一種基于陣列配置加速比模型的無損壓縮算法

徐金甫; 劉露; 李偉; 王周闖; 楊宇航

doi:10.11999/JEIT170900

一種基于陣列配置加速比模型的無損壓縮算法

doi: 10.11999/JEIT170900

1.
(解放軍信息工程大學 鄭州 450001) ②(復旦大學專用集成電路與系統國家重點實驗室上海 201203)

基金項目:

國家自然科學基金(61404175)

計量
- 文章訪問數: 1265
- HTML全文瀏覽量: 134
- PDF下載量: 121
- 被引次數: 0
出版歷程
- 收稿日期: 2017-09-22
- 修回日期: 2018-04-13
- 刊出日期: 2018-06-19

A New Lossless Compression Algorithm Based on Array Configuration Speedup Model

1.
(The PLA Information Engineering University, Zhengzhou 450001, China)

Funds:

The National Natural Science Foundation of China (61404175)

摘要

摘要: 針對現有壓縮算法通過增加復雜度來降低壓縮率，獲得信息高效傳輸?shù)膯栴}。該文提出陣列配置加速比模型，證明低壓縮率不一定能提高傳輸效率，并找到影響信息傳輸效率的因子，即解壓模塊吞吐率和數據塊壓縮率。將影響因子與配置信息特征結合，設計了一種新的無損壓縮算法，并硬件實現了解壓模塊，吞吐率可達到16.1 Gbps。采用AES, A5-1和SM4對無損壓縮算法進行測試，然后與主流無損壓縮算法LZW, Huffman, LPAQ1和Arithmetic對比。結果表明，整體壓縮率相當，但該文壓縮算法產生的數據塊壓縮率經過優化，不僅能滿足加速需求，且具有高吞吐率的解壓性能；該文無損壓縮算法獲得的配置加速比，比硬件吞吐率理想情況下的LPAQl, Arithmetic, Huffman, LZW算法分別高8%, 9%, 10%, 22%左右。
- 陣列 /
- 配置加速比 /
- 無損壓縮 /
- 吞吐率 /
- 壓縮率
Abstract: In order to obtain efficient information transmission, the existing compression algorithms reduce the compression ratio by increasing complexity. In view of this problem, an array configuration speedup model is proposed in this paper. It is proved that low compression ratio may not improve the transmission efficiency and the factors, decompression module throughput and data block compression rate which affect the efficiency of information transmission, are found. Combined the influencing factors with the configuration information, a new lossless compression method is designed and the decompression hardware circuit is implemented, whose throughput can reach 16.1 Gbps. The lossless compression algorithm is tested using AES, A5-1 and SM4. Compared with the mainstream lossless compression algorithms LZW, Huffman, LPAQ1 and Arithmetic, the results show that the overall compression ratio is equivalent. However, the compression ratio of data block generated by the compression algorithm is optimized, which can not only meet the demand of acceleration, but also possesses high throughput decompression performance. The configuration speedup ratio obtained by lossless compression algorithm is about 8%, 9%, 10% and 22% higher than LPAQl, Arithmetic, Huffman, and LZW with ideal hardware throughput.
- Array /
- Configuration speedup /
- Lossless compression /
- Throughput /
- Compression ratio
