短脈沖非相參雷達的補償相參處理方法研究
doi: 10.11999/JEIT171147
-
西北核技術研究所高功率微波技術重點實驗室 ??西安 ??710024
Compensative Coherent Processing Algorithm for Short Pulse Non-coherent Radar
-
Science and Technology on High Power Microwave Laboratory, Northwest Institute of Nuclear Technology, Xi’an 710024, China
-
摘要: 為了對短脈沖非相參雷達信號進行相參處理,該文根據其信號特征,建立了參數化信號模型。分析了信號非相參因素,提出了以匹配濾波和參數估計為基礎的補償相參處理算法。通過理論推導證明了對點目標進行補償相參處理的可行性。并對距離擴展目標進行了理論分析,推導出其獲得近似的補償相參增益所需要滿足的條件。并通過仿真驗證了理論分析結果。
-
關鍵詞:
- 短脈沖非相參雷達 /
- 補償相參 /
- 參數估計
Abstract: Based on the characteristics of short pulse non-coherent radar, the parameterized signal model is established. By analysis on the reasons of no-coherence, compensative coherent processing algorithm based on matching filter and parameter estimation is proposed. The rationality of the compensative coherent processing is proved by the mathematical derivation as to single point target. Then, requirement for the range extended target is analyzed in theory, in the condition of approximate compensative coherent processing. Finally, the theoretical analysis results are verified by simulation. -
表 1 補償相參積累的信噪比增益與理論值比較
M 理論值(dB) 仿真估計值(dB) 點目標 距離擴展目標 2 3.01 3.13 2.06 3 4.77 4.52 4.08 5 6.99 6.61 5.36 10 10.00 10.11 9.85 20 13.01 12.92 12.27 50 16.99 17.00 16.39 100 20.00 19.95 19.49 下載: 導出CSV
-
