航磁全軸總場梯度系統補償算法研究

吳佩霖; 張群英; 李光; 劉麗華; 方廣有

doi:10.11999/JEIT170233

航磁全軸總場梯度系統補償算法研究

doi: 10.11999/JEIT170233

基金項目:

國家重大科研裝備研制項目(ZDYZ2012-1-03)

計量
- 文章訪問數: 1103
- HTML全文瀏覽量: 152
- PDF下載量: 841
- 被引次數: 0
出版歷程
- 收稿日期: 2017-03-20
- 修回日期: 2017-09-01
- 刊出日期: 2017-12-19

Research on Compensation Algorithm of Three Axis Gradient Aeromagnetic Prospecting System

Funds:

RD of Key Instruments and Technologies of China (ZDYZ2012-1-03)

摘要

摘要: 航空磁法勘探是一種高效、便捷的地球物理勘探方法。使用多個光泵磁力儀實現全軸梯度測量是航空磁法勘探中的一種重要手段。該文針對無人機飛行平臺設計了一種航磁全軸總場梯度測量系統，并提出使用前饋網絡的方法來實現航磁數據的補償。系統通過4個光泵磁力儀獲得全軸總場梯度數據，經過前饋網絡實現數據補償后，全軸總場梯度數據補償質量的提升比分別為15.2, 4.7和5.9，數據峰值信噪比的提升分別為17.1 dB, 6.5 dB和6.5 dB，交叉標定系數表明前饋網絡具有很好的泛化性能。實驗結果驗證了該文采用的全軸梯度系統和數據補償方法的正確性和有效性，能夠有效地應用于高精度航磁勘探領域。
- 地球物理勘探 /
- 全軸磁總場梯度 /
- 航磁補償 /
- 光泵磁力儀 /
- 無人直升機
Abstract: Aeromagnetic prospecting is an important method in geophysical prospecting for its high-efficiency and convenience. In the paper, a new kind of the three axis gradient system based on the unmanned helicopter is designed and an aeromagnetic compensation method based on the neural network is proposed. The system is equipped with four Optically Pumped Magnetometers (OPMs), from which the three axis gradient data can be achieved. In aeromagnetic compensation, the feedforward network is used. The Improvement Ratio (IR) of the three axis gradient data is 15.2, 4.7 and 5.9, respectively. The Peak Signal to Noise Ratio (PSNR) of the three axis gradient data is improved by 17.1 dB, 6.5 dB and 6.5 dB, respectively. Through the result of the Cross Calibration Index (CCI), the generalization ability of the method is good. The three axis gradient system and the aeromagnetic compensation are proven valid in aeromagnetic prospecting by an experiment.
- Geophysical prospecting /
- Three axis gradient system /
- Aeromagnetic compensation /
- Optically Pumped Magnetometer (OPM) /
- Unmanned helicopter

HTML全文

參考文獻(29)

NABIGHIAN M N, GRAUCH V J S, HANSEN R O, et al. The historical development of the magnetic method in exploration[J]. Geophysics, 2005, 70(6): 33ND-61ND. doi: 10.1190/1.2133784.

HOOD P. History of aeromagnetic surveying in Canada[J]. Leading Edge, 2012, 26(11): 1384-1392. doi: 10.1190/1. 2805759.

DOLL W E, GAMEY T J, BELL D T, et al. Historical development and performance of airborne magnetic and electromagnetic systems for mapping and detection of unexploded ordnance[J]. Journal of Environmental Engineering Geophysics, 2012, 17(1): 1-17. doi: 10.2113/ JEEG17.1.1.

NORIEGA G. Aeromagnetic compensation in gradiometry- performance, model stability, and robustness[J]. IEEE Geoscience and Remote Sensing Letters, 2015, 12(1): 117-121. doi: 10.1109/LGRS.2014.2328436.

HARDWICK C D. Non-oriented cesium sensors for airborne magnetometry and gradiometry[J]. Exploration Geophysics, 1984, 27(4): 266-267. doi: 10.1071/EG984266d.

FORRESTER R, HUQ M S, AHMADI M, et al. Magnetic signature attenuation of an unmanned aircraft system for aeromagnetic survey[J]. IEEE/ASME Transactions on Mechatronics, 2014, 19(4): 1436-1446. doi: 10.1109/TMECH. 2013.2285224.

ZHANG B, GUO Z, and QIAO Y. A simplified aeromagnetic compensation model for low magnetism UAV platform[C]. IEEE Geoscience and Remote Sensing Symposium, Vancouver, BC, Canada, 2011: 3401-3404. doi: 10.1109/ IGARSS.2011.6049950.

HARDWICK C D. Aeromagnetic gradiometry in 1995[J]. Exploration Geophysics, 1996, 27(1): 1-11. doi: 10.1071/ EG996001.

NELSON J B. Aeromagnetic noise during low-altitude flights over the scotian shelf: DRDC-ATLANTIC-TM-2002-089[R]. Dartmouth NS: Defence Research Development Canada Atlantic, 2002, 1-40.

TOLLES W E and MINEOLA N Y. Compensation of aircraft magnetic fields[P]. US, Patent, US2692970, 1954.

TOLLES W E and MINEOLA N Y. Magnetic field compensation system[P]. US, Patent, US2706801, 1955.

LELIAK P. Identification and evaluation of magnetic-field sources of magnetic airborne detector equipped aircraft[J]. IRE Transactions on Aerospace and Navigational Electronics, 1961, 8(3): 95-105. doi: 10.1109/TANE3.1961.4201799.

LEACH B W. Aeromagnetic compensation as a linear regression problem[J]. Information Linkage Between Applied Mathematics and Industry, 1980, 2: 139-161. doi: 10.1016/ B978-0-12-628750-9.50017-6.

HARDWICK C D. Important design considerations for inboard airborne magnetic gradiometers[J]. Geophysics, 1984: 49(11): 2004-2018. doi: 10.1190/1.1441611.

NELSON J B. Aircraft magnetic noise sources[C]. 8th International Congress of the Brazilian Geophysical Society, Brazilian, 2003: 41506.

NELSON J B. Aeromagnetic noise from magnetometers and data acquisition systems[C]. 8th International Congress of the Brazilian Geophysical Society, Brazilian, 2003: 41507.

NELSON J B. Predicting in-flight MAD noise from ground measurements: DREA-TM-2001-112[R]. Dartmouth NS: Defence Research Establishment Atlantic, 2002, 1-26.

駱遙, 段樹嶺, 王金龍, 等. AGS-863航磁全軸梯度勘查系統關鍵性指標測試[J]. 物探與化探, 2011, 35(5): 620-625.

LUO Yao, DUAN Shuling, WANG Jinlong, et al. Key indicators testing for AGS-863 three axis airborne magnetic gradiometer[J]. Geophysical and Geochemical Exploration, 2011, 35(5): 620-625.

駱遙, 吳美平. 位場向下延拓的最小曲率方法[J]. 地球物理學報, 2016, 59(1): 240-251. doi: 10.6038/cjg20160120.

LUO Yao and WU Meiping. Minimum curvature method for downward continuation of potential field data[J]. Chinese Journal of Geophysics, 2016: 59(1): 240-251. doi: 10.6038/ cjg20160120.

王林飛, 薛典軍, 段樹嶺, 等. 航磁軟補償動作規范性評價[J]. 物探與化探, 2016: 40(2): 365-369. doi: 10.11720/wtyht.2016. 2.21.

WANG Linfei, XUE Dianjun, DUAN Shuling, et al. The normative evaluation of aeromagnetic compensation action[J]. Geophysical and Geochemical Exploration, 2016: 40(2): 365-369. doi: 10.11720/wtyht.2016.2.21.

趙建揚, 林春生, 賈文抖, 等. 直升機平臺背景磁干擾建模與求解[J]. 華中科技大學學報(自然科學版), 2016, 44(2): 21-25. doi: 10.13245/j.hust.160205.

ZHAO Jianyang, LIN Chunsheng, JIA Wendou, et al. Helicopter platform background magnetic interference modeling and solution[J]. Journal of Huazhong University of Science and Technology(Natural Science Edition), 2016, 44(2): 21-25. doi: 10.13245/j.hust.160205.

趙建揚, 林春生, 孫玉繪, 等. 直升機平臺背景磁干擾建模與特性分析[J]. 海軍工程大學學報, 2016, 28(1): 36-40. doi: 10.7495/j.issn.1009-3486.2016.01.008.

ZHAO Jianyang, LIN Chunsheng, SUN Yunhui, et al. Modeling and characterization of helicopter platform background magnetic interference[J]. Journal of Naval University of Engineering, 2016, 28(1): 36-40. doi: 10.7495/ j.issn.1009-3486.2016.01.008.

張寧, 趙建揚, 林春生, 等. 直升機平臺背景磁干擾小信號模型求解與補償[J]. 電子學報, 2017, 45(1): 83-88. doi: 10.3969/ j.issn.0372-2112.2017.01.012.

ZHANG Ning, ZHAO Jianyang, LIN Chunsheng, et al. Helicopter platform background magnetic interference small signal model solving and compensation[J]. Acta Electronica Sinica, 2017, 45(1): 83-88. doi: 10.3969/j.issn.0372-2112.2017. 01.012.
