基于空域稀疏性的方位依賴陣列誤差校正算法

李存勖; 陳伯孝

doi:10.11999/JEIT161318

基于空域稀疏性的方位依賴陣列誤差校正算法

doi: 10.11999/JEIT161318

李存勖¹,
陳伯孝¹

基金項目:

國家自然科學基金(61571344)

計量
- 文章訪問數: 1189
- HTML全文瀏覽量: 150
- PDF下載量: 252
- 被引次數: 0
出版歷程
- 收稿日期: 2016-12-08
- 修回日期: 2017-03-30
- 刊出日期: 2017-09-19

Spatial Sparsity Based Method on Calibration of Direction-dependent Array Errors

LI Cunxu¹,
CHEN Baixiao¹

Funds:

The National Natural Science Foundation of China (61571344)

摘要

摘要: 針對方位依賴陣列誤差的校正問題，通過引入少量精確校正的輔助陣元，該文給出一種基于空域稀疏性的方位依賴陣列誤差校正算法。將受方位依賴陣列誤差擾動的陣列流型表示為理想情況下的陣列流型與幅相誤差系數矩陣的乘積形式。同時利用接收信號的空域稀疏性，對接收信號進行稀疏表示，將陣列誤差自校正問題轉化為一個二元最優化問題，再通過交替迭代的優化方式求得兩個優化變量的最優解，從而實現了信號方位與方位依賴陣列誤差的聯合估計。該文所提算法相比于已有算法性能提升明顯，參數估計性能優于傳統算法且接近參數估計的Cramer-Rao下界，仿真實驗也驗證了算法的有效性和優越性。
- 陣列誤差校正 /
- 波達方向估計 /
- 空域稀疏性
Abstract: For calibration of direction-dependent gain-phase errors, with a few precisely calibrated instrumental sensors, a method that jointly estimates the direction-dependent gain-phase errors and the target azimuth by spatial sparsity of the signal is proposed. The array manifold that perturbed by direction-dependent gain-phase errors is denoted by the multiplication form of ideally array manifold and a gain-phase errors coefficient matrix, then the received signal is represented by sparse form. The calibration for gain-phase error problem is formulated as a dual optimization problem, through alternating iterative optimization method to acquire the optimal solution of the two optimization variables, so as to realize the signal incident angle and azimuth dependent amplitude and phase errors of the optimized calculation. In this paper, the proposed algorithm has better performance than the existing algorithm, performance of the proposed algorithm is approximate to the Cramer-Rao low bound. The simulation experiments verify the effectiveness and superiority of the proposed algorithm.
- Array calibration /
- Direction of arrive estimation /
- Spatial sparsity

HTML全文

參考文獻(20)

FRIEDLANDER B. A sensitivity analysis of the MUSIC algorithm[J]. IEEE Transactions on Acoustics, Speech, and Signal Processing, 1990, 38(10): 1740-1751. doi: 10.1109/29. 60105.

SCHMIDT R. Multiple emitter location and signal parameter estimation[J]. IEEE Transactions on Antennas and Propagation, 1986, 34(3): 276-280. doi: 10.1109/TAP.1986. 1143830.

FERREOL A, LARZABAL P and VIBERG M. On the asymptotic performance analysis of subspace DOA estimation in the presence of modeling errors: Case of MUSIC　[J]. IEEE Transactions on Signal Processing, 2006, 54(3): 907-920. doi: 10.1109/TSP.2005.861798.

DAI Z, SU W, GU H, et al. Sensor gain-phase errors estimation using disjoint sources in unknown directions[J]. IEEE Sensors Journal, 2016, 16(10): 3724-3730. doi: 10.1109 /JSEN.2016.2531282.

于斌, 宋錚, 張軍, 等. 陣列天線陣元位置誤差的一種有源校正方法[J]. 雷達科學與技術, 2004, 2(5): 315-320. doi: 10.3969 /j.issn.1672-2337.2004.05.013.

YU Bing, SONG Zheng, ZHANG Jun, et al. A new technique for calibrating position uncertainty of sensor array using signal sources[J]. Radar Science and Technology, 2004, 2(5): 315-320. doi: 10.3969/j.issn.1672-2337.2004.05.013.

Li J, JIN M, ZHENG Y, et al. Transmit and receive array gain-phase error estimation in bistatic MIMO radar[J]. IEEE Antennas and Wireless Propagation Letters, 2015, 14(3): 32-35. doi: 10.1109/LAWP.2014.2354334.

王布宏, 王永良, 陳輝, 等. 均勻線陣互耦條件下的魯棒DOA估計及互耦自校正[J]. 中國科學E輯: 技術科學, 2004, 34(2): 229-240. doi: 10.3321/j.issn:1006-9275.2004.02.010.

WANG Buhong, WANG Yongliang, CHEN Hui, et al. Robust DOA estimation and mutual coupling self-calibration algorithm for uniform linear array[J]. Science in China Series E: Technological Sciences, 2004, 34(2): 229-240. doi: 10.3321/ j.issn:1006-9275.2004.02.010.

王布宏, 王永良, 陳輝, 等. 方位依賴陣元幅相誤差校正的輔助陣元法[J]. 中國科學E輯: 技術科學, 2004, 34(8): 906-918. doi: 10.3321/j.issn:1006-9275.2004.08.006.

WANG Buhong, WANG Yongliang, CHEN Hui, et al. Array calibration of angularly dependent gain and phase uncertainties with carry-on instrumental sensors[J]. Science in China Series E: Technological Sciences, 2004, 34(8): 906-918. doi: 10.3321/j.issn:1006-9275.2004.08.006.

王鼎, 潘苗, 吳瑛, 等. 基于輔助陣元的方位依賴幅相誤差最大似然自校正: 針對確定信號模型[J]. 通信學報, 2011, 32(2): 34-41. doi: 10.3969/j.issn.1000-436X.2011.02.005.

WANG D, PAN M, WU Y, et al. Maximum likelihood self- calibration for direction-dependent gain-phase errors with carry-on instrumental sensors: Case of deterministic signal model[J]. Journal on Communications, 2011, 32(2): 34-41. doi: 10.3969/j.issn.1000-436X.2011.02.005.

LEI W and CHEN B. High-resolution DOA estimation for closely spaced correlated signals using unitary sparse Bayesian learning[J]. Electronics Letters, 2015, 51(3): 285-287. doi: 10.1049/el.2014.1317.

YANG Z, XIE L, and ZHANG C. Off-grid direction of arrival estimation using sparse Bayesian inference[J]. IEEE Transactions on Signal Processing, 2013, 61(1): 38-43. doi: 10.1109/TSP.2012.2222378.

WU J Q, ZHU W, and CHEN B. Compressed sensing techniques for altitude estimation in multipath conditions[J]. IEEE Transactions on Aerospace and Electronic Systems, 2015, 51(3): 1891-1900. doi: 10.1109/TAES.2015.130841.

林波, 張?jiān)鲚x, 朱炬波, 等. 基于壓縮感知的DOA估計稀疏化模型與性能分析[J]. 電子與信息學報, 2014, 36(3): 589-594. doi: 10.3724/SP.J.1146.2013.00149.

LIN Bo, ZHANG Zenghui, ZHU Jubo, et al. Sparsity model and perfomance analysis of DOA estimation with compressive sensing[J]. Journal Electronics Information Technology, 2014, 36(3): 589-594. doi: 10.3724/SP.J.1146.2013.00149.

ZHENG Y and CHEN B. Altitude measurement of low-angle target in complex terrain for very high-frequency radar[J]. IET Radar, Sonar Navigation, 2015, 9(8): 967-973. doi: 10.1049/iet-rsn.2014.0544.

KAUR A and BUDHIRAJA S. Sparse signal reconstruction via orthogonal least squares[C]. 2014 Fourth International Conference on Advanced Computing Communication Technologies, Rohtak, 2014: 133-137. doi: 10.1109/ACCT. 2014.49.
