PMOS晶體管工藝參數變化對SRAM單元翻轉恢復效應影響的研究

張景波; 楊志平; 彭春雨; 丁朋輝; 吳秀龍

doi:10.11999/JEIT170547

PMOS晶體管工藝參數變化對SRAM單元翻轉恢復效應影響的研究

doi: 10.11999/JEIT170547

2.
(安徽大學電子信息工程學院合肥 230601) ②(工業和信息化部產業發展促進中心北京 100804)

基金項目:

國家自然科學基金(61674002, 61474001, 61574001)

計量
- 文章訪問數: 1135
- HTML全文瀏覽量: 257
- PDF下載量: 236
- 被引次數: 0
出版歷程
- 收稿日期: 2017-06-08
- 修回日期: 2017-08-31
- 刊出日期: 2017-11-19

Study on the Effect of Upset and Recovery for SRAM Under the Varying Parameters of PMOS Transistor

2.
(School of Electronics and Information Engineering, Anhui University, Hefei 230601, China)

Funds:

The National Natural Science Foundation of China (61674002, 61474001, 61574001)

摘要

摘要: 基于Synopsys公司3D TCAD器件模擬，該文通過改變3種工藝參數，研究65 nm體硅CMOS工藝下PMOS晶體管工藝參數變化對靜態隨機存儲器(Static Random Access Memory, SRAM)存儲單元翻轉恢復效應的影響。研究結果表明：降低PMOS晶體管的P+深阱摻雜濃度、N阱摻雜濃度或調閾摻雜濃度，有助于減小翻轉恢復所需的線性能量傳輸值(Linear Energy Transfer, LET)；通過降低PMOS晶體管的P+深阱摻雜濃度和N阱摻雜濃度，使翻轉恢復時間變長。該文研究結論有助于優化SRAM存儲單元抗單粒子效應(Single-Event Effect, SEE)設計，并且可以指導體硅CMOS工藝下抗輻射集成電路的研究。
- 靜態隨機存儲器 /
- 線性能量傳輸值 /
- 翻轉恢復時間 /
- 單粒子效應
Abstract: Based on Synopsys TCAD 3-D device simulation, the effects of PMOS transistor process parameters on the upset and recovery effect of Static Random Access Memory (SRAM) memory cell are studied in a 65-nm bulk CMOS technology, mainly by changing the three process parameters. The simulation results show that reducing the doping concentration of deep-P+-well, N-well and threshold doping concentration in PMOS transistor can decrease the Linear Energy Transfer (LET) value of the upset and recovery. By reducing the doping concentration of deep-P+-well and N-well in PMOS transistor, the time of the upset and recovery increases. The conclusion of this paper is helpful to optimize the design of Static Random Access Memory cell mitigating Single-Event Effect (SEE), and can gives a great guidance for the anti-radiation integrated circuit under bulk CMOS process.
- Static Random Access Memory (SRAM) /
- Linear Energy Transfer (LET) value /
- Time of the upset and recovery /
- Single-Event Effect (SEE)

HTML全文

參考文獻(23)

DODD P E and MASSENGILL L W. Basic mechanisms and modeling of single-event upset in digital microelectronics[J]. IEEE Transactions on Nuclear Science, 2003, 50(3): 583-602. doi: 10.1109/TNS.2003.813129.

KANG M, KIM J, and CHANG I J. Studying the variation effects of radiation hardened Quatro SRAM bit-cell[J]. IEEE Transactions on Nuclear Science, 2016, 63(4): 2399-2401. doi: 10.1109/TNS.2016.2590426.

KERNS S E, SHAFER B D, ROCKETT L R, et al. The design of radiation-hardened ICs for space: A compendium of approaches[J]. Proceedings of the IEEE, 1988, 76(11): 1470-1509. doi: 10.1109/5.90115.

LIU M S, LIU H Y, BREWSTER N, et al. Limiting upset cross sections of SEU hardened SOI SRAMs[J]. IEEE Transactions on Nuclear Science, 2006, 53(6): 3487-3493. doi: 10.1109/TNS.2006.886216.

CALIN T, NICOLAIDIS M, and VELAZCO R. Upset hardened memory design for submicron CMOS technology[J]. IEEE Transactions on Nuclear Science, 1996, 43(6): 2874-2878. doi: 10.1109/23.556880.

WANG H B, LI Y Q, CHEN L, et al. An SEU-tolerant DICE latch design with feedback transistors[J]. IEEE Transactions on Nuclear Science, 2015, 62(2): 548-554. doi: 10.1109/TNS. 2015.2399019.

劉凡宇, 劉衡竹, 劉必慰, 等. 90 nm CMOS工藝下p+深阱摻雜濃度對電荷共享的影響[J]. 物理學報, 2011, 60(4): 461-468.

LIU Fanyu, LIU Hengzhu, LIU Biwei, et al. Effect of doping concentration in p+ deep well on charge sharing in 90 nm CMOS technology[J]. Acta Physica Sinica, 2011, 60(4): 461-468.

SAXENA P K and BHAT N. Process technique for SEU reliability improvement of deep sub-micron SRAM cell[J]. Solid-State Electronics, 2003, 47(4): 661-664. doi: 10.1016/ S0038-1101(02)00329-5.

DASGUPTA S, WITULSKI A F, BHUVA B L, et al. Effect of well and substrate potential modulation on single event pulse shape in deep submicron CMOS[J]. IEEE Transactions on Nuclear Science, 2007, 54(6): 2407-2412. doi: 10.1109/TNS. 2007.910863.

LI Peng, ZHANG Minxuan, ZHAO Zhenyu, et al. A novel single event upset reversal in 40-nm bulk CMOS 6 T SRAM cells[J]. Nuclear Science and Techniques, 2015, 26(5): 76-82. doi: 10.13538/j.1001-8042/nst.26.050405.

MASSENGILL L W, AMUSAN O A, DASGUPTA S, et al. Soft-error charge-sharing mechanisms at sub-100 nm technology nodes[C]. IEEE International Conference on Integrated Circuit Design and Technology, Austin, TX, USA, 2007: 1-4. doi: 10.1109/ICICDT.2007.4299576.

HE Yibai and CHEN Shuming. Simulation study of the selectively implanted deep-N-well for PMOS SET mitigation [J]. IEEE Transactions on Device Materials Reliability, 2014, 14(1): 99-103. doi: 10.1109/TDMR.2013.2290032.

BLACK J D, BALL II D R, ROBINSON W H, et al. Characterizing SRAM single event upset in terms of single and multiple node charge collection[J]. IEEE Transactions on Nuclear Science, 2008, 55(6): 2943-2947. doi: 10.1109/TNS. 2008.2007231.

AMUSAN O A, MASSENGILL L W, BHUVA B L, et al. Design techniques to reduce SET pulse widths in deep- submicron combinational logic[J]. IEEE Transactions on Nuclear Science, 2007, 54(6): 2060-2064. doi: 10.1109/TNS. 2007.907754.

HSIEH C M, MURLEY P C, and O,BRIEN R R. A field-funneling effect on the collection of alpha-particle- generated carriers in silicon devices[J]. IEEE Electron Device Letters, 1981, 2(4): 103-105. doi: 10.1109/EDL.1981.25357.

AMUSAN O A, WITULSKI A F, MASSENGILL L W, et al. Charge collection and charge sharing in a 130 nm CMOS technology[J]. IEEE Transactions on Nuclear Science, 2006, 53(6): 3253-3258. doi: 10.1109/TNS.2006.884788.

CHEN Meng, LEI Jiefeng, HUANG Shengxiang, et al. Poly-Si TFTs integrated gate driver circuit with charge- sharing structure[J]. Journal of Semiconductors, 2017, 38(5): 92-97. doi: 10.1088/1674-4926/38/5/055001.

HE Liang, CHEN Hua, SUN Peng, et al. Single event upset rate modeling for ultra-deep submicron complementary metal-oxide-semiconductor devices[J]. Science China Information Sciences, 2016, 59(4): 1-11. doi: 10.1007/s11432- 015-5362-2.

CHUMAKOV A I. Modified charge collection model by point node for SEE sensitivity estimation[C]. 2015 IEEE 15th European Conference on Radiation and Its Effects on Components and Systems (RADECS), Moscow, Russia, 2015: 1-5. doi: 10.1109/RADECS.2015.7365635.

YAN S, ZHANG W, LI G, et al. 3-D simulation of charge collection in double-gate MOSFET under low-energy proton irradiation[C]. IEEE International Nanoelectronics Conference (INEC), Chengdu, China, 2016: 1-2. doi: 10.1109/ INEC.2016.7589258.

FURUTA J, YAMAMOTO R, KOBAYASHI K, et al. Evaluation of parasitic bipolar effects on neutron-induced SET rates for logic gates[C]. IEEE International Reliability Physics Symposium (IRPS), Anaheim, CA, USA, 2012: SE. 5.1-SE.5.5. doi: 10.1109/IRPS.2012.6241930.

DING Yi, HU Jianguo, QIN Junrui, et al. Effect of body biasing on single-event induced charge collection in deep N-well technology[J]. Chinese Physics B, 2015, 24(7): 079401. doi: 10.1088/1674-1056/24/7/079401.
