一種共面波導饋電的雙陷波漸變槽天線

李振亞; 竺小松; 張建華

doi:10.11999/JEIT171055

一種共面波導饋電的雙陷波漸變槽天線

doi: 10.11999/JEIT171055

國防科技大學電子對抗學院 ??合肥 ??230037

基金項目: 國家自然科學基金(61671454)

詳細信息

作者簡介:
李振亞：男，1989年生，博士生，研究方向?yàn)閷拵炀€、共形微帶天線的理論分析與仿真計算

竺小松：男，1963年生，研究員，博士生導師，研究方向?yàn)榍度胧街悄苄盘?hào)處理、智能蒙皮技術

張建華：女，1962年生，教授，研究方向?yàn)殡姶艌?chǎng)理論與天線技術

通訊作者:
李振亞　 lizhenya7189@126.com

中圖分類號: TN823
計量
- 文章訪問數: 1762
- HTML全文瀏覽量: 827
- PDF下載量: 48
- 被引次數: 0
出版歷程
- 收稿日期: 2017-11-14
- 修回日期: 2018-04-26
- 網絡出版日期: 2018-05-30
- 刊出日期: 2018-08-01

A Co-planar Waveguide Fed Dual Band-notched Tapered Slot Antenna

Institute of Electronic Countermeasure, National University of Defense Technology, Hefei 230037, China

Funds: The National Natural Science Foundation of China (61671454)

摘要

摘要: 為了濾除WIMAX(3.3～3.8 GHz)和WLAN(5.125～5.825 GHz)窄帶信號對超寬帶系統的干擾，該文提出一款共面波導饋電的小型化雙陷波漸變槽天線。共面波導結構可以有效地?cái)U(kuò)展天線的帶寬，實現對整個UWB(3.1～10.6 GHz)頻段的全覆蓋。通過在天線的饋線上開L型縫隙和在輻射貼片上開一對E字型縫隙的方法，有效實現了在3.15～3.97 GHz和4.94～6.05 GHz頻段的雙陷波特性，能夠抑制WIMAX和WLAN對超寬帶系統的干擾。該天線結構簡單緊湊，尺寸非常小，僅為40 mm×18 mm×0.813 mm。仿真和實測結果表明該天線在超寬帶波段內具有良好的陷波特性、增益特性，可以應用于小型化超寬帶系統中。文中方法對于陷波漸變槽天線的研究具有一定的借鑒意義。
- 漸變槽天線 /
- 共面波導 /
- 雙陷波 /
- 小型化
Abstract: In order to filter out the interference of WIMAX (3.3～3.8 GHz) and WLAN (5.125～5.825 GHz) narrowband signals to Ultra WideBand(UWB) system, a Co-Planar Waveguide (CPW) fed miniaturized tapered slot antenna with dual band-notched characteristics is proposed. The CPW structure can effectively extend the bandwidth of the antenna and realize the full coverage of the whole UWB (3.1～10.6 GHz) frequency band. The dual band-notched characteristics (3.15～3.97 GHz and 4.94～6.05 GHz) are effectively achieved by etching the L-shaped slot in the antenna feeder and opening a pair of E-shaped slots in the radiating patch, which can inhibit WIMAX and WLAN interference to the UWB system. The antenna is simple and compact, and the size is very small, only 40 mm×18 mm×0.813 mm. The simulated and measured results show that the antenna has good notch and gain characteristics in the ultra wideband band, and can be used in miniaturized UWB system. The method has certain reference significance for the research of notched tapered slot antenna.
- Tapered slot antenna /
- Co-Planar Waveguide (CPW) /
- Dual band-notched /
- Compact

HTML全文

圖 1 天線結構圖

下載: 全尺寸圖片幻燈片

圖 2 天線的設計流程

下載: 全尺寸圖片幻燈片

圖 3 4種不同天線和參數優化駐波比曲線

下載: 全尺寸圖片幻燈片

圖 4 輻射貼片表面電流分布圖

下載: 全尺寸圖片幻燈片

圖 5 天線實物圖

下載: 全尺寸圖片幻燈片

圖 6 天線駐波比實測與仿真對比圖

下載: 全尺寸圖片幻燈片

圖 7 天線的峰值增益

下載: 全尺寸圖片幻燈片

圖 8 天線E面和H面輻射方向圖

下載: 全尺寸圖片幻燈片

表 1 優化后的天線單元參數

參數	數值	參數	數值
L	18.0	W	40.0
L₁	2.2	W₁	11.0
L₂	2.7	W₂	3.4
L₃	3.5	W₃	3.8
L₄	6.0	W₄	8.5
L₅	2.0	S	3.4
L₆	4.2	d	3.0

下載: 導出CSV

表 2 與相關文獻的對比

文獻	尺寸(mm³)	工作頻率(GHz)	陷波波段(GHz)	抑制增益(dB)
[11]	39×38×0.813	3.05～10.3	5～6	15.0
[12]	50×50×0.8	2.4～11.2	4.6～6.2	13.5
[13]	50×50×0.8	3～11	4.3～5.4	3.8
[14]	43×40×0.508	3～11	5.125～5.350/5.725～5.825	10.0/7.6
[15]	66.3×66.3×0.813	3～11	3.6～3.9/5.6～5.8	7.0/5.4
[16]	50×50×0.8	2.4～11.6	3.1～4.0/5.1～6.2	7.5/10.0
[17]	57.4×55×1.524	3.3～10.8	4.17～4.37/6.0～6.8	—/10.5
本文	40×18×0.813	2.8～9.7	3.15～3.97/4.94～6.05	16.0/16.5

下載: 導出CSV

參考文獻(17)

Federal Communications Commission. First report and order in the matter of revision of part 15 of the commission’s rules regarding ultra-wideband transmission systems[R]. Technical Report ET-Docket 98–153. USA, Washington: FCC, 2002.

SITU R P and SURYA P S. CPW-fed Flower shaped patch antenna for broadband applications[J]. Microwave and Optical Technology Letters, 2015, 57(12): 2908–2913.

SHRIKANTH G R, ANIL K, SHILPA K, et al.. Cross-configured directional UWB antennas for multidirectional pattern diversity characteristics[J]. IEEE Transactions on Antennas and Propagation, 2015, 63(2): 853–858. DOI: 10.1109/TAP.2014.2382687

胡章芳, 胡銀平, 羅元, 等. 具有陷波特性的改進Sierpinski分形超寬帶天線[J]. 電子與信息學報, 2017, 39(6): 1520–1524. DOI: 10.11999/JEIT160738.

HU Zhangfang, HU Yinping, LUO Yuan, et al.. Modified Sierpinskiactal UWB antenna with band-notched characteristic[J]. Journal of Electronics & Information Technology, 2017, 39(6): 1520–1524. DOI: 10.11999/JEIT160738.

ALI K H, ZAHRA S, JORDI N, et al.. Reconfigurable and tunable S-shaped split-ring resonators and application in band-notched UWB antennas[J]. IEEE Transactions on Antennas and Propagation, 2016, 64(9): 3766–3776. DOI: 10.1109/TAP.2016.2585183.

ANTHONY G, FRéDéRIC P, VUONG T P, et al.. Millimeter-wave air-filled SIW antipodal linearly tapered slot antenna[J]. IEEE Antennas and Wireless Propagation Letters, 2017, 16: 768–771. DOI: 10.1109/LAWP.2016.2602280.

王友成, 董明宇, 張鋒, 等. 漸變槽天線端射特性優化設計[J]. 電子與信息學報, 2017, 39(1): 124–128. DOI: 10.11999/JEIT160203

WANG Youcheng, DONG Mingyu, ZHANG Feng, et al.. Design of tapered-slot antenna with optimized end-fire characteristics[J]. Journal of Electronics & Information Technology, 2017, 39(1): 124–128. DOI: 10.11999/JEIT160203.

AREZOOMAND A S, SADEGHZADEH R A, and MOGHADASI M N. Novel techniques in tapered slot antenna for linearity phase center and gain enhancement[J]. IEEE Antennas and Wireless Propagation Letters, 2017, 16: 270–273. DOI: 10.1109/LAWP.2016.2572064.

KAZUTAKA K and AKIRA H. Compact folded-fin tapered slot antenna for UWB applications[J]. IEEE Antennas and Wireless Propagation Letters, 2015, 14: 1192–1195. DOI: 10.1109/LAWP.2015.2397008.

YAO Yuan, CHENG Xiaohe, and YU Junsheng. Analysis and design of a novel circularly polarized antipodal linearly tapered slot antenna[J]. IEEE Transactions on Antennas and Propagation, 2016, 64(10): 4178–4187. DOI: 10.1109/TAP.2016.2593870.

ZHU Fuguo, STEVEN G, ANTHONY T S, et al.. Miniaturized tapered slot antenna with signal rejection in 5–6 GHz band using a balun[J]. IEEE Antennas and Wireless Propagation Letters, 2012, 11: 507–510. DOI: 10.1109/LAWP.2012.2199276.

LEE D H, YANG H Y, and CHO Y K. Tapered slot antenna with band-notched function for ultra wideband radios[J]. IEEE Antennas and Wireless Propagation Letters, 2012, 11: 682–685. DOI: 10.1109/LAWP.2012.2204718.

BHASKAR M, JOHARI E, AKHTER Z, et al.. Gain enhancement of the vivaldi antenna with band notch characteristics using zero-index metamaterial[J]. Microwave and Optical Technology Letters, 2016, 58(1): 233–238. DOI: 10.1002/mop.29534.

ZHU Fuguo, STEVEN G, ANTHONY T S, et al.. Dual band-notched tapered slot antenna using λ/4 band-stop filters[J]. IET Microwaves, Antennas and Propagation, 2012, 6(15): 1665–1673. DOI: 10.1049/iet-map.2012.0502.

ALSHAMAILEH K A, ALMALKAWI M T, and DEVABHAKTUNI V K. Dual band-notched microstrip fed vivaldi antenna utilizing compact EBG structures[J]. International Journal of Antennas and Propagation, 2015, 439832: 1–7.

LEE D H, HAE Y Y, and CHO Y K. Ultra-wideband tapered slot antenna with dual band-notched characteristics[J]. IET Microwaves, Antennas and Propagation, 2014, 8(1): 29–38. DOI: 10.1049/iet-map.2013.0116.

CHINMOY S, PRIYANKA N, LATHEEF A, et al.. Square/hexagonal split ring resonator loaded exponentially tapered slot ultra wideband(UWB) antenna with frequency notch characteristics[J]. Microwave and Optical Technology Letters, 2017, 59(6): 1241–1245. DOI: 10.1002/mop.30511.
