基于最小二乘的短垂線陣匹配場處理

王奇; 陳航; 王英民; 茍艷妮

doi:10.11999/JEIT160727

基于最小二乘的短垂線陣匹配場處理

doi: 10.11999/JEIT160727

計量
- 文章訪問數: 1115
- HTML全文瀏覽量: 96
- PDF下載量: 322
- 被引次數: 0
出版歷程
- 收稿日期: 2016-07-08
- 修回日期: 2016-11-17
- 刊出日期: 2017-06-19

Matched Field Processing Based on the Least SquaresAlgorithm for Short Vertical Linear Array

摘要

摘要: 匹配場處理通常要求接收基陣能夠覆蓋整個水層，如此大尺度的布陣方式嚴重阻礙了該方法的廣泛使用。為了緩解匹配場處理對陣形的苛刻要求，該文提出一種基于最小二乘的短垂線陣匹配場處理技術。該方法把接收陣的聲場分解為模態函數矩陣和模態系數向量，并在最小范數意義下用最小二乘算法得到了各階模態系數的估計值，在此基礎上重新構造了短垂線陣的測量場向量，使得重構后的測量場包含更多的環境信息，從而提高了短垂線陣匹配場處理的性能。最后，在典型的Pekeris波導環境中進行仿真，以3種布放在水面附近的短垂線陣為例，分析了匹配場被動定位的性能，并用廣義余弦量化分析了不同布陣方式對測量場的影響。結果表明：使用最小二乘算法對短陣的測量場進行聲場重構后廣義余弦變大，此時短垂線陣匹配場處理的定位性能得到改善，驗證了該算法的有效性。
- 匹配場處理 /
- 被動定位 /
- 最小二乘算法 /
- 聲場重構
Abstract: The receiver array of matched field processing usually needs to cover the whole water column, such a large arrangement of array hinders its application seriously. To overcome this shortcoming, an approach called matched field processing based on least squares algorithm is proposed, which decomposes the received fields into depth function matrixes and amplitudes of normal mode at the beginning. Then all the mode amplitudes are estimated using the least squares in the sense of minimum norm. Next, the amplitudes estimated are used to reconstruct the received fields of the short vertical linear array, which makes the reconstructed ones contain more environmental information, therefore the performance of matched field processing with short array is improved. In the end, lots of simulations with three short vertical arrays which are located near by water surface are processed in the classical Pekeris waveguide, and the performance of matched field passive localization is evaluated. Meanwhile, in order to quantify the influence of different kinds of geometrical arrangements to the received fields, the generalized cosine-squared between two vectors is used. The results show that when the received fields of short array are reconstructed using the least squares, the generalized cosine-squared is larger obviously, finally the performance of matched field passive localization with short array is improved and the proposed algorithm is proved to be effective.
- Matched field processing /
- Passive localization /
- Least square algorithm /
- Acoustic fields reconstructed

HTML全文

參考文獻(23)

BAGGEROER A B, KUPERMAN W A, and MLKHALEVSKY P N. An overview of matched field methods in ocean acoustics[J]. IEEE Journal of Oceanic Engineering, 1993, 18(4): 401-424. doi: 10.1109/48.262292.

KUPERMAN W A. An overview of beamforming, matched-field processing, and time reversal techniques[J]. The Journal of the Acoustical Society of America, 2016, 139(4): 2081. doi: 10.1121/1.4950176.

DONG H, BADIEY M, and ChAPMAN R. Matched mode geoacoustic inversion of broadband signals in shallow water [J]. The Journal of the Acoustical Society of America, 2015, 137(4): 2390. doi: 10.1121/1.4920698.

羅新禹, 李建, 周德富, 等. 失配情況下匹配模處理方法研究 [J]. 應用聲學, 2016, 35(2): 172-178. doi: 10.11684/j.issn. 1000-310X.2016.02.012.

LUO Xinyu, LI Jian, ZHOU Defu, et al. Simulation studies of the matched-mode processing for locating underwater sound sources[J]. Journal of Applied Acoustics, 2016, 35(2): 172-178. doi: 10.11684/j.issn.1000- 310X.2016.02.012.

HARRISON B F, VACCARO R J, and TUFTS D W. Robust broadband matched-field localization: Results for a short, sparse vertical array [J]. The Journal of the Acoustical Society of America, 1999, 106(1): 515-517. doi: 10.1121/1.427072.

GEMBA K L, HODGKISS W S, and GERSTOFT P. Single and multiple snapshot compressive matched field processing [J]. The Journal of the Acoustical Society of America, 2015, 138(3): 1928. doi: 10.1121/1.4934072.

彭水, 袁蓉, 徐國貴. 淺海水平固定陣陣形對匹配場定位性能的影響[J]. 艦船科學技術, 2015, 37(9): 121-126. doi: 10.3404/j.issn.1672-7649.2015.09.024.

PENG Shui, YUAN Rong, and XU Guogui. Localization performance of different horizontal hydrophone array shape for matched field processing in shallow sea[J]. Ship Science and Technology, 2015, 37(9): 121-126. doi: 10.3404/j.issn. 1672-7649.2015.09.024.

TABRIKIAN J, KROLIK J L, and MESSER H. Robust maximum-likelihood source localization in an uncertain shallow-water waveguide[J]. The Journal of the Acoustical Society of America, 1997, 101(1): 241-249.

MICHALOPOULOU Z H and PORTER M B. Matched-field processing for broad-band source localization[J]. IEEE Journal of Oceanic Engineering, 1996, 21(4): 384-392. doi: 10.1109/48. 544049.

ORRIS G J, NICHOLAS M, and PERKINS J S. The matched-phase coherent multi-frequency matched-field processor[J]. The Journal of the Acoustical Society of America, 2000, 107(5): 2563-2575. doi: 10.1121/1.428644.

WILSON G R, KOCH R A, and VIDMAR P J. Matched mode localization[J]. The Journal of the Acoustical Society of America, 1988, 84(1): 310-320. doi: 10.1121/1.396987.

YANG T C. A method of range and depth estimation by modal decomposition[J]. The Journal of the Acoustical Society of America, 1987, 82(5): 1736-1745. doi: 10.1121/ 1.395825.

TOLLEFSEN D and DOSSO S E. Matched-field source localization with multiple small-aperture arrays[J]. The Journal of the Acoustical Society of America, 2015, 138(3): 1754-1754. doi: 10.1121/1.4933543.

Porter M B and Tolstoy A. The matched field processing benchmark problems [J]. Journal of Computational Acoustics, 1994, 2(3): 161-185. doi: 10.1142/S0218396X94000129.

YANG T C. Data-based matched-mode source localization for a moving source[J]. The Journal of the Acoustical Society of America, 2014, 135(3): 1218-1230. doi: 10.1121/1.4863270.

趙擁軍, 趙勇勝, 趙闖. 基于正則化約束總體最小二乘的單站DOA-TDOA無源定位算法[J]. 電子與信息學報, 2016, 38(9): 2336-2343. doi: 10.11999/JEIT151379.

ZHAO Yongjun, ZHAO Yongsheng, and ZHAO Chuang. Single-observer passive DOA-TDOA location based on regularized constrained total least squares[J]. Journal of Electronics Information Technology, 2016, 38(9): 2336-2343. doi: 10.11999/JEIT151379.

WU H, CHEN S, ZHANG Y, et al. Robust structured total least squares algorithm for passive location[J]. Journal of Systems Engineering and Electronics, 2015, 26(5): 946-953. doi: 10.1109/JSEE.2015.00103.

GOLUB G H and VAN LOAN C F. An analysis of the total least squares problem[J]. SIAM Journal on Numerical Analysis, 1980, 17(6): 883-893. doi: 10.1137/0717073.

王奇, 王英民, 茍艷妮. 穩健的條件概率約束匹配場處理[J]. 電子與信息學報, 2014, 36(10): 2425-2430. doi: 10.3724/SP.J. 1146.2014.00027.

WANG Qi, WANG Yingmin, and GOU Yanni. Robust conditional probability constraint matched field processing[J]. Journal of Electronics Information Technology, 2014, 36(10): 2425-2430. doi: 10.3724/SP.J.1146.2014.00027.
