一種基于開口諧振環的高增益寬帶雙極化天線設計

任宇輝; 丁君; 郭陳江

doi:10.11999/JEIT170111

一種基于開口諧振環的高增益寬帶雙極化天線設計

doi: 10.11999/JEIT170111

2.
(西北工業大學電子信息學院西安 710129) ②(西北大學信息科學與技術學院西安 710069)

基金項目:

西安愛生創新發展基金(ASN-IF2015-0901)

計量
- 文章訪問數: 1963
- HTML全文瀏覽量: 288
- PDF下載量: 295
- 被引次數: 0
出版歷程
- 收稿日期: 2017-02-10
- 修回日期: 2017-08-17
- 刊出日期: 2017-11-19

Design of a High-gain Wideband Dual-polarized Antenna Based on Split Ring Resonators

2.
(School of Electronics and Information, University of Northwestern Polytechnical, Xi&rsquo

Funds:

The Innovation Development Fund of Xi'an Aisheng Group (ASN-IF2015-0901)

摘要

摘要: 該文設計并制作了一種基于超材料的高增益寬帶雙極化天線，該天線由兩個正交放置的印刷振子單元、饋電巴倫及金屬接地板構成。為了進一步展寬帶寬、提高增益，在天線上了加載開口諧振環、互補開口諧振環等超材料結構。測試結果表明，該天線回波損耗小于-10 dB的帶寬約為69%(0.98~2.01 GHz)，在相同的頻帶內隔離度大于20 dB。由于開口諧振環的引向作用，天線的輻射特性得到改善，增益最大提高了4.1 dB左右。和已有設計相比，該天線的總體高度減小了約12%。其可以當作獨立天線使用，也可用作反射面天線的雙極化饋源。
- 開口諧振環 /
- 互補開口諧振環 /
- 雙極化天線
Abstract: A wideband and high gain dual-polarized antenna based on split ring resonators is presented. The antenna is composed of two cross printed dipole antennas vertically fixed on an aluminum plate as ground plane, which are excited by two similar micro-strip baluns. In order to further improve the gain with a broad bandwidth, split ring resonators and complementary split ring resonators are loaded on the printed dipole antennas. Measured results show that the proposed antenna achieves -10 dB return loss with bandwidth of 0.98~2.01 GHz (69%), and its port isolation is higher than 20 dB within that band. The maximum gain of antenna is improved up by 4.1 dB because of split ring resonators. Furthermore, the height of the antenna is reduced about 12% than the LPPDs- DPA.
- Split ring resonators /
- Complementary split ring resonators /
- Dual-polarized antenna

HTML全文

參考文獻(20)

CUI Guanfeng, ZHOU Shigang, ZHAO Gang, et al. A compact dual-polarized antenna for base station application [J]. Progress in Electromagnetics Research Letters, 2016, 59: 7-13. doi: 10.2528/PIERL16010804.

LI Z, CHEN L, ZHANG H, et al. Dual-polarized patch antenna with high isolation for DTV applications[J]. Journal of Electromagnetic Waves and Applications, 2013, 27(14): 1759-1766. doi: 10.1080/09205071.2013.823359.

SIMONE Z, GERARD Zamora, PAU A, et al. Analysis of the split ring resonator (SRR) Antenna applied to passive UHF- RFID tag design[J]. IEEE Transactions on Antennas and Propagation, 2016, 64(3): 856-864. doi: 10.1109/TAP.2015. 2513084.

GAO, Shichang, LI Lewei, LEONG M, et al. Dual-polarized slot-coupled planar antenna with wide bandwidth[J]. IEEE Transactions on Antennas and Propagation, 2003, 51(3): 441-448. doi: 10.1109/TAP.2003.809842.

薛飛, 王宏建, 董興超. 新型單層雙頻雙極化微帶反射陣天線的設計[J]. 電子與信息學報, 2017, 39(3): 697-702. doi: 10.11999/JEIT160332.

XUE Fei, WANG Hongjian, and DONG Xingchao. Design of a novel single layer dual-band dual-polarization microstrip reflectarray antenna[J]. Journal of Electronics Information Technology, 2017, 39(3): 697-702. doi: 10.11999/JEIT160332.

高喜, 思敏, 劉揚清, 等. 寬帶雙極化四脊喇叭饋源研究[J]. 電波科學學報, 2013, 28(2): 337-340.

GAO Xi, LI Simin, LIU Yangqing, et al. Broadband and dual-polarized horn feed source[J]. Chinese Journal of Radio Science, 2013, 28(2): 337-340.

ZHAI Guohua, CHENG Yong, YIN Qiuyan, et al. Gain enhancement of printed log-periodic dipole array antenna using director cell[J]. IEEE Transactions on Antennas and Propagation, 2014, 62(8): 5915-5919. doi: 10.1109/TAP.2014. 2355851.

ZHAI Guohua, HONG Wei, WU Ke, et al. Wideband substrate integrated printed log-periodic dipole array antenna[J]. IET Microwaves, Antennas Propagation, 2010, 4(7): 899-905. doi: 10.1049/iet-map.2009.0305..

伍捍東, 王曉娜, 任宇輝, 等. 基于缺陷地結構的寬帶雙極化天線設計[C]. 2013年全國天線年會, 廣州, 2013: 96-199.

WU Handong, WANG Xiaona, REN Yuhui, et al. New dual- polarized micro-strip dipole antenna by loading DGS[C]. 2013 National Conference on Antenna of China, Guangzhou, 2013: 196-199.

REN Yuhui, DING Jun, GUO Chenjiang, et al. A wideband dual-polarized printed antenna based on CSRRs[J]. IEEE Antennas Wireless Propagation Letters, 2015, 14: 410-413. doi: 10.1109/LAWP.2014.2367126.

REN Yuhui, DING Jun, GUO Chenjiang, et al. A wideband gain-enhanced dual-polarized printed antenna based on log- periodic parasitic directors (LPPDs)[J]. Journal of Electromagnetic Waves and Applications, 2016, 30(8): 1021-1031. doi: 10.1080/09205071.2016.1168751.

YOO M and LIM S. SRR-and CSRR-loaded ultra-wideband (UWB) antenna with tri-band notch capability[J]. Journal of Electromagnetic Waves and Applications, 2013, 27(8): 2190-2197. doi: 10.1080/09205071.2013.837013.

張明旭, 龔書喜, 劉英. 利用接地板開槽減縮微帶貼片天線的RCS [J]. 電子與信息學報, 2008, 30(2): 498-500.

ZHANG Mingxu, GONG Shuxi, and LIU Ying. Reducing the RCS of microstrip patch antenna by cutting slots on the ground plane[J]. Journal of Electronics Information Technology, 2008, 30(2): 498-500.

劉紅喜, 高軍, 曹祥玉, 等. 一種基于開口諧振環的高增益端射天線設計[J]. 物理學報, 2015, 64(23): 234101. doi: 10.7498/ aps.64.234101.

LIU Hongxi, GAO Jun, CAO Xiangyu, et al. A design of high-gain end-fire antenna based on split-ring resonator structures[J]. Acta Physica Sinica, 2015, 64(23): 234101. doi: 10.7498/aps.64.234101.

MARQUES R, MEDINA F, and RAFII-EL-LDRISSI R. Role of bianisotropy in negative permeability and left-handed metamaterials[J]. Physical Review B, 2002, 65: 144440. doi: 10.1103/PhysRevB.65.144440.
