四線渦輪式慢阻肺健康監護系統研究

趙榮建; 周旺; 湯敏芳; 陳賢祥; 杜利東; 趙湛; 楊汀; 詹慶元; 方震

doi:10.11999/JEIT180315

四線渦輪式慢阻肺健康監護系統研究

doi: 10.11999/JEIT180315

趙榮建^{1, 2},
周旺^{1, 2},
湯敏芳^{1, 2},
陳賢祥¹,
杜利東¹,
趙湛^{1, 2},
楊汀³,
詹慶元³,
方震^{1, 2, ,}

1.
中國科學院電子學研究所傳感技術國家重點實驗室 ??北京 ??100190
2.
中國科學院大學 ??北京 ??100049
3.
中日友好醫院 ??北京 ??100029

基金項目: 北京市自然科學基金(Z16003)，國家重點研發計劃(2016YFC1304302)

詳細信息

作者簡介:
趙榮建：男，1985年生，博士生，研究方向為生命信息感知技術

周旺：男，1992年生，碩士生，研究方向為可穿戴式醫療檢測技術

湯敏芳：女，1996年生，博士生，研究方向為可穿戴式醫療檢測技術

陳賢祥：男，1979年生，副研究員，碩士生導師，研究方向為可穿戴式醫療檢測技術

杜利東：男，1981年生，助理研究員，研究方向為微納制造技術

趙湛：男，1958年生，研究員，博士生導師，研究方向為微納制造技術、無線傳感器網絡、生命信息感知與計算

楊?。号?，1968年生，主任醫師，博士生導師，研究方向為呼吸與危重癥醫學

詹慶元：男，1970年生，主任醫師，博士生導師，研究方向為呼吸與危重癥醫學

方震：男，1976年生，研究員，博士生導師，研究方向為可穿戴式醫療檢測技術

通訊作者:
方震　zfang@mail.ie.ac.cn

中圖分類號: TP389.1; Q819
計量
- 文章訪問數: 1605
- HTML全文瀏覽量: 713
- PDF下載量: 44
- 被引次數: 0
出版歷程
- 收稿日期: 2018-04-03
- 修回日期: 2018-08-14
- 網絡出版日期: 2018-09-13
- 刊出日期: 2019-02-01

Research of Chronic Obstructive Pulmonary Disease Monitoring System Based on Four-line Turbine-type

Rongjian ZHAO^{1, 2},
Wang ZHOU^{1, 2},
Minfang TANG^{1, 2},
Xianxiang CHEN¹,
Lidong DU¹,
Zhan ZHAO^{1, 2},
Ting YANF³,
Qingyuan ZHAN³,
Zhen FANG^{1, 2
, ,}

1.
State Key Laboratory of Transducer Technology, Institute of Electronics, Chinese Academy of Sciences, Beijing 100190, China
2.
University of Chinese Academy of Sciences, Beijing 100049, China
3.
China-Japan Friendship Hospital, Beijing 100029, China

Funds: The Key Project of Beijing Municipal Natural Science Foundation (Z16003), The National Key Research and Development Project (2016YFC1304302)

摘要

摘要:
針對傳統渦輪式肺活量計存在檢測精度不高、可靠性差的問題，該文提出一種新穎的四線渦輪式檢測方法，研制了一款高精度、高可靠性的慢阻肺監護系統。在硬件上，根據四線渦輪式檢測方法設計了四線式呼氣采集電路，提高了光路接收分辨率，并通過合理的元器件布置，減少了發光-光敏二極管相互間串?dāng)_，提高了系統的可靠性；在軟件上，采用線性回歸算法對其脈沖計數與分析得到用力肺活量、峰值流速等早期篩查與診斷指標。該系統利用標準Fluke氣流分析儀的進行了數據標定，與傳統醫用渦輪式肺功能儀測試對比：用力肺活量平均相對誤差由1.98%降低至1.47%；峰值流速平均相對誤差由2.04%降低至1.02%。實驗表明，四線渦輪式慢阻肺監護系統的呼氣指標比傳統慢阻肺系統檢測精度更高，可靠性更好，適用于慢阻肺疾病的早期篩查與精準診斷，結合血氧飽和度、呼氣末二氧化碳等指標，能實現對慢阻肺患者的醫療監護，特別對于中度和重度慢阻肺患者能起到預警和控制病情的作用。
- 四線渦輪式 /
- 慢阻肺 /
- 用力肺活量 /
- 峰值流速
Abstract:
To improve accuracy and reliability of the traditional turbine-vital capacity meter, a novel four-line turbine-detection method is presented for the high precision and high reliability Chronic Obstructive Pulmonary Disease (COPD) monitoring system. On the hardware, a four-line breath signal acquisition circuit is designed following the four-line turbine-type detection method, which improves the resolution of the optical path through reasonable components arrangement. On the software, a linear regression algorithm is used to obtain early screening and diagnostic indicators such as Forced Vital Capacity (FVC), Peak Expiratory Flow (PEF) and so on. The standard Fluke air flow analyzer is used for data calibration, compared with the traditional medical turbine-type lung function meter: FVC average relative error is reduced from 1.98% to 1.47% and PEF average relative error is reduced from 2.04% to 1.02%. It is showed that the expiratory parameters of the four-line turbine-type COPD monitoring system is more accurate and reliable than that of the traditional COPD system which is suitable for early screening and accurate diagnosis of COPD. Combined with pulse oxygen saturation, End-tidal CO2, it can be used to achieve the medical care for COPD and play an important role to early detect and control of disease for moderate or severe COPD patients.
- Four-line turbine-type /
- Chronic Obstructive Pulmonary Disease (COPD) /
- Forced Vital Capacity (FVC) /
- Peak Expiratory Flow (PEF)

HTML全文

圖 1 呼氣信號采集原理圖

下載: 全尺寸圖片幻燈片

圖 2 系統結構框圖

下載: 全尺寸圖片幻燈片

圖 3 采用傳統方法與四線式方法二極管分布示意圖

下載: 全尺寸圖片幻燈片

圖 4 四線式方法二極管光路分布示意圖

下載: 全尺寸圖片幻燈片

圖 5 呼氣信號采集電路圖

下載: 全尺寸圖片幻燈片

圖 6 在不同轉速下呼氣信號采集的波形圖

下載: 全尺寸圖片幻燈片

圖 7 原型機照片

下載: 全尺寸圖片幻燈片

圖 8 FVC測量相關系數圖和測量Bland–Altman圖

下載: 全尺寸圖片幻燈片

圖 9 PEF測量相關系數圖和測量Bland–Altman圖

下載: 全尺寸圖片幻燈片

圖 10 四線渦輪式檢測方法與二線渦輪式檢測方法誤差對比圖

下載: 全尺寸圖片幻燈片

圖 11 四線渦輪式慢阻肺設備與醫用慢阻肺設備誤差對比

下載: 全尺寸圖片幻燈片

參考文獻(17)

ALLINSON J P, HARDY R, DONALDSON G C, et al. Combined impact of smoking and early-life exposures on adult lung function trajectories[J]. American Journal of Respiratory and Critical Care Medicine, 2017, 196(8): 1021–1030. doi: 10.1164/rccm.201703-0506OC

VOGELMEIER C F, CRINER G J, MARTINEZ F J, et al. Global strategy for the diagnosis, management, and prevention of chronic obstructive lung disease 2017 report: GOLD executive summary[J]. American Journal of Respiratory & Critical Care Medicine, 2017, 195(5): 557–582. doi: 10.1183/13993003.00214-2017

ROBERTS S D, FARBER M O, KNOX K S, et al. FEV1/FVC ratio of 70% misclassifies patients with obstruction at the extremes of age[J]. Chest, 2006, 130(1): 200–206. doi: 10.1378/chest.130.1.200

BAKER E and FATOYE F. Clinical and cost effectiveness of nurse-led self-management interventions for patients with COPD in primary care: A systematic review[J]. International Journal of Nursing Studies, 2017, 71: 125–138. doi: 10.1016/j.ijnurstu.2017.03.010

LI Yi, FENG Jing, LI Yuechuan, et al. A new pulmonary rehabilitation maintenance strategy through home-visiting and phone contact in COPD[J]. Dove Press journal, 2018, 12: 97–104. doi: 10.2147/PPA.S150679

顧宇, 葉寒生, 馮超, 等. 一種恒功率熱式氣體流量計溫度補償實現[J]. 儀表技術與傳感器, 2015(10): 38–39. doi: 10.3969/j.issn.1002-1841.2015.10.012

GU Yu, YE Hansheng, FENG Chao, et al. Temperature compensation for constant power thermal gas flowmeter[J]. Instrument Technique and Sensor, 2015(10): 38–39. doi: 10.3969/j.issn.1002-1841.2015.10.012

FANG Lide, WANG Xiaojie, et al. Wet gas over-reading characteristic research of inside and outside tube differential pressure flowmeter[J]. Applied Mechanics & Materials, 2013(241-244): 168–171. doi: 10.4028/www.scientific.net/AMM.241-244.168

PILLOW J J, LJUNGBERG H, HüLSKAMP G, et al. Functional residual capacity measurements in healthy infants: Ultrasonic flow meter versus a mass spectrometer[J]. European Respiratory Journal, 2004, 23(5): 763–771. doi: 10.1183/09031936.04.00091504

賈天震, 楊汀, 魏建磊, 等. 新型渦輪便攜式肺功能儀的研制與開發[J]. 電子技術應用, 2017, 43(11): 62–65. doi: 10.16157/j.issn.0258-7998.171411

JIA Tianzhen, YANG Ting, WEI Jianlei, et al. The research and development of a novel portable turbine pulmonary function meter[J]. Application of Electronic Technique, 2017, 43(11): 62–65. doi: 10.16157/j.issn.0258-7998.171411

何子軍. 呼氣信號分析方法及其在肺功能檢查中的應用研究[D]. [博士論文], 中國科學技術大學, 2014: 17–22.

HE Zijun. The method for analyzing expiratory signals and its application in pulmonary function testing[D]. [Ph.D. dissertation], University of Science and Technology of China, 2014: 17–22.

CLARKE M, GOKALP H, FURSSE J, et al. Dynamic threshold analysis of daily oxygen saturation for improved management of COPD patients[J]. IEEE Journal of Biomedical & Health Informatics, 2015, 20(5): 1352–1360. doi: 10.1109/JBHI.2015.2464275

韓慶陽, 王曉東, 李丙玉, 等. EEMD在同時消除脈搏血氧檢測中脈搏波信號高頻噪聲和基線漂移中的應用[J]. 電子與信息學報, 2015, 37(6): 1384–1388. doi: 10.11999/JEIT141390

HAN Qingyang, WANG Xiaodong, LI Bingyu, et al. Using EEMD to eliminate high frequency noise and baseline drift in pulse blood-oximetry measurement simultaneously[J]. Journal of Electronics &Information Technology, 2015, 37(6): 1384–1388. doi: 10.11999/JEIT141390

VERONEZ L, PEREIRA M C, da SILVA S, et al. Volumetric capnography for the evaluation of chronic airways diseases[J]. International Journal of Chronic Obstructive Pulmonary Disease, 2014, 9: 983–989. doi: 10.2147/COPD.S62886

BRIDGEMAN D, ZHAO D, TSOW F, et al. A non-invasive and inexpensive capnography device for the monitoring of COPD and other pulmonary diseases[C]. 2014 IEEE Healthcare Innovation Conference, Seattle, USA. 2014: 1–4.

ZHONG Xingfu, WU Yingxiang, TIAN Shuxiang, et al. Flow rate measurement in multiphase flow using turbine flow-meter[J]. Chinese Journal of Scientific Instrument, 2002, 23(Suppl): 858–859.

文紅燕. 渦輪流量計在線監測系統的研究[D]. [碩士論文], 中國計量大學, 2016: 8–14.

WEN Hongyan. Research on the online monitoring system of turbine flow meter[D]. [Master dissertation], China JiLiang University, 2016: 8–14.

周旺, 方震, 陳賢祥, 等. 獲取呼氣指標的裝置及方法[P].中國專利, CN107569233A. 2018-01-12.

ZHOU Wang, FANG Zhen, CHEN Xianxiang, et al. Obtaining expiration indicator device and method[P]. China Patent, CN107569233A. 2018-01-12.
