一種面向粗粒度可重構陣列的硬件木馬檢測算法的設計與實現

嚴迎建; 劉敏; 邱釗洋

doi:10.11999/JEIT180484

一種面向粗粒度可重構陣列的硬件木馬檢測算法的設計與實現

doi: 10.11999/JEIT180484

解放軍信息工程大學 ??鄭州 ??450001

詳細信息

作者簡介:
嚴迎建：男，1973 年生，教授，研究方向?yàn)榘踩珜?zhuān)用芯片設計技術

劉敏：女，1995年生，碩士生，研究方向?yàn)榘踩珜?zhuān)用芯片設計技術硬件木馬檢測

邱釗洋：男，1991年生，博士生，研究方向?yàn)樾盘?hào)分析與軟件無線電

通訊作者:
劉敏　15515671017@163.com

中圖分類號: TN406
計量
- 文章訪問數: 1792
- HTML全文瀏覽量: 782
- PDF下載量: 100
- 被引次數: 0
出版歷程
- 收稿日期: 2018-05-21
- 修回日期: 2018-09-20
- 網絡出版日期: 2018-10-22
- 刊出日期: 2019-05-01

Design and Implementation of Hardware Trojan Detection Algorithm for Coarse-grained Reconfigurable Arrays

The PLA’s Information Engineering University, Zhengzhou 450001, China

摘要

摘要: 硬件木馬檢測已成為當前芯片安全領域的研究熱點，現有檢測算法大多面向ASIC電路和FPGA電路，且依賴于未感染硬件木馬的黃金芯片，難以適應于由大規?？芍貥?gòu)單元組成的粗粒度可重構陣列電路。因此，該文針對粗粒度可重構密碼陣列的結構特點，提出基于分區和多變體邏輯指紋的硬件木馬檢測算法。該算法將電路劃分為多個區域，采用邏輯指紋特征作為區域的標識符，通過在時空兩個維度上比較分區的多變體邏輯指紋，實現了無黃金芯片的硬件木馬檢測和診斷。實驗結果表明，所提檢測算法對硬件木馬檢測有較高的檢測成功率和較低的誤判率。
- 硬件木馬檢測 /
- 粗粒度可重構密碼陣列 /
- 邏輯指紋 /
- 多變體
Abstract: Hardware Trojan horse detection has become a hot research topic in the field of chip security. Most existing detection algorithms are oriented to ASIC circuits and FPGA circuits, and rely on golden chips that are not infected with hardware Trojan horses, which are difficult to adapt to the coarse-grained reconfigurable array consisting of large-scale reconfigurable cells. Therefore, aiming at the structural characteristics of Coarse-grained reconfigurable cryptographic logical arrays, a hardware Trojan horse detection algorithm based on partitioned and multiple variants logic fingerprints is proposed. The algorithm divides the circuit into multiple regions, adopts the logical fingerprint feature as the identifier of the region, and realizes the hardware Trojan detection and diagnosis without golden chip by comparing the multiple variant logic fingerprints of the regions in both dimensions of space and time. Experimental results show that the proposed detection algorithm has high detection success rate and low misjudgment rate for hardware Trojan detection.
- Hardware Trojan detection /
- Coarse-grained reconfigurable cryptographic array /
- Logic fingerprints /
- Multiple variants

HTML全文

圖 1 粗粒度可重構密碼陣列硬件結構

下載: 全尺寸圖片幻燈片

圖 2 不同觸發信號的硬件木馬示意

下載: 全尺寸圖片幻燈片

圖 3 CGRCA電路分區示意

下載: 全尺寸圖片幻燈片

圖 4 邏輯指紋檢測原理

下載: 全尺寸圖片幻燈片

圖 5 子任務不同變體執行實例

下載: 全尺寸圖片幻燈片

圖 6 不同區域?qū)Ρ仁疽?/p>

下載: 全尺寸圖片幻燈片

圖 7 算法檢測流程示意圖

下載: 全尺寸圖片幻燈片

圖 8 硬件木馬設計示意圖

下載: 全尺寸圖片幻燈片

圖 9 不同檢測算法結果對比

下載: 全尺寸圖片幻燈片

表 1 檢測結果可能情況

實際情況	檢測情況
實際情況	不含硬件木馬	含有硬件木馬
不含硬件木馬	正確	錯誤
含有硬件木馬	錯誤	正確

下載: 導出CSV

表 2 待測電路具體情況

電路編號	分區數	線網數	輸入	輸出	木馬面積占比(%)
原始電路	16	260	49	44	/
C-10	16	260	49	44	0.015
S-10	16	260	49	44	0.025
CS-5/5	16	260	49	44	0.031

下載: 導出CSV

表 3 檢測算法實驗結果對比(%)

電路編號		ATMR			DRMaSV			RLF			本文算法
電路編號		R_s	R_f	APCO	R_s	R_f	APCO	R_s	R_f	APCO	R_s	R_f	APCO
C-10	AES	91.1	1.02	91.3	97.2	0.37	93.7	93.1	0.45	52.1	97.3	0.31	93.2
	SMS4	92.9	0.98	91.7	97.3	0.35	93.8	93.2	0.41	54.1	97.7	0.29	93.7
	A5/1	89.7	0.99	89.9	93.5	0.32	93.9	91.1	0.37	52.7	94.7	0.30	92.1
	均值	91.2	1.00	91.0	96.0	0.35	93.8	92.5	0.41	53.0	96.6	0.30	93.0
S-10	AES	89.7	1.13	90.2	93.2	0.39	93.5	89.6	0.47	53.7	93.4	0.32	93.3
	SMS4	88.5	1.05	90.3	93.4	0.38	93.9	90.1	0.44	53.9	93.3	0.31	92.9
	A5/1	85.3	1.01	89.7	90.5	0.33	93.4	90.2	0.39	54.1	92.7	0.33	91.7
	均值	87.8	1.06	90.1	92.4	0.37	93.6	90.0	0.43	53.9	93.1	0.32	92.6
CS-5/5	AES	90.1	1.00	91.0	95.3	0.39	93.8	93.0	0.46	54.6	95.4	0.27	92.1
	SMS4	91.3	0.99	91.3	95.6	0.37	94.0	92.7	0.43	54.7	95.6	0.27	93.2
	A5/1	89.3	1.01	90.7	93.7	0.35	93.5	92.3	0.39	53.3	93.7	0.31	92.7
	均值	90.2	1.00	91.0	94.9	0.37	93.8	92.7	0.43	54.2	94.9	0.28	92.7
均值		89.8	1.02	90.7	94.4	0.36	93.7	91.7	0.42	53.7	94.9	0.30	92.8

下載: 導出CSV

參考文獻(16)

AGRAWAL D, BAKTIR S, KARAKOYUNLU D, et al. Trojan detection using IC fingerprinting[C]. IEEE Symposium on Security and Privacy. IEEE Computer Society, Berkeley, USA, 2007: 296–310.

KITSOS P, SIMOS D E, TORRES-Jimenez J, et al. Exciting FPGA cryptographic trojans using combinatorial testing[C]. IEEE International Symposium on Software Reliability Engineering, Gaithersbury, USA, 2016: 69–76.

趙劍鋒, 史崗. 硬件木馬研究動態綜述[J]. 信息安全學報, 2017, 2(1): 74–90. doi: 10.19363/j.cnki.cn10-1380/tn.2017.01.006

ZHAO Jianfeng and SHI Gang. A survey on the studies of hardware trojan[J]. Journal of Cyber Security, 2017, 2(1): 74–90. doi: 10.19363/j.cnki.cn10-1380/tn.2017.01.006

COMPTON K and HAUCK S. Reconfigurable computing: A survey of systems and software[J]. ACM Computing Surveys, 2002, 34(2): 171–210. doi: 10.1145/508352.508353v

VEERANNA N and SCHAFER B C. Hardware trojan avoidance and detection for dynamically re-configurable FPGAs[C]. International IEEE Conference on Field-Programmable Technology. Xi'an, China, 2017: 193–196.

LIU Leibo, ZHOU Zhuoquan, WEI Shaojun, et al. DRMaSV: Enhanced capability against hardware trojans in coarse grained reconfigurable architectures[J]. IEEE Transactions on Computer-Aided Design of Integrated Circuits and Systems, 2017, 37(4): 782–795. doi: 10.1109/TCAD.2017.2729340

KHALEGHI B, AHARI A, ASADI H, et al. FPGA-based protection scheme against hardware trojan horse insertion using dummy logic[J]. IEEE Embedded Systems Letters, 2015, 7(2): 46–50. doi: 10.1109/LES.2015.2406791

PIRPILIDIS F, STEFANIDIS K G, VOYIATZIS A G, et al. On the effects of ring oscillator length and hardware Trojan size on an FPGA-based implementation of AES[J]. Microprocessors & Microsystems, 2017, 54(1): 75–82. doi: 10.1016/j.micpro.2017.09.001

SARAN T, RANJANI R S, DEVI M N, et al. A region based fingerprinting for hardware Trojan detection and diagnosis[C]. International Conference on Signal Processing and Integrated Networks. Noida, India. 2017: 166–172.

MAL-SARKAR S, KARAM R, NARASIMHAN S, et al. Design and validation for FPGA trust under hardware trojan attacks[J]. IEEE Transactions on Multi-Scale Computing Systems, 2017, 2(3): 186–198. doi: 10.1109/TMSCS.2016.2584052

陳韜, 羅興國, 李校南, 等. 一種基于流處理框架的可重構分簇式分組密碼處理結構模型[J]. 電子與信息學報, 2014, 36(12): 3027–3034. doi: 10.3724/SP.J.1146.2014.00023

CHEN Tao, LUO Xingguo, LI Xiaonan, et al. An architecture of stream based reconfigurable clustered block cipher processing array[J]. Journal of Electronics &Information Technology, 2014, 36(12): 3027–3034. doi: 10.3724/SP.J.1146.2014.00023

WAKSMAN A and SETHUMADHAVAN S. Silencing hardware backdoors[C]. IEEE Security and Privacy. Berkeley, USA, 2011: 49–63.

SASHANK K A, REDDY H S, PAVITHRAN P, et al. Hardware trojan detection using effective test patterns and selective segmentation[C]. International Symposium on Security in Computing and Communication. Singapore, 2017: 379–386.

SALMANI H, TEHRANIPOOR M, and PLUSQUELLIC J. A layout-aware approach for improving localized switching to detect hardware trojans in integrated circuits[C]. IEEE International Workshop on Information Forensics and Security, Seattle, USA, 2011: 1–6.

XIAO Kan, FORTE D, JIN Yier, et al. Hardware trojans: lessons learned after one decade of research[J]. ACM Transactions on Design Automation of Electronic Systems, 2016, 22(1): 1–23. doi: 10.1145/2906147

MCINTYRE D, WOLFF F, PAPACHRISTOU C, et al. Trustworthy computing in a multi-core system using distributed scheduling[C]. IEEE On-Line Testing Symposium. Corfu, Greece, 2010: 211–213.
