寬帶高性能四脊波導圓極化器設計

王進; 杜彪; 孫立杰; 解磊

doi:10.11999/JEIT180423

寬帶高性能四脊波導圓極化器設計

doi: 10.11999/JEIT180423

王進^1, ,,
杜彪¹,
孫立杰¹,
解磊^{1, 2}

1.
中國電子科技集團公司第五十四研究所 ??石家莊 ??050081
2.
西安電子科技大學天線與微波技術重點實驗室 ??西安 ??710071

基金項目: 國家高技術研究發展計劃(2014AA123601)，政府間國際科技創新合作重點專項(2016YFE0100100)

詳細信息

作者簡介:
王進：男，1983年生，博士生，高級工程師，研究方向?yàn)槲⒉o源器件、天線饋電網絡與饋源技術

杜彪：男，1962年生，博士生導師，研究員，研究方向?yàn)榉瓷涿嫣炀€和高效率饋源、陣列天線和超材料天線等

孫立杰：男，1985年生，工程師，研究方向?yàn)槲⒉o源器件、天線饋電網絡

解磊：男，1985年生，博士生，研究方向?yàn)樾l(wèi)星通信天線與饋源技術

通訊作者:
王進　15831969575@139.com

中圖分類號: TN821
計量
- 文章訪問數: 4042
- HTML全文瀏覽量: 1819
- PDF下載量: 216
- 被引次數: 0
出版歷程
- 收稿日期: 2018-05-04
- 修回日期: 2018-10-10
- 網絡出版日期: 2018-11-01
- 刊出日期: 2019-03-01

Design of Wideband High Performance Quad-ridge Waveguide Polarizer

Jin WANG^{1
, ,},
Biao DU¹,
Lijie SUN¹,
Lei XIE^{1, 2}

1.
The 54th Research Institute of CETC, Shijiazhuang 050081, China
2.
Science and Technology on Antenna and Microwave Laboratory, Xidian University, Xi’an 710071, China

Funds: The National High Technology Research and Development Program of China (2014AA123601), The Bilateral Inter-Governmental Science and Technology Cooperation Proposal of China (2016YFE0100100)

摘要

摘要:
在射電望遠鏡和衛星通信天線中，圓極化器是關鍵部件之一。傳統圓極化器在保證0.75 dB軸比時的相對帶寬最多為41%，無法滿足日益增長的寬頻帶應用需求。該文利用四脊波導的寬帶特性，通過采用具有不同尺寸的水平脊和垂直脊，使四脊波導兩個正交主模的相位常數不同，來實現寬帶移相特性，并給出了一種寬帶四脊波導圓極化器的設計方法。按照這一方法，設計了一款寬帶C波段圓極化器，工作帶寬為3.625～7.025 GHz，相對帶寬64%。該文還研究了圓極化器主要參數變化對其性能的影響，加工并實測了一個圓極化器樣機。實測結果顯示出，該圓極化器兩個正交極化的反射損耗均小于–21 dB，相差90°±3.8°，相應的軸比小于0.6 dB。測試與仿真結果吻合良好，證明了分析與設計方法的正確性。
- 天線 /
- 圓極化器 /
- 寬頻帶 /
- 四脊波導 /
- 敏感性分析
Abstract:
Circular polarizer is a key component in feed systems with circular polarization in radio astronomy telescope and satellite communication antennas. Conventional polarizers are capable of operating over a maximum bandwidth of 40% with an axial ratio value of 0.75 dB, which is unable to meet the growing demand for wide band applications. In this paper, the design of the wide band quad ridges waveguide polarizer is introduced, and the relationship between the phase constants of two orthogonal principal modes is analyzed. The broadband phase shift characteristics are achieved by employing different horizontal and vertical ridges dimensions. Based on this method, a C-Band polarizer is designed, which operates at 3.625～7.025 GHz, 64% bandwidth. The effects of main parameters on the polarizer performances are studied. A prototype of the polarizer is developed. The measurements of the prototype show that return losses are less than –21 dB for two orthogonal polarizations and the phase difference is 90°±3.8°, the corresponding axial ratio is less than 0.6 dB. Measured and simulated results show good agreements, thus validating the analysis and design methods.
- Antenna /
- Circular polarizer /
- Wideband /
- Quad-ridge waveguide /
- Sensitivity analysis

HTML全文

圖 1 四脊波導圓極化器結構示意圖

下載: 全尺寸圖片幻燈片

圖 2 四脊波導TE₁₀和TE₀₁模場分布圖

下載: 全尺寸圖片幻燈片

圖 3 四脊波導圓極化器仿真模型

下載: 全尺寸圖片幻燈片

圖 4 相位常數隨頻率的變化曲線

下載: 全尺寸圖片幻燈片

圖 5 垂直脊厚度s₁對圓極化器性能的影響圖

下載: 全尺寸圖片幻燈片

圖 6 水平脊厚度s₂對圓極化器性能的影響

下載: 全尺寸圖片幻燈片

圖 7 垂直脊間距d₁對圓極化器性能的影響

下載: 全尺寸圖片幻燈片

圖 8 水平脊間距d₂對圓極化器性能的影響

下載: 全尺寸圖片幻燈片

圖 9 圓極化器結構與加工工藝設計

下載: 全尺寸圖片幻燈片

圖 10 s₁, s₂, d₁, d₂誤差均為+0.03 mm或?yàn)楱C0.03 mm情況下對圓極化器性能影響

下載: 全尺寸圖片幻燈片

圖 11 s₁, d₂誤差為+0.03 mm, s₂, d₁為–0.03 mm和s₁, d₂為–0.03 mm, s₂, d₁為+0.03 mm情況下對圓極化器性能影響

下載: 全尺寸圖片幻燈片

圖 12 圓極化器樣機照片和性能仿真與測試結果

下載: 全尺寸圖片幻燈片

表 1 四脊波導結構參數值

參數	a	b	d₁	d₂	s₁	s₂
數值	45	45	13	31	7	4

下載: 導出CSV

表 2 四脊波導圓極化器主要參數表

參數	a	b	d₁	d₂	s₁	s₂	L
數值	47.13	47.13	12.93	32.24	6.84	4.67	207

下載: 導出CSV

表 3 四脊波導圓極化器與其他型式圓極化器的實測性能比較

圓極化器類型	相對帶寬(%)	反射損耗(dB)	相位平坦度	軸比(dB)	來源
螺釘極化器	15	≤ –20	90°±3°	≤ 0.50	文獻[4,5]
介質極化器	25	≤ –20	90°±4.5°	≤ 0.75	文獻[6,7]
波紋極化器	41	≤ –24	90°±4°	≤ 0.60	文獻[8–10]
隔板極化器	23	≤ –25	90°±5°	≤ 0.75	文獻[11–16]
雙脊極化器	15	≤ –25	90°±3°	≤ 0.50	文獻[17,18]
四脊極化器	64	≤ –21	90°±3.8°	≤ 0.60	本文

下載: 導出CSV

參考文獻(18)

RAHMAT-SAMII Y and DENSMORE A C. Technology trends and challenges of antennas for satellite communication systems[J]. IEEE Transactions on Antennas and Propagation, 2015, 63(4): 1191–1204. doi: 10.1109/TAP.2014.2366784

王進, 杜彪, 焦永昌, 等. 寬頻帶四端口饋源網絡系統設計[J]. 電子與信息學報, 2017, 39(6): 1313–1318. doi: 10.11999/JEIT160918

WANG Jin, DU Biao, JIAO Yongchang, et al. Design of broadband 4-port feed network system[J]. Journal of Electronics &Information Technology, 2017, 39(6): 1313–1318. doi: 10.11999/JEIT160918

陳卯蒸, 劉奇, 馬軍, 等. 大口徑射電望遠鏡超寬帶接收機發展[J]. 中國科學: 物理學力學天文學, 2017, 47(5): 1–13. doi: 10.1360/SSPMA2016-00505

CHEN Maozheng, LIU Qi, MA Jun, et al. Ultra-wideband receiver technology development for radio astronomical large aperture telescope (in Chinese)[J]. Scientia Sinica Physica,Mechanica &Astronomica, 2017, 47(5): 1–13. doi: 10.1360/SSPMA2016-00505

SUBBARAO B and FUSCO V F. Compact coaxial-fed CP polarizer[J]. IEEE Antennas and Wireless Propagation Letters, 2004, 3(1): 145–147. doi: 10.1109/LAWP.2004.831084

施陽, 石志東, 李銘祥, 等. 8 mm 波導螺釘圓極化器的設計與優化[J]. 上海大學學報(自然科學版), 2007, 13(2): 134–137. doi: 10.3969/j.issn.1007-2861.2007.02.006

SHI Yang, SHI Zhidong, LI Mingxiang, et al. Design and optimization of waveguide circular polarizer using 8 mm adjustable metal screws[J]. Journal of Shanghai University (Natural Science), 2007, 13(2): 134–137. doi: 10.3969/j.issn.1007-2861.2007.02.006

WANG S W, CHIEN C H, and WANG C L. A circular polarizer designed with a dielectric septum loading[J]. IEEE Transactions on Microwave Theory and Techniques, 2004, 52(7): 1719–1723. doi: 10.1109/TMTT.2004.830487

ZHANG T L and YAN Z H. A Ka dual-band circular waveguide polarizer[C]. 7th International Symposium on Antennas, Propagation & EM Theory, Guilin, China, 2006: 1–4.

USHIJIMA Y, YUKAWA H, YONEDA N, et al. Dual band rectangular waveguide polarizer using corrugated/elongated conductive plates for Ka-band[C]. 47th European Microwave Conference (EuMC), Nuremberg, Germany, 2017: 520–523.

王海倫, 李斌. K波段寬帶圓極化器設計[J]. 天文研究與技術, 2015, 12(4): 455–460. doi: 10.3969/j.issn.1672-7673.2015.04.010

WANG Hailun and LI Bin. A design of a K-band circular polarizer[J]. Astronomical Research and Technology, 2015, 12(4): 455–460. doi: 10.3969/j.issn.1672-7673.2015.04.010

賈茹, 李斌. 天馬望遠鏡Ka波段寬帶圓極化器研制[J]. 天文研究與技術, 2017, 14(4): 488–494. doi: 10.14005/j.cnki.issn1672-7673.20170922.002

JIA Ru and LI Bin. Development of Ka-band wideband circular polarizer[J]. Astronomical Research and Technology, 2017, 14(4): 488–494. doi: 10.14005/j.cnki.issn1672-7673.20170922.002

CHAKRABARTI S. Microwave conical horn antenna with dual circular polarization—Close-form design equations[J]. International Journal of RF and Microwave Computer-Aided Engineering, 2018, 28(7): 1–9. doi: 10.1002/mmce.21398

向小春, 張宇環, 金偉清, 等. 一種Ka頻段金屬膜片圓極化器設計[J]. 無線電工程, 2017, 47(11): 59–62. doi: 10.3969/j.issn.003-3106.2017.11.13

XIANG Xiaochun, ZHANG Yuhuan, JIN Weiqing, et al. A design of Ka-band metal waveguide iris circular polarizer[J]. Radio Engineering, 2017, 47(11): 59–62. doi: 10.3969/j.issn.003-3106.2017.11.13

LEAL-SEVILLANO C A, COOPER K B, and RUIZ-CRUZ J A. A 225 GHz circular polarization waveguide duplexer based on a septum orthomode transducer polarizer[J]. IEEE Transactions on Terahertz Science and Technology, 2013, 3(5): 574–583. doi: 10.1109/TTHZ.2013.2264317

史俊, 殷曉星, 仲偉業. K波段低軸比的隔板式極化器[J]. 微波學報, 2017, 33(6): 21–24. doi: 10.14183/j.cnki.1005-6122.201706005

SHI Jun, YIN Xiaoxing, and ZHONG Weiye. Band septum polarizer with low axial ratio[J]. Journal of Microwaves, 2017, 33(6): 21–24. doi: 10.14183/j.cnki.1005-6122.201706005

HASEGAWA Y, HARADA R, TOKUDA K, et al. A new approach to suppress the effect of machining error for waveguide septum circular polarizer at 230 GHz band in radio astronomy[J]. Journal of Infrared Millimeter & Terahertz Waves, 2017, 38(5): 638–652. doi: 10.1007/s10762-017-0364-3

JAZANI G and PIRHADI A. Design of dual-polarised (RHCP/LHCP) quad-ridged horn antenna with wideband septum polariser waveguide feed[J]. IET Microwaves, Antennas & Propagation, 2018, 12(9): 1541–1545. doi: 10.1049/iet-map.2017.0611

MANUILOV M B and KOBRIN K V. Dual band compact polarizer based on ridged sections in square waveguide[C]. 2016 International Conference on Actual Problems of Electron Devices Engineering, Saratov, Russia, 2016: 1–5.

MANUILOV M B and KOBRIN K V. Fast and accurate technique for CAD of ridge waveguide polarizers[C]. Progress in Electromagnetics Research Symposium-Spring (PIERS), St.Petersburg, Russia, 2017: 1181–1183.
