基于回波序列最小二乘擬合的高分辨率SAR運動目標速度估計

王超; 王巖飛; 王琦; 詹學麗

doi:10.11999/JEIT180695

基于回波序列最小二乘擬合的高分辨率SAR運動目標速度估計

doi: 10.11999/JEIT180695

王超^{1, 2, ,},
王巖飛¹,
王琦¹,
詹學麗¹

1.
中國科學院電子學研究所 ??北京 ??100190
2.
中國科學院大學 ??北京 ??100049

基金項目: 國家重點研發計劃(2017YFB0503001)，國家自然科學基金(61471340)

詳細信息

作者簡介:
王超：男，1983年生，博士生，研究方向?yàn)镾AR信號處理等

王巖飛：男，1963年生，研究員，博士生導師，研究方向?yàn)槲⒉ǔ上窭走_(dá)系統及其理論、數字信號處理等

王琦：男，1976年生，副研究員，研究方向?yàn)镾AR信號處理等

詹學麗：男，1976年生，副研究員，研究方向?yàn)镾AR信號處理等

通訊作者:
王超　wangchao_thu@163.com

中圖分類號: TN957.51
計量
- 文章訪問數: 2500
- HTML全文瀏覽量: 787
- PDF下載量: 99
- 被引次數: 0
出版歷程
- 收稿日期: 2018-07-13
- 修回日期: 2019-01-17
- 網絡出版日期: 2019-01-31
- 刊出日期: 2019-05-01

Velocity Estimation of Moving Targets Based on Least Square Fitting of High-resolution SAR Echo Sequences

Chao WANG^{1, 2
, ,},
Yanfei WANG¹,
Qi WANG¹,
Xueli ZHAN¹

1.
Institute of Electronics, Chinese Academy of Sciences, Beijing 100190, China
2.
University of Chinese Academy of Sciences, Beijing 100049, China

Funds: The National Key Research and Development Program of China (2017YFB0503001), The National Natural Science Foundation of China (61471340)

摘要

摘要:
運動目標速度估計是機載單天線高分辨率合成孔徑雷達(SAR)實現運動目標成像和定位的關鍵環節。針對現有方法運算量大、易受距離徙動干擾等缺點，該文提出一種基于回波序列最小二乘擬合的速度估計方法。利用該方法，首先通過包絡相關提取相鄰回波序列的距離變化量，然后對其做最小二乘線性擬合，目標的距離向速度和方位向速度可由擬合系數計算得到。與傳統方法相比，該方法不僅計算量小，而且無須先做距離徙動校正(RCMC)。該文給出了新方法的數學模型和參數選取原則，分析了該方法的估計精度、計算量和適用條件，并通過仿真和實際數據處理驗證了該方法的有效性。
- 合成孔徑雷達 /
- 運動目標成像 /
- 速度估計 /
- 回波序列 /
- 最小二乘擬合
Abstract:
Velocity estimation of moving targets is a key part of ground moving target imaging and positioning in airborne single-antenna high-resolution SAR system. In order to solute the defects of traditional algorithms, such as high computation brought by searching and interpolation and low reliability caused by range cell migration, a novel method based on least square fitting of echo sequence is proposed. Range changes between adjacent echo sequences are extracted using envelope correlation, and coefficients of range change equation are obtained by least square linear fitting, from which radial velocity and along-track velocity can be derived. Compared with the traditional algorithms, the new method has less computation and can work without RCMC. The mathematical model is presented and the principle of parameter selection is provided, and accuracy, computation and applicable conditions of the algorithm are analyzed. The effectiveness of the proposed algorithm is validated by simulation and real data.
- Synthetic Aperture Radar (SAR) /
- Ground Moving Target Imaging (GMTIm) /
- Velocity estimation /
- Echo sequence /
- Least square fitting

HTML全文

圖 1 運動目標和載機的幾何關系

下載: 全尺寸圖片幻燈片

圖 2 回波序列示意圖

下載: 全尺寸圖片幻燈片

圖 3 本文算法流程圖

下載: 全尺寸圖片幻燈片

圖 4 最小二乘擬合結果

下載: 全尺寸圖片幻燈片

圖 5 運動目標與靜止場景的合成SAR圖像

下載: 全尺寸圖片幻燈片

表 1 雷達仿真參數

參數名稱	參數值
距離向點數	2048
方位向點數	32768
中心頻率(GHz)	15.6
距離向采樣率(GHz)	1
信號帶寬(MHz)	700
信號脈寬(μs)	2
飛機地速(m/s)	80
脈沖重復頻率(Hz)	1440
中心斜距	15
目標1距離向速度(m/s)	3
目標1方位向速度(m/s)	–20
目標2距離向速度(m/s)	–10
目標2方位向速度(m/s)	–10

下載: 導出CSV

表 2 勻速運動目標距離向速度估計結果

目標編號	Hough變換速度估計結果 (m/s)	Hough變換估計相對誤差(%)	本文算法速度估計結果(m/s)	本文算法估計相對誤差(%)
目標1	3.34	11.50	3.06	2.25
目標2	–10.17	1.75	–9.92	0.80

下載: 導出CSV

表 3 勻速運動目標方位向速度估計結果

目標編號	MD速度估計結果(m/s)	MD估計相對誤差(%)	本文算法速度估計結果(m/s)	本文算法估計相對誤差(%)
目標1	–20.50	2.54	–20.71	3.58
目標2	–9.98	0.16	–10.06	0.60

下載: 導出CSV

表 4 算法運算時間

目標編號	Hough變換執行時間	MD執行時間	本文算法執行時間
目標1	2.96	32.26	0.50
目標2	3.44	24.78	0.34

下載: 導出CSV

表 5 加速運動目標距離向速度估計結果

目標編號	Hough變換速度估計結果 (m/s)	Hough變換估計相對誤差(%)	本文算法速度估計結果(m/s)	本文算法估計相對誤差(%)
目標3	–13.50	35.00	–9.93	0.70

下載: 導出CSV

表 7 加速運動目標方位調頻率估計結果

目標編號	MD速度估計結果(Hz/s)	MD估計相對誤差(%)	本文算法速度估計結果(Hz/s)	本文算法估計相對誤差(%)
目標3	444.67	313.3	108.08	0.46

下載: 導出CSV

表 6 加速運動目標方位向速度估計結果

目標編號	MD 速度估計結果(m/s)	MD估計相對誤差(%)	本文算法速度估計結果(m/s)	本文算法估計相對誤差(%)
目標3	–173.24	1632.40	–45.49	354.90

下載: 導出CSV

表 8 清除地雜波頻譜后的速度估計結果

波束角(°)	距離向速度估計結果(m/s)	距離向速度估計相對誤差(%)	方位向速度估計結果(m/s)	方位向速度估計相對誤差(%)
1	2.93	2.33	–21.83	9.15
3	3.27	9.00	–23.90	19.50
5	4.01	33.67	–24.93	24.65

下載: 導出CSV

表 9 不同信噪比下的速度估計結果

信噪比(dB)	距離向速度估計結果(m/s)	距離向速度估計相對誤差(%)	方位向速度估計結果(m/s)	方位向速度估計相對誤差(%)
0	–9.92	0.80	–10.06	0.60
–20	–9.93	0.70	–9.68	3.20
–30	–9.74	2.60	–14.30	43.00

下載: 導出CSV

表 10 實測數據參數

參數名稱	參數值
距離向點數	733
方位向點數	32768
中心頻率(GHz)	15.6
距離向采樣率(GHz)	1
信號帶寬(MHz)	700
信號脈寬(μs)	60
飛機地速(m/s)	78
脈沖重復頻率(Hz)	1400
中心斜距	33

下載: 導出CSV

參考文獻(20)

RANEY R K. Synthetic aperture imaging radar and moving targets[J]. IEEE Transactions on Aerospace and Electronic Systems, 1971, AES-7(3): 499–505. doi: 10.1109/TAES.1971.310292

LI Yake, WANG Yanfei, and LIU Chang. Detect and autofocus the moving target by its range walk in time domain[C]. Proceedings of 2011 International Conference on Wireless Communications and Signal Processing, Nanjing, China, 2011: 1－5. doi: 10.1109/WCSP.2011.6096755.

王智睿, 張旭東, 許稼. 基于Radon變換的SAR地面運動目標徑向速度估計[J]. 清華大學學報: 自然科學版, 2015, 55(8): 860–865. doi: 10.16511/j.cnki.qhdxxb.2015.08.008

WANG Zhirui, ZHANG Xudong, and XU Jia. Radial velocity estimation based on Radon transforms for SAR images of moving ground targets[J]. Journal of Tsinghua University:Science and Technology, 2015, 55(8): 860–865. doi: 10.16511/j.cnki.qhdxxb.2015.08.008

SAMCZYNSKI P and KULPA K S. Coherent MapDrift technique[J]. IEEE Transactions on Geoscience and Remote Sensing, 2010, 48(3): 1505–1517. doi: 10.1109/TGRS.2009.2032241

李亞超, 周峰, 邢孟道, 等. 一種直升機的艦船Dechirp實測數據SAR成像方法[J]. 電子與信息學報, 2007, 29(8): 1794–1798. doi: 10.3724/SP.J.1146.2005.01535

LI Yachao, ZHOU Feng, XING Mengdao, et al. An effective method for ship dechirp data imaging in helicopter SAR system[J]. Journal of Electronics &Information Technology, 2007, 29(8): 1794–1798. doi: 10.3724/SP.J.1146.2005.01535

HUANG Penghui, LIAO Guisheng, YANG Zhiwei, et al. A fast SAR imaging method for ground moving target using a second-order WVD transform[J]. IEEE Transactions on Geoscience and Remote Sensing, 2016, 54(4): 1940–1956. doi: 10.1109/TGRS.2015.2490582

ZHOU F, WU R, XING M, et al. Approach for single channel SAR ground moving target imaging and motion parameter estimation[J]. IET Radar, Sonar & Navigation, 2007, 1(1): 59–66. doi: 10.1049/iet-rsn:20060040

YANG Jiefang, ZHANG Yunhua, and KANG Xueyan. A Doppler ambiguity tolerated algorithm for airborne SAR ground moving target imaging and motion parameters estimation[J]. IEEE Geoscience and Remote Sensing Letters, 2015, 12(12): 2398–2402. doi: 10.1109/LGRS.2015.2478799

KIRSCHT M. Detection and velocity estimation of moving objects in a sequence of single-look SAR images[C]. Proceedings of 1996 International Geoscience and Remote Sensing Symposium, Lincoln, USA, 1996: 333–335.

盛蔚, 毛士藝. 一種合成孔徑雷達對地面運動目標成像和精確定位的算法[J]. 電子與信息學報, 2004, 26(4): 598–606.

SHENG Wei and MAO Shiyi. An effective method for ground moving target imaging and location in SAR system[J]. Journal of Electronics &Information Technology, 2004, 26(4): 598–606.

WANG Zhirui, XIA Xianggen, XU Jia, et al. Ground moving target imaging based on 2-D velocity search in high resolution SAR[C]. Proceedings of 2017 IEEE Radar Conference, Seattle, USA, 2017: 68–72.

GU Dandan, LIANG Zichang, WU Yajun, et al. Efficient motion compensation of moving targets in SAR imaging[C]. Proceedings of 2017 International Applied Computational Electromagnetics Society Symposium, Suzhou, China, 2017: 1–2.

SHI Hongyin, YANG Xiaoyan, ZHOU Qiuxiao, et al. SAR slow moving target imaging based on over-sampling smooth algorithm[J]. Chinese Journal of Electronics, 2017, 26(4): 876–882. doi: 10.1049/cje.2017.06.005

SU Jia, TAO Haihong, WANG Ling, et al. Coherently integrated cubic function based Doppler parameters estimation for moving-target imaging[C]. Proceedings of 2017 International Applied Computational Electromagnetics Society Symposium, Suzhou, China, 2017: 1–2.

LI Dong, ZHAN Muyang, SU Jia, et al. Performances analysis of coherently integrated CPF for LFM signal under low SNR and its application to ground moving target imaging[J]. IEEE Transactions on Geoscience and Remote Sensing, 2017, 55(11): 6402–6419. doi: 10.1109/TGRS.2017.2727508

WANG Hanyun and JIANG Yicheng. Real-time parameter estimation for SAR moving target based on WVD slice and FrFT[J]. Electronics Letters, 2018, 54(1): 47–49. doi: 10.1049/el.2017.1740

LI Zhongyu, WU Junjie, LIU Zhutian, et al. An optimal 2-D spectrum matching method for SAR ground moving target imaging[J]. IEEE Transactions on Geoscience and Remote Sensing, 2018, 56(10): 5961–5974. doi: 10.1109/TGRS.2018.2829166

DELISLE G Y and WU Haiqing. Moving target imaging and trajectory computation using ISAR[J]. IEEE Transactions on Aerospace and Electronic Systems, 1994, 30(3): 887–899. doi: 10.1109/7.303757

STRUTZ T. Data Fitting and Uncertainty: A Practical Introduction to Weighted Least Squares and Beyond[M]. Wiesbaden, Vieweg + Teubner, 2011: 89–91.

王琦, 王巖飛. 利用短時FFT的距離-多普勒域SAR運動目標檢測[J]. 電子與信息學報, 2006, 28(4): 628–631.

WANG Qi and WANG Yanfei. Moving target detection with short time FFT for SAR[J]. Journal of Electronics &Information Technology, 2006, 28(4): 628–631.
