超高頻射頻識別近場系統互耦效應中頻率偏移研究

何怡剛,  佘培亮,  佐磊,  張超群

何怡剛, 佘培亮, 佐磊, 張超群. 超高頻射頻識別近場系統互耦效應中頻率偏移研究[J]. 電子與信息學報, 2019, 41(3): 602-610. doi: 10.11999/JEIT180375
引用本文: 何怡剛, 佘培亮, 佐磊, 張超群. 超高頻射頻識別近場系統互耦效應中頻率偏移研究[J]. 電子與信息學報, 2019, 41(3): 602-610. doi: 10.11999/JEIT180375
Yigang HE, Peiliang SHE, Lei ZUO, Chaoqun ZHANG. Study on Frequency Shift in Mutual Coupling Effect of Ultra-high-frequency Radio Frequency IDentification Near-field System[J]. Journal of Electronics & Information Technology, 2019, 41(3): 602-610. doi: 10.11999/JEIT180375
Citation: Yigang HE, Peiliang SHE, Lei ZUO, Chaoqun ZHANG. Study on Frequency Shift in Mutual Coupling Effect of Ultra-high-frequency Radio Frequency IDentification Near-field System[J]. Journal of Electronics & Information Technology, 2019, 41(3): 602-610. doi: 10.11999/JEIT180375

超高頻射頻識別近場系統互耦效應中頻率偏移研究

doi: 10.11999/JEIT180375

  • 合肥工業大學電氣與自動化工程學院 ??合肥 ??230000

基金項目: 國家自然科學基金(51577046, 51637004)，國家重點研發計劃(2016YFF0102200)
詳細信息
    作者簡介:

    何怡剛：男，1966年生，教授，博士生導師，研究方向為射頻識別技術、高速低壓低耗集成電路、物聯網技術、混合信號電路與系統測試與診斷等

    佘培亮：男，1993年生，碩士生，研究方向為射頻識別技術和標簽集成電路設計與測試等

    佐磊：男，1982年生，副教授，碩士生導師，研究方向為射頻識別技術、物聯網技術、信號處理及智能電網等

    張超群：女，1994年生，碩士生，研究方向為射頻識別技術和物聯網技術等

    通訊作者:

    何怡剛　18655136887@163.com

  • 中圖分類號: TN801; TP391.45

Study on Frequency Shift in Mutual Coupling Effect of Ultra-high-frequency Radio Frequency IDentification Near-field System

  • School of Electrical Engineering and Automation, Hefei University of Technology, Hefei 230000, China

Funds: The National Natural Science Foundation of China (51577046, 51637004), The National Key Research and Development Plan (2016YFF0102200)
  • 摘要:

    在超高頻射頻識別(UHF RFID)系統近場(NF)密集標簽應用中，由于微帶標簽天線的結構特點，傳統線圈間互阻抗表達式在預估系統頻率偏移等互耦效應問題方面誤差較大，精確性不夠。首先，基于變壓器模型，從無線電能傳輸?shù)慕嵌韧茖?dǎo)了近場密集標簽間的互阻抗表達式。然后，結合近場電感耦合型標簽，通過建立電磁仿真模型間接獲取有關電氣參數值。最后，驗證推導公式并從影響雙標簽間互阻抗的環境因素角度去研究UHF RFID近場頻率偏移問題。測試結果表明，當標簽間距小于30 mm時，推導的互阻抗表達式應用于頻率偏移計算誤差范圍為1.6～7.3 MHz。研究結果為基于標簽間互阻抗預估UHF RFID近場標簽間的互耦效應問題提供了參考依據。

    Abstract:

    In Near-Field (NF) applications of Ultra-High-Frequency Radio Frequency IDentification (UHF RFID) systems, due to the structural characteristics of the microstrip tag, the traditional inter-coil mutual impedance expression has a large error in the estimation of the mutual coupling effect such as the frequency shift of the prediction system, and the accuracy is not enough. Firstly, based on the transformer model, the mutual impedance expressions of the NF dense tags are derived from the perspective of radio energy transmission. Then, the electrical parameter values are obtained indirectly by establishing the electromagnetic simulation model combining with the NF inductance coupling tag. Finally, the derivation formula is verified and UHF RFID NF frequency shift is studied from the perspective of environmental factors that affect the mutual impedance between the two tags. The test results show that the derived mutual impedance expression is applied to the frequency offset calculation with error range in 1.6～7.3 MHz when the tags’ spacing is less than 30 mm. The results provide a reference for studying the mutual coupling effect between UHF RFID NF tags based on the mutual impedance between tags.

    • HTML全文

  • 圖  1  UHF RFID近場磁場耦合電路模型

    圖  2  雙標簽互耦等效二端口網絡

    圖  3  雙標簽電感耦合等效電路

    圖  4  標簽

    圖  5  標簽J41的回波損耗性能

    圖  6  HFSS下的雙標簽互耦仿真模型圖

    圖  8  雙標簽布放不同時耦合系數與距離的關系

    圖  7  標簽間插入損耗曲線圖(垂直疊放)

    圖  9  不同距離下的標簽間互阻抗仿真值

    圖  10  標簽間的互阻抗虛部理論值與仿真值對比

    圖  11  標簽1受到互耦時的工作頻率偏移

    圖  12  實驗布置示意圖

    圖  13  $ Δf$ 隨d12及$\theta$的變化圖

    圖  14  $ Δf$ 隨標簽間相對位置的變化

    圖  15  $ Δf$ 隨 ${\cal E}_ {\rm{r}}$的變化($\theta={0^ \circ }$)

    表  1  標簽?zāi)Ｐ蛥?shù)(mm)

    參數名稱$h$${r_0}$${r_1}$${r_2}$${a_1}$${a_2}$$l$
    數值0.058.005.905.20$2\sqrt 2 $$2\sqrt 2 - 1.4$04.20
    下載: 導出CSV
  • FINKENZELLER K. RFID Handbook: Fundamentals and Applications in Contactless Smart Cards, Radio Frequency Identification and Identification and Near-Field Communication[M]. New York, USA: John Wiley & Sons, Ltd, 2010: 29–110.
    NIKITIN P V, RAO K V S, and LAZAR S. An overview of near field UHF RFID[C]. IEEE International Conference on RFID Gaylord Texan Resort, Grapevine, TX, USA, 2007: 167–174. doi: 10.1109/RFID.2007.346165.
    ZHOU Lin, FLORIN H, GUILLAUME V, et al. Simulation framework for performance evaluation of passive RFID tag-to-tag communications[C]. 11th European Conference on Antennas and Propagation (EUCAP), Paris, France, 2017: 500–504. doi: 10.23919/EuCAP.2017.7928387.
    MICHEL A, BUFFI A, NEPA P, et al. Wireless power transfer in UHF RFID printer encoder[C]. International Conference on Electromagnetics in Advanced Applications (ICEAA), Verona, Italy, 2017: 1902–1905. doi: 10.1109/ICEAA.2017.8065678.
    MICHELZ A, BUFFI A, and MANARA G. Near-field coupling in UHF-RFID printer-encoders[C]. URSI International Symposium on Electromagnetic Theory (EMTS), Espoo, Finland, 2016: 464–467. doi: 10.1109/URSI-EMTS.2016.7571427.
    佐磊, 何怡剛, 李兵, 等. 標簽密集條件下天線互偶效應研究[J]. 物理學報, 2013, 62(4): 1021–1029. doi: 10.7498/aps.62.044102

    ZUO Lei, HE Yigang, LI Bing, et al. Theory and measurement for mutual coupling effect of ultra high frequency radiofrequency identification in dense environments[J]. Acta Physica Sinica, 2013, 62(4): 1021–1029. doi: 10.7498/aps.62.044102
    LU Feng, CHENG Xiaosheng, and YE T T. Performance analysis of stacked RFID tags[C]. IEEE International Conference on RFID, Orlando, USA, 2009: 330–337. doi: 10.1109/RFID.2009.4911194.
    彭章友, 任秀方, 孟春陽, 等. 超高頻射頻識別小間隔雙標簽天線增益特性研究研究[J]. 電子與信息學報, 2015, 37(7): 1874–1878. doi: 10.11999/JEIT141371

    PENG Zhangyou, REN Xiufang, MENG Chunyang, et al. Study on gain characteristics of dual ultra-high-frequency radio frequency identification tag antennas with small interval[J]. Journal of Electronics &Information, 2015, 37(7): 1874–1878. doi: 10.11999/JEIT141371
    彭章友, 孟春陽, 任秀方, 等. 密集布放環境下的標簽互阻設計方法[J]. 電子與信息學報, 2015, 37(6): 1304–1309. doi: 10.11999/JEIT141340

    PENG Zhangyou, MENG Chunyang, REN Xiufang, et al. Design method of tag mutual resistance in dense environment[J]. Journal of Electronics &Information, 2015, 37(6): 1304–1309. doi: 10.11999/JEIT141340
    CHEN Xiaosheng, LU Feng, and YE T T. The " weak spots” in stacked UHF RFID tags in NFC applications[C]. IEEE International Conference on RFID , Orlando, USA, 2010: 181–186. doi: 10.1109/RFID.2010.5467262.
    YAO Yuan, LIANG Yishan, YU Junsheng, et al. Design of a multipolarized RFID. Reader antenna for UHF near-field applications[J]. IEEE Transactions on Antennas and Propagation, 2017, 65(7): 3344–3351. doi: 10.1109/TAP.2017.2700873
    JIANG Bing, SIMITH J R, PHILIPOSE M, et al. Energy scavenging for inductively coupled passive RFID systems[J]. IEEE Transactions on Instrumentation and Measurement, 2007, 56(1): 118–125. doi: 10.1109/TIM.2006.887407
    HONG J S and LANCASTER M J. Couplings of microstrip square open-loop resonators for cross-coupled planar microwave filters[J]. IEEE Transactions Microwave Theory Techniques, 1996, 44(12): 2099–2109. doi: 10.1109/22.543968
    彭章友, 任秀方, 孟春陽, 等. UHF RFID密集標簽互耦效應的頻移特性研究[J]. 電子測量技術, 2015, 38(6): 11–15. doi: 10.3969/j.issn.1002-7300.2015.06.004

    PENG Zhangyou, REN Xiufang, MENG Chunyang, et al. Study on frequency shift characteristics of mutual coupling between UHF RFID tags in dense environment[J]. Electronic Measurement Technology, 2015, 38(6): 11–15. doi: 10.3969/j.issn.1002-7300.2015.06.004
    HAN Jinsong, QIAN Chen, WANG Xing, et al. Twins: Device-free object tracking using passive tags[J]. IEEE Transactions on Networking, 2016, 24(3): 1605–1617. doi: 10.1109/INFOCOM.2014.6847970
    CAIZZONE S and MARROCCO G. RFID grids: Part II-experimentations[J]. IEEE Transactions on Antennas & Propagation, 2011, 59(8): 2896–2904. doi: 10.1109/TAP.2011.2158974
    肖芳鑫, 張雪凡, 李帥, 等. 密集布放環境下RFID標簽受限鏈路[J]. 上海大學學報(自然科學版), 2014(5): 624–632. doi: 10.3969/j.issn.1007-2861.2014.05.010

    XIAO Fangxin, ZHANG Xuefan, LI Shuai, et al. RFID tags constrained links in a densely distributed environment[J]. Journal of Shanghai University(Natural Science), 2014(5): 624–632. doi: 10.3969/j.issn.1007-2861.2014.05.010
    BENAMARA M, GRZESKOWIAK M, and LISSORGUES G. Reader antenna including resonators for HF RFID detection[C]. IEEE Antennas & Propagation Conference, Loughborough, UK, 2018. doi: 10.1109/LAPC.2016.7807592
