基于偽逆極坐標傅里葉變換的快速ISAR方位定標

李東; 張成祥; 趙迪; 譚曉衡; 周喜川; 占木楊

doi:10.11999/JEIT180299

基于偽逆極坐標傅里葉變換的快速ISAR方位定標

doi: 10.11999/JEIT180299

李東^{1, 2, ,},
張成祥¹,
趙迪²,
譚曉衡³,
周喜川³,
占木楊¹

1.
重慶大學通信與測控中心 ??重慶 ??400044
2.
上海衛星工程研究所 ??上海 ??200240
3.
重慶大學通信工程學院 ??重慶 ??400044

基金項目: 國家自然科學基金(61501068, 61571069)，上海航天科技創新基金(SAST2017041)，廣西無線寬帶通信與信號處理重點實驗室2017年主任基金(GXKL06170202)，重慶市基礎研究與前沿探索項目(cstc2018jcyjAX0351)

詳細信息

作者簡介:
李東：男，1983年生，副教授，研究方向?yàn)镾AR/ISAR成像算法設計、參數估計等

張成祥：男，1990年生，碩士生，研究方向?yàn)镮SAR成像算法設計以及參數估計

趙迪：男，1982年生，高級工程師，研究方向?yàn)槔走_(dá)信號處理

譚曉衡：男，1976年生，教授，研究方向?yàn)樾盘?hào)檢測與估計

周喜川：男，1983年生，教授，研究方向?yàn)橹悄苄盘?hào)處理

占木楊：男，1991年生，碩士生，研究方向?yàn)镮SAR成像算法設計

通訊作者:
李東　lidongcuit@126.com

中圖分類號: TN957
計量
- 文章訪問數: 1785
- HTML全文瀏覽量: 1130
- PDF下載量: 70
- 被引次數: 0
出版歷程
- 收稿日期: 2018-03-30
- 修回日期: 2018-08-13
- 網絡出版日期: 2018-09-03
- 刊出日期: 2019-02-01

Fast Cross-range Scaling for ISAR Imaging Based on Pseudo Polar Fourier Transform

1.
Center of Communication and Tracking Telemetering Command, Chongqing University, Chongqing 400044, China
2.
Shanghai Satellite Engineering Research Institute, Shanghai 200240, China
3.
College of Communication Engineering, Chongqing University, Chongqing 400044, China

Funds: The National Natural Science Foundation of China (61501068, 61571069), The Shanghai Aerospace Science and Technology Innovation Fund (SAST2017041), 2017 Director Fund of Key Laboratory of Wireless Broadband Communication and Signal Processing in Guangxi (GXKL06170202), The Chongqing Research Program of Basic Research and Frontier Technology (cstc2018jcyjAX0351)

摘要

摘要:
在逆合成孔徑雷達(ISAR)成像中，由距離多普勒或時頻分析方法得到的ISAR圖像方位向僅是目標的多普勒頻率分布，不能反映目標的真實形狀，需對ISAR圖像進行方位定標。該文提出一種快速的ISAR方位定標方法來估計目標的旋轉角速度(RAV)。首先，該方法利用高效的偽逆極坐標快速傅里葉變換把兩幅不同時刻ISAR圖像的旋轉運動轉化為沿極角的平移運動。然后，在極坐標域定義了一種新的積分相關代價函數來粗估目標的RAV。最后，通過采用二分法估計得到最優的RAV，進而實現ISAR方位定標。相比于現有方位定標算法，所提方法避免了插值操作帶來的精度損失和高計算復雜度問題。計算機仿真和實測數據實驗結果證明了所提方法的有效性。
- 逆合成孔徑雷達 /
- 旋轉角速度 /
- 偽逆極坐標快速傅里葉變換 /
- 二分法
Abstract:
For the Inverse Synthetic Aperture Radar (ISAR) imaging, the ISAR image obtained by the Range-Doppler (RD) or time-frequency analysis methods can not display the target's real shape due to its azimuth relating to the target Doppler frequency, thus the cross-range scaling is required for ISAR image. In this paper, a fast cross-range scaling method for ISAR is proposed to estimate the Rotational Angular Velocity (RAV). Firstly, the proposed method utilizes efficient Pseudo Polar Fast Fourier Transform (PPFFT) to transform the rotational motion of two ISAR images from two different instant time into translation in the polar angle direction. Then, a new cost function called integrated correction is defined to obtain the RAV coarse estimation. Finally, the optimal RAV can be estimated using the Bisection method to realize the cross-range scaling. Compared with the available algorithms, the proposed method avoids the problems of precision loss and high computational complexity caused by interpolation operation. The results of computer simulation and real data experiments are provided to demonstrate the validity of the proposed method.
- Inverse Synthetic Aperture Radar (ISAR) /
- Rotational Angular Velocity (RAV) /
- Pseudo Polar Fast Fourier Transform (PPFFT) /
- Bisection method

HTML全文

圖 1 ISAR成像的幾何模型示意圖

下載: 全尺寸圖片幻燈片

圖 2 偽逆極坐標采樣網格

下載: 全尺寸圖片幻燈片

圖 3 偽逆極坐標采樣區域${P_1}$的2維傅里葉變換快速實現示意圖

下載: 全尺寸圖片幻燈片

圖 4 提出的ISAR方位定標算法實現流程圖

下載: 全尺寸圖片幻燈片

圖 5 兩個不同時刻得到的RD圖像

下載: 全尺寸圖片幻燈片

圖 6 粗估的1維相關曲線

下載: 全尺寸圖片幻燈片

圖 7 迭代收斂曲線

下載: 全尺寸圖片幻燈片

圖 8 方位定標后的ISAR圖像

下載: 全尺寸圖片幻燈片

圖 9 RAV估計的均方根誤差隨信噪比變化曲線

下載: 全尺寸圖片幻燈片

圖 10 實測數據圖像

下載: 全尺寸圖片幻燈片

表 1 雷達參數和目標運動模型

參數	數值
載波頻率	5.6 GHz
波長	0.0536 m
傳輸信號帶寬	400 MHz
距離采樣頻率	512 MHz
脈沖重復頻率	150 Hz
有效回波脈沖	600
旋轉角速度	0.0436 rad/s

下載: 導出CSV

表 2 兩種方法運行時間對比

方法名稱	粗估所用時間	定標總時間
文獻[11]方法	107.224	958.659
本文方法	12.203	96.712

下載: 導出CSV

參考文獻(15)

XU Gang, XING Mengdao, XIA Xianggen, et al. 3D geometry and motion estimations of maneuvering targets for interferometric ISAR with sparse aperture[J]. IEEE Transactions on Geoscience & Remote Sensing, 2017, 25(5): 2005–2020. doi: 10.1109/TIP.2016.2535362

LI Dong, ZHAN Muyang, ZHANG Xinzheng, et al. ISAR imaging of nonuniformly rotating target based on the multicomponent CPS model under low SNR environment[J]. IEEE Transactions on Aerospace & Electronic Systems, 2017, 53(3): 1119–1135. doi: 10.1109/TAES.2017.2667538

李璽, 顧紅, 劉國歲. ISAR成像中轉角估計的新方法[J]. 電子學報, 2000, 28(6): 44–47. doi: 10.3321/j.issn:0372-2112.2000.06.012

LI Xi, GU Hong, and LIU Guosui. A method estimating the rotation angle in ISAR imaging[J]. Acta Electronica Sinica, 2000, 28(6): 44–47. doi: 10.3321/j.issn:0372-2112.2000.06.012

WANG Yong and JIANG Yicheng. A novel algorithm for estimating the rotation angle in ISAR imaging[J]. IEEE Geoscience & Remote Sensing Letters, 2008, 5(4): 608–609. doi: 10.1109/LGRS.2008.2000955

MARTORELLA M. Novel approach for ISAR image cross-range scaling[J]. IEEE Transactions on Aerospace & Electronic Systems, 2008, 44(1): 281–294. doi: 10.1109/TAES.2008.4517004

WANG Xin, ZHANG Min, and ZHAO Jia. Efficient cross-range scaling method via two-dimensional unitary ESPRIT scattering center extraction algorithm[J]. IEEE Geoscience & Remote Sensing Letters, 2017, 12(5): 928–932. doi: 10.1109/LGRS.2014.2367521

XU Zhiwei, ZHANG Lei, and XING Mengdao. Precise cross-range scaling for ISAR images using feature registration[J]. IEEE Geoscience & Remote Sensing Letters, 2014, 11(10): 1792–1796. doi: 10.1109/LGRS.2014.2309604

SHENG Jialian, XING Mengdao, ZHANG Lei, et al. ISAR cross-range scaling by using sharpness maximization[J]. IEEE Geoscience & Remote Sensing Letters, 2015, 12(1): 165–169. doi: 10.1109/LGRS.2014.2330625

陳倩倩, 徐剛, 李亞超, 等. 短孔徑ISAR方位定標[J]. 電子與信息學報, 2013, 35(8): 1854–1861. doi: 10.3724/SP.J.1146.2012.01252

CHEN Qianqian, XU Gang, LI Yachao, et al. Cross-range scaling of short aperture ISAR[J]. Journal of Electronics &Information Technology, 2013, 35(8): 1854–1861. doi: 10.3724/SP.J.1146.2012.01252

YEH Chunmao, XU Jia, PENG Yingning, et al. Cross-range scaling for ISAR based on image rotation correlation[J]. IEEE Geoscience & Remote Sensing Letters, 2009, 6(3): 597–601. doi: 10.1109/LGRS.2009.2021990

PARK S H, KIM H T, and KIM K T. Cross-range scaling algorithm for ISAR images using 2-D fourier transform and polar mapping[J]. IEEE Transactions on Geoscience & Remote Sensing, 2011, 49(2): 868–877. doi: 10.1109/TGRS.2010.2060731

AVERBUCH A, COIFMAN R R, DONOHO D L, et al. A framework for discrete integral transformations I-the pseudopolar fourier transform[J]. SIAM Journal on Scientific Computing, 2014, 30(2): 764–784.

KELLER Y, SHKOLNISKY Y, and AVERBUCH A. The angular difference function and its application to image registration[J]. IEEE Transactions on Pattern Analysis & Machine Intelligence, 2005, 27(6): 969–976. doi: 10.1109/TPAMI.2005.128

XING Hao, MOU Yuting, FU Minyue, et al. Distributed bisection method for economic power dispatch in smart grid[J]. IEEE Transactions on Power Systems, 2016, 30(6): 3024–3035. doi: 10.1109/TPWRS.2014.2376935

LI Dong, LIU Hongqing, LIAO Yong, et al. A novel helicopter-borne rotating SAR imaging model and algorithm based on inverse Chirp-Z transform using frequency-modulated continuous wave[J]. IEEE Geoscience & Remote Sensing Letters, 2016, 12(8): 1625–1629. doi: 10.1109/LGRS.2015.2416437
