一種高效的混合Test-Per-Clock測試方法

劉鐵橋; 牛小燕; 楊潔; 毛峰

doi:10.11999/JEIT161202

一種高效的混合Test-Per-Clock測試方法

doi: 10.11999/JEIT161202

基金項目:

浙江省自然科學基金(LQ15F040005)

計量
- 文章訪問數: 1109
- HTML全文瀏覽量: 258
- PDF下載量: 193
- 被引次數: 0
出版歷程
- 收稿日期: 2016-11-08
- 修回日期: 2017-04-10
- 刊出日期: 2017-09-19

An Efficient Mixed-mode Test-Per-Clock Scheme

Funds:

Zhejiang Provincial Natural Science Foundation (LQ15F040005)

摘要

摘要: 該文提出了一種基于內建自測試(BIST)的Test-Per-Clock混合模式向量產生方法。測試由兩個部分組成：自由線性反饋移位寄存器(LFSR)偽隨機測試模式和受控LFSR確定型測試模式。偽隨機測試模式用于快速地檢測偽隨機易測故障，減少確定型數據存儲。受控LFSR測試模式采用直接存儲在ROM中的控制位流對剩余故障產生確定型測試。通過對提出的BIST混合模式測試結構理論分析，提出了偽隨機向量的選取方法以及基于受控線性移位確定型測試生成方法?；鶞?zhǔn)電路的仿真結果表明，該方法可以獲得完全單固定型故障覆蓋率，其測試產生器設計簡單且具有良好的穩定性，與其他方法相比，具有較低的測試開銷和較短的測試應用時間。
- IC測試 /
- 內建自測試 /
- Test-Per-Clock測試 /
- 測試生成
Abstract: A mixed-mode Test-Per-Clock Built In Self Test (BIST) scheme is proposed. The test consists of two parts: the free Linear Feedback Shift Register (LFSR) pseudo-random test mode and the deterministic test pattern based on controlled LFSR. Pseudo random test mode is used to quickly detect pseudo-random susceptible faults and reduce the deterministic data storage. Controlled LFSR test mode uses the control bits directly stored in the ROM to generate a deterministic test of the remaining faults. Based on the theoretical analysis of the proposed mixed-mode BIST test structure, a pseudo-random test sequence selection method and a deterministic test generation method based on controlled linear shifter are proposed. Simulation results on benchmark circuits show that the proposed method can obtain the complete single stuck-at fault coverage and has good stability in test generation. Compared with other methods, it has simpler Test Pattern Generator (TPG) design and lower test cost as well as shorter test application time.
- IC test /
- Built In Self Test (BIST) /
- Test-Per-Clock test /
- Test generation

HTML全文

參考文獻(21)

LI L and MIN Y. An efficient BIST design using LFSR- ROM architecture[C]. 9th Asian Test Symposium, Taipei, 2000: 386-390.

CHATTERJEE M and PRADHAN D K. A BIST pattern generator design for near-perfect fault coverage[J]. IEEE Transactions on Computers, 2003, 52(12): 1543-1558. doi: 10.1109/TC.2003.1252851.

FISER P and KUBATOVA H. An efficient mixed-mode BIST technique[C]. 7th IEEE Design and Diagnostics of Electronic Circuits and Systems Workshop 2004, Tatransk Lomnica, SK, 2004: 227-230.

JAS A, KRISHANA C V, and TOUBA N A. Weighted pseudo-random hybrid BIST[J]. IEEE Transactions on Very Large Scale Integration (VLSI) Systems, 2004, 12(12): 1277-1283. doi: 10.1109/TVLSI.2004.837985.

WANG Seongmoon, WEI Wenlong, and WANG Zhanglei. A low overhead high test compression technique using pattern clustering with n-detection test support[J]. IEEE Transactions on Very Large Scale Integration (VLSI) Systems, 2010, 18(12): 1672-1685. doi: 10.1109/TVLSI.2009.2026420.

KALLIGEROUS E, BAKALIS D, KAVOUSIANOS X, et al. Reseeding-based test set embedding with reduced test sequences[C]. International Symposium on Quality Electronic Design, San Jose, 2005: 226-231.

胡晨, 許舸夫, 張哲. 一種基于受控LFSR的內建自測試結構及其測試矢量生成[J]. 電路與系統學報, 2002, 7(3): 13-16.

HU Chen, XU Gefu, and ZHANG Zhe. A BIST structure and test pattern generation method based on controlled LFSR[J]. Journal of Circuits and Systems, 2002, 7(3): 13-16.

YOU Zhiqiang, WANG Weizheng, DOU Zhiping, et al. A scan disabling-based BAST scheme for test cost reduction[J]. IEICE Electronics Express, 2011, 8(16): 1367-1373.

ACEVEDO O and KAGARIS D. On the computation of LFSR characteristic polynomials for built-in deterministic test pattern generation[J]. IEEE Transactions on Computers, 2016, 65(2): 664-669. doi: 10.1109/TC.2015.2428697.

CHEN L, CUI Aijiao, and CHANG C H. Design of optimal scan tree based on compact test patterns for test time reduction[J]. IEEE Transactions on Computers, 64(12), 2015: 3417-3492. doi: 10.1109/TC.2015.2401019.

LIU T, KUANG J, YOU Z, et al. An effective deterministic test generation for test-per-clock testing[J]. IEEE Aerospace Electronic Systems Magazine, 2014, 29(5): 25-33. doi: 10.1109/MAES.2014.130192.

MRUGALSKI G, RAJSKI J, SOLECKI J, et al. Test express -new time-effective scan-based deterministic test paradigm[C]. 2015 IEEE 24th Asian Test Symposium(ATS), Mumbai, 2015: 19-24.

RAJSKI J, SOLECKI J, TYSZER J, et al. Scan chain configuration for test-per-clock based on circuit topology[P]. US9009553, 2015.

SHIAO C M, LIEN W C, and LEE K J. A test-per-cycle BIST architecture with low area overhead and no storage requirement[C]. 2016 International Symposium on VLSI Design, Automation and Test (VLSI-DAT), Hsinchu, 2016: 1-4.

NOVAK O and NOSEK J. Test-per-clock testing of the circuits with scan[C]. Proceedings Seventh International On-Line Testing Workshop, Giardini Naxos, Taormina, Italy, 2001: 90-92.

LEE H K and HA D S. Atalanta: An efficient ATPG for combinational circuits[R]. Technical Report, 93-12, Department of Electrical Engineering, Virginia Polytechnic Institute and State University, Blacksburg, Virginia, 1993.

LEE H K and HA D S. HOPE: An efficient parallel fault simulator for synchronous sequential circuits[J]. IEEE Transactions on Computer-Aided Design of Integrated Circuits and Systems, 1996, 15(9): 1048-1058. doi: 10.1109/ 43.536711.

鄺繼順, 周穎波, 蔡爍. 一種用于測試數據壓縮的自適應EFDR編碼方法[J]. 電子與信息學報, 2015, 37(10): 2529-2535. doi: 10.11999/JEIT150177.

KUANG Jishun, ZHOU Yingbo and CAI Shuo. Adaptive EFDR coding method for test data compression[J]. Journal of Electronics Information Technology, 2015, 37(10): 2529-2535. doi: 10.11999/JEIT150177.

KUANG J, ZHANG L, YOU Z, et al. Improve the compression ratios for code-based test vector compressions by decomposing[C]. 20th IEEE European Test Symposium (ETS), Cluj-Napoca, 2015: 1-6.
