基于PolInSAR的植被區高精度數字表面模型反演方法
doi: 10.11999/JEIT180387
-
西安電子科技大學雷達信號處理國家重點實驗室 ??西安 ??710071
High-precision Digital Surface Model Inversion Approach in Forest Region Based on PolInSAR
-
National Laboratory of Radar Signal Processing, Xidian University, Xi’an 710071, China
-
摘要:
針對傳統方法無法估計電磁波在植被中的穿透深度導致植被數字表面模型(DSM)反演誤差較大的問題，該文提出一種高精度DSM估計方法。該方法首先通過極化干涉相干最優中最大化相位差法分離得到電磁波在植被中高、低散射相位中心的干涉相位。然后提出一種歸一化高、低散射相位中心高度隨消光系數變化的模型，基于該模型搜索得到電磁波在植被中的最淺穿透深度。最后利用干涉處理方法得到高散射相位中心的高程，將最淺穿透深度補償?shù)皆摳叱讨?，從而提升植被區DSM估計精度。利用PolSARpro軟件在不同植被種類和不同植被高度下進行仿真試驗以及機載全極化數據進行實測數據試驗，試驗結果表明該方法能有效提高植被區DSM反演精度。
-
關鍵詞:
- 極化干涉 /
- 散射相位中心 /
- 穿透深度 /
- 數字表面模型
Abstract:The general method for inversion of Digital Surface Model (DSM) in forest region has great errors due to the inestimable waves’ penetration depth. For this problem, an approach to inversion of high-precision DSM is proposed. First, the phases of high and low scattering phase centers of the waves in forest are obtained by maximizing the phase separation of the coherence optimization. Then, the normal height variation models of the high and low scattering centers with extinction factors are constructed. According to the models, the least penetration depth of the waves in forest is acquired. Eventually, by implementing the interferometric technique on the phase of high scattering phase center, a coarse DSM is retrieved, and a high-precision DSM is developed by compensating the least penetration depth to the coarse one. The validation of the method is investigated by simulated datasets of PolSARpro under different tree species and different forest heights and by airborne real datasets. It shows that the proposed method can improve the accuracy on the inversion of DSM effectively in forest region.
-
表 1 雷達幾何參數
參數名 參數值 雷達平臺高度 3000 有效基線長度 6.33 雷達下視角(°) 45 雷達工作頻率(GHz) 1.3
下載: 導出CSV
表 2 場景參數
參數名 參數值 樹種類型 闊葉林/針葉林 植被高度 18/10 樹種密度(株/Ha) 600 距離向地形坡度(°) 0
下載: 導出CSV
-
ROSEN P A, HENSLEY S, JOUGHIN I R, et al. Synthetic aperture radar interferometry[J]. Proceedings of IEEE, 2000, 88(3): 333–382. doi: 10.1109/5.838084 CLARK M L, CLARK D B, and ROBERTS D A. Small-footprint Lidar estimation of sub-canopy elevation and tree height in a tropical rain forest landscape[J]. Remote Sensing of Environment, 2004, 91(1): 68–89. doi: 10.1016/j.rse.2004.02.008 ANDERSEN H E, REUTEBUCH S E, and MCGAUGHEY R J. Active Remote Sensing[M]. Netherlands: Springer, 2006: 43–66. doi: 10.1007/978-1-4020-4387-1_3. GUSTAVO H X, KARLUS A, CAMARA D M, et al. The dual-band PolInSAR method for forest parametrization[J]. IEEE Journal of Selected Topics in Applied Earth Observations and Remote Sensing, 2017, 9(7): 3189–3201. doi: 10.1109/JSTARS.2016.2520900 GONZáLEZ C, BR?UTIGAM B, RIZZOLI P, et al. Relative height accuracy analysis of Tandem-X DEM products[C]. The 11th European Conference on Synthetic Aperture Radar, Hamburg, Germany, 2016: 1172–1176. YASER S, BENO?T S, BRIGITTE L, et al. Canopy Height Model (CHM) derived from a TanDEM-X InSAR DSM and an airborne lidar DTM in boreal forest[J]. IEEE Journal of Selected Topics in Applied Earth Observations and Remote Sensing, 2016, 9(1): 381–397. doi: 10.1109/JSTARS.2015.2512230 周偉, 陳爾學, 劉國林, 等. 基于ALOS極化干涉SAR數據的DEM提取方法研究[J]. 遙感技術與應用, 2013, 28(1): 44–51. doi: 10.11873/j.issn.1004-0323.2013.1.44ZHOU Wei, CHEN Erxue, LIU Guolin, et al. Extract DEM from ALOS based on polarinetric SAR Interferometry[J]. Remote Sensing Technology and Application, 2013, 28(1): 44–51. doi: 10.11873/j.issn.1004-0323.2013.1.44 龍江平, 劉峰, 段祝庚. 聯合干涉相位和相干性幅度的極化干涉SAR最優相干性估計[J]. 測繪學報, 2017, 46(1): 73–82. doi: 10.11947/j.AGCS.2017.20150509LONG Jiangping, LIU Feng, and DUAN Zhugeng. A new method of coherence optimization based on the phase and coherence magnitude in polarimetric SAR interferometry[J]. Acta Geodaetica et Cartographica Sinica, 2017, 46(1): 73–82. doi: 10.11947/j.AGCS.2017.20150509 KUGLER F, LEE S K, HAJNSEK I, et al. Forest height estimation by means of Pol-InSAR data inversion: The role of the vertical wavenumber[J]. IEEE Transactions on Geoscience and Remote Sensing, 2015, 53(10): 5294–5311. doi: 10.1109/TGRS.2015.2420996 CLOUDE S R. Polarization Application in Remote Sensing[M]. Oxford: Oxford University Press, 2009: 265–274. 盧紅喜, 宋文青, 李飛, 等. 基于幅相一致性校正的穩健植被參數反演方法[J]. 電子與信息學報, 2015, 37(2): 283–290. doi: 10.11999/JEIT140261LU Hongxi, SONG Wenqing, LI Fei, et al. Forest parameters inversion based on nonstationarity compensation and mapping space regularization[J]. Journal of Electronics &Information Technology, 2015, 37(2): 283–290. doi: 10.11999/JEIT140261 孫寧霄, 吳瓊之, 孫林. 基于PolInSAR相干區域的最優正規矩陣近似解的地形與樹高估計[J]. 電子與信息學報, 2017, 39(5): 1051–1057. doi: 10.11999/JEIT160774SUN Ningxiao, WU Qiongzhi, and SUN Lin. Topography and tree height estimation based on the best normal matrix approximation for polinsar coherence region[J]. Journal of Electronics &Information Technology, 2017, 39(5): 1051–1057. doi: 10.11999/JEIT160774 FRANCK G and THUY L T. Forest modeling for height inversion using single-baseline InSAR/Pol-InSAR data[J]. IEEE Transactions on Geoscience and Remote Sensing, 2010, 48(3): 1528–1539. doi: 10.1109/TGRS.2009.2032538 LAGARIAS J C, REEDS J A, WRIGHT M H, et al. Convergence properties of the nelder-mead simplex method in low dimensions[J]. SIAM Journal of Optimization, 1998, 9(1): 112–147. doi: 10.1137/S1052623496303470 BANDA F and TEBALDINI S. Texture-free absolute DEM retrieval from opposite-side multibaseline InSAR data[J]. IEEE Geoscience and Remote Sensing Letters, 2016, 13(1): 43–47. doi: 10.1109/LGRS.2015.2494684 CHOI C and KIM D J. Optimum baseline of a single-pass InSAR system to generate the best DEM in tidal flats[J]. IEEE Journal of Selected Topics in Applied Earth Observations & Remote Sensing, 2018, 11(3): 919–929. doi: 10.1109/JSTARS.2018.2795107 BRYAN M, ZHANG Q P, MARCUS S, et al. Extraction of DTM beneath forest canopy using a combination of X-Band InSAR and L-band PolInSAR data[C]. European Conference on Synthetic Aperture Radar, Aachen, Germany, 2010: 821–824. -
