一種AlGaN/GaN HEMT非線性器件模型參數提取的方法

常永明; 毛維; 杜林; 郝躍

doi:10.11999/JEIT170097

一種AlGaN/GaN HEMT非線性器件模型參數提取的方法

doi: 10.11999/JEIT170097

基金項目:

國家自然科學基金(61574112 )，陜西省自然科學基礎研究計劃(605119425012)

計量
- 文章訪問數: 980
- HTML全文瀏覽量: 129
- PDF下載量: 179
- 被引次數: 0
出版歷程
- 收稿日期: 2017-01-24
- 修回日期: 2017-09-18
- 刊出日期: 2017-12-19

A Method for AlGaN/GaN HEMT Nonlinear Device Model Parameter Extraction

Funds:

The National Natural Science Foundation of China (61574112), The Natural Science Foundation Research Project of Shaanxi Provience (605119425012)

摘要

摘要: 該文提出一種新的絕對誤差函數，應用該函數進行非線性模型參數提取可以避免計算誤差，顯著降低參數提取的不準確性。由于氮化物半導體器件，尤其是AlGaN/GaN HEMT器件已經開始得到廣泛應用，其模型和參數對射頻和電力電子器件和電路設計至關重要，分別使用3種誤差函數對 AlGaN/GaN HEMT器件模型進行了參數提取并對比，對比結果表明該文提出的誤差函數更加精確和有效。同時為今后的電子器件的模型參數提取提供了一種有效且精確的方法。
- AlGaN/GaN HEMT /
- 絕對誤差函數 /
- 參數提取 /
- 遺傳算法
Abstract: A new absolute error function is presented in this paper. The function is applied to extract parameters of the nonlinear model, which can avoid the calculation error and reduce the inaccurate parameter extraction significantly. Nitride semiconductor devices are widely used, especially the AlGaN/GaN HEMT devices. The AlGaN/GaN HEMT model and parameters is very important to radio frequency, power electronic devices and circuit design. The new absolute error function is applied to extract the parameters of AlGaN/GaN HEMT nonlinear devices model. Through comparing three kinds of error function, the results show that the proposed error function is more accurate and effective. At the same time, a precise and effective method is provided to extract the parameters of electronic devices in the future.
- AlGaN/GaN HEMT /
- Absolute error function /
- Parameter extraction /
- Genetic algorithm
