基于目標極化特性的人體隱藏危險品檢測方法

安健飛; 成彬彬; 桑子儒; 陸彬; 岑冀娜; 鄧賢進

doi:10.11999/JEIT160915

基于目標極化特性的人體隱藏危險品檢測方法

doi: 10.11999/JEIT160915

基金項目:

國家973計劃項目(2015CB755406)

計量
- 文章訪問數: 1326
- HTML全文瀏覽量: 105
- PDF下載量: 339
- 被引次數: 0
出版歷程
- 收稿日期: 2016-09-09
- 修回日期: 2017-01-22
- 刊出日期: 2017-07-19

Method of Standoff Detection of Concealed Body-worn Targets Based on Radar Polarization Properties

Funds:

The National 973 Program of China (2015CB 755406)

摘要

摘要: 為解決在站開式距離的人體隱藏危險品檢測問題，利用目標對雷達回波的退極化現象實現對槍支等金屬物的遠距離檢測。通過測量待測對象的雷達的不同極化方向的回波并計算出檢測參量，就可以據此判斷待測對象是否攜帶有隱藏危險品。為驗證該方法有效性，設計并研制了一套140 GHz寬帶極化雷達，并進行了實驗測量。實驗結果表明：一方面，對于槍支，或者簡易爆炸物等退極化效應顯著的目標，系統具有較好的檢測效果；另一方面，對于退極化效應不明顯的目標的檢測以及檢測距離的增加會導致系統的虛警和漏警概率增大，從而降低檢測性能。通過增大發射天線尺寸可以改善檢測效果，并且通過檢測參量的優化可以提高同等距離下檢測性能。
- 隱藏危險品檢測 /
- 站開式非成像 /
- 退極化效應 /
- 寬帶極化雷達
Abstract: In order to detect concealed body-worn weapon at standoff range, the depolarization effect of radar targets is utilized. By measuring radar echoes of the object at different polarization directions, detection parameters can be obtained and whether the human is carrying concealed weapon or not can be decided. In order to verify the effectiveness of the method, a 140 GHz broadband polarized radar is designed and used to carry out experimental measurements. The experimental results show that, on the one hand, for the firearms, or Improvised Explosive Devices (IED) and other targets that have significant depolarization effect, the system has a better detection effect; on the other hand, the detection of targets with less depolarization effect and the increase of detection distance will result in the increase of the probability of false alarm and probability of leakage alarm and deterioration of the system performance. The system performance can be improved by increasing the size of the transmitting antenna, and the detection performance at the same distance can also be improved by optimizating the detection parameters.
- Concealed weapon detection /
- Standoff non-image /
- Depolarization effect /
- Broadband polarized radar

HTML全文

參考文獻(18)

KOWALSKI M, KASTEK M, WALCZAKOWSKI M, et al. Passive imaging of concealed objects in terahertz and long-wavelength infrared[J]. Applied Optics, 2015, 54(13): 3826-3833. doi: 10.1364/AO.54.003826.

ARTTU L, LEIF G, MARKUS G, et al. Enhancement of real- time THzimaging system based on 320240 uncooled microbolometer detector[J]. Journal of Infrared, Millimeter, and Terahertz Waves, 2016, 37(10): 965-976. doi: 10.1007/ s10762-016-0287-4.

GROSSMAN E N, GORDAN J, NOVOTNY D, et al. Terahertz active and passive imaging[C]. Proceedings of 8th European Conference on Antennas and Propagation (EuCAP), Netherlands, 2014: 2221-2225.

FARSAEE A, SEYEDTABLEBI J, MOKHTARI F, et al. Improved two-dimensional millimeter-waveimaging for concealed weapon detection through partial fourier sampling [J]. Journal of Infrared, Millimeter, and Terahertz Waves, 2016, 37(3): 267-280. doi: 10.1007/s10762-015-0223-z.

SHEEN D M, HALL T E, MCMAKIN D L, et al. Three- dimensional radar imaging techniques and systems for near- field applications[J]. SPIE, 2016, 9829. doi: 10.1117/12. 2229235.

TEKAVEC P F, KOVZLOV V G, and MCNEE I. Real time THz imaging based on frequency up-conversion[C]. Infrared, Millimeter, and Terahertz waves (IRMMW-THz), Hong Kong, 2015. doi: 10.1109/IRMMW-THz.2015.7327921.

KAPILEVICH B Y, HARMER S W, and BOWRING N J. Non-Imaging Microwave and Millimeter-Wave Sensors for Concealed Object Detection[M]. USA: CRC Press, 2015: 1-210.

KAPILEVICH B Y and LIPELES A. Hand-held device and method for detecting concealed weapons and hidden objects [P]. US, Patent, WO 2007148327A2, 2007-6-18.

DOUGLASS R J, GORMAN J D, and BURNS T J. System and method for standoff detection of human carried explosives[P]. US, Patent, US20080129581, 2005-10-11.

HAUSNER Jerry and WEST Jonathan. Object detection method and apparatus[P]. US, Patent, US20070052576, 2007- 5-8 .

ANDREWS D A, HARMER S W, BOWRING N J, et al. Active millimeter wave sensor for standoff concealed threat detection[J]. IEEE Sensors Journal, 2013, 13(12): 4948-4954. doi: 10.1109/JSEN.2013.2273487.

保錚, 邢孟道, 王彤. 雷達成像技術[M]. 北京, 電子工業出版社, 2005: 19-44.

BAO Zheng, XING Mengdao, and WANG Tong. Technologies of Radar Imaging[M]. Beijing: Publishing House of Electronics Industry, 2005: 19-44.

劉杰, 張健, 蔣均, 等. D波段功率放大器設計[J]. 強激光與粒子束, 2016, 28(2): 28023102-1-28023102-4. doi: 10.11884/ HPLPB201628.023102.

LIU Jie, ZHANG Jian, JIANG Jun, et al. Design of D-band power amplifier[J]. High Power Laser and Particle Beams, 2016, 28(2): 28023102-1-28023102-4. doi: 10.11884/ HPLPB201628.023102.

王成, 鄧賢進, 肖仕偉. 基于肖特基二極管的140 GHz次諧波混頻器[J]. 信息與電子工程, 2011, 9(6): 713-717. doi: 1672- 2892(2011)06-0713-05.

WANG Cheng, DENG Xianjin, and XIAO Shiwei. 140 GHz sub-harmonic mixer based on Schottky diode[J]. Information and Electronic Engineering, 2011, 9(6): 713-717, doi: 1672- 2892(2011)06-0713-05.

SKOLNIK Merrill. Radar Handbook[M]. 3rd Ed., New York, USA: McGraw Hill, Inc., 2008: 9-10.
