一種適于縫隙等表面缺陷類目標的評估方法

趙京城; 付鑫如; 楊濤; 高旭; 艾俊強

doi:10.11999/JEIT180378

一種適于縫隙等表面缺陷類目標的評估方法

doi: 10.11999/JEIT180378

1.
北京航空航天大學電子信息工程學院 ??北京 ??100191
2.
航空工業第一飛機設計研究院 ??西安 ??710089

詳細信息

作者簡介:
趙京城：男，1979年生，講師，主要研究方向?yàn)槲⒉〝?shù)字信號處理、微波毫米波成像、輻射散射測量

付鑫如：女，1995年生，碩士生，研究方向?yàn)槲⒉ê撩撞ǔ上?/p>
楊濤：男，1993年生，碩士生，研究方向?yàn)槲⒉ê撩撞y量及成像、VxWorks系統嵌入式應用-雷達模擬器

高旭：女，1983年生，高級工程師，主要研究方向?yàn)轱w行器總體及隱身設計

艾俊強：男，1964年生，研究員，主要研究方向?yàn)轱w機總體與氣動設計

通訊作者:
楊濤　buaaviptao@163.com

中圖分類號: V218
計量
- 文章訪問數: 1256
- HTML全文瀏覽量: 572
- PDF下載量: 61
- 被引次數: 0
出版歷程
- 收稿日期: 2018-04-25
- 修回日期: 2018-11-13
- 網絡出版日期: 2018-11-19
- 刊出日期: 2019-02-01

Assessment Method for Gaps and Other Surface Defects

1.
School of Electronics and Information Engineering, Beihang University, Beijing 100191, China
2.
Avic The First Aircraft Institute, Xi’an 710089, China

摘要

摘要:
縫隙等表面缺陷類目標對飛行器的隱身性能具有重要影響。根據縫隙等表面缺陷類目標的散射機理，該文提出一種載體背景對消方法，用于評估表面缺陷類目標散射。該方法將載體作為目標背景的一部分，通過矢量場相減的方式對消掉載體的自身散射影響，特別是載體強散射角域的散射影響，從而獲得了全角域范圍內表面缺陷類目標的散射特性數據，解決了使用常規方法目標受載體影響無法獲得完整散射特性的問題。通過數值計算和實驗測量的結果對比表明：該方法可以對缺陷類目標的電磁散射特性進行有效評估。對消后載體散射得到了極大程度的降低，有效提高了缺陷類目標的計算或測量精度；同時由于排除載體自身散射的影響，避免了對載體尺寸、超低散射特性的要求，有效降低了載體的加工設計成本。
- 雷達散射截面 /
- 矢量對消 /
- 電磁缺陷 /
- 數值計算 /
- 實驗測量
Abstract:
Surface defects such as gaps have a significant impact on the stealth performance of the aircraft. According to the scattering mechanism of surface defects such as gaps, a method of evaluating the surface defect targets based on vector cancellation is proposed. The carrier is regarded as the target background and is subtracted the scattering effect of the carrier, especially the strong scattering angle of the carrier, and then the scattering characteristic data of the surface defect class target in the whole angle range are obtained, which solves the problem that the complete scattering characteristic can not be obtained using the conventional method. The comparison between the numerical calculation and the experimental results shows that the vector cancellation method can effectively evaluate the electromagnetic scattering characteristics of defective targets. After vector cancellation, the scattering of the carrier is greatly reduced, and the calculation or measurement accuracy of the defective target is effectively improved. At the same time, due to reducing the influence of the scattering of the carrier itself, this method avoids the requirement of the carrier size and ultra-low scattering characteristics, and reduces effectively the processing cost of the carrier.
- Radar Cross Section (RCS) /
- Vector cancellation /
- Electromagnetic defect /
- Numerical calculation /
- Experimental measurement

HTML全文

圖 1 單縫隙計算模型

下載: 全尺寸圖片幻燈片

圖 2 入射角度示意圖

下載: 全尺寸圖片幻燈片

圖 3 縫隙板和光滑板RCS隨角度變化曲線

下載: 全尺寸圖片幻燈片

圖 4 數值計算1維成像圖

下載: 全尺寸圖片幻燈片

圖 5 22°下縫隙板的俯視圖

下載: 全尺寸圖片幻燈片

圖 6 兩種方法獲得的縫隙2維成像圖

下載: 全尺寸圖片幻燈片

圖 7 不同方法獲得的2維成像圖

下載: 全尺寸圖片幻燈片

圖 8 常規方法及對消法獲得的縫隙RCS曲線

下載: 全尺寸圖片幻燈片

圖 9 緊縮場中目標RCS測量示意圖

下載: 全尺寸圖片幻燈片

圖 10 圓錐載體上有鋸齒縫的示意圖

下載: 全尺寸圖片幻燈片

圖 11 圓錐載體上有鋸齒縫的實物圖

下載: 全尺寸圖片幻燈片

圖 12 緊縮場微波暗室中的縫隙模型圖

下載: 全尺寸圖片幻燈片

圖 13 兩種方法獲得的鋸齒縫隙2維成像圖

下載: 全尺寸圖片幻燈片

圖 14 對消前后鋸齒縫的RCS測試曲線

下載: 全尺寸圖片幻燈片

圖 15 對消前后載體自身的RCS測試曲線

下載: 全尺寸圖片幻燈片

圖 16 對消后鋸齒縫及背景電平的RCS測試曲線

下載: 全尺寸圖片幻燈片

參考文獻(21)

柴建忠, 高旭, 劉學強, 等. 幾種載體表面縫隙對雷達目標特性的影響[J]. 南京航空航天大學學報, 2014, 46(4): 567–572. doi: 10.16356/j.1005-2615.2014.04.022

CHAI Jianzhong, GAO Xu, LIU Xueqiang, et al. Effect of gaps in different surfaces on radar target characteristic[J]. Journal of Nanjing University of Aeronautics &Astronautics, 2014, 46(4): 567–572. doi: 10.16356/j.1005-2615.2014.04.022

桑建華, 張宗斌, 王爍. 低RCS飛行器表面弱散射源研究[J]. 航空工程進展, 2012, 3(3): 257–262. doi: 10.16615/j.cnki.1674-8190.2012.03.008

SANG Jianhua, ZHANG Zongbin, and WANG Shuo. Research on the radar cross section of weak scatters on stealth vehicle[J]. Advances in Aeronautical Science and Engineering, 2012, 3(3): 257–262. doi: 10.16615/j.cnki.1674-8190.2012.03.008

何國瑜, 盧才成, 洪家才, 等. 電磁散射的計算和測量[M]. 北京: 北京航空航天大學出版社, 2006: 19–20.

HE Guoyu, LU Caicheng, HONG Jiacai, et al. The Computation and Test for RCS[M]. Beijing: Beihang University Press, 2006: 19–20.

劉戰合, 黃沛霖, 高旭. 表面不連續特征雙站散射特性的試驗研究[J]. 航空學報, 2009, 30(12): 2322–2327. doi: 10.3321/j.issn:1000-6893.2009.12.013

LIU Zhanhe, HUANG Peilin, and GAO Xu. Experimental research on biostatic scattering characteristics of surface discontinuous character[J]. Acta Aeronautics et Astronautica Sinica, 2009, 30(12): 2322–2327. doi: 10.3321/j.issn:1000-6893.2009.12.013

劉戰合, 蔣勝矩, 姬金祖, 等. 基于MLFMA的表面臺階多頻散射特性[J]. 探測與控制學報, 2009, 31(z1): 20–24. doi: 10.3969/j.issn.1008-1194.2009.z1.007

LIU Zhanhe, JIANG Shengju, JI Jinzu, et al. Multi-frequencies scattering characteristic of steps in surface based on MLFMA[J]. Journal of Detection &Control, 2009, 31(z1): 20–24. doi: 10.3969/j.issn.1008-1194.2009.z1.007

袁俊超, 張小寬, 孫銘, 等. 基于FEKO隱身飛機目標動態角閃爍特性實時仿真[J]. 現代雷達, 2017, 39(8): 58–62. doi: 10.16592/j.cnki.1004-7859.2017.08.013

YUAN Junchao, ZHANG Xiaokuan, SUN Ming, et al. Analysis of stealth aircraft target’s dynamic angular glint charac teristics based on FEKO[J]. Modern Radar, 2017, 39(8): 58–62. doi: 10.16592/j.cnki.1004-7859.2017.08.013

趙京城, 楊濤, 付鑫如, 等. 基于載體對消方法的縫隙小角域散射特性研究[J]. 北京航空航天大學學報, 2018, 44(7): 1554–1561. doi: 10.13700/j.bh.1001-5965.2017.0498

ZHAO Jingcheng, YANG Tao, FU Xinru, et al. Research on small angle domain scattering characteristics based on carrier cancellation method[J]. Journal of Beijing University of Aeronautics and Astronautics, 2018, 44(7): 1554–1561. doi: 10.13700/j.bh.1001-5965.2017.0498

WU Taitsun. High frequency scattering[J]. Physics Review Journals, 1956, 104(5): 1201–1212.

LAGER D L and LYTLE R J. Determining a subsurface electromagnetic profile from high-frequency measurements by applying reconstruction-technique algorithms[J]. Radio Science, 2016, 12(2): 249–260.

HARRING RogerF. Field Computation by Moment Methods[M]. London, England: Macmillan, 1968: 120–148.

張文, 胡俊, 張婕玲, 等. 一種新型的矩量法并行實現方法[J]. 微波學報, 2017, 33(S1): 26–29.

ZHANG Wen, HU Jun, ZHANG Jieling, et al. A new parallel realization for MOM[J]. Journal of Microwave, 2017, 33(S1): 26–29.

CHEN K S, WU Tzongdar, TSANG Leung, et al. Emission of rough surfaces calculated by the integral equation method with comparison to three-dimensional moment method simulations[J]. IEEE Transactions on Geoscience & Remote Sensing, 2003, 41(1): 90–101. doi: 10.1109/TGRS.2002.807587

高旭, 楊碩, 柴建忠, 等. 基于矢量對消的缺陷類目標散射試驗改進方法[J]. 北京航空航天大學學報, 2017, 43(7): 1293–1299. doi: 10.13700/j.bh.1001-5965.2016.0517

GAO Xu, YANG Shuo, CHAI Jianzhong, et al. Improved measurement method based on vector cancellation for scattering characteristic of electromagnetic discontinuities targets[J]. Journal of Beijing University of Aeronauties and Astronautics, 2017, 43(7): 1293–1299. doi: 10.13700/j.bh.1001-5965.2016.0517

趙京城, 田進軍, 楊碩, 等. 一種弱散射目標的RCS測量方法[P]. 中國專利, CN106443611A. 2017.

ZHAO Jingcheng, TIAN Jinjun, YANG Shuo, et al. A RCS measurement method for electromagnetic discontinuities tar-gets [P]. Patent, China, CN106443611A, 2017.

SENIOR T B A, SARABANDI K, and NATZKE J R. Natzke scattering by a narrow gap[J]. IEEE Transactions on Antennas and Propagation, 1990, 38(7): 1102–1110. doi: 10.1109/8.55624

PARK T J, KANG S H, and EOM H J. TE scattering from a slit in a thick conducting screen: Revisited[J]. IEEE Transactions On Antennas And Propagation, 1994, 42(1): 112–114. doi: 10.1109/8.272309

SHENG Xining, YUNG Edward K N, CHAN C H, et al. Scattering from a large body with cracks and cavities by the fast and accurate finite-element boundary-integral method[J]. IEEE Transactions on Antennas and Propagation, 2000, 48(8): 1153–1160. doi: 10.1109/8.884482

袁寧, 聶小春, 梁昌洪. 有限厚導電平板上任意縫隙的耦合特性分析[J]. 電波科學學報, 1999, 14(3): 261–267. doi: 10.13443/j.cjors.1999.03.004

YUAN Ning, NIE Xiaochun, LIANG Changhong. Analysis of coupling properties of an arbitrary slit in a thick conducting plate[J]. Chinese Journal of Radio Science, 1999, 14(3): 261–267. doi: 10.13443/j.cjors.1999.03.004

曾學剛, 林為干, 阮成禮. 有耗目標的電磁相似性及矩形涂覆平板RCS的縮比關系[J]. 應用科學學報, 1993, 11(3): 213–218.

ZENG Xuegang, LIN Weigan, and RUAN Chengli. The electromagnetic similitude of the object containing lossy materials and the RCS scaled-down relationships of the coated plate[J]. Journal of Applied Sciences, 1993, 11(3): 213–218.

黃沛霖, 劉戰合. 飛行器表面縫隙電磁散射特性研究[J]. 航空學報, 2008, 29(3): 675–680. doi: 10.3321/j.issn:1000-6893.2008.03.023

HUANG Peilin and LIU Zhanhe. Research on electromagnetic scattering characteristics of slits on aircraft[J]. Acta Aeronautica et Ast ronautica Sinica, 2008, 29(3): 675–680. doi: 10.3321/j.issn:1000-6893.2008.03.023

呂可, 鄭威. 角反射體RCS微波暗室測量及分析[J]. 計算機測量與控制, 2016, 24(9): 28–31. doi: 10.16526/j.cnki.11-4762/tp.2016.09.008

Lü Ke and ZHENG Wei. Measurement and analysis of corner reflector’s RCS in microwave anechoic chamber[J]. Computer Measurement and Control, 2016, 24(9): 28–31. doi: 10.16526/j.cnki.11-4762/tp.2016.09.008
