基于中國余數定理的跳頻信號相時延估計方法
doi: 10.11999/JEIT170544
-
1.
(盲信號處理重點實驗室 成都 610041)
A Phase Delay Estimation Algorithm of Frequency Hopping Signal Based on Chinese Reminder Theorem
-
1.
(National Key Laboratory of Science and Technology on Blind Signal Processing, Chengdu 610041, China)
-
摘要: 跳頻信號每跳帶寬窄且多跳間積累困難,利用傳統方法對其時延估計精度都很低。針對該問題,該文充分挖掘跳頻信號寬跳帶的潛能,建立了多頻點相時延估計模型,把時延估計問題轉化為整周模糊求解問題;然后在解模糊過程中引入中國余數定理,針對非合作場景中模數無法選擇的問題,提出一種基于虛擬頻點的干涉相位外推方法,構造出魯棒中國余數定理的適用條件;最后采用閉式魯棒中國余數定理解算整周模糊,得到高精度的相時延。該方法具有精度高、運算量小、不依賴于信道衰落特性的優點。仿真結果驗證了所提模型及方法的有效性和正確性。
-
關鍵詞:
- 相時延 /
- 跳頻信號 /
- 干涉相位 /
- 中國余數定理 /
- 虛擬頻點
Abstract: The bandwidth of each hop in frequency hopping signal is very narrow, and the accumulating between multiple hop is difficult, thus the accuracy of time delay estimation for frequency hopping is low. To deal with the problem, the potential of wide band hopping of frequency hopping signal is fully exploited. A multi-frequency phase delay estimation model is established, and the problem of time delay estimation is transformed into ambiguity resolution. Then, Chinese Remainder Theorem (CRT) is used to solve the ambiguity, but in the non-cooperation scene the module can not be chosen easily, thus an extrapolation method for interferometric phase based on virtual frequency is proposed to relax the constraint of module selection. Finally, the closed-form Robust Chinese Remainder Theorem (RCRT) is used to solve the ambiguity, and the phase delay is obtained with high accuracy. Compared with the conventional algorithm, the proposed algorithm has the advantages of high precision, low computation complexity and independence on the propagation characteristics of the channel. The simulation results verify the validity and correctness of the proposed model and algorithm. -
CHAMPAGNE B, BEDARD S, and STEPHENNE A. Performance of time delay estimation in presence of room reverberation[J]. IEEE Transactions on, Speech and Audio Processing, 1996, 4(2): 148-152. KNAPP C H and CARTER G C. The generalized correlation method for estimation of time delay[J]. IEEE Transactions on Acoust, Speech, and Signal Processing, 1976, 24(4): 320-327. 歐陽鑫信, 萬群, 熊瑾煜, 等. 慢跳跳頻信號的時差估計方法[J]. 現代雷達, 2016, 38(2): 19-22. doi: 10.16592/j.cnki.1004- 7859.2016.02.005. OUYANG Xinxin, WAN Qun, XIONG Jinyu, et al. A new time delay estimate method of wide-band FH signal and precision analysis[J]. Modern Radar, 2016, 38(2): 19-22. doi: 10.16592/j.cnki.1004-7859.2016.02.005. 劉偉, 羅景青. 一種新的寬帶跳頻信號時延估計方法及精度分析[J]. 信號處理, 2010, 26(9): 1323-1328. LIU Wei and LUO Jingqing. A new time delay estimate method of wide-band FH signal and precision analysis[J]. Signal Processing, 2010, 26(9): 1323-1328. 陸晨曦, 李宏宇, 年豐, 等. 一種應用于射頻系統群時延測量的相關峰精化算法[J]. 電子與信息學報, 2013, 35(12): 2921-2926. doi: 10.3724/SP.J.1146.2013.00221. LU Chenxi, LI Hongyu, NIAN Feng, et al. A correlation-peak fining algorithm for group delay measurement of radio frequency system[J]. Journal of Electronics Information Technology, 2013, 35(12): 2921-2926. doi: 10.3724/SP.J.1146. 2013.00221. 吳亞軍, 劉慶會, 陳冠磊, 等. VLBI相時延及其在深空探測器測定軌中的應用[J]. 中國科學: 信息科學, 2014, 44(2): 221-230. doi: 10.1360/112013-1110. WU Yajun, LIU Qinghui, CHEN Guanlei, et al. VLBI phase delay and its application in orbit determination of spacecraft [J]. Science China Information Sciences, 2014, 44(2): 221-230. doi: 10.1360/112013-1110. ROSEN K H. Elementary Number Theory and Its Applications[M]. Englewood Cliffs, NJ, US, Addison Wesley, 2010: 155-200. LI Xiaowei and XIA Xianggen. A fast robust Chinese Remainder Theorem based phase unwrapping algorithm[J]. IEEE Signal Processing Letters, 2008, 15(2): 665-668. doi: 10.1109/LSP.2008.2002926. LI Xiaowei, LIANG Hong, and XIA Xianggen. A robust Chinese Remainder Theorem with its applications in frequency estimation from undersampled waveforms[J]. IEEE Transactions on Signal Processing, 2009, 57(11): 4314-4322. doi: 10.1109/TSP.2009.2025079. WANG Wenjie and XIA Xianggen. A close-form robust Chinese Reminder Theorem and its performance analysis[J]. IEEE Transactions on Signal Processing, 2010, 58(11): 5655-5666. doi: 10.1109/TSP.2010.2066974. WANG Chen, YIN Qinye, and WANG Wenjie. An efficient ranging method based on Chinese Remainder Theorem for RIPS measurement[J]. Science China Information Sciences, 2010, 53(6): 1233-1241. doi: 10.1007/s11432-101-0105-x. WANG Chen, YIN Qinye, and CHEN Hongyang. Robust Chinese Remainder Theorem ranging method based on dual-frequency measurements[J]. IEEE Transactions on Vehicular Technology, 2011, 60(8): 4094-4099. doi: 10.1109/ TVT.2011.2167690. XIAO Li, XIA Xianggen, and WANG Wenjie. Multi-stage robust Chinese Remainder Theorem[J]. IEEE Transactions on Signal Processing, 2014, 62(18): 4772-4785. doi: 10.1109/ TSP.2014.2339798. WANG Wenjie, LI Xiaoping, WANG Wei, et al. Maximum likelihood estimation based robust Chinese Remainder Theorem for real numbers and its fast algorithm[J]. IEEE Transactions on Signal Processing, 2015, 63(13): 3317-3331. doi: 10.1109/TSP.2015.2413378. LI Xiaoping, XIA Xianggen, WANG Wenjie, et al. A robust generalized Chinese Remainder Theorem for two integers[J]. IEEE Transactions on Information Theory, 2016, 62(12): 7491-7504. doi: 10.1109/TIT.2016.2614322. LI Xiaoping, WANG Wenjie, ZHANG Weile, et al. Phase- detection-based range estimation with robust Chinese Remainder Theorem[J]. IEEE Transactions on Vehicular Technology, 2016, 65(12): 10132-10137. doi: 10.1109/TVT. 2016.2550083. -
