基于多通道最小均方算法的多發單收同車電臺射頻干擾對消

孫慧賢; 劉建成; 崔佩璋; 全厚德; 唐友喜

doi:10.11999/JEIT180356

基于多通道最小均方算法的多發單收同車電臺射頻干擾對消

doi: 10.11999/JEIT180356

孫慧賢^{1, 2},
劉建成^{3, 4, ,},
崔佩璋²,
全厚德²,
唐友喜¹

1.
電子科技大學通信抗干擾國家級重點實驗室 ??成都 ??611731
2.
解放軍陸軍工程大學 ??石家莊 ??050003
3.
解放軍31634部隊 ??昆明 ??650217
4.
中國電子科技集團公司第五十四研究所 ??石家莊 ??050081

基金項目: 國家自然科學基金(61531009, 61471108)，國家重大專項基金(2016ZX03001009)

詳細信息

作者簡介:
孫慧賢：男，1980年生，博士，講師，研究方向?yàn)閼?zhàn)術無線通信技術、指揮控制系統工程

劉建成：男，1987年生，博士，研究方向?yàn)闊o線通信干擾抑制和通信信號自適應處理

崔佩璋：男，1974年生，副教授，研究方向?yàn)橹笓]控制系統抗干擾技術

全厚德：男，1963年生，教授，博士生導師，研究方向?yàn)闊o線通信技術、指揮控制系統工程

唐友喜：男，1964年生，教授，博士生導師，研究方向?yàn)闊o線通信中的信號處理

通訊作者:
劉建成　liujiancheng1987@126.com

中圖分類號: TN92; TN972
計量
- 文章訪問數: 1857
- HTML全文瀏覽量: 714
- PDF下載量: 89
- 被引次數: 0
出版歷程
- 收稿日期: 2018-04-18
- 修回日期: 2018-11-26
- 網絡出版日期: 2018-12-03
- 刊出日期: 2019-03-01

RF Interference Cancellation Based on Multi-channel Least Mean Square for Multi-transmits and Single-receive Co-vehicle Radios

1.
National Key Laboratory of Science and Technology on Communications, University of Electronic Science and Technology of China, Chengdu 611731, China
2.
PLA Army Engineering University, Shijiazhuang 050003, China
3.
31634 PLA Troops, Kunming 650217, China
4.
The 54th Research Institute of CETC, Shijiazhuang 050081, China

Funds: The National Natural Science Foundation of China (61531009, 61471108), The National Major Projects of China (2016ZX03001009)

摘要

摘要:
戰術指揮車內多部電臺同時工作，發射電臺將對接收電臺產生嚴重的互擾。針對上述問題，該文提出基于多通道最小均方算法(MCLMS)的多發單收同車電臺射頻干擾對消方法。首先，分析同車電臺N 發M 收情況可分離為M個N發單收?qǐng)鼍暗寞B加，進而建立多發單收射頻干擾對消模型。在此基礎上，提出基于MCLMS算法的射頻干擾對消方法，并理論分析該對消方法的性能，推導得出互擾對消比(MICR)與發射電臺數目N、收斂因子
\begin{document}$\mu $\end{document}
之間的閉合數學表達式。最后，通過仿真驗證了理論結果的正確性，表明該方法能夠有效抑制同車發射電臺對接收電臺的互擾影響，增強指揮車電磁兼容性。
- 電臺互擾 /
- 射頻干擾對消 /
- 多通道最小均方算法 /
- 互擾對消比
Abstract:
The transmit radios would severely interfere the receive radios, only if they are simultaneously operating in the same tactical command vehicle. Considering this problem, the RF interference cancellation method for multi-transmits and single-receive co-vehicle radios, based on Multi-Channel Least Mean Square (MCLMS) algorithm, is proposed. Firstly, the analysis indicates that the situation of N-transmits and M-receives co-vehicle radios is the equivalent of M case of N-transmits and single-receive, by which the RF interference cancellation model of multi-transmits and single-receive is constructed. Secondly, the RF interference cancellation method based on MCLMS algorithm is presented, and the performance of this method is analyzed to obtain the mathematical relation expression between Mutual-Interference Cancellation Ratio (MICR) and transmit radio number N, convergence factor
\begin{document}$\mu $\end{document}
. Finally, the simulations demonstrate the validity of the theory result, and indicate that the mutual-interference between transmit radios and receive radios is efficiently suppressed to enhance the electromagnetic compatibility of communication command vehicle.
- Radio mutual-interference /
- RF interference cancellation /
- Multi-Channel Least Mean Square (MCLMS) algorithm /
- Mutual-Interference Cancellation Ratio (MICR)

HTML全文

圖 1 單發單收射頻干擾對消基本原理圖

下載: 全尺寸圖片幻燈片

圖 2 多發單收射頻干擾對消模型

下載: 全尺寸圖片幻燈片

圖 3 多發單收互擾時接收天線輸出信號功率譜

下載: 全尺寸圖片幻燈片

圖 4 同車發送電臺數目N 對應的MICR收斂曲線

下載: 全尺寸圖片幻燈片

圖 5 N=2時不同收斂因子對應的MICR收斂曲線

下載: 全尺寸圖片幻燈片

表 1 多發單收射頻干擾對消仿真參數設置

發送電臺數目N	2	3	4
工作頻率f (MHz)	65.250, 65.375	65.200, 65.325, 65.425	65.250, 65.300, 65.375, 65.450
互擾信道衰減(dB)	20.500, 21.200	20.100, 20.200, 21.900	20.500, 20.800, 21.200, 22.100

下載: 導出CSV

參考文獻(16)

趙波, 全厚德, 崔佩璋. 無線電同址干擾定量分析方法研究[J]. 電波科學學報, 2011, 26(5): 837–843.

ZHAO Bo, QUAN Houde and CUI Peizhang. Quantitative an alysis on radio co-site interference[J]. Chinese Journal of Radio Science, 2011, 26(5): 837–843.

SAMTEL J H and STEPHEN J R. High power HF and noise cancellation system, RADC-TR-80-56 [R]. NewYork: Rome Air Development Center, 1980.

LEE D W and BURTON S A. High power broadband cancellation system, RADC-TR-81-15 [R]. NewYork: Rome Air Development Center, 1981.

DUARTE M, DICK C, and SABHARWAL A. Experiment-driven characterization of full-duplex wireless systems[J]. IEEE Transactions on Wireless Communications, 2012, 11(12): 4296–4307. doi: 10.1109/TWC.2012.102612.111278

劉建成, 趙宏志, 全厚德, 等. 結合天線互耦分析的同車電臺射頻干擾對消[J]. 系統工程與電子技術, 2015, 37(11): 2598–2605. doi: 10.3969/j.issn.1001-506X.2015.11.27

LIU Jiancheng, ZHAO Hongzhi, QUAN Houde, et al. RF interference cancellation based on antennas coupling analysis for radios on the co-vehicl[J]. Systems Engineering and Electronics, 2015, 37(11): 2598–2605. doi: 10.3969/j.issn.1001-506X.2015.11.27

李文祿, 趙治華, 李毅, 等. 含有用信號的自適應干擾對消系統時域分析[J]. 通信學報, 2012, 33(10): 183–190. doi: 10.3969/j.issn.1000-436X.2012.10.024

LI Wenlu, ZHAO Zhihua, LI Yi, et al. Time-domain analysis of adaptive interference cancellation system with the desired signal[J]. Journal on Communications, 2012, 33(10): 183–190. doi: 10.3969/j.issn.1000-436X.2012.10.024

CHOI J I, JAIN M, KANNAN S, et al. Achieving single channel, full-duplex wireless communication[C].Proceedings of the Sixteenth Annual International Conference on Mobile Computing and Networking, Chicago, USA, 2010: 1–12. doi: 10.1109/WiCOM.2012.6478497.

JAIN M, CHOI J I, KIM T, et al. Practical, real-time, full-duplex wireless[C].Proceedings of the 17th Annual International Conference on Mobile Computing and Networking, Las Vegas, USA, 2011: 301–312. doi: 10.1145/2030613.2030647.

LI Wenlu, ZHAO Zhihua, TANG Jian, et al. Performance analysis and optimal design of the adaptive interference cancellation System[J]. IEEE Transactions on Electromagnetic Compatibility, 2013, 55(6): 1068–1075. doi: 10.1109/temc.2013.2265803

王俊, 趙宏志, 唐友喜. 基于降維原理的全雙工射頻域快速自干擾抑制算法研究[J]. 通信學報, 2017, 38(8): 28–36. doi: 10.11959/j.issn.1000-436x.2017161

WANG Jun, ZHAO Hongzhi, and TANG Youxi. Quick self-interference cancellation algorithm based on dimension reduction at radio frequency domain in full duplex system[J]. Journal on Communications, 2017, 38(8): 28–36. doi: 10.11959/j.issn.1000-436x.2017161

黎斯, 魯宏濤, 邵士海, 等. 全雙工通信射頻域自干擾抑制量對數字域自干擾抑制能力的影響[J]. 電子與信息學報, 2017, 39(6): 1278–1283. doi: 10.11999/JEIT160967

LI Si, LU Hongtao, SHAO Shihai, et al. Impact of the amount of RF self-interference cancellation on digital self-interference cancellation in full duplex communications[J]. Journal of Electronics &Information Technology, 2017, 39(6): 1278–1283. doi: 10.11999/JEIT160967

王俊, 趙宏志, 唐友喜. 同時同頻全雙工射頻快速自適應干擾抵消算法[J]. 電子科技大學學報, 2017, 46(4): 505–512. doi: 10.3969/j.issn.1001-0548.2017.04.005

WANG Jun, ZHAO Hongzhi, and TANG Youxi. Quick adaptive self-interference cancellation at RF domain in full duplex systems[J]. Journal of University of Electronic Science and Technology of China, 2017, 46(4): 505–512. doi: 10.3969/j.issn.1001-0548.2017.04.005

SYRJALA V, VALKAMA M, snd ANTTILA L. Analysis of oscillator phase-noise effects on self-interference cancellation in full-duplex OFDM radio transceivers[J]. IEEE Transactions on Wireless Communications, 2014, 13(6): 2977–2990. doi: 10.1109/TWC.2014.041014.131171

CHOI Y S and HOOMAN S M. Simultaneous transmission and reception: Algorithm, design and system level performance[J]. IEEE Transactions on Wireless Communications, 2013, 12(12): 5992–6010. doi: 10.1109/TWC.2013.101713.121152

SIMON H. Adaptive Filter Theory (Fifth Edition)[M]. NewYork: Pearson Education, Inc, 2016: 245–253.

HUANG Y A and BENESTY J. Adaptive multi-channel least mean square and Newton algorithms for blind channel identification[J]. Signal Processing, 2002, 82(8): 1127–1138. doi: 10.1016/S0165-1684(02)00247-5
