparse direction of arrival estimation using co-prime arrays with off-grid targets[J]. IEEE Signal Processing Letters, 2014, 21(1): 26–29. doi: 10.1109/LSP.2013.2289740
