基于模式匹配及BLT方程的腔體內場線耦合計算方法研究

任丹; 杜平安; 陳珂; 肖培; MichelsonGDavid

doi:10.11999/JEIT161101

基于模式匹配及BLT方程的腔體內場線耦合計算方法研究

doi: 10.11999/JEIT161101

2.
(電子科技大學機械電子工程學院成都 611731) ②(英屬哥倫比亞大學電氣與信息工程學院溫哥華 V6T1Z4)

基金項目:

國家自然科學基金(51675086)

計量
- 文章訪問數: 1027
- HTML全文瀏覽量: 177
- PDF下載量: 280
- 被引次數: 0
出版歷程
- 收稿日期: 2016-10-18
- 修回日期: 2017-02-15
- 刊出日期: 2017-08-19

Analytic Method Based on Mode Matching and BLT Equation for Field to Wire Coupling in an Enclosure

2.
(Department of Mechatronics Engineering, University of Electronic Science and Technology of China, Chengdu 611731, China)

Funds:

The National Natural Science Foundation of China (51675086)

摘要

摘要: 金屬腔體內的場線耦合是電磁兼容領域的一個重要的問題，基于模式匹配及BLT方程理論，該文提出一種計算帶孔陣腔體內場線耦合的方法。將外部激勵源對腔體內傳輸線的耦合分解為孔腔耦合和場線耦合兩個過程，腔體內任意點的場強由模式匹配理論及矩量法計算得到，腔體內的場線耦合由Agrawal模型構建BLT方程進行計算。與測試數據對比得出，模式匹配理論可以準確計算腔體內部電磁場。與CST數值仿真數據對比得到，該方法可以準確計算任意入射波激勵下線纜終端負載上的電流響應且計算效率高，可用于腔體內場線耦合的研究。
- 模式匹配 /
- BLT方程 /
- 孔腔耦合 /
- 場線耦合
Abstract: The field-to-wire coupling in metal enclosure is an important issue in the field of electromagnetic compatibility. In this paper, an efficient and accurate approach is presented to calculate the EMI (ElectroMagnetic Interference) of a complex cable bundle in an enclosure, which involves two methods: mode matching and BLT equation. The issue is divided into the two sub-questions: aperture coupling and field-to-wire coupling, the electromagnetic field in enclosure is calculated by the Mode function and MOM, the EMI of the cables in an enclosure is calculated by Agrawal,s field-to-wire coupling theory and BLT equation. In comparison with measurement data shows that the electromagnetic field in enclosure can be accurately calculated by the mode matching method. The proposed method can also significantly reduce the simulation time and improve the efficiency of simulation compared with CST, which can be used to calculate the field-to-wire coupling in an enclosure.
- Mode matching /
- BLT equation /
- Aperture coupling /
- Field-to-wire coupling

HTML全文

參考文獻(15)

SURESHKUMAR T R, VENKATESH C, SALIL P, et al. Transmission line approach to calculate the shielding effectiveness of an enclosure with double-layer frequency selective surface[J]. IEEE Transactions on Electromagnetic Compatibility, 2015, 57(6): 1736-1739. doi: 10.1109/TEMC. 2015.2453333.

REN Dan, DU Pingan, HE Yin, et al. A fast calculation approach for the shielding effectiveness of an enclosure with numerous small apertures[J]. IEEE Transactions on Electromagnetic Compatibility, 2016, 58(4): 1033-1041. doi: 10.1109/TEMC.2016.2547739.

JESUS G G, ZACHARY B D, ANDREADIS T D, et al. Prediction of induced voltages on ports in complex, three- dimensional enclosures with apertures, using the random coupling model[J]. IEEE Transactions on Electromagnetic Compatibility, 2016, 58(5): 1535-1540. doi: 10.1109/TEMC. 2016.2580301.

BETHE H A. Theory of diffraction by small holes[J]. Physical Review, 1944, 66(7/8): 163-182. .

ROBINSON M P, BENSON T M, CHRISTOPOULOS C, et al. Analytical formulation for the shielding effectiveness of enclosures with apertures[J]. IEEE Transactions on Electromagnetic Compatibility, 1998, 40(3): 240-248.

DEHKHODA P, TAVAKOLI A, and MOINI R. An efficient and reliable shielding effectiveness evaluation of a rectangular enclosure with numerous apertures[J]. IEEE Transactions on Electromagnetic Compatibility, 2008, 50(1): 208-212. doi: 10.1109/TEMC.2007.911922.

TAYLOR C D, SATTERWHITE R S, and HARRISON C W. The response of a terminated two-wire transmission line excited by a nonuniform electromagnetic field[J]. IEEE Transactions on Antennas and Propagation, 1965, 13(6): 987-989.

AGRWAL A K, PRICE H J, and GURBAXANI S H. Transient response of multiconductor transmission lines excited by a nonuniform electromagnetic field[J]. IEEE Transactions on Electromagnetic Compatibility, 1980, 22(2): 119-129.

RACHIDI F. Formulation of field-to-transmission line coupling equations in terms of magnetic excitation field[J]. IEEE Transactions on Electromagnetic Compatibility, 1993, 35(3): 404-407.

ABDELGHAFOUR B, ALAIN R, CHRISTOPHE G, et al. An efficient analytical method for electromagnetic field to transmission line coupling into a rectangular enclosure excited by an internal source[J]. IEEE Transactions on Electromagnetic Compatibility, 2015, 57(3): 565-573. doi: 10. 1109/TEMC.2014.2386913.

XIAO Pei, DU Pingan, REN Dan, et al. A hybrid method for calculating the coupling to PCB inside a nested shielding enclosure based on electromagnetic topology[J]. IEEE Transactions on Electromagnetic Compatibility, 2016, 58(6): 1701-1709. doi: 10.1109/TEMC.2016.2588505.

XIE Haiyan, WANG Jianguo, FAN Ruyu, et al. SPICE models for prediction of disturbances induced by nonuniform fields on shielded cables[J]. IEEE Transactions on Electromagnetic Compatibility, 2011, 53(1): 185-192. doi: 10.1109/TEMC.2010.2045895.

郁濱, 方哲, 周長林. 并行傳輸線共模泄漏的等效場-線耦合數值模型[J]. 電子與信息學報, 2015, 37(1): 214-219. doi: 10.11999/JEIT140210.

YU Bin, FANG Zhe, and ZHOU Changlin. Equivalent field- to-line coupling numerical model for parallel transmission line common-mode electromagnetic leakage[J]. Journal of Electronics Information Technology, 2015, 37(1): 214-219. doi: 10.11999/JEIT140210.

CHEN C C. Transmission through a conducting screen perforated periodically with apertures[J]. IEEE Transactions on Microwave Theory Techniques, 1970, 18(9): 627-632.
