Ka波段寬頻帶高線性空間行波管研制
doi: 10.11999/JEIT161267
-
1.
(中國科學院電子學研究所 北京 100190) ②(上海航天技術研究院804所 上海 201109)
基金項目:
國家自然科學基金(61401430)
Development of Ka-band Broadband, High-linearity Space Traveling Wave Tube
-
1.
(Institute of Electronics, Chinese Academy of Sciences, Beijing 100190, China)
-
2.
(Shanghai Academy of Spaceflight Technology 804, Shanghai 201109, China)
Funds:
The National Natural Science Foundation of China (61401430)
-
摘要: 該文對Ka波段空間行波管寬頻帶、高線性、高效率的慢波系統進行設計，通過動態漸變技術實現了低相位失真、高效率的指標要求。在此設計基礎上研制的Ka波段空間行波管實現了寬頻帶(25~27 GHz)、低非線性失真(非線性相移40 , AM/PM2.86/dB ，三階交調10.39 dBc)、高效率(總效率51.7%)。經數傳系統測試，誤碼pe優于10-6 的情況下C/N0有2.4 dB裕度，滿足了衛星數傳系統對多通道并行傳輸方案的工作需求。Abstract: In this paper, the design of Ka-band broadband, high-linearity and high-efficiency slow-wave system is proposed for Space Traveling Wave Tube (TWT). The dynamic phase-shifting technique is used to achieve low phase distortion and high efficiency. Based on this design, the Ka-band TWT is developed to realize wideband (25~27 ), low nonlinear distortion (non-linear phase shift40, AM / PM2.86/dB, third order intermodulation10.39 dBc), high efficiency (total efficiency51.7%). By the digital transmission system test, the error codepe is better than10-6 in the case ofC/N0 2.4 dB margin, it meets the satellite data transmission system for multi-channel parallel transmission program work requirements.
-
Key words:
- Space Traveling Wave Tube (TWT) /
- Ka band /
- Wide bandwidth /
- High linearity
-
GOEBEL D M, ADLER E A, and MENNINGER W L. Efficient, highly linear traveling wave tube[P]. US. Patent 59428521999. GOEBEL D M and ADLER E A. Optimally designed traveling wave tube for operation backed off from saturation [P]. U.S. Patent 59329711999. ABE D K, LEVUSH B, ANTONSEN T M, et al. Design of a linear C-band helix TWT for digital communications experiments using the CHRISTINE suite of large-signal codes[J]. IEEE Transactions on Plasmas Science, 2002, 30(3): 1053-1062. doi: 10.1109/TPS.2002.801635. HU X, WANG G, and LUO J R. A type of TWTA predistortion linearizer for space telecommunication applications[C]. IEEE International Conference on Wireless Communications, Networking and Information Security, Washington, DC, USA, 2010: 77-79. GARY H, NISHIMURA T B, and IWATA N. A highly efficient linearized wide-band CDMA handset power amplifier based on predistortion under various bias conditions[J]. IEEE Transactions on Microwave Theory and Techniques, 2001, 49(6): 1194-1201. doi: 10.1109/22.925522. WOLHLBIER J G, BOOSKE J H, and DOBSON I. Generation and growth rates of nonlinear distortions in a traveling wave tube[J]. Physics Review E, 2002, 66(5): 56504. doi: 10.1103/PhysRevE.66.056504. WOLHLBIER J G, DOBSON I, and BOOSKE J H. The Multifrequency Spectral Eulerian (MUSE) model of a traveling-wave tube[J]. IEEE Transactions on Plasmas Science, 2002, 30(3): 1063-1075. doi: 10.1109/TPS.2002. 801603. JOO Y D, SINHA A K, and PARK G S. Helix traveling wave tube performance optimization through circuit tapering[C]. The 30th International Conference on Plasmas Science, 2003: 176. doi: 10.1109/PLASMA.2003.1228635. LI Li, FENG Jinjun, and CAI Shaolun. Experiment on TWT 3IM suppression using harmonic and IM3 injection[C]. IEEE International Vacuum Electronics Conference, Monterey, CA, USA, 2008: 105-106. doi: 10.1109/IVELEC.2008.4556474. TSUTAKI K, YUASA Y, and MORIZUMI Y. Numerical analysis and design for high performance helix traveling wave tubes[J]. IEEE Transactions on Electron Devices, 1985, 32(9): 1842-1849. doi: 10.1109/T-ED.1985.22207. VGENERON L. Ka band traveling wave tube[OL]. www. thalesgroup.com/components-subsystems, 2010. -
