復雜電磁環境下通信裝備干擾預測方法

李偉; 魏光輝; 潘曉東; 王雅平; 萬浩江; 孫梳清

doi:10.11999/JEIT170107

復雜電磁環境下通信裝備干擾預測方法

doi: 10.11999/JEIT170107

1.
(軍械工程學院電磁環境效應國家級重點實驗室石家莊 050003) ②(中國人民解放軍61469部隊 石家莊 050000)

基金項目:

國家自然科學基金(61372040)

計量
- 文章訪問數: 1372
- HTML全文瀏覽量: 240
- PDF下載量: 295
- 被引次數: 0
出版歷程
- 收稿日期: 2017-02-10
- 修回日期: 2017-04-24
- 刊出日期: 2017-11-19

Interference Prediction Method of Communication Equipment Under Complex Electromagnetic Environment

1.
(National Key Laboratory of Electromagnetic Environment Effects, College of Ordnance Engineering, Shijiazhuang 050003, China)
2.
(Unit 61469 of the PLA, Shijiazhuang 050000, China)

Funds:

The National Natural Science Foundation of China (61372040)

摘要

摘要: 該文通過通信裝備帶內電磁干擾效應機理研究，分別以峰值場強敏感和平均功率敏感為基礎，建立了兩種用頻裝備帶內多頻電磁干擾預測模型，提出一種電磁干擾預測方法。首先通過單頻和調幅波試驗確定受試裝備的敏感參量，然后根據不同敏感參量模型對某電磁環境下受試裝備是否會受到干擾進行預測。該文以不同制式通用通信裝備為試驗對象，通過帶內雙頻、帶內三頻電磁輻射效應試驗對預測方法進行了驗證。試驗結果表明：通過單頻和調幅連續波電磁輻射敏感度之間的差別能夠區分受試設備符合哪種帶內多頻電磁干擾預測模型，對干擾峰值場強敏感的EUT1預測模型效應指數都略大于1，對干擾平均功率敏感的EUT2預測模型效應指數都在1左右。以此為基礎提出了通信裝備帶內多頻電磁干擾預測方法，能夠有效解決通信裝備帶內多頻電磁干擾預測問題。
- 復雜電磁環境 /
- 效應預測 /
- 電磁干擾 /
- 帶內 /
- 多頻
Abstract: The communication equipment effect mechanism under in-band electromagnetic interference is studied in this paper. Two electromagnetic interference prediction models are established. One model is based on the assumption that in-band interference is sensitive to the amplitude of field strength, and the other is based on the assumption that in-band interference is sensitive to the average power. The sensitive parameter can be distinguished by sine and AM test, and the Equipment Under Test (EUT) interference is predicted according to different models. The sine and AM continuous wave test, in-band dual-frequency test, in-band triple-frequency test are conducted with two typical VHF radios as test objects. Experiment results show that EUT1 is sensitive to the amplitude of field strength, and the model results are slightly greater than 1, and EUT2 is sensitive to the average power. The model results are all approximate 1. The prediction method of in-band multi-frequency electromagnetic interference is modified and improved by the test results. The proposed prediction method is able to forecast the communication equipment interference effectively under the in-band multi-frequency electromagnetic environment.
- Complex electromagnetic environment /
- Effect prediction /
- Electromagnetic interference /
- In-band /
- Multi-frequency
