基于可變形卷積神經網絡的遙感影像密集區域車輛檢測方法

高鑫; 李慧; 張義; 閆夢龍; 張宗朔; 孫顯; 孫皓; 于泓峰

doi:10.11999/JEIT180209

基于可變形卷積神經網絡的遙感影像密集區域車輛檢測方法

doi: 10.11999/JEIT180209

高鑫¹,
李慧^{1, 2, ,},
張義¹,
閆夢龍¹,
張宗朔³,
孫顯¹,
孫皓¹,
于泓峰¹

1.
中國科學院電子學研究所空間信息處理與應用系統技術重點實驗室 ??北京 ??100190
2.
中國科學院大學 ??北京 ??100049
3.
中央蘭開夏大學 ??英國 ??PR1 2HE

基金項目: 國家自然科學基金(41501485)

詳細信息

作者簡介:
高鑫：男，1966年生，研究員，研究方向?yàn)闄C(jī)載SAR信息處理應用、空間信息處理與應用系統技術研究

李慧：女，1992年生，碩士生，研究方向?yàn)閳D像處理與分析

張義：男，1987年，助理研究員，研究方向?yàn)殛嚵行盘柼幚?/p>
閆夢龍：男，1985年生，副研究員，研究方向?yàn)闄C(jī)器學習與遙感影像智能解譯

張宗朔：男，1995年生，本科生

孫顯：男，1981年生，副研究員，研究方向?yàn)闄C(jī)器學習與遙感影像智能解譯

孫皓：男，1984年生，副研究員，研究方向?yàn)闄C(jī)器學習與遙感影像智能解譯

于泓峰：男，1991年生，助理研究員，研究方向?yàn)闄C(jī)器學習與遙感影像智能解譯

通訊作者:
李慧　 lihuiiecas@163.com

中圖分類號: TP751.2
計量
- 文章訪問數: 2248
- HTML全文瀏覽量: 1012
- PDF下載量: 130
- 被引次數: 0
出版歷程
- 收稿日期: 2018-03-02
- 修回日期: 2018-06-11
- 網絡出版日期: 2018-07-16
- 刊出日期: 2018-12-01

Vehicle Detection in Remote Sensing Images of Dense Areas Based on Deformable Convolution Neural Network

1.
Key Laboratory of Technology in Geo-spatial Information Processing and Application System, Institute of Electronics, Chinese Academy of Sciences, Beijing 100190, China
2.
University of Chinese Academy of Sciences, Beijing 100049, China
3.
University of Central Lancashire (UCLan), Preston PR1 2HE, United Kingdom

Funds: The National Natural Science Foundation of China (41501485)

摘要

摘要: 車輛檢測是遙感圖像分析領域的熱點研究內容之一，車輛目標的智能提取和識別，對于交通管理、城市建設有重要意義。在遙感領域中，現有基于卷積神經網絡的車輛檢測方法存在實現過程復雜并且對于車輛密集區域檢測效果不理想的缺陷。針對上述問題，該文提出基于端到端的神經網絡模型DF-RCNN以提高車輛密集區域的檢測精度。首先，在特征提取階段，DF-RCNN模型將深淺層特征圖的分辨率統一并融合；其次，DF-RCNN模型結合可變形卷積和可變形感興趣區池化模塊，通過加入少量的參數和計算量以學習目標的幾何形變。實驗結果表明，該文提出的模型針對密集區域的車輛目標具有較好的檢測性能。
- 遙感影像 /
- 車輛檢測 /
- 密集區域 /
- 端到端卷積神經網絡
Abstract: Vehicle detection is one of the hotspots in the field of remote sensing image analysis. The intelligent extraction and identification of vehicles are of great significance to traffic management and urban construction. In remote sensing field, the existing methods of vehicle detection based on Convolution Neural Network (CNN) are complicated and most of these methods have poor performance for dense areas. To solve above problems, an end-to-end neural network model named DF-RCNN is presented to solve the detecting difficulty in dense areas. Firstly, the model unifies the resolution of the deep and shallow feature maps and combines them. After that, the deformable convolution and RoI pooling are used to study the geometrical deformation of the target by adding a small number of parameters and calculations. Experimental results show that the proposed model has good detection performance for vehicle targets in dense areas.
- Remote sensing images /
- Vehicle detection /
- Dense areas /
- End-to-end convolution neural network

HTML全文

圖 1 Faster-CNN結構圖

下載: 全尺寸圖片幻燈片

圖 2 DF-RCNN模型結構

下載: 全尺寸圖片幻燈片

圖 3 融合特征圖結構

下載: 全尺寸圖片幻燈片

圖 4 可變性卷積和可變形RoI池化模塊學習過程

下載: 全尺寸圖片幻燈片

圖 5 融合1, 3, 5層特征圖和結合可變形模塊的檢測結果

下載: 全尺寸圖片幻燈片

圖 6 不同模型的檢測結果

下載: 全尺寸圖片幻燈片

表 1 3 種尺度和 3 種比例映射候選區域尺寸

區域尺寸和比例	20², 1:1	20², 1:2	20², 2:1	30², 1:1	30², 1:2	30², 2:1	40², 1:1	40², 1:2	40², 2:1
映射區域大小	20×20	14×28	28×14	30×30	21×42	42×21	40×40	28×56	57×28

下載: 導出CSV

表 2 不同層檢測性能比較

模型	檢測區域	召回率	準確率	F₁指標
層1	密集區域	0.461	0.611	0.525
層3	密集區域	0.623	0.754	0.682
層5	密集區域	0.655	0.923	0.766
層3+5	密集區域	0.714	0.930	0.808
層2+4	密集區域	0.709	0.925	0.803
層1+3+5	密集區域	0.725	0.927	0.814

下載: 導出CSV

表 3 結合可變形模塊檢測性能比較

模型	檢測區域	召回率	準確率	F₁指標
層1+3+5，可變形卷積	密集區域	0.731	0.932	0.819
層1+3+5，可變形RoI池化	密集區域	0.726	0.925	0.814
層1+3+5，可變形卷積，可變形RoI池化	密集區域	0.744	0.940	0.831
層5，可變形卷積，可變形RoI池化	密集區域	0.725	0.924	0.812
層2+4，可變形卷積，可變形RoI池化	密集區域	0.715	0.922	0.805
層3+5，可變形卷積，可變形RoI池化	密集區域	0.729	0.928	0.817

下載: 導出CSV

表 4 不同模型檢測性能比較

模型	檢測區域	召回率	準確率	F₁指標
Faster-RCNN	密集區域	0.655	0.932	0.766
DCNN	密集區域	0.402	0.925	0.560
DF-RCNN	密集區域	0.744	0.940	0.831
Faster-RCNN	非密集區域	0.901	0.942	0.921
DCNN	非密集區域	0.962	0.785	0.865
DF-RCNN	非密集區域	0.910	0.952	0.931

下載: 導出CSV

參考文獻(21)

SHAO Wen, YANG Wen, LIU Guang, et al. Car detection from high-resolution aerial imagery using multiple features[C]. Geoscience and Remote Sensing Symposium, Munich, Germany, 2012: 4379–4382.

MORANDUZZO T and MELGANI F. Automatic car counting method for unmanned aerial vehicle images[J]. IEEE Transactions on Geoscience&Remote Sensing, 2013, 52(3): 1635–1647 doi: 10.1109/TGRS.2013.2253108

KLUCKNER S, PACHER G, GRABNER H, et al. A 3D teacher for car detection in aerial images[C]. International Conference on Computer Vision, Rio de Janeiro, Brazil, 2007: 1–8.

TUERMER S, KURZ F, Reinartz P, et al. Airborne vehicle detection in dense urban areas using HoG features and disparity maps[J]. IEEE Journal of Selected Topics in Applied Earth Observations&Remote Sensing, 2013, 6(6): 2327–2337 doi: 10.1109/JSTARS.2013.2242846

CHEN Ziyi, WANG Cheng, WEN Chenglu, et al. Vehicle detection in high-resolution aerial images via sparse representation and superpixels[J]. IEEE Transactions on Geoscience and Remote Sensing, 2015, 54(1): 103–116 doi: 10.1109/TGRS.2015.2451002

康妙, 計科峰, 冷祥光, 等. 基于棧式自編碼器特征融合的SAR圖像車輛目標識別[J]. 雷達學報, 2017, 6(2): 167–176 doi: 10.12000/JR16112

KANG Miao, JI Kefeng, LENG Xiangguang, et al. SAR target recognition with feature fusion based on stacked autoencoder[J]. Journal of Radars, 2017, 6(2): 167–176 doi: 10.12000/JR16112

王思雨, 高鑫, 孫皓, 等. 基于卷積神經網絡的高分辨率SAR圖像飛機目標檢測方法[J]. 雷達學報, 2017, 6(2): 195–203 doi: 10.12000/JR17009

WANG Siyu, GAO Xin, SUN Hao, et al. An aircraft detection method based on convolutional neural networks in high-resolution SAR images[J]. Journal of Radars, 2017, 6(2): 195–203 doi: 10.12000/JR17009

田壯壯, 占榮輝, 胡杰民, 等. 基于卷積神經網絡的SAR圖像目標識別研究[J]. 雷達學報, 2016, 5(3): 320–325 doi: 10.12000/JR16037

TIAN Zhuangzhuang, ZHAN Ronghui, HU Jiemin, et al. SAR ATR based on convolutional neural network[J]. Journal of Radars, 2016, 5(3): 320–325 doi: 10.12000/JR16037

YANG Zi and PUN-CHENG L S C. Vehicle detection in intelligent transportation systems and its applications under varying environments: A review[J]. Image&Vision Computing, 2017, 69: 143–154 doi: 10.1016/j.imavis.2017.09.008

CHEN Xueyun, XIANG Shiming, LIU Chenglin, et al. Vehicle detection in satellite images by hybrid deep convolutional neural networks[J]. IEEE Geoscience&Remote Sensing Letters, 2014, 11(10): 1797–1801 doi: 10.1109/LGRS.2014.2309695

LI Hao, FU Kun, YAN Menglong, et al. Vehicle detection in remote sensing images using denoizing-based convolutional neural networks[J]. Remote Sensing Letters, 2017, 8(3): 262–270 doi: 10.1080/2150704X.2016.1258127

REN Shaoqing, HE Kaiming, SUN Jian, et al. Faster R-CNN: Towards real-time object detection with region proposal networks[J]. IEEE Transactions on Pattern Analysis&Machine Intelligence, 2017, 39(6): 1137–1149 doi: 10.1109/TPAMI.2016.2577031

DENG Zhipeng, SUN Hao, ZHOU Shilin, et al. Toward fast and accurate vehicle detection in aerial images using coupled region-based convolutional neural networks[J]. IEEE Journal of Selected Topics in Applied Earth Observations&Remote Sensing, 2017, 10(8): 3652–3664 doi: 10.1109/JSTARS.2017.2694890

ELMIKATY M and STATHAKI T. Car detection in aerial images of dense urban areas[J]. IEEE Transactions on Aerospace&Electronic Systems, 2017, 54(1): 51–63 doi: 10.1109/TAES.2017.2732832

DAI Jifeng, QI Haozhi, XIONG Yunwen, et al. Deformable convolutional networks[OL]. http://arxiv.org/abs/1703.06211.2017.

LIU Derong, LI Hongliang, and WANG Ding. Feature selection and feature learning for high-dimensional batch reinforcement learning: A survey[J]. International Journal of Automation and Computing, 2015, 12(3): 229–242 doi: 10.1007/s11633-015-0893-y

YANG Bin, YAN Junjie, LEI Zhen, et al. Convolutional channel features[C]. IEEE International Conference on Computer Vision, Santiago, Chile, 2015: 82–90.

ZHONG Bin, ZHANG Jun, WANG Pengfei, et al. Jointly feature learning and selection for robust tracking via a gating mechanism[J]. Plos One, 2016, 11(8): e0161808 doi: 10.1371/journal.pone.0161808

SIMONYAN K and ZISSERMAN A. Very deep convolutional networks for large-scale image recognition[OL]. http://arxiv.org/abs/1409.1556.2014.

HE Kaiming, ZHANG Xiangyu, REN Shaoqing, et al. Deep residual learning for image recognition[C]. IEEE Conference on Computer Vision and Pattern Recognition (CVPR), Las Vegas, United States, 2016: 770–778.

ZEILER M D and FERGUS R.Visualizing and Understanding Convolutional Networks[C]. European Conference on Computer Vision, Zurich, Switzerland, 2014: 818–833.
