基于瞬態電磁響應的埋地細長良導體目標長度和方位估計
doi: 10.11999/JEIT160718
-
1.
(西安電子科技大學電子工程學院 西安 710071) ②(桂林電子科技大學廣西無線寬帶通信與信號處理重點實驗室 桂林 541004)
基金項目:
國家自然科學基金(61371186, 61162007)，廣西自然科學基金(2013GXNSFFA019004)
Estimation of Length and Orientation of Subsurface Thin-wire Structures Based on Transient Electromagnetic Responses
-
1.
(School of Electronic Engineering, Xidian University, Xi&rsquo
Funds:
The National Natural Science Foundation of China (61371186, 61162007), Guangxi Natural Science Foundation (2013GXNSFFA019004)
-
摘要: 對地下管道電纜等目標的幾何特征估計在城市建設和市政基礎設施維護中尤為重要，針對此類埋地細長良導體目標，該文提出一種基于瞬態電磁響應的管道目標長度與方位角估計方法。建立了介電媒質中水平極化電磁波在布魯斯特角入射下細長良導體目標后向散射回波時延差模型，通過分析瞬態響應時頻分布，建立了其諧振態與目標長度的關系，并由此估計目標的長度。利用瞬態響應早時部分首達回波與晚時部分諧振回波的能量變化趨勢，判斷電磁波到達目標兩端點的時間順序，再根據首達時間延遲差估計目標的方位角。數值仿真結果表明在電場方向與目標軸線方向偏離不大的情況下，提出方法有效并且對噪聲具有魯棒性，適用于信噪比SNR5 dB的長度估計以及SNR10 dB的方位角估計。
-
關鍵詞:
- 瞬態響應 /
- 諧振 /
- 長度估計 /
- 方位估計
Abstract: It is particularly important to estimate the geometric features of buried pipe cables in urban construction and municipal infrastructure maintenance. For this kind of subsurface thin-wire structure targets, a method for estimation of the length and orientation of a target based on transient electromagnetic responses is proposed. In this method, a time delay difference model of the backscattering responses from such thin-wire structures illuminated by electromagnetic wave at Brewsters angle with horizontal polarization is established. By analyzing the time-frequency distribution of the transient responses, the relationship between the resonant state and the target length is established and the length of the target is estimated. The energy change between the early time responses and late time resonances is applied to determining the time sequence of the arrival of the electromagnetic wave to the target. Then the target orientation is estimated by the time delay difference of early time responses. Numerical simulation results show that the proposed method is effective in the case of the direction of electric field close to the target axial direction. Meanwhile, the proposed method is robust to noise, and can be applied to length estimation forSNR5 dB and orientation estimation for SNR10 dB.-
Key words:
- Transient responses /
- Resonances /
- Length estimation /
- Orientation estimation
-
