一種基于參數更新的機載SAR圖像目標定位方法

吳元

doi:10.11999/JEIT180564

一種基于參數更新的機載SAR圖像目標定位方法

doi: 10.11999/JEIT180564

吳元^,

中國西南電子技術研究所 ??成都 ??610036

詳細信息

作者簡介:
吳元：男，1987年生，工程師，研究方向?yàn)楹铣煽讖嚼走_(dá)成像與圖像處理

通訊作者:
吳元　wuyuaner@126.com

中圖分類號: TN957.5
計量
- 文章訪問數: 2169
- HTML全文瀏覽量: 900
- PDF下載量: 105
- 被引次數: 0
出版歷程
- 收稿日期: 2018-06-08
- 修回日期: 2018-12-25
- 網絡出版日期: 2019-01-02
- 刊出日期: 2019-05-01

An Airborne SAR Image Target Location Algorithm Based on Parameter Refining

Yuan WU^,

Southwest China Institute of Electronic Technology, Chengdu 610036, China

摘要

摘要:
目標定位精度是機載合成孔徑雷達(SAR)系統的一項重要技術指標，因此機載SAR圖像目標定位具有重要的應用價值。在基于距離-多普勒模型的SAR圖像目標定位方法中，載機運動參數的精度會直接影響定位的精度，在機載平臺導航精度受限的情況下，定位精度會受到很大影響。因此，該文提出一種基于距離-多普勒模型參數更新的機載SAR圖像目標定位方法，利用機載SAR圖像與基準圖像匹配得到的匹配點來對載機運動參數進行更新，提高參數的精度，進而提高定位的精度。實驗證明了該方法的有效性。
- 合成孔徑雷達 /
- 距離-多普勒模型 /
- SAR圖像定位
Abstract:
The target location accuracy is an important technical parameter of airborne SAR system, thus the target location of airborne SAR image is important for application. The precision of the moving parameters directly influences the precision of the SAR image target location algorithm based on the Range-Doppler (RD) model. The locating accuracy is greatly affected if the navigation accuracy of the airborne platform is limited. To solve this problem, an airborne SAR image target location algorithm based on RD model parameter refining is proposed. Using the matching points of airborne SAR image matching with the reference image, the moving parameters are refined with better accuracy, and the locating accuracy is improved. The experiments show that the proposed algorithm is effective.
- SAR /
- Range-Doppler (RD) model /
- SAR image location

HTML全文

圖 1 機載SAR圖像目標定位方法流程圖

下載: 全尺寸圖片幻燈片

圖 2 機載SAR圖像和光學基準圖像

下載: 全尺寸圖片幻燈片

圖 3 6個目標放大后的圖像

下載: 全尺寸圖片幻燈片

表 1 定位結果與誤差

	目標1	目標2	目標3	目標4	目標5	目標6
真實位置	(109.533047°, 34.834823°, 374 m)	(109.540250°, 34.833684°, 360 m)	(109.546419°, 34.836492°, 370 m)	(109.545977°, 34.823204°, 364 m)	(109.531886°, 34.820393°, 375 m)	(109.534006°, 34.833703°, 369 m)
RD方法結果	(109.532502°, 34.835272°, 375 m)	(109.539727°, 34.834130°, 354 m)	(109.545901°, 34.836621°, 372 m)	(109.545668°, 34.823400°, 372 m)	(109.531688°, 34.820907°, 359 m)	(109.533567°, 34.834173°, 361 m)
RD方法誤差	63.05	60.74	57.96	35.29	29.27	51.98
本文方法結果	(109.532917°, 34.834972°, 372 m)	(109.540145°, 34.833778°, 360 m)	(109.546375°, 34.836374°, 372 m)	(109.545927°, 34.823166°, 364 m)	(109.531866°, 34.820466°, 375 m)	(109.533968°, 34.833748°, 372 m)
本文方法誤差	15.52	12.23	6.60	5.78	3.49	4.50

下載: 導出CSV

參考文獻(15)

保錚, 邢孟道, 王彤. 雷達成像技術[M]. 北京, 電子工業出版社, 2005: 2–6.

范劍超, 王德毅, 趙建化, 等. 高分三號SAR影像在國家海域使用動態監測中的應用[J]. 雷達學報, 2017, 6(5): 456–472. doi: 10.12000/JR17080

FAN Jianchao, FAN Deyi, ZHAO Jianhua, et al. National sea area use dynamic monitoring based on GF-3 SAR imagery[J]. Journal of Radars, 2017, 6(5): 456–472. doi: 10.12000/JR17080

劉澤宇, 柳彬, 郭煒煒, 等. 高分三號NSC模式SAR圖像艦船目標檢測初探[J]. 雷達學報, 2017, 6(5): 473–482. doi: 10.12000/JR17059

LIU Zeyu, LIU Bin, GUO Weiwei, et al. Ship detection in GF-3 NSC mode SAR images[J]. Journal of Radars, 2017, 6(5): 473–482. doi: 10.12000/JR17059

周金萍. SAR產品圖像像素定位方法選擇與參數優化[J]. 上海航天, 2000(1): 32–39. doi: 10.19328/j.cnki.1006-1630.2000.01.007

ZHOU Jinping. Selection and optimization of the location method for pixels in SAR imagery[J]. Aerospace Shanghai, 2000(1): 32–39. doi: 10.19328/j.cnki.1006-1630.2000.01.007

尤紅建, 丁赤飚, 付琨. SAR圖像對地定位的嚴密共線方程模型[J]. 測繪學報, 2007, 36(2): 158–162. doi: 10.3321/j.issn:1001-1595.2007.02.008

YOU Hongjian, DING Chibiao, and FU Kun. SAR image localization using rigorous SAR collinearity equation model[J]. Acta Geodaetica et Cartographica Sinica, 2007, 36(2): 158–162. doi: 10.3321/j.issn:1001-1595.2007.02.008

JOHN C C and ROBERT M M. Synthetic Aperture Radar: Systems and Signal Processing[M]. New York: John Wiley & Sons, Inc, 1991: 1–100.

張耀天, 孫進平, 毛士藝. 機載SAR圖像直接定位算法研究[J]. 信號處理, 2009, 25(4): 669–673. doi: 10.3969/j.issn.1003-0530.2009.04.032

ZHANG Yaotian, SUN Jinping, and MAO Shiyi. Study on direct location algorithm for airborne SAR image[J]. Signal Processing, 2009, 25(4): 669–673. doi: 10.3969/j.issn.1003-0530.2009.04.032

楊杰, 潘斌, 李德仁, 等. 無地面控制點的星載SAR影像直接對地定位研究[J]. 武漢大學學報·信息科學版, 2006, 31(2): 144–147. doi: 10.3969/j.issn.1671-8860.2006.02.013

YANG Jie, PAN Bin, LI Deren, et al. Location of spaceborne SAR imagery without reference points[J]. Geomatics and Information Science of Wuhan University, 2006, 31(2): 144–147. doi: 10.3969/j.issn.1671-8860.2006.02.013

傅文學, 郭小方, 田慶久. 星載SAR距離-多普勒定位算法中地球模型的修正[J]. 測繪學報, 2008, 37(1): 59–63. doi: 10.3321/j.issn:1001-1595.2008.01.011

FU Wenxue, GUO Xiaofang, and TIAN Qingjiu. Correction of earth model in range-doppler location algorithm[J]. Acta Geodaetica et Cartographica Sinica, 2008, 37(1): 59–63. doi: 10.3321/j.issn:1001-1595.2008.01.011

尤紅建, 丁赤彪, 向茂生. 機載高分辨率SAR圖像直接對地定位原理及精度分析[J]. 武漢大學學報·信息科學版, 2005, 30(8): 712–715. doi: 10.3969/j.issn.1671-8860.2005.08.013

YOU Hongjian, DING Chibiao, and XIANG Maosheng. Principle and accuracy for airborne SAR image direct localization[J]. Geomatics and Information Science of Wuhan University, 2005, 30(8): 712–715. doi: 10.3969/j.issn.1671-8860.2005.08.013

陸靜, 郭克成, 陸洪濤. 星載SAR圖像距離-多普勒定位精度分析[J]. 雷達科學與技術, 2009, 7(2): 102–106. doi: 10.3969/j.issn.1672-2337.2009.02.005

LU Jing, GUO Kecheng, and LU Hongtao. Analysis of R-D location precision in spaceborne SAR image[J]. Radar Science and Technology, 2009, 7(2): 102–106. doi: 10.3969/j.issn.1672-2337.2009.02.005

SCHUBERT A, SMALL D, JEHLE M, et al. COSMO-skymed, Terra SAR-X, and RADARSAT-2 geolocation accuracy after compensation for earth-system effects[C]. 2012 IEEE International Geoscience and Remote Sensing Symposium, Munich, Germany, 2012: 3301–3304.

丁赤飚, 劉佳音, 雷斌, 等. 高分三號SAR衛星系統級幾何定位精度初探[J]. 雷達學報, 2017, 6(1): 11–16. doi: 10.12000/JR17024

DING Chibiao, LIU Jiayin, LEI Bin, et al. Preliminary exploration of systematic geolocation accuracy of GF-3 SAR satellite system[J]. Journal of Radars, 2017, 6(1): 11–16. doi: 10.12000/JR17024

梅海文, 孟自強, 李亞超, 等. 雙基前視SAR幾何定位及同步誤差分析[J]. 電子與信息學報, 2018, 40(4): 882–889. doi: 10.11999/JEIT170677

MEI Haiwen, MENG Ziqiang, LI Yachao, et al. Bistatic forward-looking SAR geometrical positioning and analysis of synchronization error[J]. Journal of Electronics &Information Technology, 2018, 40(4): 882–889. doi: 10.11999/JEIT170677

YUE Linwei, SHEN Huanfeng, ZHANG Liangpei, et al. High-quality seamless DEM generation blending SRTM-1, ASTER GDEM v2 and ICESat/GLAS observations[J]. Isprs Journal of Photogrammetry & Remote Sensing, 2017, 123: 20–34. doi: 10.1016/j.isprsjprs.2016.11.002
