基于分段鑿孔的極化碼級聯方案
doi: 10.11999/JEIT171113
-
1.
重慶理工大學電氣與電子工程學院 ??重慶 ??400054
-
2.
電子科技大學物理電子學院 ??成都 ??611731
基金項目: 國家自然科學基金(61205106)，中國博士后科學基金(2014M552329)，重慶市教委科學技術研究項目(KJ1500934, KJ120827)，重慶市科委社會事業與民生保障科技創新專項(cstc2017shmsA40019)
Concatenated Polar Codes Scheme Based on Segmented Puncturing
-
1.
School of Electrical and Electronic Engineering, Chongqing University of Technology, Chongqing 400054, China
-
2.
School of Physical Electronics, University of Electronic Science and Technology of China, Chengdu 611731, China
Funds: The National Natural Science Foundation of China (61205106), China Postdoctoral Science Foundation (2014M552329), The Science and Technology Project Affiliated to the Education Department of Chongqing Municipality (KJ1500934, KJ120827), Chongqing Municipal Science and Technology Commission’s Special Project (cstc2017shmsA40019)
-
摘要: 極化碼擁有出色的糾錯性能，但編碼方式?jīng)Q定了其碼長不夠靈活，需要通過鑿孔構造碼長可變的極化碼。該文引入矩陣極化率來衡量鑿孔對極化碼性能的影響，選擇矩陣極化率最大的碼字作為最佳鑿孔模式。對極化碼的碼字進行分段，有效減小了最佳鑿孔模式的搜索運算量。由于各分段的第1個碼字都會被鑿除，且串行抵消譯碼過程中主要發生1位錯，因此在各段段首級聯奇偶校驗碼作為譯碼提前終止標志，檢測前段碼字的譯碼錯誤并進行重新譯碼。對所提方法在串行抵消譯碼下的性能進行仿真分析，結果表明，相比傳統鑿孔方法，所提方法在10–3誤碼率時能獲得約0.7 dB的編碼增益，有效提升了鑿孔極化碼的譯碼性能。
-
關鍵詞:
- 極化碼 /
- 串行抵消譯碼 /
- 鑿孔 /
- 奇偶校驗碼 /
- 誤碼率
Abstract: Polar codes have outstanding error correction performance, but the code length of conventional polar codes is not compatible because of their coding method. To construct rate-compatible polar codes, a segmented puncturing method is proposed. Using the rate of polarization, the puncturing effect is measured and the codeword is removed to make the largest rate of polarization, which is the optimal puncturing mode. As the first codeword of the optimal puncturing mode is 0, the parity check codes are introduced to detect the decoding error of preceding segments codeword. The decoding performance of the method is simulated, results show that this method can obtain about 0.7 dB coding gain at 10–3 bit error rate compared with the traditional puncturing method, which can effectively improve the performance of the punctured polar codes.-
Key words:
- Polar codes /
- Successive cancellation decoding /
- Puncturing /
- Parity check codes /
- Bit error rate
-
表 1 不同分段碼長s 的譯碼性能增益比較
碼長N Eb/N0(dB) 32 64 128 256 512 1024 s=4 0 0 0 0 0 0 s=8 0.012 0.036 0.091 0.108 0.138 0.159 s=16 –0.107 –0.043 0.055 0.118 0.188 0.233 最優s 8 8 8 16 16 16 對應m 4 8 16 16 32 64
下載: 導出CSV
表 2 剩余碼長分配方法
算法1：剩余碼長分配方法 輸入：N, L,m, s 輸出： ${L_1}$, ${L_2}$, ${n_1}$, ${n_2}$ (1) 定義 ${L_1},\;{L_2}$為各分段中較短與較長的分段剩余碼長； (2) 定義 ${n_{\min }},\;{n_{\max }}$為分段剩余碼長為 ${L_1},\;{L_2}$的分段個數； (3) 較短分段剩余碼長 ${L_1} \!=\!\! \left\lfloor \!{\displaystyle\frac{{sL}}{N}}\! \right\rfloor $，較長分段剩余碼長 ${L_2} \! =\! \! \left\lceil \!{\displaystyle\frac{{sL}}{N}}\! \right\rceil $； (4) ${n_1}$與 ${n_2}$的比值為： $\frac{{{n_1}}}{{{n_2}}} = \frac{{m{L_2} - L}}{{L - m{L_1}}}$； (5) ${L_1}$的個數 ${n_1} = \frac{{m{L_2}{\rm{ - }}L}}{{{L_2} - {L_1}}}$, ${L_{\max }}$的個數 ${n_2} = \frac{{L{\rm{ - }}m{L_1}}}{{{L_2} - {L_1}}}$。
下載: 導出CSV
表 3 N=8對應的最佳鑿孔模式
L ${{E} _{\max }}{\rm{(}}{{G}})$ ${{{P}}_{8,L}}$ 7 0.6008 01111111 6 0.6022 01111110 5 0.5949 00011111
下載: 導出CSV
表 4 N=16對應的最佳鑿孔模式
L ${{E} _{\max }}{\rm{(}}{{G}})$ ${{{P}}\!_{16,L}}$ 15 0.5445 0111111111111111 14 0.5635 0111111111111110 13 0.5616 0111111111111100 12 0.5654 0111111111111000 11 0.5764 0111111011111000 10 0.5794 0111111011101000 9 0.5582 0111011011101000
下載: 導出CSV
表 5 PPCA-SC復雜度比較
信噪比(dB) 時間復雜度 1.5(PPCA-SC) 12275 2.0(PPCA-SC) 10858 2.5(PPCA-SC) 10360 SC 10240
下載: 導出CSV
表 6 PPCA-SC平均重復譯碼次數比較
碼長 平均重復譯碼次數 256 0.72 512 0.47 1024 0.20
下載: 導出CSV
表 7 最大重復次數對PPCA-SC復雜度的影響
信噪比(dB) 最大重復次數 時間復雜度 1.5 4 3522 2 2527 2.0 4 2486 2 2331 2.5 4 2126 2 2107
下載: 導出CSV
表 8 分段數對PPCA-SC復雜度的影響
信噪比(dB) 分段數 時間復雜度 1.5 16 3522 8 3424 2.0 16 2466 8 2338 2.5 16 2126 8 2121
下載: 導出CSV
-
ARIKAN E and TELATAR E. On the rate of channel polarization[C]. 2009 IEEE International Symposium on Information Theory, Seoul, Korea, 2009: 1493–1495. SASOGLU E, TELATAR E, and ARIKAN E. Polarization for arbitrary discrete memoryless channels[C]. IEEE Information Theory Workshop, Taormina, Italy, 2009: 144–148. VANGALA H, HONG Y, and VITERBO E. Efficient algorithms for systematic polar encoding[J]. IEEE Communications Letters, 2016, 20(1): 17－20. DOI: 10.1109/LCOMM.2015.2497220. TAHIR B and RUPP M. New construction and performance analysis of polar codes over AWGN channels[C]. 2017 24th International Conference on Telecommunications (ICT), Limassol, Cyprus, 2017: 1–4. NIU Kai and CHEN Kai. CRC-aided decoding of polar codes[J]. IEEE Communications Letters, 2012, 16(10): 1668－1671. DOI: 10.1109/LCOMM.2012.090312.121501. SHARMA A and SALIM M. Polar code: The channel code contender for 5G scenarios[C]. IEEE International Conference on Computer, Communications and Electronics, Jaipur, India, 2017: 676–682. CHANDESRIS L, SAVIN V, and DECLERCQ D. On puncturing strategies for polar codes[C]. IEEE International Conference on Communications Workshops, Paris, France, 2017: 766–771. BIOGLIO V, GABRY F, and LAND I. Low-complexity puncturing and shortening of polar codes[C]. Wireless Communications and Networking Conference Workshops, San Francisco, USA, 2017: 1–6. ESLAMI A and PISHRO N. A practical approach to polar codes[C]. IEEE International Symposium on Information Theory Proceedings, St. Petersburg, Russia, 2011: 16–20. HONG S N, HUI D, and MARI? I. On the catastrophic puncturing patterns for finite-length polar codes[C]. Signals, Systems and Computers, 2016, Asilomar Conference, Pacific Grove, USA, 2017: 235–239. NIU Kai, CHEN Kai, and LIN Jiaru. Beyond turbo codes: Rate-compatible punctured polar codes[C]. IEEE International Conference on Communications, Pacific Grove, USA, 2013: 3423–3427. WANG Runxin and LIU Rongke. A novel puncturing scheme for polar codes[J]. IEEE Communications Letters, 2014, 18(12): 2081–2084. DOI: 10.1109/LCOMM.2014.2364845. KORADA S B, ?A?O?LU E, and URBANKE R. Polar codes: Characterization of exponent, bounds, and constructions[J]. IEEE Transactions on Information Theory, 2010, 56(12): 6253－6264. DOI: 10.1109/TIT.2010.2080990. LEE M K and YANG K. The exponent of a polarizing matrix constructed from the Kronecker product[J]. Designs Codes & Cryptography, 2014, 70(3): 313－322. DOI: 10.1007/s10623-012-9689-z. SHIN D M, LIM S C, and YANG K. Mapping selection and code construction for 2.m-ary polar-coded modulation[J]. IEEE Communications Letters, 2012, 16(6): 905－908. DOI: 10.1109/LCOMM.2012.040912.120070 SHIN D M, LIM S C, and YANG K. Design of Length-compatible polar codes based on the reduction of polarizing matrices[J]. IEEE Transactions on Communications, 2013, 61(7): 2593－2599. DOI: 10.1109/TCOMM.2013.052013.120543. AFISIADIS O, BALATSOUKAS-STIMMING A, and BURG A. A low-complexity improved successive cancellation decoder for polar codes[C]. Signals, Systems and Computers, Asilomar Conference, Pacific Grove, USA, 2014: 2116–2120. -
