電源調制器電路對脈沖行波管功率放大器相位穩定性影響研究

董戈; 胡波雄; 肖曦

doi:10.11999/JEIT160876

電源調制器電路對脈沖行波管功率放大器相位穩定性影響研究

doi: 10.11999/JEIT160876

董戈^1, ,,
胡波雄²,
肖曦²

1.
(清華大學航天航空學院北京 100084) ②(中國科學院電子學研究所北京 100190) ③(清華大學電機工程與應用電子技術系北京 100084)

基金項目:

中國科技部政府間科技合作項目(S2016G5061)

計量
- 文章訪問數: 1355
- HTML全文瀏覽量: 152
- PDF下載量: 508
- 被引次數: 0
出版歷程
- 收稿日期: 2016-08-24
- 修回日期: 2016-11-07
- 刊出日期: 2017-02-19

Study on Influence of Electric Power Conductor Circuits on Traveling Wave Tube Amplifier Phase Stability

DONG Ge^{1
, ,},
HU Boxiong²,
XIAO Xi²

1.
(School of Aerospace Engineering, Tsinghua University, Beijing 100084, China)
2.
(Institute of Electronics, Chinese Academy of Sciences, Beijing 100190, China)

Funds:

Program of International Science and Technology Cooperation (CR20-09)

摘要

摘要: 行波管放大器(TWTA)廣泛應用在雷達、通訊等領域。相位穩定性影響傳輸信號質量、目標參數檢測精度、電磁兼容性等指標。該文在定量分析電源調制器(EPC)電路參數對TWTA相位穩定性影響的基礎上，提出提高TWTA相位穩定性的EPC電路的幾種設計方案：選擇合理的供電電路，利用低壓儲能高頻高壓電源提高陰極電壓的穩定性，利用調節控制脈沖幅度補償陰極電壓脈沖頂降造成的相位不穩定性。該文成果為研制體積小、功率大、相位穩定性高的TWTA提供了依據。
- 行波管放大器 /
- 電源調制器 /
- 相位穩定性
Abstract: Traveling Wave Tube Amplifier (TWTA) is used extensively in the fields of radars and communication. And its phase stability could exert influence upon the quality of transmission signals, the detection accuracy of target parameters and the electromagnetic compatibility. This paper quantitatively analyses the effects of Electric Power Conductor (EPC)s circuit parameters upon the phase stability of TWTA, and proposes further advanced three designing schemes on the EPC to improve the phase stability of TWTA, i.e. selecting a reasonable power supply circuit; adopting low-voltage-charging, high-frequency, high-voltage source to raise the stability of high-cathode voltage; compensating the phase instability from the cathode voltage pulse top fall effect through the adjusting of the amplitude of control pulse. This paper provides theoretical basis for the researching of TWTAs with compact size, high power, and high phase stability.
- Traveling Wave Tube Amplifier (TWTA) /
- Electric Power Conductor (EPC) /
- Phase stability
