平面陣列方向圖優化的改進PSO算法
doi: 10.11999/JEIT170167
-
2.
(空軍哈爾濱飛行學院飛行仿真技術研究所 哈爾濱 150001) ②(哈爾濱工業大學導航制導與控制理論中心 哈爾濱 150001)
基金項目:
國家自然科學基金(61273095)
Modified PSO Algorithm for Planar Arrays Pattern Optimization
-
2.
(Flight Simulation Technology Institute, Air Force Harbin Flight Academy, Harbin 150001, China)
Funds:
The National Natural Science Foundation of China (61273095)
-
摘要: 粒子群優化算法(PSO)是合成天線陣列預期方向圖的有效手段。但對于某些大型平面陣列方向圖復雜的非線性優化問題，該算法收斂速度慢且最優粒子易陷入局部最優解，因而使得算法失效。針對這一問題，該文提出一種改進PSO算法來提高傳統PSO算法的收斂特性。該算法在初始化最優粒子時采用解析初值而不是隨機初值。對于給定的預期方向圖，通過矩陣運算解析對應該方向圖的陣元權系數。之后將這些權系數指定為任意一個粒子的解析初值，而種群的其他粒子仍然賦隨機初值，之后再銜接標準PSO算法的尋優迭代過程。這種初始化方法使得種群粒子在尋優搜索過程開始之前，即可得到最優粒子初值的有效估計。仿真結果表明，相對于全部粒子賦隨機初值的標準算法而言，這種改進算法收斂速度更快，適應度值收斂得更深，因而有效提高了算法的收斂特性，從而能夠得到滿足預期方向圖指標要求的優化結果。
-
關鍵詞:
- 有源相控陣 /
- 平面陣列 /
- 副瓣干擾 /
- 方向圖優化 /
- 粒子群優化算法
Abstract: Particle Swarm Optimization (PSO) is an efficient technology to synthesize desired pattern of antenna arrays. But in some complicated cases, the optimizer will fail because the optimum particles fall into local best solutions and the convergence is so bad, especially for nonlinear optimization of large planar arrays pattern. To solve this problem, a modified optimizer is presented to improve the convergence of traditional PSO by means of initializing the particles with analytical values rather than random values. For any given desired pattern, the corresponding aperture weights can be derived by matrix operations and these weights are then used as a particles initial values while other particles are still initialized randomly. By this initialization, an efficient estimation of the optimum particles initial values can be achieved before the beginning of all particles searching process. After that the standard PSO iterations work as usual. The simulation results prove that this modified optimizer converges more rapidly and deeply than the traditional PSO and more satisfying global solutions and desired pattern could be obtained. -
KINGHORN T, SCOTT I, and TOTTEN E. Recent advances in airborne phased array radar systems[C]. IEEE International Symposium on Phased Array Systems and Technology, Waltham, Massachusetts, USA, 2016: 1-7. doi: 10.1109/ARRAY.2016.7832541. MAHAFZA B R and ELSHERBENI A Z. MATLAB Simulations for Radar Systems Design[M]. Boca Raton London New York Washington, D.C. USA, Chapman Hall/ CRC CRC Press LLC, 2004: 8.5. 趙菲, 齊會穎, 邱磊, 等. 自適應動態Meta粒子群優化算法綜合多方向圖共形陣列[J]. 電子與信息學報, 2012, 34(6): 1476-1482. doi: 10.3724/SP.J.1146.2011.01187. ZHAO Fei, QI Huiying, QIU Lei, et al. Adaptive dynamic meta particle swarm optimization algorithm synthesizing multiple-pattern conformal array[J]. Journal of Electronics Information Technology, 2012, 34(6): 1476-1482. doi: 10.3724 /SP.J.1146.2011.01187. 袁智皓, 耿軍平, 金榮洪, 等. 基于改進的粒子群算法的二維陣列天線方向圖綜合技術[J]. 電子與信息學報, 2007, 29(5): 1236-1239. YUAN Zhihao, GENG Junping, JIN Ronghong, et al. Pattern synthesis of 2-D arrays based on a modified particle swarm optimization algorithm[J]. Journal of Electronics Information Technology, 2007, 29(5): 1236-1239. OLIVERI G, VIANI F, ANSELMI N, et al. Synthesis of multilayer WAIM coatings for planar-phased arrays within the system-by-design framework[J]. IEEE Transactions on Antennas and Propagation, 2015, 63(6): 2482-2496. doi: 10.1109/TAP.2015.2415516. HADJ A L and BOUSSOUAR B. New optimisation algorithm for planar antenna array synthesis[J]. AEU- International Journal of Electronics and Communications, 2012, 66(9): 752-757. doi: 10.1016/j.aeue.2012.01.00. YU Xiaomeng, ZHANG Yan, DONG Tao, et al. Design of low side-lobe level conformal antenna array by PSO-GA[C]. IEEE International Conference on Ubiquitous Wireless Broadband, Nanjing, China, 2016: 1-3. doi: 10.1109/ICUWB.2016. 7790529. GHATAK R, KARMAKAR A, and PODDAR D R. Evolutionary optimization of Haferman carpet fractal patterned antenna array[J]. International Journal of RF and Microwave Computer-Aided Engineering, 2015, 25(8): 719-729. doi: 10.1002/mmce.20911. MANICA L, CARLIN M, MALCIC I, et al. Wideband multilayer WAIM design and optimization[C]. 8th European Conference on Antennas and Propagation, Hague, the Netherlands, 2014: 2997-3000. doi: 10.1109/EuCAP.2014. 6902458. BERA R, MANDAL D, GHOSHAL S P, et al. Optimal design of concentric elliptical array antenna for maximum side-lobe level reduction using particle swarm optimization with aging leader and challengers[C]. International Conference on Communication and Signal Processing (ICCSP), Melmaruvathur, Tamilnadu, India, 2016: 1817-1821. doi: 10.1109/ICCSP.2016.7754482. REZAGHOLI A and MOHAJERI F. Directivity optimization of fractal antenna arrays using PSO algorithm[C]. IEEE 24th Iranian Conference on Electrical Engineering (ICEE), Shiraz, Iran, 2016: 1224-1228. doi: 10.1109/IranianCEE.2016. 7585708. BROWN A D. Electronically Scanned Arrays: MATLAB Modeling and Simulation[M]. Boca Raton London New York, CRC Press, Taylor Francis Group, LLC, 2012: 35-80. KENNEDY J and EBERHART R. Particle swarm optimization[C]. Proceedings of the 1995 IEEE International Conference on Neural Networks, Part 1 (of 6), Perth, Austrilia, 1995, 4: 1942-1948. SHI Yuhui and EBERHART R. A modified particle swarm optimizer[C]. Proceedings of the IEEE International Conference on Evolutionary Computation, Anchorage, AK, USA, 1998: 69-73. -
