基于SRAM物理不可克隆函數的高效真隨機種子發生器設計

李冰; 涂云晶; 陳帥; 吉建華

doi:10.11999/JEIT160835

基于SRAM物理不可克隆函數的高效真隨機種子發生器設計

doi: 10.11999/JEIT160835

1.
(東南大學集成電路學院南京 210000) ②(深圳大學信息工程學院深圳 518060)

基金項目:

國家自然科學基金(61571116)

計量
- 文章訪問數: 1275
- HTML全文瀏覽量: 117
- PDF下載量: 373
- 被引次數: 0
出版歷程
- 收稿日期: 2016-08-15
- 修回日期: 2017-01-11
- 刊出日期: 2017-06-19

Efficient Design of Truly Random Seed Generator Based on SRAM Physical Unclonable Functions

1.
(School of Integrated Circuit, Southeast University, Nanjing 210000, China)
2.
(College of Information Engineering, Shenzhen University, Shenzhen 518060, China)

Funds:

The National Natural Science Foundation of China (61571116)

摘要

摘要: 該文設計了一種基于SRAM物理不可克隆函數(PUFs)的高效真隨機種子發生器。通過將不提供熵值的穩定節點和提供低熵值的噪聲節點篩除，只選用能夠提供較高熵值的噪聲節點來生成滿熵種子，大幅降低需要處理的數據量，提高節點數據的處理效率。通過測試SRAM PUFs內部噪聲節點的振蕩特性，提出篩選出SRAM PUFs內部高熵值的噪聲節點的最佳策略，最終基于此策略設計出真隨機種子發生器。該設計可以產生128~256 bit長度的滿熵的種子且處理的節點數據量只有當前方法的0.5%~4%。生成的種子滿足NIST架構的隨機數生成器要求，產生的偽隨機數全部通過了隨機數檢測。與現有設計相比，該文提出的真隨機種子發生器是一種高效的、適用范圍較廣的設計。
- 物理不可克隆函數 /
- 噪聲節點 /
- 真隨機種子 /
- 高效率
Abstract: An efficient design of truly random seed generator based on SRAM Physical Unclonable Functions (PUFs) is proposed in this paper. Only the noisy cells of high min-entropy are selected to generate full entropy seeds in this design. Therefore, it can reduce the amount of data to be processed significantly and improve the efficiency of seed generation. The oscillating characteristics of the noisy cells inside SRAM are measured, and screening strategies for filtering out the selected noisy cells inside the SRAM are put forward. Finally, based on the strategies, a truly random seed generator is designed, which can generate full entropy seeds. The length of seeds generated by this design is from 128 bit to 256 bit. The number of the selected cells which are used to generate seeds is from 0.5% to 4% of all SRAM cells. Compared to the current design, it is shown that the proposed design in this paper is efficient and widely applicable.
- Physical Unclonable Functions (PUFs) /
- Noisy cells /
- Truly random seed /
- Efficient

HTML全文

參考文獻(15)

PAPPU R, RECHT B, TAYLOR J, et al. Physical one-way functions[J]. Science, 2002, 297(5589): 2026-2030. doi: 10.1126/science.1074376.

BARBARESCHI M, BATTISTA E, MAZZEO A, et al. Testing 90 nm microcontroller SRAM PUF quality[C]. IEEE International Conference on Design Technology of Integrated Systems in Nanoscale Era, Naples, Italy, 2015: 1-6.

HOLCOMB D E, BURLESON W P, and FU K. Power-Up SRAM state as an identifying fingerprint and source of true random numbers[J]. IEEE Transactions on Computers, 2008, 58(9): 1198-1210. doi: 10.1109/TC.2008.212.

XIAO K, RAHMAN M T, FORTE D, et al. Bit selection algorithm suitable for high-volume production of SRAM-PUF[C]. IEEE International Symposium on Hardware-Oriented Security and Trust, Arlington, Virginia, USA, 2014: 101-106.

LEEST V V D, SLUIS E V D, SCHRIJEN G J, et al. Efficient implementation of true random number generator based on SRAM PUFs[J]. Lecture Notes in Computer Science, 2012, 6805: 300-318. doi: 10.1007/978-3-642-28368-0_20.

ZHANG J, LIN Y, LYU Y, et al. A PUF-FSM binding scheme for FPGA IP protection and pay-per-device licensing[J]. IEEE Transactions on Information Forensics Security, 2015, 10(6): 1137-1150. doi: 10.1109/TIFS.2015.2400413.

DELVAUX J, GU D, SCHELLEKENS D, et al. Helper data algorithms for PUF-based key generation: Overview and analysis[J]. IEEE Transactions on Computer-Aided Design of Integrated Circuits and Systems, 2015, 34(6): 889-902. doi: 10.1109/TCAD.2014.2370531.

KIM H and HONG S. AES Sbox GF(24) inversion functions based PUFs[C]. IEEE International SoC Design Conference (ISOCC), Jeju, South Korea, 2014: 15-16.

VARCHOLA M, DRUTAROVSKY, M, and FISCHER V. New universal element with integrated PUF and TRNG capability[C]. International Conference on Reconfigurable Computing and FPGAs, Cancun, Mexico. 2013: 1-6.

HUSSAIN S U, MAJZOOBI M, and KOUSHANFAR F. A built-in-self-test scheme for online evaluation of physical unclonable functions and true random number generators[J]. IEEE Transactions on Multi-Scale Computing Systems, 2016, 2(1): 2-16. doi: 10.1109/TMSCS.2016.2519902.

LI D, LU Z, ZOU X, et al. PUFKEY: A high-security and high-throughput hardware true random number generator for sensor networks[J]. Sensors, 2015, 15(10): 26251-26266. doi: 10.3390/s151026251.

HERREWEGE V A, VINCENT V D L, SCHALLER A, et al. Secure PRNG seeding on commercial off-the-shelf microcontrollers[C]. International Workshop on Trustworthy Embedded Devices, Berlin, Germany, 2013: 55-64.

CORTEZ M, DARGAR A, HAMDIOUI S, et al. Modeling SRAM start-up behavior for physical unclonable functions[C]. IEEE International Symposium on Defect and Fault Tolerance in VLSI and Nanotechnology Systems, Austin, TX, USA, 2012: 815-828.

BARKER E and KELSEY J. Recommendation for random number generation using deterministic random bit generators[R]. NIST Special Publication, 2012: 800-890.

GUAJARDO J, KUMAR S S, SCHRIJEN G J, et al. FPGA intrinsic PUFs and their use for IP protection[C] Cryptographic Hardware and Embedded Systems, CHES 2007, International Workshop, Vienna, Austria, 2007: 63-80.
