一種新的高重頻寬帶相干激光雷達系統研究
doi: 10.11999/JEIT170479
-
1.
(上海交通大學電子信息與電氣工程學院 上海 200240)
-
2.
(中國科學院電子學研究所 北京 100190)
A Novel Coherent Ladar System with High Repetition Frequency and Wide Bandwidth
-
1.
(School of Electronic Information and Electrical Engineering, Shanghai Jiaotong University, Shanghai 200240,China)
-
2.
(Insititute of Electronics, Chinese Academy of Sciences, Beijing 100190, China)
-
摘要: 該文提出一種新的同時具有高重復頻率和大帶寬性能的相干激光雷達系統。該系統基于IQ調制器正交調制技術與帶寬合成信號處理技術,使得系統能夠同時滿足大帶寬和高重復頻率的要求,解決了傳統激光雷達寬帶信號調制速度慢的問題。該系統能夠生成高重頻、大帶寬的相干線性調頻激光雷達信號,在高分辨距離成像、(逆)合成孔徑激光雷達成像、距離分辨的振動測量等方面,具有重要的應用價值。文中闡述了寬帶高重復頻率調制的原理和方法、基于微波域頻率步進的帶寬合成信號處理方法,并進行光纖環路實驗和自由空間實驗。作為演示,該激光雷達系統獲得了16.7 kHz重復頻率、6 GHz帶寬,實現了優于2.5 cm距離向分辨率成像及遠距離運動目標逆合成孔徑激光雷達成像。實驗結果證明了該系統與方法的有效性。
-
關鍵詞:
- 相干激光雷達 /
- 高重復頻率 /
- 帶寬合成 /
- 高分辨率距離成像
Abstract: A novel coherent ladar system with high repetition and wide bandwidth is proposed. Based on the IQ modulator from the fiber communication community and the bandwidth synthesis technique, the proposed system provides wide bandwidth with high repetition rate, which is difficult for conversional ladar system based on tuning the wavelength of a tunable laser. The proposed system is expected to be useful for high range resolution imaging, Inverse Synthetic Aperture Ladar (ISAL), range resolved vibration measurement. The operation principle, system description, and signal processing method for bandwidth synthesis are discussed in the paper. And experiments are performed both in fiber delay line and free space. As a demonstration, the system generates signal with 6 GHz at repetition rate of 16.7 kHz. The resolution of the obtained images is finer than 2.5 cm. The experimental results demonstrates the effectiveness of the proposed system and the processing method. -
PIERROTTET D, AMZAJERDIAN F, PETWAY L, et al. Linear FMCW laser radar for precision range and vector velocity measurements[C]. Material Research Society (MRS) Meeting, San Francisco, U.S.A, 2008: 1076-1085. KRAUSE B W, BUCK J, Hwang D, et al. Synthetic aperture ladar flight demonstration[C]. IEEE Lasers and Electro- Optics Conference, Baltimore, Maryland, USA, 2011: 1-2. CARNS J. Semiconductor optical amplifier as a phase modulator for short-pulse synthetic aperture ladar and vibrometry[D]. [Ph.D. dissertation], The Dayton University, 2012: 7-9. RICHARDS M. Fundamentals of Radar Signal Processing[M]. New York: McGraw-Hill, 2005: 139-147. BUELL W, MARECHAL N, BUCK J, et al. Demonstrations of synthetic aperture imaging ladar[J]. Proceedings of the SPIE, 2005, 5791: 152-166. doi: 10.1117/12.609682. BECK S, BUCK J, BUELl W, et al. Synthetic-aperture imaging laser radar: Laboratory demonstration and signal processing[J]. Applied Optics, 2005, 44(35): 7621-7629. LI G, WANG R, WANG P, et al. Synthetic aperture LADAR at 1550 nm: System demonstration, imaging processing and experimental result[J]. Proceedings of the SPIE, 2016, 10155: 155-158. doi: 10.1117/12.2247376. ADANY P, ALLEN C, and HUI R. Chirped lidar using simplified homodyne detection[J]. Journal of Lightwave Technology, 2009, 27(16): 3351-3357. GAO S and HUI R. Frequency-modulated continuous-wave lidar using I∕Q modulator for simplified heterodyne detection[J]. Optics Letters, 2012, 37(11): 2022-2024. LI G, WANG R, SONG Z, et al. Linear frequency modulated continuous wave ladar system for synthetic aperture imaging[J] Applied Optics, 2017, 56(12): 3257-3262. LI G, WANG N, WU Y, et al. Imaging method for airborne SAL data[J]. Electronics Letters, 2017, 53(5): 351-353. doi: 10.1049/el.2016.4205. SCHIMPF H, WAHLEN A, and ESSEN H. High range resolution by means of synthetic bandwidth generated by frequency- stepped chirps[J]. Electronics Letters, 2003, 39(18): 1346-1348. doi: 10.1049/el:20030829. ESSEN H, SCHIMPF H, and WAHLEN A. Improvement of the millimeterwave SAR MEMPHIS for very high resolution [R]. FGAN-FHR Technical Report, Werthhoven, 2003. 王巖飛, 劉暢, 李和平, 等. 基于多通道合成的優于 0.1 m 分辨率的機載 SAR 系統[J]. 電子與信息學報, 2013, 35(1): 29-35. doi: 10.3724/SP.J.1146.2011.01370. WANG Yanfei, LIU Chang, LI Heping, et al. An airborne SAR with 0.1 m resolution using multi-channel synthetic bandwidth[J]. Journal of Electronics Information Technology, 2013, 35(1): 29-35. doi: 10.3724/SP.J.1146.2011. 01370. MOTTET A and NICOLAS B. Tunable frequency shifter based on LiNbO3-IQ modulators[R]. Pthotline Delivering Modulation Solutions, 2016. CARRAR G, GOODMAN R S, and MAJEWSKI R M. Spotlight Synthetic Aperture Radar Signal Processing Algorithms[M]. Norwood Massachusetts, Artech House, 1995: 501-506. -
