基于Relax算法的星載高分寬幅成像方法研究
doi: 10.11999/JEIT180596
-
南京航空航天大學電子信息工程學院 ??南京 ??210000
基金項目: 國家自然科學基金(61501231)，民用航天“十三五”背景型號預研項目(D010102)
Research on Spaceborne High Resolution Wide Swath Imaging Method Based on Relax Algorithm
-
College of Electronic Information Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210000, China
Funds: The National Natural Science Foundation of China (61501231), The Civil Aerospace 13th Five-year Background Model Pre-research Project (D010102)
-
摘要:
現代星載合成孔徑雷達(SAR)系統要求同時具備高分辨率和寬測繪帶的能力，而傳統單通道星載SAR系統在分辨率和測繪帶兩個重要指標之間存在固有矛盾，因此方位向多通道的方法被提出并用于解決上述問題。該文在分析方位向多通道回波模型的基礎上，結合Relax算法的特點，提出了一種基于Relax算法的星載SAR高分寬幅(HRWS)成像方法，并給出了新方法的詳細迭代流程。通過點目標回波仿真，并與傳統的方位向多通道HRWS重建方法進行對比，驗證了新方法的可靠性和有效性。
-
關鍵詞:
- 星載合成孔徑雷達 /
- 高分寬幅 /
- Relax算法
Abstract:The modern spaceborne SAR system requires both high resolution and wide swath, and the conventional single channel spaceborne SAR system has a contradiction between the two important indexes, the azimuth multichannel method is proposed and used to solve the above problem. Based on the analysis of the azimuth multichannel echo model and the characteristics of the Relax algorithm, a spaceborne SAR High Resolution Wide Swath (HRWS) imaging method is proposed, and the iterative process of the new method is described in detail. By the simulation of point target echo, and comparing with the traditional azimuth multichannel HRWS reconstruction methods, the reliability and effectiveness of the proposed method are verified.
-
表 1 公式中用到的符號說明
符號 說明 $M$ 通道個數 $r$ 距離變量，$r = {\rm c}t/2$ c 光速 $t$ 距離向時間變量 ${f_{\rm d}}$ 多普勒頻率 $\vartheta $ 目標參數向量，$\vartheta = {[{T_0}, {R_0}, {\sigma ^2}, \varTheta ]^{\rm{T}}}$ ${T_0}$ 最小斜距對應的時間 ${R_0}$ 最小斜距$\min \{ R(T\,)\} = R({T_0}) = {R_0}$ ${\sigma ^2}$ 目標功率 $\varTheta $ 目標相位 ${f\!_{p}}$ 各通道的脈沖重復頻率 $\varOmega $ 2次相位項的變化率 $R(T\,)$ 雷達與目標之間的距離 $T\,$ 慢時間變量 ${{u}}[{f_{\rm d}}, \vartheta ]$ 天線與目標間的瞄準線向量 ${A_m}$ 第$m$個通道的雙向天線方向圖 ${d_m}$ 第$m$個通道的等效相位中心
下載: 導出CSV
表 2 基于Relax算法的模糊抑制
For $m = 1: \rm Na$ For $n = 1:{\rm Nr}$
%遍歷所有距離-多普勒單元(其中，$\rm Na$表示多普勒單元的個數，
$\rm Nr$表示距離單元的個數)
${Z_{{\rm{rec_{-}1}}}}(r, {f_{\rm d}} + p{f\!_{p}}) = \frac{{{{a}}_p^{\rm{H}}\left( {{f_{\rm d}}} \right){{Z}}\left( {r, {f_{\rm d}}} \right)}}{M}$ %初始化操作
%第1次迭代
$\begin{align}{{{Z}}_{p_{-}1}}\left( {r, {f_{\rm d}}} \right) =& {{Z}}\left( {r, {f_{\rm d}}} \right) \\&- \sum\limits_{i = - \left( {M - 1} \right)/2, i \ne p}^{\left( {M - 1} \right)/2} {{{{a}}_i}\left( {{f_{\rm d}}} \right)} \cdot {Z_{{\rm{rec_{-}1}}}}\left( {r, {f_{\rm d}} + p{f\!_{p}}} \right)\end{align}$
${\hat Z_{{\rm{rec_{-}1}}}}\left( {r, {f_{\rm d}} + p{f\!_{p}}} \right) = \frac{{{{a}}_p^{\rm{H}}\left( {{f_{\rm d}}} \right){{{Z}}_{p_{-}1}}\left( {r, {f_{\rm d}}} \right)}}{M}$
如果未滿足收斂條件或者未達到迭代次數
%第$k$次迭代($k \ge 2$)
$\begin{align}{{{Z}}_{p_{-}k}}\left( {r, {f_{\rm d}}} \right) =& {{Z}}\left( {r, {f_{\rm d}}} \right) \\& - \sum\limits_{i = - \left( {M - 1} \right)/2, i \ne p}^{\left( {M - 1} \right)/2} {{{{a}}_i}\left( {{f_{\rm d}}} \right)} \cdot {\hat Z_{{{{\rm rec}_{-}k - 1}}}}\left( {r, {f_{\rm d}} + p{f\!_{p}}} \right)\end{align}$
${\hat Z_{{{{\rm rec}_{-}k}}}}\left( {r, {f_{\rm d}} + p{f\!_{p}}} \right) = \frac{{{{a}}_p^{\rm{H}}\left( {{f_{\rm d}}} \right){{{Z}}_{p_{-}k}}\left( {r, {f_{\rm d}}} \right)}}{M}$
End
End
End
下載: 導出CSV
表 3 不同重建方法的性能對比
算法類別 PSLR(dB) 方位向分辨率 SNR(dB) SANR(dB) 矩陣求逆法 13.99 1.66 39.46 27.08 最大信號法 13.99 1.66 40.33 12.97 Relax法 13.82 1.66 50.56 21.22
下載: 導出CSV
-
