高吞吐率雙模浮點可重構FFT處理器設計實現

魏星 黃志洪 楊海鋼

魏星, 黃志洪, 楊海鋼. 高吞吐率雙模浮點可重構FFT處理器設計實現[J]. 電子與信息學報, 2018, 40(12): 3042-3050. doi: 10.11999/JEIT180170
引用本文: 魏星, 黃志洪, 楊海鋼. 高吞吐率雙模浮點可重構FFT處理器設計實現[J]. 電子與信息學報, 2018, 40(12): 3042-3050. doi: 10.11999/JEIT180170
Xing WEI, Zhihong HUANG, Haigang YANG. High Throughput Dual-mode Reconfigurable Floating-point FFT Processor[J]. Journal of Electronics & Information Technology, 2018, 40(12): 3042-3050. doi: 10.11999/JEIT180170
Citation: Xing WEI, Zhihong HUANG, Haigang YANG. High Throughput Dual-mode Reconfigurable Floating-point FFT Processor[J]. Journal of Electronics & Information Technology, 2018, 40(12): 3042-3050. doi: 10.11999/JEIT180170

高吞吐率雙模浮點可重構FFT處理器設計實現

doi: 10.11999/JEIT180170
基金項目: 國家自然科學基金(61704173, 61474120),北京市科技重大專項課題(Z171100000117019)
詳細信息
    作者簡介:

    魏星:男,1991年生,博士,研究方向為算法硬件加速設計、可重構計算芯片架構設計

    黃志洪:男,1984年生,助理研究員,研究方向為可編程邏輯結構設計、新型卷積神經網絡芯片體系架構開發

    楊海鋼:男,1960年生,研究員,研究方向為數?;旌闲盘柤呻娐吩O(shè)計、超大規模集成電路設計等

    通訊作者:

    楊海鋼  yanghg@mail.ie.ac.cn

  • 中圖分類號: TN47

High Throughput Dual-mode Reconfigurable Floating-point FFT Processor

Funds: The National Natural Science Foundation of China (61704173, 61474120), The Major Program of Beijing Science and Technology (Z171100000117019)
  • 摘要: 高吞吐浮點可靈活重構的快速傅里葉變換(FFT)處理器可滿足尖端雷達實時成像和高精度科學計算等多種應用需求。與定點FFT相比,浮點運算復雜度更高,使得浮點型FFT的運算吞吐率與其實現面積、功耗之間的矛盾問題尤為突出。鑒于此,為降低運算復雜度,首先將大點數FFT分解成若干個小點數基2k 級聯子級實現,提出分別針對128/256/512/1024/2048點FFT的優化混合基算法。同時,結合所提出同時支持單通道單精度和雙通道半精度兩種浮點模式的新型融合加減與點乘運算單元,首次提出一款高吞吐率雙模浮點可變點FFT處理器結構,并在28 nm標準CMOS工藝下進行設計并實現。實驗結果表明,單通道單精度和雙通道半精度浮點兩種模式下的運算吞吐率和輸出平均信號量化噪聲比分別為3.478 GSample/s, 135 dB和6.957 GSample/s, 60 dB。歸一化吞吐率面積比相比于現有其他浮點FFT實現可提高約12倍。
  • 圖  1  雙模浮點128/256/512/1024/2048點FFT頂層結構框圖

    圖  2  雙模浮點數據格式示意圖

    圖  3  雙模浮點融合加減運算單元結構

    圖  4  雙模式前導零預測電路結構

    圖  5  雙模浮點融合點乘運算單元結構

    圖  6  雙模式4:2 CSA結構

    表  1  本文所提出的混合基算法

    點數 優化算法 每個子級相應的基底
    1 2 3 4 5 6 7 8 9 10
    128 23-22-22 4 8 128 4 16 4
    256 24-22-22 4 16 4 256 4 16 4
    512 24-22-23 4 16 4 512 4 32 4 8
    1024 25-22-23 4 8 32 4 1024 4 32 4 8
    2048 25-23-23 4 8 32 4 2048 4 8 64 4 8
    下載: 導出CSV

    表  2  雙模浮點融合加減運算單元關鍵路徑

    模塊名 流水級 延時
    數據提取與尾數生成 1 0.43
    指數比較與尾數交換 1 0.77
    指數階差與尾數對齊 2 1.98
    尾數求和差 3 1.47
    LZA 3 0.35
    規格化左移 3 0.16
    下載: 導出CSV

    表  3  雙模浮點融合加減運算單元性能比較結果

    參數 文獻[6] 參考結構T1 本文
    工藝 (nm) 45 28 28
    歸一化面積 (μm2) 5226 (100%) 2665 (51%) 2317 (44%)
    工作頻率 (MHz) 1920 500 435
    計算延遲 (ns) 1.0 6.0 6.9
    功耗 (mW) 5.2 0.6 0.4
    功耗×周期 2.70 (100%) 1.20 (44%) 0.84 (31%)
    下載: 導出CSV

    表  4  雙模浮點融合點乘運算單元關鍵路徑

    模塊名 流水級 延時
    數據提取與指數比較 1 0.33
    尾數部分積相乘 1 0.87
    指數階差與乘積對齊 2 1.25
    雙模4:2 CSA 2 0.20
    雙加法舍入路徑 2 0.53
    LZD與規格化左移 3 1.98
    下載: 導出CSV

    表  5  雙模浮點融合點乘運算單元性能比較結果

    參數 文獻[5] 參考結構T2 本文
    工藝 (nm) 45 28 28
    歸一化面積 (μm2) 12865 (100%) 10336 (80%) 10701 (83%)
    工作頻率 (MHz) 1493 500 435
    計算延遲 (ns) 2.1 6.0 6.9
    功耗 (mW) 16.9 2.7 2.5
    功耗×周期 11.3 (100%) 5.3 (47%) 5.6 (50%)
    下載: 導出CSV

    表  6  雙模浮點FFT整體性能對比

    性能參數 文獻[2] 文獻[9] 文獻[16] 本文
    工藝 (nm) 90 65 55 28
    FFT結構 基于存儲器 Hybrid MDF MDF
    FFT點數 512 1024 1024 128/256/512/1024/2048
    并行度 8 1 1 8
    數據類型:字長 (bit) 塊浮點:12 浮點:32 定點:16 浮點:32/浮點:16
    平均輸出SQNR (dB) 57 139 55 SP:135/HP:60
    時鐘頻率 (MHz) 324 400 200 435
    計算時間 (μs) 0.3 2.6 5.1 0.2/0.3/0.6/1.1/2.2
    運算吞吐率 (MSample/s) 2592 400 200 SP:3478/HP:6957
    平均功耗 (mW) 42 417 8 104 @435 MHz
    有效面積 (mm2) 0.93 1.19 0.15 1.41
    歸一化面積 10.0 22.1 1.9 16.0
    歸一化吞吐率面積比 259 18 103 SP:220/HP:440
    下載: 導出CSV
  • 呂倩, 蘇濤. 基于改進型快速雙線性參數估計的復雜運動目標ISAR成像[J]. 電子與信息學報, 2016, 38(9): 2301–2308 doi: 10.11999/JEIT151359

    Lü Qian and SU Tao. ISAR imaging of targets with complex motion based on the modified fast bilinear parameter estimation[J]. Journal of Electronics&Information Technology, 2016, 38(9): 2301–2308 doi: 10.11999/JEIT151359
    HUANG Shenjui and CHEN S. A high-throughput radix-16 FFT processor with parallel and normal input/output ordering for IEEE 802.15.3c systems[J]. IEEE Transactions on Circuits and Systems Ⅰ:Regular Papers, 2012, 59(8): 1752–1765 doi: 10.1109/TCSI.2011.2180430
    LAN G and FRANK H. Digital Processing of Synthetic Aperture Radar Data: Algorithms and Implementation[M]. Boston: Artech House Publishers, 2005: 154–210.
    陳杰男, 費超, 袁建生, 等. 超高速全并行快速傅里葉變換器[J]. 電子與信息學報, 2016, 38(9): 2410–2414 doi: 10.11999/JEIT160036

    CHEN Jienan, FEI Chao, YUAN Jiansheng, et al. An ultra-high-speed fully-parallel fast Fourier transform design[J]. Journal of Electronics&Information Technology, 2016, 38(9): 2410–2414 doi: 10.11999/JEIT160036
    JONGWOOK S and EARL E. Improved architectures for a floating-point fused dot product unit[C]. IEEE Symposium on Computer Arithmetic, Austin, USA, 2013: 41–48. doi: 10.1109/ARITH.2013.26.
    JONGWOOK S and EARL E. Improved architectures for a fused floating-point add-subtract unit[J]. IEEE Transactions on Circuits and Systems Ⅰ:Regular Papers, 2012, 59(10): 2285–2291 doi: 10.1109/TCSI.2012.2188955
    CHO T and LEE H. A high-speed low-complexity modified radix-25 FFT processor for high rate WPAN applications[J]. IEEE Transactions on Very Large Scale Integration(VLSI)Systems, 2013, 21(1): 187–191 doi: 10.1109/TVLSI.2011.2182068
    WANG Chao, YAN Yuwei, and FU Xiaoyu. A high-throughput low-complexity radix-24-22-23 FFT/IFFT processor with parallel and normal input/output order for IEEE 802.11ad systems[J]. IEEE Transactions on Very Large Scale Integration(VLSI)Systems, 2015, 23(11): 2728–2732 doi: 10.1109/TVLSI.2014.2365586
    WANG Mingyu and LI Zhaolin. A hybrid SDC/SDF architecture for area and power minimization of floating-point FFT computations[C]. IEEE International Symposium on Circuits and Systems, Montreal, Canada, 2016: 2170–2173. doi: 10.1109/ISCAS.2016.7539011.
    EARL E and HANI H. FFT implementation with fused floating-point operations[J]. IEEE Transactions on Computers, 2012, 61(2): 284–288 doi: 10.1109/TC.2010.271
    TANG S N, TSAI J W, and CHANG T Y. A 2.4-GS/s FFT processor for OFDM-based WPAN applications[J]. IEEE Transactions on Circuits and Systems Ⅱ:Express Briefs, 2010, 57(6): 451–455 doi: 10.1109/TCSII.2010.2048373
    NIE Zedong, ZHANG Fengjuan, LI Jie, et al. Low-power digital ASIC for on-chip spectral analysis of low-frequency physiological signals[J]. Journal of Semiconductors, 2012, 33(6): 67–70 doi: 10.1088/1674-4926
    IEEE 754-2008. IEEE Standard for Floating-Point Arithmetic[S]. 2008. doi: 10.1109/IEEESTD.2008.5976968.
    PETER K. Correcting the normalization shift of redundant binary representations[J]. IEEE Transactions on Computers, 2009, 58(10): 1453–1439 doi: 10.1109/TC.2009.38
    YANG C H, YU T H, and DEJAN M. Power and area minimization of reconfigurable FFT processors: A 3GPP-LTE example[J]. IEEE Journal of Solid-State Circuits, 2011, 47(3): 757–768 doi: 10.1109/JSSC.2011.2176163
    MARIO G, HUANG S J, CHEN S G, et al. The serial commutator FFT[J]. IEEE Transactions on Circuits and Systems Ⅱ:Express Briefs, 2016, 63(10): 974–978 doi: 10.1109/TCSII.2016.2538119
    YANG K J, TSAI S H, and CHUANG G. MDC FFT/IFFT processor with variable length for MIMO-OFDM systems[J]. IEEE Transactions on Very Large Scale Integration(VLSI)Systems, 2013, 21(4): 720–731 doi: 10.1109/TVLSI.2012.2194315
