低軸間耦合的MEMS三維電場傳感器

凌必赟; 彭春榮; 任仁; 儲昭志; 張洲威; 雷虎成; 夏善紅

doi:10.11999/JEIT171188

低軸間耦合的MEMS三維電場傳感器

doi: 10.11999/JEIT171188

凌必赟^{1, 2},
彭春榮¹,
任仁¹,
儲昭志^{1, 2},
張洲威^{1, 2},
雷虎成^{1, 2},
夏善紅^1, ,

1.
中國科學院電子學研究所傳感器技術國家重點實驗室 ??北京 ??100190
2.
中國科學院大學 ??北京 ??100049

基金項目: 國家自然科學基金(61327810)，國家863計劃項目(2015AA042602)，中國科學院創新面上基金(CXJJ-17-M151)

詳細信息

作者簡介:
凌必赟：男，1990年生，博士生，研究方向?yàn)镸EMS 3維電場傳感器

彭春榮：男，1979年生，博士，副研究員，研究方向?yàn)镸EMS電場傳感器及系統

任仁：男，1982年生，博士，副研究員，研究方向?yàn)镸EMS電場傳感器標定和檢測系統

儲昭志：男，1990年生，博士生，研究方向?yàn)镸EMS電場傳感器及制備技術

張洲威：男，1993年生，博士生，研究方向?yàn)殪o電探測技術

雷虎成：男，1993年生，博士生，研究方向?yàn)楦哽`敏MEMS電場傳感器

夏善紅：女，1958年生，博士，研究員，研究方向?yàn)槲⒓{傳感器與微系統技術

通訊作者:
夏善紅 ? shxia@mail.ie.ac.cn

中圖分類號: TP212
計量
- 文章訪問數: 2455
- HTML全文瀏覽量: 996
- PDF下載量: 72
- 被引次數: 0
出版歷程
- 收稿日期: 2017-12-18
- 修回日期: 2018-05-07
- 網絡出版日期: 2018-06-12
- 刊出日期: 2018-08-01

MEMS-based Three-dimensional Electric Field Sensor with Low Cross-axis Coupling Interference

Biyun LING^{1, 2},
Chunrong PENG¹,
Ren REN¹,
Zhaozhi CHU^{1, 2},
Zhouwei ZHANG^{1, 2},
Hucheng LEI^{1, 2},
Shanhong XIA^{1
, ,}

1.
State Key Laboratory of Transducer Technology, Institute of Electronics, Chinese Academy of Sciences, Beijing 100190, China
2.
University of Chinese Academy of Sciences, Beijing 100049, China

Funds: The National Natural Science Foundation of China (61327810), The National 863 Program of China (2015AA042602), Chinese Academy of Sciences Project (CXJJ-17-M151)

摘要

摘要: 軸間耦合干擾是影響3維電場傳感器測量準確性的重要因素。該文提出了一種低耦合干擾的MEMS 1維電場敏感芯片，并將3個上述的芯片正交組合研制出一款低軸間耦合的MEMS 3維電場傳感器。不同于已見報道的測量垂直方向電場分量的MEMS 1維電場敏感芯片，該文提出的芯片采用軸對稱設計，在差分電路的配合下能夠測量垂直于對稱軸方向的面內電場分量，并能夠消除正交于測量軸方向的電場分量的耦合干擾。該MEMS 3維電場傳感器具尺寸小和集成度高等優點。實驗結果表明在0～120 kV/m電場強度范圍內，該MEMS 3維電場傳感器的軸間耦合靈敏度小于3.48%，3維電場測量誤差小于7.13%。
- MEMS /
- 3維 /
- 電場傳感器 /
- 軸間耦合干擾
Abstract: Cross-axis coupling interference influences greatly the measurement accuracy of Three-Dimensional (3D) Electric Field Sensor (EFS). A MEMS-based One-Dimensional (1D) Electric Field Microsensor (EFM) chip with low coupling interference is presented, and a MEMS-based 3D EFS with low cross-axis coupling interference is developed by arranging three 1D EFM chips orthogonally. Different from previously reported 1D EFM chips sensitive to perpendicular electric field component, the proposed 1D EFM chip is designed to be symmetrical and connected to difference circuit, so that it is capable of sensing parallel electric field component perpendicular to axis of symmetry and eliminating coupling interference. The proposed 3D EFS has the advantages of small size and high integration. Experimental results reveal that in the range of 0～120 kV/m, the cross-axis sensitivities are within 3.48%, and the total measurement errors of this 3D EFS are within 7.13%.
- Micro-Electro-Mechanical System (MEMS) /
- Three-dimensional /
- Electric field sensor /
- Cross-axis coupling interference

HTML全文

圖 1 1 維電場敏感芯片示意圖

下載: 全尺寸圖片幻燈片

圖 2 1 維電場敏感芯片的仿真模型

下載: 全尺寸圖片幻燈片

圖 3 1 維電場敏感芯片對不同方向電場的仿真結果

下載: 全尺寸圖片幻燈片

圖 4 1 維電場敏感芯片的微加工工藝流程

下載: 全尺寸圖片幻燈片

圖 5 1 維電場敏感芯片掃描電鏡照片

下載: 全尺寸圖片幻燈片

圖 6 MEMS 3 維電場傳感器的實物圖

下載: 全尺寸圖片幻燈片

圖 7 MEMS 3 維電場傳感器測試標定裝置

下載: 全尺寸圖片幻燈片

圖 8 MEMS 3維電場傳感器的標定曲線

下載: 全尺寸圖片幻燈片

表 1 1 維電場敏感芯片的關鍵參數

結構參數	參數值
感應電極寬度w_sn	8 μm
屏蔽電極寬度w_sh	10 μm
感應電極與屏蔽電極的間距(平衡位置)g	15 μm
相鄰的兩個感應電極的間距W	95 μm
感應電極長度L_sn	1030 μm
屏蔽電極長度L_sh	1045 μm
結構厚度 $\tau $	25 μm
襯底厚度h	300 μm
感應電極數量N_e	14×2
梳齒數量N_d	84×20
諧振結構質量m_eff	4.4×10^–5 g
等效彈性系數k_q	11.3 N/m

下載: 導出CSV

表 2 X軸，Y軸和Z軸1維電場敏感芯片的靈敏度

電場方向	X軸1維電場敏感芯片的靈敏度 (mV·m/kV)	Y軸1維電場敏感芯片的靈敏度 (mV·m/kV)	Z軸1維電場敏感芯片的靈敏度 (mV·m/kV)
沿X軸	0.293	0.001	0.008
沿Y軸	0.011	0.316	0.007
沿Z軸	0.008	0	0.287

下載: 導出CSV

表 3 3 維電場傳感器在空間作不同角旋轉的輸出與計算電場

旋轉角度	施加電場(kV/m)	X軸1維電場敏感芯片的輸出(mV)	Y軸1維電場敏感芯片的輸出(mV)	Z軸1維電場敏感芯片的輸出(mV)	合成電場(kV/m)	誤差(%)
$\theta $₁	50	0.01	8.67	12.08	49.77	0.46
$\theta $₁	100	0.01	17.51	24.35	100.40	0.40
$\theta $₂	50	0.01	13.97	6.86	49.84	0.32
$\theta $₂	100	0.04	27.74	13.99	99.56	0.44
$\theta $₃	50	0.03	–10.08	–11.63	51.08	2.16
$\theta $₃	100	0.05	–20.50	–22.84	101.67	1.67
$\theta $₄	50	2.56	–13.02	8.57	52.21	4.42
$\theta $₄	100	5.22	–26.73	15.99	104.02	4.02
$\theta $₅	50	–8.67	9.77	8.49	53.30	6.60
$\theta $₅	100	–16.94	19.32	17.84	107.13	7.13

下載: 導出CSV

參考文獻(17)

羅福山. 雷擊飛行器事件與美國航天活動的發射規范[J]. 中國航天, 1993, 1:27－29.

LUO Fushan. The events of lightning strikes spacecraft and the criteria of the spacecraft launches of aerospace maneuver of USA[J]. Aerospace China, 1993, 1: 27－29.

ZENG Qingfeng, WANG Zhenhui, GUO Fengxia, et al. The application of lightning forecasting based on surface electrostatic field observations and radar data[J]. Journal of Electrostatics, 2013, 71(1):6－13. DOI: 10.1016/j.elstat.2012.10.007.

MARUVADA P S, DALLARIE R D, and PEDNEAULT R. Development of field-mill instruments for ground-level and above-ground electric field measurement under HVDC transmission lines[J]. IEEE Transactions on Power Apparatus and Systems, 1983, 102(3): 738－744. DOI: 10.1109/TPAS.1983.318035.

VAILLANCOURT G H, CARIGNAN S, and JEAN C. Experience with the detection of faulty composite insulators on high-voltage power lines by the electric field measurement method[J]. IEEE Transactions on Power Delivery, 1998, 13(2): 661－666. DOI: 10.1109/61.660958.

RIEHL P S, SCOTT K L, MULLER R S, et al. Electrostatic charge and field sensors based on micromechanical resonators[J]. Journal of Microelectromechanical Systems, 2003, 12(5): 577－589. DOI: 10.1109/JMEMS.2003.818066.

PENG Chunrong, CHEN Xianxiang, YE Cao, et al. Design and testing of a micromechanical resonant electrostatic field sensor[J]. Journal of Micromechanics and Microengineering, 2006, 16(5): 914－919. DOI: 10.1088/0960-1317/16/5/006.

CHEN Xianxiang, PENG Chunrong, TAO Hu, et al. Thermally driven micro-electrostatic fieldmeter[J]. Sensors and Actuators A: Physical, 2006, 132(2): 677－682. DOI: 10.1016/j.sna.2006.02.044.

KOBAYASHI T, OYAMA S, MAKIMOTO N, et al. An electrostatic field sensor operated by self-excited vibration of MEMS-based self-sensitive piezoelectric microcantilevers[J]. Sensors and Actuators A: Physical, 2013, 198: 87－90. DOI: 10.1016/j.sna.2013.04.016.

YANG Pengfei, PENG Chunrong, FANG Dongming, et al. Design, fabrication and application of an SOI-based resonant electric field microsensor with coplanar comb-shaped electrodes[J]. Journal of Micromechanics and Microengineering, 2013, 23(5): 1－8. DOI: 10.1088/0960-1317/23/5/055002.

RONCIN A, SHAFAI C, and SWATEK D R. Electric field sensor using electrostatic force deflection of a micro-spring supported membrane[J]. Sensors and Actuators A: Physical, 2005, 123: 179－184. DOI: 10.1016/j.sna.2005.02.018.

CHEN T, SHAFAI C, RAJAPAKSE A, et al. Micromachined ac/dc electric field sensor with modulated sensitivity[J]. Sensors and Actuators A: Physical, 2016, 245: 76－184. DOI: 10.1016/j.sna.2016.04.054.

WILLIAMS K, BRUYKER D, LIMB S, et al. Vacuum steered-electron electric-field sensor[J]. Journal of Microelectromechanical Systems, 2014, 23(1): 157－167. DOI: 10.1109/JMEMS.2013.2262924.

MOHAMMED Z, GILL W A, and RASRAS M. Double-comb-finger design to eliminate cross-axis sensitivity in a dual-axis accelerometer[J]. IEEE Sensors Letters, 2017, 1(5): 1－4. DOI: 10.1109/LSENS.2017.2756108.

方奕庚, 彭春榮, 方東明, 等. 微型折疊式三維電場傳感器[J]. 傳感器與微系統, 2016, 35(5): 67－69. DOI: 10.13873/J.1000-9787(2016)05-0067-03.

FANG Yigeng, PENG Chunrong, FANG Dongming, et al. Micro 3-dimensional folding electric field sensor[J]. Transducer and Microsystem Technologies, 2016, 35(5): 67－69. DOI: 10.13873/J.1000-9787(2016)05-0067-03.

聞小龍, 彭春榮, 方東明, 等. 基于共面去耦結構的空間三維電場測量方法[J]. 電子與信息學報, 2014, 36(10): 2504－2508. DOI: 10.3724/SP.J.1146.2013.01921.

WEN Xiaolong, PENG Chunrong, FANG Dongming, et al. Measuring method of three dimensional atmospheric electric field based on coplanar decoupling structure[J]. Journal of Electronics & Information Technology, 2014, 36(10): 2504－2508. DOI: 10.3724/SP.J.1146.2013.01921.

李冰, 彭春榮, 凌必赟, 等. 基于遺傳算法的三維電場傳感器解耦標定方法研究[J]. 電子與信息學報, 2017, 39(9): 2252－2258. DOI: 10.11999/JEIT161277.

LI Bing, PENG Chunrong, LING Biyun, et al. The decoupling calibration method based on genetic algorithm of three dimensional electric field sensor[J]. Journal of Electronics & Information Technology, 2017, 39(9): 2252－2258. DOI: 10.11999/JEIT161277.

LING Biyun, WANG Yu, PENG Chunrong, et al. Single-chip 3D electric field microsensor[J]. Frontiers of Mechanical Engineering, 2017, 12(4): 581－590. DOI: 10.1007/s11465-017-0454-x.
